5. Locate the DIMM socket and gently open the retaining clips at each end of the socket
(see letter "A" in the following figure). This will slightly lift the DIMM from its
socket. Holding the DIMM by the edges, remove it from the socket (see letter "B").
Important: Store the removed DIMM in an anti-static package.
B
A
AF002454

Figure 33. Removing DIMMs

30 Intel® Compute Module MFS5000SI User Guide
