Register Description
at DID of 2C22h. Device 4, Function 3 contains the thermal control registers for
Integrated Memory Controller Channel 0 and resides at DID of 2C23h.
• Device 5: Integrated Memory Controller Channel 1. Device 5, Function 0 contains
the control registers for Integrated Memory Controller Channel 1 and resides at
DID of 2C28h. Device 5, Function 1 contains the address registers for Integrated
Memory Controller Channel 1 and resides at DID of 2C29h. Device 5, Function 2
contains the rank registers for Integrated Memory Controller Channel 1 and resides
at DID of 2C2Ah. Device 5, Function 3 contains the thermal control registers for
Integrated Memory Controller Channel 1 and resides at DID of 2C2Bh.
• Device 6: Integrated Memory Controller Channel 2. Device 6, Function 0 contains
the control registers for Integrated Memory Controller Channel 2 and resides at
DID of 2C30h. Device 6, Function 1 contains the address registers for Integrated
Memory Controller Channel 2 and resides at DID of 2C31h. Device 6, Function 2
contains the rank registers for Integrated Memory Controller Channel 2 and resides
at DID of 2C32h. Device 6, Function 3 contains the thermal control registers for
Integrated Memory Controller Channel 2 and resides at DID of 2C33h.
2.3

Device Mapping

Each component in the processor is uniquely identified by a PCI bus address consisting
of Bus Number, Device Number, and Function Number. Device configuration is based on
the PCI Type 0 configuration conventions. All processor registers appear on the PCI bus
assigned for the processor socket. Bus number is derived by the max bus range setting
and processor socket number.
Table 2-1.

Functions Specifically Handled by the Processor

Component
Processor
Notes:
1. Applies only to processors supporting sparing, mirroring, and scrubbing RAS features.
Datasheet
Register Group
Intel QuickPath Architecture Generic Non-core Registers
Intel QuickPath Architecture System Address Decoder
Intel QPI Link 0
Intel QPI Physical 0
Integrated Memory Controller Registers
Integrated Memory Controller Target Address Decoder
Integrated Memory Controller RAS Registers
Integrated Memory Controller Test Registers
Integrated Memory Controller Channel 0 Control
Integrated Memory Controller Channel 0 Address
Integrated Memory Controller Channel 0 Rank
Integrated Memory Controller Channel 0 Thermal Control
Integrated Memory Controller Channel 1 Control
Integrated Memory Controller Channel 1 Address
Integrated Memory Controller Channel 1 Rank
Integrated Memory Controller Channel 1 Thermal Control
Integrated Memory Controller Channel 2 Control
Integrated Memory Controller Channel 2 Address
Integrated Memory Controller Channel 2 Rank
Integrated Memory Controller Channel 2 Thermal Control
DID Device Function
2C41h 0
0
2C01h 1
2C10h 0
2
2C11 1
2C18h 0
2C19h 1
3
1
2C1Ah 2
2C1Ch 4
2C20h 0
2C21h 1
4
2C22h 2
2C23h 3
2C28h 0
2C29h 1
5
2C2Ah 2
2C2Bh 3
2C30h 0
2C31h 1
6
2C32h 2
2C33h 3
17
