BMW R 1200 R Rider's Manual page 120

Replace the defective bulb.
8
Bulb for tail light/brake
light
116
P21/5W / 12 V / 5 W / 21 W
z
Press bulb 6 into socket 7 and
turn it clockwise to install.
Turn bulb socket 5 clockwise
to install it in the bulb housing.
Seat the bulb housing in hold-
ers 4.
Install screw 3.
Install cover 2 with 3 screws 1.
Installing seat ( 61).
