- Page 1 Cat No. S102-E1-03 Grid Connect Photovoltaic Inverter KP100L-OD- Quick Installation Guideline Note: Dec, 2010 KP100L does not have the compatibility with thin-film module at this moment. The compatibility is under evaluation. Part number 2132254-1 C...
- Page 2 The software and the protective functions are not accessible and/or changeable to the user. • This QIG is intended for: Users and Installers of the KP100L • Read this QIG carefully and make sure that you understand it well to ensure that you are using the KP100L correctly.
- Page 3 The following are some examples of applications for which particular attention must be given. This is not intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses listed may be suitable for the products: •...
-
Page 4: Dimensions And Weights
PERFORMANCE DATA Performance data given in this manual is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of OMRON's test conditions, and the users must correlate it to actual application requirements. -
Page 5: Safety Precautions
Safety Precautions ■ Indications and Meanings of Safety Information In this user's QIG, the following precautions and signal words are used to provide information to ensure the safe use of the KP100L. The information provided here is vital to safety. Strictly observe the precautions provided. - Page 6 Functional lesion by injury and fire damage may possibly occur. Do not remove the MC cap on the back of the product when you exchange the FAN Assembly. Ask to the store where you purchased the product or to an authorized service person when disposing of the product.
- Page 7 Functional lesion by injury and fire damage may possibly occur. Do not remove the MC cap on the back of the product when you exchange the FAN Assembly. Significant property damage may possibly occur. Execute the installation by a person who has the qualification that authorized by the electric power company in the region.
- Page 8 Fire damage or functional lesion of internal part may occasionally occur. Do not obstruct the heat sink or place any objects within 200mm of the heat sink. Fire damage and malfunction may occasionally occur. Do not use the product that dropped or applied a strong impact.
-
Page 9: Precautions For Safe Use
• IP65 performance can not be provided, if you don´t follow these instructions: 3) Use the cable of φ18.5-20.5mm when you use the rubber bush of one hole for the AC cable clamp. 4) Use the five cables of φ3.5-4.0mm when you use the rubber bush of five holes for the AC cable clamp. -
Page 10: Precautions For Correct Use
12) Locations subject to being damaged the wiring by animals or other factors. Protect the wiring by, for example, placing wiring ducts. 13) Locations subject to near the equipment (such as a radio or TV) that is likely to be affected by electric waves, or to near an antenna. -
Page 11: Checking The Accessories
1. Checking After Unpacking 1. Checking After Unpacking ■ Checking the Accessories The follow items are included in the KP100L package. Check that all of the items shown in the package before you start the installation. KP100L Mounting base plate QIG (Quick Install Guide) User’s Manual... -
Page 12: Typical System Configuration
The KP100L is designed to operate with grid network system type TT, TN as shown in the figure below. If the KP100L is connected to the different type of grid network such as IT, it may be fault occur. Connection with grid network type TN... - Page 13 2. Typical System Configuration The KP100L is designed with grid network system type TT, TN. Then If you use transformer, connect the Neutral to the ground as shown in the figure below. 3P+N 3P+N 3P+N Grid Grid Neutral in KP100L side should be connected to the ground.
-
Page 14: Application Information
AC breaker For protection of AC over current, use a 20 A trip breaker with B or C or D trip characteristics. If you use the transformer, install the breaker between the transformer and the KP100L as shown in the figure below. - Page 15 3. Application information Ground fault breaker / RCD (Residual Current Device) For KP100L, the use of RCDs type B is not indispensable and RCDs type A can be used. KP100L has built-in fault current protection function required in Germany standard of VDE V 0126-1-1:2006-02, so DC residual current can be detected and cannot flow to the grid.
-
Page 16: Dimensional Drawing
Leave specific space as shown in the figure below between the KP100L and the ceiling or eave, the floor or ground, and wall when you install the KP100L. ・ When you install multiple Inverters, leave a space of 200mm the minimum to the side of the Inverter. Do not install multiple Inverters vertically. 200mm... - Page 17 (2) Mark the positions of the 8 outer mounting holes onto the wall with the mounting base plate. (3) Drill the 8 marked holes in the wall, and then drive the 8 Snap Bushings by the hammer into the wall, when the wall is a hard wall like concrete.
- Page 18 (5)Set it in product so that 4 places in the part where both sides of the mounting base plate are curved may come outside of the heat sink (6)Set it up so that the 2 screws in the both sides of the heat sink may fall into the ditch of the mounting base plate.
- Page 19 R (2) Pass the AC cable through the cap and the rubber bush of the cable clamp. Rubber bush (one hole type and five hole type) is bundled. (2)-1 In the case of you use the rubber bush of the one hole type The rubber bush of one hole is used for connection with multiple-cable.
- Page 20 ■ Options The screw of hexagon (For Italy) The customer who uses KP100L in Italy must buy the following screw. And, fix Cover foreside R according to the following procedure. This is a requirements of ENEL Guideline. Refer to User’s manual for detail installation.
- Page 21 Mount the enclosed MC caps onto MC connector that is not used. Each set of DC terminals takes a maximum DC input of 13A. 3 pairs of DC terminals can take a combined input of up to 33A. Maximum PV input power for each tracking is 5,500W.
-
Page 22: Check List
There has been no mechanical stress, which applies continuously yet negligible, such as vibration or shock to the inverter. The heat sink of the inverters is purged to avoid any clog of air convection and do not place any objects close to the air duct. - Page 23 Set a specified country. Refer to “Procedure at the First Time Operation” for detail. After the Solar modules are connected to KP100L, the input voltage is greater than 200 VDC and the AC grid is not connected to the in KP100L, the Data Logger LCD displays. Fault:...
-
Page 24: Procedure At The First Time Operation
The display moves to the display of the setting of the country when you start KP100L with Country Setting not fixed. Refer to the figure below for setup. Table shows the relation between the menu and the country. - Page 25 After 5 second pass To the Normal Display (1) In the country selection display, select the items that you want to set by the “<<” and “>>” key and you decide the item by the ENT key. (2) In the last confirmation display of country setting, fix the country setting when you push the ENT key for 5 second.
-
Page 26: Display Transition
