Kit Instructions
10.4-inch LCD Customer Display
4505-K451
Issue A

Advertisement

Table of Contents
loading

Related Manuals for NCR 4505-K451

Summary of Contents for NCR 4505-K451

  • Page 1 Kit Instructions 10.4-inch LCD Customer Display 4505-K451 Issue A...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.

  • Page 3: Table Of Contents

    Table of Contents 10.4-inch Customer Display Introduction Kit Components Installation Procedures Laying the Terminal Face Down Removing the Stand Installing the 10.4-inch Customer Display Installing the Stand Connecting the Cables...
  • Page 4 Revision Record Issue Date Remarks Nov 2018 First Issue...

  • Page 5: 10.4-Inch Customer Display

    10.4-inch Customer Display Introduction This document provides procedures for installing the 10.4-inch LCD Customer Display on the EX15 POS. The 10.4-inch LCD Customer Display is mounted on the back of the stand. It interfaces to the terminal through VGA port in the display head.

  • Page 6: Kit Components

    10.4-inch Customer Display Kit Components Part Number Description 497-0522774 Customer Display, 10.4-inch...

  • Page 7: Installation Procedures

    10.4-inch Customer Display Installation Procedures To install the 10.4-inch Customer Display, perform the following procedures: 1. Lay the terminal face down. 2. Remove the stand. 3. Install the Customer Display. 4. Re–install the stand. 5. Connect the Customer Display cables to the terminal ports.

  • Page 8: Laying The Terminal Face Down

    10.4-inch Customer Display Laying the Terminal Face Down 1. Pivot the display toward the back. 2. Lay the terminal face down on a flat surface. Caution: Always use a soft material (cloth, foam) to protect the display screen when placing the terminal face down.

  • Page 9: Removing The Stand

    10.4-inch Customer Display Removing the Stand 1. Remove the four screws that secure the stand to the back of the display. 2. Remove the stand and lay it down on a flat surface. Installing the 10.4-inch Customer Display 1. Remove the compartment cover on the display holder.
  • Page 10 10.4-inch Customer Display 2. Route the Customer Display cables through the compartment on the display holder. 3. Position the neck of the Customer Display onto the display holder compartment, and then secure with two M4x6.5 screws. Note: Ensure that the cables are not pinched and the holes on the are all aligned.

  • Page 11: Installing The Stand

    10.4-inch Customer Display 4. Position the stand onto the back of the display, and then secure with four M4x10 screws. Note: Ensure that the Customer Display cables are not pinched. Installing the Stand Position the stand onto the back of the display, and then secure with four M4x10 screws. Note: Ensure that the Customer Display cables are not pinched.

  • Page 12: Connecting The Cables

    10.4-inch Customer Display Connecting the Cables 1. Connect the VGA Cable to the VGA Output port. 2. Connect the Power Cable to the DC OUT port.
