Introducing the Function Blocks
1-1-2

Function Block Specifications

Item
Model number
Setup disk
Compatible CPU Units (PLC models)
Note The function block and structured
text functions supported by CS/
CJ-series CPU Units with unit ver-
sion 4.0 or later can not be used
in CS/CJ-series CPU Units with
unit version 3.0 or earlier, CP-
series PLCs, NSJ-series PLCs, or
FQM1-series PLCs.
For details, refer to 1-6 Version
Upgrade Information.
For specifications that are not listed in the following table, refer to the CX-Pro-
grammer Operation Manual (W446).
WS02-CXPC1-E-V7
CD-ROM
CS/CJ-series CS1-H, CJ1-H, and CJ1M CPU Units with unit version 3.0 or later
are compatible.
Device Type CPU Type
• CJ2H CJ2H-CPU68/67/66/65/64/68-EIP/67-EIP/66-EIP/65-EIP
/64-EIP
• CS1G-H CS1G-CPU42H/43H/44H/45H
• CS1H-H CS1H-CPU63H/64H/65H/66H/67H
• CJ1G-H CJ1G-CPU42H/43H/44H/45H
• CJ1H-H CJ1H-CPU65H/66H/67H/64H-R/65H-R/66H-R/67H-R
• CJ1M CJ1M-CPU11/12/13/21/22/23
The following CP-series CPU Units are compatible.
• CP1H CP1H-X/XA/Y
• CP1L CP1L-M/L
Note If a user program containing function blocks created on the CX-Program-
mer Ver. 5.0 or later is downloaded to a CPU Unit that does not support
function blocks (CS/CJ-series CPU Units with unit version 2.0 or earlier),
all instances will be treated as illegal commands and it will not be possi-
ble to edit or execute the user program.
• NSJ G5D (Used for the NSJ5-TQ0@-G5D, NSJ5-SQ0@-G5D, NSJ8
-TV0@-G5D, NSJ10-TV0@-G5D, and NSJ12-TS0@-G5D)
M3D (Used for the NSJ5-TQ0@-M3D, NSJ5-SQ0@-M3D, and
NSJ8-TV0@-M3D)
• FQM1-CM FQM1-CM002
• FQM1-MMA FQM1-MMA22
• FQM1-MMP FQM1-MMP22
CS/CJ/CP Series Function Restrictions
• Instructions Not Supported in Function Block Definitions
Block Program Instructions (BPRG and BEND), Subroutine Instructions (SBS,
GSBS, RET, MCRO, and SBN), Jump Instructions (JMP, CJP, and CJPN),
Step Ladder Instructions (STEP and SNXT), Immediate Refresh Instructions
(!), I/O REFRESH (IORF), ONE-MS TIMER (TMHH and TMHHX) (These tim-
ers can be used with CJ1-H-R CPU Units.)
Note For details and other restrictions, refer to 2-4 Programming Restrictions.
Specifications
Section 1-1
5
