171501389/3
04/2023
PRS 1501
IT
Dispositivo potatore - MANUALE DI ISTRUZIONI
CS
Odvětvovací zařízení - NÁVOD K POUŽITÍ
DA
Beskærer - BRUGSANVISNING
DE
Hochentaster - GEBRAUCHSANWEISUNG
EL
Σύστημα κλαδευτήρι - ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ
EN
Device Pruner - OPERATOR'S MANUAL
ES
Dispositivo podador - MANUAL DE INSTRUCCIONES
ET
Oksalõikur - KASUTUSJUHEND
FI
Karsimissaha - KÄYTTÖOHJEET
Dispositif d'élagueuse - MANUEL D'UTILISATION
FR
HR
Obrezivač - PRIRUČNIK ZA UPORABO
NL
Snoei-inrichting - GEBRUIKERSHANDLEIDING
NO
Beskjæringsutstyr - INSTRUKSJONSBOK
Urządzenie do przycinania gałęzi - INSTRUKCJE OBSŁUGI
PL
Dispositivo de poda - MANUAL DE INSTRUÇÕES
PT
RU
Садовые ножницы - РУKОВОДСТВО ПО ЭKСПЛУАТАЦИИ
SL
Naprava za obrezovanje - PRIROČNIK ZA UPORABU
Beskärningsverktyg - BRUKSANVISNING
SV
TR
Budama aparatı - KULLANIM KILAVUZU
ATTENZIONE: prima di utilizzare la macchina, leggere attentamente
il presente libretto.
POZOR: Před použitím stroje si pozorně přečtěte tento návod
k použití.
ADVARSEL: Læs instruktionsbogen omhyggeligt igennem,
før du tager denne maskine i brug.
ACHTUNG: vor Inbetriebnahme des Geräts die Gebrauchsanleitung
aufmerksam lesen.
Προσοχή: πριν χρησιμοποιήσετε το μηχάνημα, διαβάστε προσεκτικά
το παρόν εγχειρίδιο.
WARNING: read thoroughly the instruction booklet before
using this machine.
CUIDADO: antes de utilizar esta máquina, lea atentamente el manual
de instrucciones.
TÄHELEPANU: enne masina kasutamist lugege tähelepanelikult
kasutusjuhendit.
VAROITUS: lue käyttöopas huolellisesti ennen koneen
käyttöä.
ATTENTION: lire attentivement le manuel avant d'utiliser
cette machine.
POZOR: Prije nego pristupite uporabi stroja,
pažljivo pročitajte upute.
LET OP: Voordat u de deze machine gaat gebruiken dient u eerst deze
handleiding aandachtig door te lezen.
ADVARSEL: Les denne bruksanvisningen nøye før du bruker
maskinen.
UWAGA: Przed użyciem urządzenia przeczytaj uważnie niniejszą
instrukcję.
ATENCAO! Antes de usar a moto-roçadeira, ler com atenção
este manual de instruções.
ВНИМАНИЕ: Прежде чем пользоваться оборудованием, внимательно прочтите зто
руководсво по зксплуатации.
POZOR: Preden uporabite stroj, pazljivo preberite priročnik
z navodili.
VARNING: Läs igenom hela detta häfte innan du använder
maskinen.
DİKKAT! Makineyi kullanmadan önce talimatlar içeren kılavuzu dikkatle
okuyun.

Advertisement

Table of Contents
loading

Related Manuals for Stiga PRS 1501

Summary of Contents for Stiga PRS 1501

  • Page 1 171501389/3 04/2023 PRS 1501 Dispositivo potatore - MANUALE DI ISTRUZIONI ATTENZIONE: prima di utilizzare la macchina, leggere attentamente il presente libretto. Odvětvovací zařízení - NÁVOD K POUŽITÍ POZOR: Před použitím stroje si pozorně přečtěte tento návod k použití. Beskærer - BRUGSANVISNING ADVARSEL: Læs instruktionsbogen omhyggeligt igennem,...
  • Page 3 ITALIANO - Istruzioni Originali ..............ENGLISH - Translation of the original instructions .......... FRANÇAIS - Traduction de la notice originale ..........DEUTSCH - Übersetzung der Originalbetriebsanleitung ........ESPAGNOL - Traducción del Manual Original ..........NEDERLANDS - Vertaling van de oorspronkelijke gebruiksaanwijzing ..PORTUGUÊS - Tradução do manual original ..........
  • Page 4 IT - ATTENZIONE! - Questo accessorio può essere applicato solo sui modelli di decespuglia- tori/tagliabordi con asta giuntabile, indicati sotto. Per Comandi-Manutenzioni-Dati Tecnici-Avvertenze: fare rifemento al Manuale di Istruzioni della macchina sulla quale viene montato l’accesso- rio. EN - WARNING! - This accessory can be applied only on models of brush cutters / trim- mers with jointed rod, shown below.

  • Page 5: Dati Tecnici

    Käskude-hoolduse-tehniliste andmete-hoiatuste jaoks: vaadake selle seadme kasutusjuhendit, millele lisavarustus on paigaldatud. B 26 J - B 26 JA - T 26 J - T 26 JA DATI TECNICI PRS 1501 Peso a secco senza barra e catena 1,18 kg Passo catena 3/8”...
  • Page 7 > 5 mm...
  • Page 9 1] EN - TECHNICAL 1] FR - CARACTÉRISTIQUES 1] DE - TECHNISCHE DATEN SPECIFICATIONS TECHNIQUES 2] Nettogewicht (ohne Kettenschwert 2] Dry weight without bar and 2] Poids à sec sans guide ni chaîne und Kette) chain 3] Pas de la chaîne 3] Kettenteilung 3] Chain pitch 4] Épaisseur du maillon moteur...
  • Page 10 viii 1] SL - TEHNIČNI PODATKI 1] RU - ТЕХНИЧЕСКИЕ 1] HR - TEHNIČKI PODACI 2] Ciężar na sucho bez drążka i ХАРАКТЕРИСТИКИ 2] Neto težina, bez šipke i reznog łańcucha 2] Вес в сухом состоянии без шины noža 3] Rozstaw łańcucha и...

  • Page 11: Identification Of Main Components

    IDENTIFICATION OF MAIN COMPONENTS / SYMBOLS 1. IDENTIFICATION OF MAIN COMPONENTS MAIN COMPONENTS 1. Starter unit 2. Connecting rod 3. Chain catcher 4. Bar 5. Chain 6. Bar cover 7. Chain oil tank cap IDENTIFICATION PLATE Type: 11. Name and address of the manufacturer Max rotational frequency of the spindle: 12.

  • Page 12: Safety Requirements

    SAFETY REQUIREMENTS operator’s hearing. If the operator is working in an to the ground. Make sure it is correctly fitted on area where there is a risk of falling objects, a safety the brush cutter. helmet must also be worn. •) Always work in stable, safe positions.

  • Page 13: Causes And Operator Prevention Of Kickback

    SAFETY REQUIREMENTS / USING THE MACHINE 1) Whenever the machine is to be handled or tran- injury. sported you must: Kickback is the result of tool misuse and/or in- – turn off the engine, wait for the chain to stop and correct operating procedures or conditions and disconnect the spark plug cap;...
  • Page 14 USING THE MACHINE / MAINTENANCE AND STORAGE Mount the bar and chain very carefully so as not to impair the safety and efficiency of the • Checking the oil delivery machine. If in doubt, contact your dealer. DANGER! Perform all operations DANGER! Make sure the bar and the with the engine off.

  • Page 15: Maintenance And Storage

    MAINTENANCE AND STORAGE 5. MAINTENANCE AND STORAGE DANGER! During maintenance oper- If you sharpen the chain yourself, use special ations: round-section files with the right diameter de- – Disassemble the pruner rod from the brush pending on the type of chain (see “Chain Main- cutter.
  • Page 16 – the inside of the guide is worn enough to make the chain lean to one side. Given product evolution, the tools may be replaced in time with others having similar interchangeable and operating safety characteristics. Chain pitch Limiter tooth level (a) File diameter (d) a = 0,45 mm (0,018”) a = 0,45 mm (0,018”)
  • Page 17 1. La Società: ST. S.p.A. – Via del Lavoro, 6 – 31033 Castelfranco Veneto (TV) – Italy 2. Dichiara sotto la propria responsabilità, che la macchina: Dispositivo potatore a) Tipo / Modello Base: PRS 1501 c) Numero di Serie: 23A••CHA000001 ÷ 99L••CHA999999 d) Motore: 3.
  • Page 18 ST. S.p.A. n) Person authorised to compile the technical file: Via del Lavoro, 6 31033 Castelfranco Veneto (TV) - Italia o) Castelfranco Veneto, 01/03/2023 CEO Stiga Group Sean Robinson UK Importer: STIGA LTD Unit 8, Bluewater Estate Plympton, Devon, PL7 4JH, England...
  • Page 19 FR (Traduction de la notice originale) EN (Translation of the original instruction) DE (Übersetzung der Originalbetriebsanleitung) Déclaration CE de Conformité EC Declaration of Conformity (Directive Machines 2006/42/CE, Annexe II, (Machine Directive 2006/42/EC, Annex II, EG-Konformitätserklärung partie A) part A) (Maschinenrichtlinie 2006/42/EG, Anhang 1.
  • Page 20 NO (Oversettelse av orginal bruksanvisning) SV (Översättning av bruksanvisning i DA (Oversættelse af den originale original) brugsanvisning) EF- Samsvarserklæring (Maskindirektiv 2006/42/EF, Vedlegg II, del A) EG-försäkran om överensstämmelse EF-overensstemmelseserklæring 1. Firmaet (Maskindirektiv 2006/42//EG, bilaga II, (Maskindirektiv 2006/42/EF, bilag II, del A) 2.
  • Page 21 SL (Prevod izvirnih navodil) BS (Prijevod originalnih uputa) SK (Preklad pôvodného návodu na použitie) ES izjava o skladnosti EZ izjava o sukladnosti (Direktiva 2006/42/ES) , priloga II, del A) (Direktiva o mašinama 2006/42/EZ, ES vyhlásenie o zhode 1. Družba Prilog II, deo A) (Smernica o Strojných zariadeniach 2.
  • Page 22 © by ST. S.p.A. IT • Il contenuto e le immagini del presente manuale d’uso sono stati realizzati per conto di ST. S.p.A. e sono tutelati da diritto d’autore – E’ vietata ogni riproduzione o alterazione anche parziale non autorizzata del documento. CS •...
  • Page 23 Points de collecte sur www.quefairedemesdechets.fr Privilégiez la réparation ou le don de votre appareil ! ST. S.p.A. STIGA LTD (UK Importer) Via del Lavoro, 6 Unit 8, Bluewater Estate Plympton, 31033 Castelfranco Veneto (TV) ITALY Devon, PL7 4JH, England...
