Omron KP100L Datasheet

KP100L
Ordering information
Description Applicable country
Photovoltaic Inverter Italy, Spain, France, Germany, Czech Republic, Portugal, Greece (Only Mainland),
Denmark, Turkey, Republic of South Africa
Specifications
Item
DC Input Max. open-circuit voltage
DC voltage range
MPPT voltage range
Norminal voltage
Number of MPPT
Type of DC terminals
Max. current per one pair of DC terminals
Max. power per one pair of DC termminals
AC Output Nominal power
Peak power (10 minutes)
Nominal Output Current
Output voltage
Nominal frequency
Output frequency range
THD of output current
Power factor (cos phi)
Wiring sytem
Performance Max.efficiency
European efficiency
Standby consumption power
Night time consumption power
Certifications EMC
Low voltage regulation
German regulation
Spanish regulation
Italian regulation
Other Operation temperature range
Tolerable relative humidity
Degree of protection
Cooling
Dimensions (W  H  D)
Weight
Display
Data transmission
Warranty
6
Highest Reliability and Quality, Fastest
return of Investment in string inverters
category.
• Versatile matching: Monocrystal and Polycristal solar modules on the same
inverter driven by different MPPT.*
• Top level performance: 3MPPT, Wide MPPT voltage range, Max peak output power
(+10%).
• Smart control for solar tracker: one stop solution (control components and
software).
* Suited for crystaline module that grounding isn't required. For compatibility please contact
OMRON sales representative.
Order code
KP100L-OD-EU
KP100L-OD-EU
850 VDC
200 to 850 VDC
225 to 850 VDC
585 VDC
3
MC4
13 ADC
5,500 W
10,000W
11,000W
14.5 A
230/400 VAC
50 Hz
45 to 55 Hz
4% or less
1 (typical) (at output power 10 kW)
3-phase 4-wire
97.5%
97.1%
1 W or less
1 W or less
EN 61000-6-2, EN61000-6-3, EN61000-3-2
EN50178
VDE0126-1-1
RD1663/2000
DK5940 Ed2.2
20 to + 60C
4 to 100%, non-condensing
Housing:IP65 (acc. To DIN EN60529)
Forced ventilation
455  700  270 mm
Approx. 42 kg
LCD (16 charactors, 2 lines)
RS-232C/RS-485
5 years ( Option:10 years)
Photovoltaic Inverter
