- Page 1 How to connect up, build-in, set up, use and look after your B1641 oven NEFF (UK) Ltd...
-
Page 2: Table Of Contents
Removing/installing the oven door Control panel overview Oven light Accessories Removing the shelf railings Shelf positions Heating element Before Using Your Appliance for the Service and Repair Information First Time Trouble-shooting Guide Setting the time of day Preliminary cleaning Initial burn-in... -
Page 3: Important Information
They contain important information again. concerning your personal safety as well Before you dispose of your old as on use and care of the appliance. appliance, make sure that it has been The Instructions for Use apply to several rendered inoperable. -
Page 4: Appliance Safety Considerations
Do not insert a baking sheet at the Hot steam may escape. bottom of the oven, or cover the base of the oven with aluminium foil, as this would result in heat build up. Roasting and baking times would change, and the enamel would be damaged. - Page 5 The control panel: The switches are retractable. To engage and disengage, depress the switch, making sure that it is in OFF position. Oven functions: Note: Circotherm and defrosting position The oven light switches on for every Conventional oven function.
-
Page 6: Accessories
Introducing: Your new Oven Accessories Your appliance is supplied with: 2 Wire shelves 1 Roasting/grill pan with grid The following accessories can be obtained from the supplier of your Order no. oven: Deep roasting pan Z 1270 X2 Baking tray, aluminium... -
Page 7: Before Using Your Appliance For The First Time
To amend the time of day, press button > until the indicator flashes unter symbol. The correct time of day can then be set. Note: The time cannot be set if an automatic function is active (see Electronic clock for cancelling automatic function). Preliminary cleaning: Initial burn-in 1. -
Page 8: Electronic Timer
(e.g. minutes). Å When the timer switches on, the remaining time is displayed. 2. A signal tone is emitted when the time has elapsed and the indicator flashes. > To stop the signal tone, press the button. -
Page 9: Automatic Timer 9+10
Electronic timer Automatic timer You can switch the oven on and off via the electronic clock. Setting the length of cooking time: Automatic switch off: If you wish to bake or roast food immediately, it is only necessary to set the cooking time. - Page 10 Electronic timer Automatic switch on and switch off: Setting the length of cooking time: If the food is to be cooked later on, both the cooking time and Off time must be set. 1. Select the heating system and the oven temperature.
-
Page 11: Special Functions
7 seconds. automatically dimmed. The display then goes blank and the time continues running in the background. 2. To switch on the display, briefly press > button. Note: The automatic timer is best used with dishes which require little attention. -
Page 12: Definition Of Oven Features 12+13
Radiant grill —————————— Advantages: The food being cooked is exposed to heat – low soiling of oven interior from the grill element at the top of the oven cavity. – cooking on up to 3 shelf levels at once is possible Advantages: –... - Page 13 The dough proving function provides ideal The hydroclean system featured in your conditions inside the oven for getting yeast oven is intended to help you keep your dough to rise. oven neat and tidy. An amount of cleaning solution is vaporised automatically. The Temperature: 35 –...
-
Page 14: Switching The Oven On And Off
When the set temperature has been in ° C in ° C reached, the indicator light goes out. 40 – 200 Switching off the oven: To switch off the oven, turn the function ”Defrost” selector and the temperature selector to setting –– –– –– temperature position. -
Page 15: Safety Features
Safety features Locking the oven: Using the function selector, switch 3 x in rapid succession from the position to the oven light function and back again. Å – – is displayed. The oven cannot be unintentionally switched on, e.g. by children. -
Page 16: Baking
Always place baking tins in the centre of the wire shelf. Circotherm: You can use baking tins of any material and of any colour, as long as they are oven-proof. Do not place baking tins or high cakes too close to the rear oven wall. -
Page 17: Roasting
150 grams (5 oz) or more. Place the shelf on top of the roasting Baste the meat if desired. pan. Place in a cold oven to save energy or Place the meat on the shelf, season if pre-heat if desired. desired. -
Page 18: Grilling
Use the shelf and roasting pan together. Season meat as required. Place on shelf. Do not turn food over – the hot air will circulate around the food cooking all sides. Use a temperature of 180–190 °C. -
Page 19: Cooking Tips And Helpful Hints
Cooking Tips and Helpful Hints When cooking with Circotherm: Cakes baked in a tin get too dark at the Avoid blocking the air vents at the rear wall back. of the oven with the cake tins. Cakes remain doughy and collapse Reduce the temperature for deep cakes. -
Page 20: Defrosting And Cooking 20+21
For defrosting and cooking of frozen Shelf-in levels: foods, use circotherm. With 1 baking sheet: Slide-in level 3 With 2 baking sheets: Slide-in levels 1 and 3 With all frozen foods, follow the food manufacturers instructions on the All stated times are approximate package. - Page 21 The circotherm fan operates without heat. Depending on size and type of bakeware, defrost for 25 – 45 minutes. After this time, remove the food from the oven. Let it stand at room temperature for 30 – 40 minutes. Function selector Temperature selector With smaller amounts (pastries) the defrosting time is reduced to 15 –...
-
Page 22: Dough Proving Function
Please read the enclosed cookery book for suggestions on how to make subsequent use of the dough. Before you start baking, remove the water left inside the oven. If any traces of lime are left behind, they can be dissolved with a little vinegar and wiped off using clear water. -
Page 23: Cleaning And Care
Important cleaning basics: For cleaning, do not use abrasives, corrosive cleaners, aerosol cleaners or sharp objects. Do not scratch off burnt-on food residues, but soak off them with a damp cloth and washing up liquid. Oven cleaners must not be used on aluminium or plastic parts. -
Page 24: Hydroclean System 24+25
In the case of heavy soil build-up, you may wish to allow the cleaning solution to soak in for a while before you activate the cleaning function. 3. Close the oven door. 4. Turn the function selector to position... - Page 25 Cleaning tips: Never leave the residual water in the oven for any length of time, e.g. overnight. 1. Open the oven door and pick up the remaining water with a large absorbent sponge cloth. 2. Using the detergent-soaked sponge cloth, a soft brush or a nylon scrubber, wipe off the oven interior.
-
Page 26: Removing/Installing The Oven Door
Removing the oven door: 1. Fully open the oven door. 2. Move the catch levers on the right and left-hand sides to the fully open position. 3. Placing the door at an upward angle toward you, grasp the door with both hands and lift it out of the hinges toward you. -
Page 27: Service And Repair Information
Important general safety guidelines: Service or repair work on the electronic components may only be performed by a qualified expert. Without exception, prior to starting such repairs, the appliance must be disconnected from the mains. This may be accomplished by tripping the automatic fuse or by removing the fuse from the fuse box that controls your home. -
Page 28: Trouble-Shooting Guide
Trouble-shooting Guide Problem Possible cause Remedy ... if the oven suddenly stop functio- The electronic timer is set to an auto- Set electronic timer to operation ning. matic timing cycle. without automatic timer: 1. Reset ON time {:{{ 2. Press the button. -
Page 29: Assembly Instructions
Assembly Instructions... -
Page 30: For The Installer And Kitchen Expert
WARNING: Connection and first start of the appliance may only be performed by an authorised specialist. Connection must be made using an H 0 5 V V- F mains connection cable. Nominal connected loading, nominal voltage and model number of the appliance:... -
Page 31: Installation Of The Built-In Oven
Assembly Instructions Installation of the built-in oven Push the built-in oven into the housing unit and align the unit until it is in a level position. Open the oven door and, using one screw on each side, fasten the built-in oven to the side strips of the housing mind. - Page 32 NEFF (UK) Ltd. Grand Union House, Old Wolverton Road, Old Wolverton Milton Keynes, MK12 5PT Tel: 01908 328300 Fax: 01908 328399 5750 201 846 Printed in Germany 1103 Es.
