10 U-CONTROL UCA222
Thank you
Thank you for choosing the UCA222 U-CONTROL audio
interface. The UCA222 is a high-performance interface that
includes a USB connector, making it an ideal sound card for
your laptop computer or an essential recording/playback
component for studio environments that involve desktop
computers. The UCA222 is PC and Mac-compatible, therefore no
separate installation procedure is required. Thanks to its robust
construction and compact dimensions, the UCA222 is also
ideal for traveling. The separate headphones output allows
you to play back your recordings at any time, even if you don't
happen to have any loudspeakers available. Two inputs and
outputs as well as the S/PDIF output give you total connecting
flexibility to mixing consoles, loudspeakers or headphones.
Power is supplied to the unit via the USB interface and the LED
gives you a quick check that the UCA222 is properly connected.
The UCA222 is the ideal extra for every computer musician.

1. Before You Get Started

1.1 Shipment
◊ ◊ Your UCA222 was carefully packed at the assembly
plant to assure secure transport. Should the condition
of the cardboard box suggest that damage may have
taken place, please inspect the unit immediately and
look for physical indications of damage.
◊ ◊ Damaged equipment should NEVER be sent directly
to us. Please inform the dealer from whom you
acquired the unit immediately as well as the
transportation company from which you took
delivery. Otherwise, all claims for replacement/repair
may be rendered invalid.
◊ ◊ Please always use the original packaging to avoid
damage due to storage or shipping.
◊ ◊ Never let unsupervised children play with the
equipment or with its packaging.
◊ ◊ Please dispose of all packaging materials in an
environmentally friendly fashion.
1.2 Initial operation
Please make sure the unit is provided with sufficient
ventilation, and never place the UCA222 on top of an amplifier
or in the vicinity of a heater to avoid the risk of overheating.
The current supply is made via the USB connecting cable,
so that there is no external power supply unit required.
Please adhere to all required safety precautions.
1.3 Online registration
Please register your new Behringer equipment right after your
purchase by visiting http://behringer.com and read the terms
and conditions of our warranty carefully.
Should your Behringer product malfunction, it is our intention
to have it repaired as quickly as possible. To arrange for
warranty service, please contact the Behringer retailer from
whom the equipment was purchased. Should your Behringer
dealer not be located in your vicinity, you may directly contact
one of our subsidiaries. Corresponding contact information is
included in the original equipment packaging (Global Contact
Information/European Contact Information). Should your
country not be listed, please contact the distributor nearest
you. A list of distributors can be found in the support area of
our website (http://behringer.com).
User Manual
Registering your purchase and equipment with us helps us
process your repair claims more quickly and efficiently.
Thank you for your cooperation!
2. System Requirements
The UCA222 is PC and Mac-compatible. Therefore, no installation
procedure or drivers are required for the correct functioning of
the UCA222.
To work with the UCA222, your computer must fulfill the
following minimum requirements:
PC PC Mac
Intel or AMD CPU, 400 MHz or higher G3, 300 MHz or higher
Minimum 128 MB RAM Minimum 128 MB RAM
USB 1.1 interface USB 1.1 interface
Mac OS 9.0.4 or higher,
Windows XP, 2000
10.X or higher
2.1 Hardware connection
Use the USB connecting cable to connect the unit to your
computer. The USB connection also supplies the UCA222 with
current. You can connect a variety of devices and equipment to
the inputs and outputs.
