Installation
1.
Choose a spot near an electrical outlet and a telephone jack. Your phone requires a modular
telephone jack and a standard electrical outlet (110vAC). The outlet should not be controlled by a wall
switch; if the switch is ever turned off, the phone will not operate.
2.
Insert the cassette: Lift the cover. Insert the cassette with the full reel to the right.
3.
Set the TONE/PULSE switch: Set the TONE/PULSE switch to TONE if you have touch tone service,
or PULSE if you have dial pulse (rotary) service.
4.
Set the RINGER switch (ON, OFF). Set the RINGER switch on the base unit to ON so the phone
will ring. When the switch is set to OFF, the phone will not ring. The answering system will continue
to answer calls as long as the ANS ON Light is on.
For table or desk installation skip to number 8 and proceed.
For Wall Installation Only:
Tools you will need: A hammer, a nail, a pencil or ballpoint pen, a Philips head (+) screwdriver, and the
Wall Mounting Template.
5.
Choose and mark the mounting position. The mounting screws should screw into a wooden stud
within the wall – they will not hold securely in wall board alone. Locate a wall stud in the area where
you want to install your phone. Use the Wall Mounting Template and a pencil to mark the screw
positions on the wall over the stud. Put the template aside.
6.
Install the mounting sleeves and screws. Start the screw holes by lightly tapping a nail into the
marks you made on the wall. Remove the nail from the wall. Now slip the mounting sleeves onto the
screws as shown, with the larger end of the sleeve toward the screw head. Insert the screws into the
holes you started. Tighten the screws until the smaller end of the sleeve is flat against the wall.
7.
Mount the base on the wall. Hold the base so the mounting sleeves on the wall will fit into the holes
on the bottom of the base. Arrange the power cord through the groove on the bottom of the base.
Slide the base down onto the mounting sleeves until it locks into place.
8.
Connect the telephone line cord. The telephone line cord has a snap-in plug on each end. Insert one
of the plugs into the jack in the rear of the base unit. Insert the other plug into a telephone jack. Make
sure the plugs snap into place.
9.
Plug in the power cord. Plug the AC adapter on the power cord into an electrical outlet not
controlled by a wall switch. The cassettes will automatically rewind in 10 to 15 seconds.
10. Fill in the telephone number cards. On both the handset and base, insert a pointed object into the
hole in the plastic window, and gently pry up the window until it pops out. Write your phone number
on the card and replace the window.
11. Charge the handset batteries for 10 hours. Place the handset in the base and let the batteries charge
for 10 hours. You can use your phone before the 10 hours are up, but be sure to return the handset to
the base so it can charge fully. The CHARGING Light on the base unit will light to show the batteries
are charging.
12. Check for dial tone. After the batteries are charged, pick up the handset. Now press PHONE on the
handset. The PHONE Light should light, and you should hear the dial tone.
CORDLESS ANSWERING SYSTEM 4695
Installation
Telephone Operation
Memory Dialing
Answering System
At the Base
Away From the Base
Advertisement
Table of Contents
Related Manuals for AT&T 4695
Summary of Contents for AT&T 4695
- Page 1 CORDLESS ANSWERING SYSTEM 4695 Installation Telephone Operation Memory Dialing Answering System At the Base Away From the Base Installation Choose a spot near an electrical outlet and a telephone jack. Your phone requires a modular telephone jack and a standard electrical outlet (110vAC). The outlet should not be controlled by a wall switch;...
-
Page 2: Telephone Operation
Telephone Operation Making a Call You can make calls from the handset anywhere within range of the base. Press PHONE. When you see the PHONE Light go on and hear a dial tone, dial the number you’re calling. If you make a mistake when dialing, press OFF to hang up, then press PHONE to get the dial tone again. You must always press PHONE before dialing a call. -
Page 3: Operating Range
Operating Range Your cordless telephone operates at the maximum power allowed by the Federal Communications Commission (FCC). Even so, your handset and base unit can communicate over only a certain distance – which can vary with the locations of the base unit and handset, the weather and the construction of your home or office. -
Page 4: Memory Dialing
Answering a Call During an Intercom Conversation If you receive a call while using the intercom, press PHONE to turn off the intercom and connect the incoming call. If you try to end a call when you are almost out of range, you will hear two short beeps when you press OFF. -
Page 5: Dialing A Number Stored In Memory
Programming a Number in Memory The handset must be turned OFF. Press PROG on the handset. The PHONE Light will flash to show that you are in the programming mode. Dial the phone number you want to store. (The number can be up to 16 digits long.) Press MEM. -
Page 6: Answering System Operation: At The Base
Changing or Replacing a Stored Number You can change or replace a stored number just by storing a new number in its place. Answering System Operation: At the Base Setting the Time Press and hold the TIME/SET button for one second. When the system announces the current day (for example, “Tuesday”), release the button. -
Page 7: Automatic Answering Operation
Reviewing Your Announcement Set the volume control to the middle. Press the OGM/REC button. Automatic Answering Operation The system is ready to answer calls whenever the ANS ON Light is on. To turn ANS ON on or off, press ANS ON/OFF. When the system answers a call, the caller will hear the announcement you recorded, followed by a beep. -
Page 8: Listening To Your Messages
Set to 4 if you want the system to answer all calls after the fourth ring. This selection allows you more time to answer the call before the system answers and plays your announcement. Set to TOLL SAVER if you want the system to answer calls after the second ring if you have messages, and after the fourth ring if you have no new messages. - Page 9 Recording a Memo This feature allows you to record your own memo or message. (For example, if you want to record a reminder to yourself about a meeting, or if someone else at the base wants to leave you a message.) This memo can be played back at the base, from the portable handset, or from another touch tone line, along with your other messages.
-
Page 10: Call Intercept
Recording a Memo Once you’ve established a connection with the answering system, you can record a memo for yourself or anyone else who has access to the system. When the system plays messages, it plays the memo along with the other messages on the tape. Recording a Memo Press and release 4 (MEMO). -
Page 11: Room Monitoring
the base, press PHONE and take the call as soon as the PHONE Light goes on. You can also pick up the handset of any extension phone on the same line to take the call. The answering system should stop playing the announcement (or recording the message), and ready itself to answer calls again. - Page 12 The Outgoing Announcement Once you’ve established a connection with the answering system, you can change your outgoing announcement from another touch tone phone away from your home or office. You can work with your outgoing announcement any time after the system has given you the 1-beep signal to indicate that it is ready to accept a command.
