Troubleshooting the CSS Hardware Components
Table 2-12 Troubleshooting the CSS Modules (continued)
Symptom
During normal CSS operation,
the following message appears
and then, the CSS reboots:
ONDM: Port C Path Failure
%s, turning off Focus-C
Port.
During normal CSS operation,
the following message appears
and then, the CSS reboots:
ONDM: Port D Path Failure
%s, turning off Focus-D
Port.
During normal CSS operation,
the following message appears
and then, the CSS reboots:
ONDM: Both Port C and Port
D Focus Connect paths have
failed.
During normal CSS operation,
the following message appears:
Temperature has reached x
celsius for slot number
Cisco 11500 Series Content Services Switch Hardware Installation Guide
2-40
Chapter 2 Cabling and Troubleshooting the CSS
Recommended Action
The Switch Module in slot 1 failed.
1. Power down the CSS.
Remove and replace the module. Refer to
2.
the reference sheet that comes with the
replacement module.
3. Reboot the CSS to boot the module.
The Switch Module in slot 2 failed.
Power down the CSS.
1.
2. Remove and replace the module. Refer to
the reference sheet that comes with the
replacement module.
Reboot the CSS to boot the module.
3.
The Switch Modules in slot 1 and 2 failed.
1. Power down the CSS.
Remove and replace the modules. Refer to
2.
the reference sheet that comes with the
modules.
3. Reboot the CSS to boot the modules.
Check the fans in the chassis. The module in
the designated slot number is running a
temperature that is too high, indicated by the x
variable.
For a CSS 11503, replace the chassis.
•
• For a CSS 11506, replace the fan module.
Refer to the reference sheet that comes
with the replacement module.
