Lexmark T656DNE Quick Reference

Quick Reference

Loading paper
Loading paper
1
Squeeze the width guide tab inward and move it to fit the
paper size being loaded.
2
Unlock the length guide, squeeze the length guide tab inward,
and slide it to fit the paper size being loaded.
3
Flex, fan, and straighten the paper stack.
4
Load the paper.
Note: The maximum fill line. Do not overload the tray.
5
If a different paper type was loaded, then change the Paper
Type setting for the tray from touch screen.

Clearing jams

200 and 201 paper jams

1
Lower the multipurpose feeder door, and then push the
release latch to open the front cover.
2
Lift and pull the print cartridge out of the printer.
1
Warning—Potential Damage: Do not touch the
photoconductor drum on the underside of the cartridge. Use
the cartridge handle whenever you are holding the cartridge.
3
Place the print cartridge aside on a flat, smooth surface.
Warning—Potential Damage: Do not leave the cartridge
exposed to light for extended periods.
Warning—Potential Damage: The jammed paper may be
covered with unfused toner which can stain garments and
skin.
4
Remove the jammed paper.
CAUTION—HOT SURFACE: The inside of the printer
might be hot. To reduce the risk of injury from a hot
component, allow the surface to cool before touching.
Note: If the paper is not easy to remove, then open the rear
door and remove the paper from there.
5
Align and reinstall the print cartridge.
6
Close the front cover.
7
Close the multipurpose feeder door.
8
Touch Continue.

202 and 203 paper jams

Touch Status/Supplies to identify the location of the jam. If the
paper is exiting the printer, then pull the paper out, and then touch
Continue.
