Figure 64 Typical enclosure certification label
NOTE:
The certification symbols on the label depend upon the certification level. For example, the FCC Class
A certification symbol is not the same as the FCC Class B certification symbol.

Storage system specifications

This appendix defines the physical, environmental, and power specifications of the EVA
4x00/6x00/8x00 storage systems.

Physical specifications

This section describes the physical specifications of the drive enclosure and elements.
Table 31 defines the dimensions and weights of the storage system components.
Table 31 Enterprise Virtual Array 4x00/6x00/8x00 Product Dimensions, Weight and Clearance
Physical Dimen-
sions
Evacuees and
EVA8x00 2C2D
(42U rack)
EVA6x00 and
EVA8x00 2C6D
(42U rack)
EVA8x00 2C12D
(42U rack)
EVA4x00/6x00/8x00
Controller Assembly
M5314B/M5314C
Drive Enclosure
Height Width
in/cm in/cm
78.75
23.7 (60.3)
(200.03)
78.75
23.7 (60.3)
(200.03)
78.75
23.7 (60.3)
(200.03)
7.0/17.78 17.6/44.70
5.25/13.34 19.0/42.26
HP StorageWorks 4x00/6x00/8x00 Enterprise Virtual Array user guide
Depth Max
in/cm Weight
lb/kg
40.2
537 (244.1)
(102.2)
40.2
854 (308.2)
(102.2)
40.2 1290
(102.2) (586.4)
27.5/69.85 120/54.55
20/50.8 71/32.21
Req. Front Req. Rear
Clearance Clearance
in/cm in/cm
30 (76.2) 30 (76.2)
30 (76.2) 30 (76.2)
30 (76.2) 30 (76.2)
N/A N/A
N/A N/A
139
