workshop, preferably an author-
8
ised BMW Motorrad dealer.
104
Slip spacing bushing 3 into
the wheel hub on the left-hand
z
side.
with BMW Motorrad Integral
ABS OE
Do not damage the ABS
sensor on the left-hand side
when rolling in the wheel.
The front wheel must be
installed right way round to
rotate in the correct direction.
Note the direction-of-rotation ar-
rows on the tyre or the wheel
rim.
Roll the front wheel into posi-
tion between the front forks.
Raise the front wheel, insert
quick-release axle 2 and tight-
en to specified torque.
Quick-release axle in axle
holder
50 Nm
Tighten axle clamping screw 1
to the specified torque.
Clamp screw of quick-
release axle
19 Nm
Remove the front-wheel stand.
OA
without centre stand
Remove the auxiliary stand.
Ease the brake calipers on to
the brake discs.
Tighten screws 2 on left and
right to the specified tightening
torque.
