Clearing staple jams

289 Jam
1
Check that the machine stops operations, and
open Door G (front door) of the finisher.
2
Hold the lever on the staple cartridge holder,
and move the holder to the right (towards you).
3
Firmly pull the colored tab to remove the staple
cartridge.
4
Use the metal tab to lift the staple guard, and
then pull out the sheet of staples.
Discard the entire sheet.
5
Remove any loose staples from the staple
guard.
6
Look through the clear covering on the bottom
of the cartridge holder to make sure no staples
are jammed in the entry throat.
7
Press down on the staple guard until it snaps
securely into place.
8
Push the cartridge holder firmly into the stapler
until the holder clicks into place.
9
Close Door G.
Priming Stapler appears on the operator
panel display. Priming ensures the stapler is
functioning properly.

Clearing ADF Jams

290, 291, 292, and 294 Jams
1
Remove all original documents from the ADF.
2
Lift the ADF cover latch.
3
Open the ADF cover.
