Push release lever 2 down until
it engages.
Turn the key in the topcase
lock to the LOCK position and
z
remove the key from the lock.
Removing topcase
Turn the key to the RELEASE
position in the topcase lock.
The handle pops out.
Pull handle 3 up as far as it will
go.
Lift the topcase at the rear and
remove it from the luggage
carrier.
Installing topcase
Pull the topcase handle up as
far as it will go.
Hook the topcase into pos-
ition on the luggage carrier.
Make sure that front and rear
hooks 4 are securely seated in
corresponding keepers 5.
