Hard Drives

NOTE:
The system's drive configuration must consist of all SATA hard drives or all SAS hard drives.

Hard Drive Installation Guidelines

Your system contains up to two SATA or SAS hard drives in internal drive bays. Both drives must be
either SAS or SATA; mixed configurations are not supported. Up to two SATA drives may be connected
to the system's integrated SATA controller or to an optional SAS controller expansion card. Up to two
SAS drives may be connected to an optional SAS controller expansion card. Table 3-1 describes the
possible drive configurations.
Table 3-1. Hard-Drive Configurations
Drive Drive Type
Number
1 SATA
1 SAS
2 SATA
2 SAS

Removing a Hard Drive

CAUTION:
Many repairs may only be done by a certified service technician. You should only perform
troubleshooting and simple repairs as authorized in your product documentation, or as directed by the online or
telephone service and support team. Damage due to servicing that is not authorized by Dell is not covered by your
warranty. Read and follow the safety instructions that came with the product.
1 Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
2 Open the system. See "Opening the System" on page 41.
3 Disconnect the hard drive power cable from the hard drive that you are removing.
4 Disconnect the blue data cable from the hard drive that you are removing by pulling up on the blue
tab.
5 Press the blue tabs on each side of the hard-drive bracket toward each other and slide the drive up and
out of the bay. See Figure 3-9.
Location Controller
HDD0 integrated SATA controller
SAS expansion card (slot 2)
HDD0 SAS expansion card (slot 2)
HDD1 integrated SATA
SAS expansion card (slot 2)
HDD1 SAS expansion card (slot 2)
Connector
SATA0
HDD0
HDD0
SATA2
HDD1
HDD1
