- Page 1 EZ Connect Powerline™ EZ Connect N 200Mbps HomePlug AV Adapter Draft 11n Wireless USB2.0 Adapter SMCHPAV-ETH...
- Page 2 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.
-
Page 3: Product Registration
Warranty and Product Registration To register SMC products and to review the detailed warranty statement, please refer to the Support Section of the SMC Website at http://www.smc.com SMC Networks, Inc. 20 Mason Irvine, CA 92618... -
Page 4: Federal Communication Commission Interference Statement
Compliances Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 5 EC Declaration of Conformity SMC contact for these products in Europe is: SMC Networks Spain, S.L. Edificio Conata II, Group CTSG Fructuos Gelabert 6-8 2o2a 08970 Sant Joan Despi, Barcolona,Spain This product indicates compliance with the Essential Requirements of the EMC Directive (2004/108/EC) and the LVD Directive (2006/95/EC) of the European Union.
-
Page 6: Table Of Contents
Index Preface…………………………………………………………………………....Important Safety Instructions………………………………………………………… Chapter 1 Installation Notice…………………………………........8 Chapter 2 Product Installation Guide……………………………………………….. 2.1 Installing the local powerline network……….……………………………………. 9 2.2 Sharing a xDSL or cable modem Internet connection………………………….. 9 2.3 Extending a wireless network with powerline to share an Internet connection. 10 Chapter 3 Utility…………………………………………………………………………. -
Page 7: Preface
PREFACE This document describes the installation of the SMCHPAV-ETH device. Please read this document before installing the product. This publication contains the following sections: Important safety instructions The first thing you need to know before you begin to install Product installation guide Specification IMPORTANT SAFETY INSTRUCTIONS This product is intended for connection to the AC power line. - Page 8 Only a qualified technician should service this product. Opening or removing covers may result in exposure to dangerous voltage points or other risks. Unplug the powerline adapter from the power outlet and refer the product to qualified service personnel for the following conditions: When the interconnect cords are damaged or frayed.
-
Page 9: Chapter 1 Installation Notice
Chapter 1. Installation notice The first thing you need to know before you begin to install…… 1. Before installing, make sure your PC meets these requirements for hardware installation: Microsoft Windows® 98SE, ME, 2000, XP, Vista, Mac OS or Linux OS Pentium®... -
Page 10: Chapter 2 Product Installation Guide
Chapter 2. Product Installation Guide Important: Do not plug the device into a power strip or surge protector because these devices may consist of filter and impair signal. Also avoid plugging the device right next to noisy sources such as cell phone charger, Halogen light, Energy saving bulb, noisy desktop computer, vacuum cleaner, etc. -
Page 11: Extending A Wireless Network With Powerline To Share An Internet Connection
2.3 Extending a wireless network with powerline to share an Internet connection 1. Connect one SMCHPAV-ETH device to the broadband router Plug the SMCHPAV-ETH into an AC power outlet. Plug the provided Ethernet cable into the RJ45 connector of SMCHPAV-ETH and plug the other end of the cable into an available Ethernet port of the broadband router. -
Page 12: Chapter 3 Utility
Chapter 3. Utility This Windows utility enables users to find the SMCHPAV-ETH on the Powerline network, measures data transfer rates, ensures privacy and performs diagnostics. 3.1 System Requirements Operation System Microsoft Windows® 2000, XP, Vista Intel Pentium III or better, clock rate faster than 2.0GHz recommended Minimum 128MB Free Disk Space... -
Page 13: Running The Utility
3.3 Running the Utility After installing the utility, please run it from the Start/All Programs menu or double click the utility icon on the desktop. Figure 2 shows the main screen of the utility. This screen shows a SMCHPAV-ETH connected as local device and another SMCHPAV-ETH connected as remote device. -
Page 14: How To Use
3.4 How to use 3.4.1. Main Tab The Main tab lists all SMCHPAV-ETH devices that are currently logically connected to the available powerline network. See chapter 3.4.2 on “privacy” to learn more about logical powerline networks. Upper Window The upper window, entitled “Local Device(s) on your computer”, shows all the local SMCHPAV-ETH devices directly connected to your computer via Ethernet. - Page 15 CCo MAC Address This window shows the Hardware MAC Address of the “CCo”(Central Coordinator) of this Powerline network. The CCo is automatically appointed by the Powerline network and cannot be changed unless the original CCo is unplugged. Lower Window The lower window lists all the SMCHPAV-ETH devices discovered in the current logical Powerline network.
- Page 16 Figure 3. Set Device Password “Add Remote” button The “Add Remote” button is used to add a remote device which is not listed in the lower window to your logical network (for example, a device is currently in another logical network).
-
Page 17: Privacy Tab
“Scan” button The “Scan” button is used to immediately search for SMCHPAV-ETH devices connected to your logical network. By default setting, it will automatically scan every 10 seconds and update the display lists accordingly. 3.4.2 Privacy Tab By factory default, every SMCHPAV-ETH device carries a default logical network name: “HomePlug AV”. -
Page 18: Diagnostics Tab
“Set Local Device Only” button The “Set Local Device Only” button is used to change the network name of the local device only. After changing the network name to a new one, all the devices existing in the same network before will no longer be able to communicate or respond to you because they will not have the same network name within the local device. - Page 19 Figure 6. The Diagnostics Tab Screen The lower window of Diagnostics tab contains the history of all remote devices which have been found by the computer previously. All the devices will be shown here, regardless whether they are currently active or not. The following information is available from the list: TEI (Terminal Equipment Identifier)
- Page 20 “View Report…” button Click this button to view all the device information displayed on the upper and lower window in the default text editor. “Save Report…” button Click this button to save all the device information displayed on the upper and lower window to a text file.
-
Page 21: About Tab
3.4.4 About Tab The “About” Tab shows the software version and manufacturer information. Figure 7. The About Tab Screen... -
Page 22: Appendix
Appendix A-1.Specification Items Description 200Mbps PHY Rate TCP: Up to 65 Mbps effective throughput Effect Data Rate UDP: Up to 85 Mbps effective throughput Frequency Band 2~28 MHz (With Mask) Access Methods CSMA/CA channel-access schemes Four-level priority based contention access, and multi segment bursting 8-levels VLAN priority field, TOS Field QoS Classification by destination MAC address and IP Port... - Page 23 Power Consumption 4W Max (Normal mode) Below 2W (Standby mode) CE / FCC Certification LEDs Power LED On: Power on (Red) Blinking: Standby mode (*1) Off: Power off Link LED On: Powerline Link detected and no traffic (Green/Orange/Red) Blinking: Powerline traffic detected Green: The Powerline connection quality is good Orange: The Powerline connection quality is fair Red: The Powerline connection quality is bad...
-
Page 24: A-2. Push Buttons
A-2. Push buttons Please note that push button functions are disabled in standby mode. ※Security Button Usage: 1. First time to setup your private network: It is highly recommended to setup a private network with encryption to protect the network from unauthorized access through the Powerline network. In a private network each device must use exactly the same private network name to be able to communicate. - Page 25 Step 4. The new device starts to communicate with the device from the existing private network, and tries to join the existing private network. It will complete the process within 10 seconds. On the new device’s all LEDs are turned off and on again.
- Page 26 SMCHPAV-ETH...
