Section Five - Other Functions

Rhythm

The Rhythm mode in the RP2000 is a great tool for improving your timing, rehearsing different musical styles, or just
jamming when your drummer is out delivering pizzas.The Rhythm mode plays sampled drum beats in an infinite loop
and lets you to select different patterns, change tempo, and adjust the volume level.When the Rhythm mode is activat-
ed, the drum samples are mixed with your guitar signal at the left, right, and headphone outputs of the RP2000, and at
the Digital Output if the Dry Track feature is off.
The Rhythm mode is activated by pressing the Rhythm button. At this time, the Rhythm button's LED will light and the
current drum pattern will loop continuously. If Rhythm mode is activated from Performance mode, the LEDs in the
Store, Utility, and Assign buttons will light indicating that the function of these switches has changed.The Store button is
now used to select the drum Pattern, the Utility is used to select the Tempo, and the Assign is used to adjust the Level
of the drum loop.
The RP2000's Display will show the currently selected Rhythm function for 5 seconds and allow you to change the
Rhythm Pattern,Tempo, or Level when they are selected. If no adjustment is made after 5 seconds, the RP2000 will
revert back to the name of the currently selected Preset. Presets can be changed or edited while the Rhythm mode is
enabled.

Pattern

Press the Pattern (Store) button once.The currently selected drum pattern will be shown in the Display.
Rotate the Data Wheel to select the Pattern.There are 30 different Patterns available.

Tempo

Press the Tempo (Utility) button once.The display shows the current tempo in beats per minute (bpm).
Rotate the Data Wheel to change the tempo of the selected Pattern.Tempo ranges from 60bpm (60
beats per minute) to 248bpm (248 beats per minute).

Level

Press the Level (Assign) button once.The display reads dlevel. Rotate the Data Wheel to select the
playback volume of the drum loop. Level ranges from 1 to 50.

Assign

The Assign button is used to assign Parameters to the Expression Pedal, the Control Footswitch, or two internal LFOs
(Low Frequency Oscillator). Individual minimum and maximum values can be programmed for each of these con-
trollers, and the LFOs include programmable frequency (speed), and waveforms. Assigning Parameters to these con-
trollers is a very simple and intuitive process. Simply press the Assign button once and the Display will briefly show
Assign, after which it will alternate between showing expdl= and the current assignment for the Expression Pedal.
