Bionaire BAP706-CN Instruction Leaflet

BAP706-CN_07EFM1.qxd:BAP706_CN07Final.qxd 7/10/07 3:23 PM Page 1
AIR CLEANER SAFETY
PLEASE READ AND SAVE
True HEPA
THESE IMPORTANT SAFETY
Air Purifier
BAP706-CN INSTRUCTIONS
MODEL:
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons. These precautions include:
1. Read all instructions before using the appliance.
2. To avoid fire or shock hazard, plug the appliance
directly into a 120V AC electrical outlet.
3. If the filter is covered by a bag when shipped, remove
plastic bag before use.
4. Keep the cord out of heavy traffic areas. To avoid fire
hazard, NEVER put the cord under rugs, near heat
registers, radiators, stoves, or heaters.
5. To protect against electrical hazards, DO NOT immerse
the appliance in water or other liquids. Do not use near
water.
6. Close supervision is necessary when any appliance is
used by or near children, or disabled persons.
7. Always unplug the air cleaner before moving or
cleaning the unit, opening the grill, changing the filters
and whenever the unit is not in use. To disconnect the
unit, be sure to pull the plug and not the cord.
8. NEVER drop or insert any objects into the openings of
the unit.
9. Do not operate any appliance with a damaged cord or
plug. If the motor fan fails to operate or the unit has
been dropped or damaged in any manner, return
appliance to manufacturer for examination and/or
repair.
10. Use appliance only for intended household use as
described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock, or injury to persons. The use of
attachments not recommended or sold by Jarden
Consumer Solutions may cause hazards.
Read instructions
11. DO NOT use outdoors.
before operating.
12. NEVER place on a soft surface such as a bed or sofa
Retain for future reference.
as this could cause the unit to tip over and block the
Instruction Leaflet
air inlet or outlet grills.
13. Keep unit away from heated surfaces and open
☎
flames.
INFO-LINE
If after having read this leaflet, you have any
questions or comments on your air cleaner,
call 1-800-253-2764 in North America.
122278/9100040003019
REPLACING THE FILTER TIPS AND TROUBLESHOOTING
ISSUE
• DO NOT attempt to wash and re-use the filter.
• If the filters are enclosed in plastic bags, remove before
UNIT WILL NOT
use.
OPERATE
Every few weeks, check the condition of filters. Filter life will
vary, depending on air quality and usage. On average,
DECREASED
filters need replacement every 10-12 months.
AIR FLOW
1. Turn off and unplug the air cleaner.
2. Open the air inlet grill and examine the foam pre-filter.
EXCESSIVE
Remove any dust or lint, and wash in warm soapy
NOISE
water. Rinse, drip dry, and place back into grill inlet.
3. Remove filter from the unit by pulling it gently towards
LEARNING MORE
you and discard it. attempt to clean the old
filter.
For a wealth of information about your air cleaner and
4. Install the new BAPF300 Fig. 2 other Bionaire
www.bionaire.com.
filter into the unit.This
model utilizes a hang tab
and filter clips to insure
that the filter is properly in
place. Before replacing the
filter, make sure that the
hang tab is securely in
place. The clip can only be
attached to the tabs on
the filter one way. The filter
clip should easily slide
onto the filter hang tab
Fig. 3
with only a small amount
of pressure. use
force while attaching the
clip to the filter. (Fig. 2)
5. Align the clip on the top of
filter with rails on the inside
of the cleaner unit. Gently
slide the filter onto the rail.
(Fig. 3)
6. Replace air inlet grill.
Filters can be purchased at a retailer near you or
by calling 1-800-253-2764.
Air Cleaner Filter Quantity Filter Model Filter
Model Number Needed Number Description
True HEPA
BAP706-CN 1
BAPF300
Filter
14. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void
your warranty. The inside of the unit contains no user
serviceable parts. All servicing should be performed by
Jarden Consumer Solutions or an authorized Jarden
Consumer Solutions Center.
15. DO NOT place anything on top of unit.
16. NEVER use detergents, gasoline, glass cleaner,
furniture polish, paint thinner, or other household
solvents to clean any part of the appliance.
17. Always turn the appliance off before unplugging it.
18. The ionizer in this appliance produces less ozone than
the UL established limits of 50ppb. However, in high
concentrations, ozone can be harmful to birds and
small pets. To prevent ozone buildup, we suggest using
the ionizer in well ventilated areas with the fan on.
19. This appliance should only be used in a room with
temperatures between 40° F (4.4° C) and 110° F
(43.3° C).
20. WARNING: To reduce the risk of fire or electric shock,
DO NOT use this appliance with any solid-state speed
control device.
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
INSTRUCTIONS
PLUG SAFETY
To reduce the risk of electric shock, THIS
PRODUCT HAS A POLARIZED PLUG (one blade is wider
than the other).
This plug will fit into a polarized outlet only
one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does
not fit, contact qualified personnel to
install the proper outlet.
DO NOT ALTER THE PLUG IN ANY WAY.
CORD SAFETY
• The length of cord used on this appliance was selected
to reduce tangling or tripping hazards.
• If a longer cord is necessary, an approved extension
cord may be used. The electrical rating of the extension
cord must be equal to or greater than the electrical
rating of the air cleaner (see rating label marked on
product).
• Care must be taken to arrange the extension cord so
that it will not drape over the countertop or tabletop
where it can be pulled on by children or accidentally
tripped over.
2 Year Limited Warranty
Sunbeam Products, Inc. doing business as Jarden
SOLUTION
Consumer Solutions or if in Canada, Sunbeam Corporation
(Canada) Limited doing business as Jarden Consumer
• Make sure unit is properly plugged Solutions (collectively "JCS") warrants that for a period of
in and outlet is energized. two years from the date of purchase, this product will be
free from defects in material and workmanship. JCS, at its
• Make sure unit turned ON.
option, will repair or replace this product or any component
of the product found to be defective during the warranty
• Make sure nothing is blocking air
period. Replacement will be made with a new or
inlet and filtered air outlets.
remanufactured product or component. If the product is no
• Check condition of the filter and
longer available, replacement may be made with a similar
clean/replace if necessary.
product of equal or greater value. This is your exclusive
warranty. Do NOT attempt to repair or adjust any electrical
• Make sure parts are firmly
or mechanical functions on this product. Doing so will void
positioned in place.
this warranty.
This warranty is valid for the original retail purchaser from
the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is
required to obtain warranty performance. JCS dealers,
® products, visit our website at
service centers, or retail stores selling JCS products do not
have the right to alter, modify or any way change the terms
and conditions of this warranty.
This warranty does not cover normal wear of parts or
damage resulting from any of the following: negligent use
or misuse of the product, use on improper voltage or
current, use contrary to the operating instructions,
disassembly, repair or alteration by anyone other than JCS
or an authorized JCS service center. Further, the warranty
does not cover: Acts of God, such as fire, flood, hurricanes
and tornadoes.
JCS shall not be liable for any incidental or consequential
damages caused by the breach of any express, implied or
statutory warranty or condition.
Except to the extent prohibited by applicable law, any
implied warranty or condition of merchantability or fitness
for a particular purpose is limited in duration to the duration
of the above warranty.
JCS disclaims all other warranties, conditions or
representations, express, implied, statutory or otherwise.
JCS shall not be liable for any damages of any kind
resulting from the purchase, use or misuse of, or inability to
use the product including incidental, special, consequential
or similar damages or loss of profits, or for any breach of
contract, fundamental or otherwise, or for any claim
brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the
exclusion or limitation of incidental or consequential
damages or limitations on how long an implied warranty
lasts, so the above limitations or exclusion may not apply
to you.
GET TO KNOW YOUR AIR CLEANER TRUE HEPA FILTER
HEPA (High Efficiency Particulate Air) filters are designed to
Your true HEPA air cleaner removes up to 99.97% of
airborne allergens as small as 0.3 microns, including remove up to 99.97% of airborne pollutants at 0.3 microns
ragweed pollen, grass pollen, tree pollen, household dust, or larger, from the air that passes through them. These
dust mite debris, mold spores, pet dander and smoke include tobacco smoke, household dust, pet dander and
from the air passing through the filter. pollen.
IONIZER HIGH, MEDIUM AND LOW SPEED SETTINGS
This appliance has an optional ionizer feature which, when For optimum air filtration, operate your Bionaire
turned on, releases negative ions into outgoing filtered air continuously on the HI setting. Its rugged motor has been
to help the air purification process. designed to give many years of use. For quieter operation
(such as in a bedroom), select LOW setting.
Ions are tiny particles that carry a positive or negative
BEFORE USE
charge. They exist naturally around us: in the air, water,
1. Carefully unpack your air cleaner.
and ground. Both positive and negative ions are colorless,
2. Select a firm, level surface with no obstructions to the
odorless, and completely harmless.
air inlets or outlets.
3. If the filter is covered by a bag when shipped, remove
Negative ions help air purification by attaching themselves
plastic bag before use and place filters into unit.
to very small airborne particles in the room. These particles
take on a negative charge and may join with positively
OPERATING INSTRUCTIONS
charged particles such as dust, pollen, smoke, and pet
dander to form larger particles. These larger particles are
then more easily captured by the filter system. • Remove all plastic bags from filters before use.
• DO NOT POINT FILTERED AIR OUTLET TOWARDS
WALL.
Your ionizer may produce an occasional popping or
cracking sound. This is normal and occurs when a small
buildup of ions is discharged.
1. Plug into a 120V AC electrical outlet.
After extended use, you may notice dust around the grills 2. Select the operating speed of HIGH ( ), MEDIUM ( )
or front panel. This is caused by negative ions exiting the
or LOW ( ) by turning the speed control knob to the
air outlet, evidence of the ionizer's air cleaning appropriate setting.
effectiveness. You can remove the dust with a soft brush
3. To release negative ions into the filtered air, turn the
or clean, damp cloth.
Ionizer ( ) Control Knob to ON and the light will
Larger particles may be attracted to positively charged illuminate.
surfaces throughout the home, like walls or floors. 4. The lonizer will not work unless air cleaner is running.
• This may occur more frequently when the filter is 5. For optimum air filtration, it is recommended to operate
nearing the end of its useful product life and unable to the air cleaner continuously. Its rugged motor has been
capture as many charged particles. designed to give many years of use.
• Excessive amounts of pet dander, dust, or smoke may
decrease the life expectancy of the filter and interfere
with the ionization process.
To help prevent particles from attracting to surfaces
throughout your home:
• You may want to run the ionizer less often.
• Check the condition of the filter more frequently.
The ionizer in this appliance produces less
ozone than the UL* established limits of 50ppb. However,
in high concentrations, ozone can be harmful to birds and
small pets. To prevent ozone buildup, we suggest using
the ionizer in well ventilated areas with the fan on.
*tested and listed by the Underwriters Laboratories, Inc.
This warranty gives you specific legal rights, and you may
also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.
In the U.S.A.
If you have any question regarding this warranty or would
like to obtain warranty service, please call 1-800-253-2764
and a convenient service center address will be provided
to you.
In Canada
If you have any question regarding this warranty or would
like to obtain warranty service, please call 1-800-253-2764
and a convenient service center address will be provided
to you.
In the U.S.A., this warranty is offered by Sunbeam
Products, Inc. doing business as Jarden Consumer
Solutions located in Boca Raton, Florida 33431. In
Canada, this warranty is offered by Sunbeam Corporation
(Canada) Limited doing business as Jarden Consumer
Solutions, located at 20B Hereford Street, Brampton,
Ontario L6Y 0M1.
© 2007 Sunbeam Products, Inc. doing business as Jarden
Consumer Solutions. All Rights Reserved. Distributed by
Sunbeam Products, Inc. doing business as Jarden
Consumer Solutions, Boca Raton, FL 33431.
BAP706CN07EFM1 Printed In China
Fig. 1
B
C
A
D
® air cleaner
G
E
F
A. Speed Control Knob E. Washable Foam
Pre-Filter
B. Ionizer Control Knob
F. True HEPA Filter
C. Ionizer Indicator Light
G. Filtered Air Outlet
D. Air Inlet Grill
