Configuring a Modem

78-13884-06

Connecting a Modem to the CSS

This appendix explains how to configure a dial-up modem and connect it to the
console port on the CSS. Connecting a modem to the CSS allows you to remotely
perform the same CSS console operations as you would locally. The CSS supports
the following modems:
3Com (US Robotics) Courier Model 3453 Modem
•
3Com OfficeConnect Model 3294 Modem
•
• 3Com (US Robotics) Sportster Model 5686 Modem
MultiTech Model MT5634ZBA Modem
•
This appendix includes the following sections:
• Configuring a Modem
Cabling a Modem to the CSS
•
You must configure the modem before you can connect it to the CSS. You can
connect the modem to a terminal or a PC using a terminal emulation program,
such as Hyperterm. If you connect the modem to the COM port on a PC, you need
the following cable and connectors (see Appendix B,
• RJ-45-to-RJ-45 rolled cable
RJ-45-to-DB-25 modem adapter
•
• DB-9-to-RJ-45 terminal adapter
Cisco 11500 Series Content Services Switch Hardware Installation Guide
A P P E N D I X
Cable Connector
C
Pinouts):
C-1
