72 U-CONTROL UCA222
3.
控制与接口
(7)
(6)
(5)
(1)
(8)
(2)
(3)
(4)
(1) POWER LED
USB
—
电源的状态。
(2) OPTICAL OUTPUT
Toslink
—
接口可传送通过光纤
S/PDIF
线连接的
信号。
(3) PHONES
1/8"
— 用于连接配有
迷你插头的标准头
戴式耳机。
(4) VOLUME
— 调节头戴式耳机输出端的音量。
连接耳机前请将其向左旋转, 将音量调至最小,
以免因音量过大而损坏听力。 需要将音量调大时
向右旋转即可。
(5) OUTPUT
RCA
— 用立体声
线将音箱连接至电脑
的音频输出。
(6) INPUT
RCA
— 用带有
接口的音频线连接需要的
录制信号。
(7) OFF/ON MONITOR
MONITOR
OFF
—
开关
时, 耳机输
USB
RCA
出端通过
接口 (同
输出端) 接收电脑信
MONITOR
ON
RCA
号。
开关
时, 耳机接收连接
输入
端输入的信号。
(8) USB CABLE
UCA222
— 从电脑及
发送信号或将信
UCA222
USB
号发送至电脑及
时使用的
线。 另外,
还可为设备供电。
4.
软件安装
• •
本品无需特殊设置或驱动, 只要将其插在电脑
MAC
USB
或
电脑的
口处即可。
◊ ◊
UCA222
注意—当
与百灵达其他产品连用时,
ASIO
随货供应的软件可能有所改变。 若不含
behringer.com
驱动, 可在我们的网站
上下载。
5.
基本操作
UCA222
为电脑, 调音台及监听系统提供了一个简便易
用的接口。 基本操作如下:
1)
USB
USB
UCA222
将
线插入
接口, 从而将
连接至
电脑。 电源指示灯会自动点亮。
2)
将要录制的音源, 如调音台, 前置放大器等设备
INPUT
RCA
连接至
立体声
输入端。
3)
1/8" PHONES
将耳机插入
(耳机) 接口并调节音量,
RCA
也可将一对音箱插入
立体声输出端以监听
输出。
4)
Toslink
用
光纤线从光纤输出端将立体声信号以
S/PDIF
数字音频模式 (
) 发送至外置录音设备。
启动之前
6.
应用图
XENYX 2222FX
B3031A
Active Monitor Speakers
RCA Input
RCA Outputs
Computer
USB
HPM1000
