Installing Additional Memory; Dimms; Ddr3-Sdram Dimms - HP Compaq MultiSeat ms6005 Hardware Reference Manual

Table 3-1
No. System Board Connector
16 Hood Sensor
17 PCI Express x1
18 PCI Express x1
19 PCI Express x16
20 PCI

Installing Additional Memory

The computer comes with double data rate 3 synchronous dynamic random access memory (DDR3-
SDRAM) dual inline memory modules (DIMMs).

DIMMs

The memory sockets on the system board can be populated with up to four industry-standard DIMMs.
These memory sockets are populated with at least one preinstalled DIMM. To achieve the maximum
memory support, you can populate the system board with up to 16-GB of memory configured in a high-
performing dual channel mode.

DDR3-SDRAM DIMMs

CAUTION:
processor is not compatible with DDR3U memory and if you plug DDR3U memory into the system
board, it can cause the physical damage to the DIMM or invoke system malfunction.
For proper system operation, the DDR3-SDRAM DIMMs must be:
industry-standard 240-pin
●
unbuffered non-ECC PC3-8500 DDR3-1066 MHz-compliant or PC3-10600 DDR3-1333 MHz-
●
compliant
1.5 volt DDR3-SDRAM DIMMs
●
The DDR3-SDRAM DIMMs must also:
support CAS latency 7 DDR3 1066 MHz (7-7-7 timing) and CAS latency 9 DDR3 1333 MHz
●
(9-9-9 timing)
contain the mandatory JEDEC SPD information
●
58 Chapter 3 MultiSeat ms6200 Desktop Hardware Upgrades
System Board Connections (continued)
System Board Label
HSENSE
X1PCIEXP1
X4PCIEXP
X16PCIEXP
PCI
This product DOES NOT support DDR3 Ultra Low Voltage (DDR3U) memory. The
Color Component
white Hood Sensor
black Expansion Card
black Expansion Card
black Expansion Card
white Expansion Card
