- Page 1 User Manual TMB 1700 – Programmable Amplifier Ar cle Ar cle no. 360242 TMB 1700 Programmable Amplifier 360243 Version V1.0 Date 2023/12...
-
Page 2: Table Of Contents
1.2 Typical installa on ............................3 1.3 Package contents ............................. 3 1.4 Hardware installa on ............................4 1.5 Moun ng the TMB 1700 ..........................4 2 Configuring the TMB 1700 ......................5 2.1 Naviga ng through the menu .......................... 5 2.2 Menu overview .............................. -
Page 3: Introduc On
1.2 Typical installa on The TMB 1700 can be used to provide high quality TV signals in a wide range of projects, both in the hospitality as in the residen al market. Typical buildings or infrastructures where the TMB 1700 can be used include, but are not... -
Page 4: Hardware Installa On
Connect the inputs to the TMB 1700 Connect a coaxial cable to the output connector for distribu on of the signal Power the device via the output (use the TRIAX Power Supply) Configure the device using the arrows & ENTER bu ons... -
Page 5: Configuring The Tmb 1700
TMB 1700 is situated. Use the arrows to select and confirm by pressing ENTER. The default se ng is Europe. The TMB 1700 is also opera onal in the following countries/regions: Australia, Brazil, China, Hongkong, Italia, New-Zealand, Russia, South Africa, UK and USA. -
Page 6: Channel Scan
TMB 1700 programmable Amplifier 2.4 CHANNEL scan DISPLAY READOUT EXPLANATION Use the arrows and validate with ENTER to enter the channel scan menu Scroll down to START and press ENTER to start scanning Note: If you use an ac ve antenna or mast amplifier, ac vate... -
Page 7: Input Se Ngs
TMB 1700 programmable Amplifier 2.5 INPUT se ngs DISPLAY READOUT EXPLANATION Tap INPUT FM/V/U1 to enter the menu to configure input 1. Use the arrows to navigate down in the submenu. PRE-AMPLI: The internal amplifier is by default ON, only in case of very strong incoming signals (if the strongest channel on that input is higher than 80dBµV), it can be advised to... -
Page 8: Output Se Ngs
300MHz) output level (compared to the UHF output level (above 300MHz). Note: In the OUTPUT menu, you define the output level in dBµV of the MUX’s. The TMB 1700 has enough gain to guarantee this output level under all input condi ons. -
Page 9: Advanced Se Ngs
2.7 ADVANCED se ngs DISPLAY READOUT EXPLANATION The language of the TMB 1700 can be set to English, Italian, Spanish or French. Tap REGION to check to which region/country the TMB 1700 is set. To change the region/country, a hard reset is required (see instruc ons above (cfr. -
Page 10: Exit Se Ngs
TMB 1700 programmable Amplifier 2.8 EXIT se ngs DISPLAY READOUT EXPLANATION To avoid unauthorized people changing the se ngs, the TMB 1700 can be locked with a security code. Select LOCK and SET LOCK CODE. When the lock code is set, the device will shut down. - Page 11 TMB 1700 programmable Amplifier Gain FM: >65 VHF: >65 UHF: >65 Gain adjustment Channel AGC General a enuator FM/VHF attenuator Noise figure Selec vity dB/1MHz Return Loss Output MER VHF: 35 UHF: 35 ESD protec on All inputs Remote voltage for preamp...
-
Page 12: Block Diagram
TMB 1700 programmable Amplifier 4 Block diagram 5 Safety Instruc ons Read these instruc ons carefully before connec ng the unit ATTENTION Failure to comply with the specified precau onary measures may cause serious injury to persons or damage to property. - Page 13 TMB 1700 programmable Amplifier CAUTION The devices meet the EU direc ves 2011/65/EU, 2014/30/EU and 2014/35/EU. The safety requirements are according to the standards EN/DIN EN 50083 resp. IEC/EN/DIN EN 60728 and must be observed, especially concerning equipoten al bonding and earthing.
-
Page 14: Condi Ons Of Warranty
If during this period of warranty the product proves defec ve, under normal use, due to defec ve materials or workmanship, TRIAX UK, at its sole op on, will repair or replace the product. Return the product to your local dealer for repara on.
