The following table describes the STP parameters in RSTP or MSTP mode.
Table 23 Rapid Spanning Tree parameter descriptions
Parameter
Current Root
Path-Cost
Port
Priority (bridge)
Hello
MaxAge
FwdDel
Aging
Priority (port)
Cost
State
Role
Designated bridge
Designated port
Type
Description
Shows information about the root bridge for the Spanning Tree. Information includes the
priority (hex) and MAC address of the root.
Path-cost is the total path cost to the root bridge. It is the summation of the path cost
between bridges (up to the root bridge).
The current root port refers to the port on the switch that receives data from the current root.
Zero (0) indicates the root bridge of the STP.
The bridge priority parameter controls which bridge on the network will become the STP
root bridge.
The hello time parameter specifies, in seconds, how often the root bridge transmits a
configuration bridge protocol data unit (BPDU). Any bridge that is not the root bridge uses
the root bridge hello value.
The maximum age parameter specifies, in seconds, the maximum time the bridge waits
without receiving a configuration bridge protocol data unit before it reconfigures the STP
network. If the bridge is not the root bridge, it uses the
The forward delay parameter specifies, in seconds, the amount of time that a bridge port
has to wait before it changes from learning state to forwarding state. If the bridge is not the
root bridge, it uses the
FwdDel
The aging time parameter specifies, in seconds, the amount of time the bridge waits without
receiving a packet from a station before removing the station from the Forwarding
Database.
The port priority parameter helps determine which bridge port becomes the designated port.
In a network topology that has multiple bridge ports connected to a single segment, the port
with the lowest port priority becomes the designated port for the segment.
The port path cost parameter is used to help determine the designated port for a segment.
Generally speaking, the faster the port, the lower the path cost. A setting of zero (0)
indicates that the cost will be set to the appropriate default after the link speed has been
auto-negotiated.
Shows the current state of the port. The State field in RSTP/MSTP mode can be one of the
following: Discarding (DISC), Learning (LRN), Forwarding (FWD), or
Disabled (DSB).
Shows the current role of this port in the Spanning Tree. The port role can be one of the
following: Designated (DESG), Root (ROOT), Alternate (ALTN), Backup (BKUP), Master
(MAST), or Unknown (UNK).
Shows information about the bridge connected to each port, if applicable. Information
includes the priority (hex) and MAC address of the Designated Bridge.
The port ID of the port on the Designated Bridge to which this port is connected.
Type of link connected to the port, and whether the port is an edge port. Link type values
are AUTO, P2P, or SHARED.
MaxAge
value of the root bridge.
value of the root bridge.
