AVIOTEC 8000i IR
Firmware 8.81
en
User manual

Advertisement

Table of Contents
loading

Related Manuals for Bosch AVIOTEC 8000i IR

Summary of Contents for Bosch AVIOTEC 8000i IR

  • Page 1 AVIOTEC 8000i IR Firmware 8.81 User manual...

  • Page 3: Table Of Contents

    AVIOTEC 8000i IR Table of contents | en Table of contents Safety instructions General safety messages / Notices Introduction Disclaimer About this manual Conventions in this manual Definition of optical terms Illumination 2.4.1 Focal length 2.4.2 Monitoring area 2.4.3 Different angle types 2.4.4...
  • Page 4 | Table of contents AVIOTEC 8000i IR Enhance 7.4.4 Relay settings Use cases Fire detection only Fire detection profiles Scheduled fire detection External trigger to switch fire detection mode Troubleshooting False Alarms False alarms under 4 seconds concerning the whole detection area 9.1.1...

  • Page 5: Safety Instructions

    AVIOTEC 8000i IR Safety instructions | en Safety instructions Danger! Indicates a hazardous situation which, if not avoided, will result in death or serious injury. Warning! Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
  • Page 6 | Safety instructions AVIOTEC 8000i IR Notice! No detection of moving fire. Moving fires might not be detected by the video-based fire detection. An example of a moving fire is a fire on a moving conveyor belt. Notice! Ensure that you are always using the latest version of the documentation and the current camera firmware.
  • Page 7 Warning! Bosch Security Systems assumes no liability for the reliability of fire detection in case of configuration changes in Expert Mode. This means it is your responsibility to ensure the reliability of the fire detection and, if necessary, fire tests.

  • Page 8: Introduction

    In addition, and for the U.S. market only, Bosch Security Systems makes no representation that the video fire indication system will prevent any personal injury or property loss by fire or otherwise;...

  • Page 9: Definition Of Optical Terms

    AVIOTEC 8000i IR Introduction | en Definition of optical terms 2.4.1 Illumination Dynamic range The dynamic range is the ratio between the darkest spot compared to the lightest spot in the application. Use a luxmeter to determine the brightness in your application. The dynamic range in the camera image / the detection area must be equal or less than factor 1000.
  • Page 10 | Introduction AVIOTEC 8000i IR The maximum width of the field of view (w) may be realized by the minimum focal length. This adversely affects the maximum distance (d) to a detectable fire. The maximum distance to a detectable fire may be reached by adjusting the largest focal length which decreases the width of the field of view to the minimum.

  • Page 11: Monitoring Area

    AVIOTEC 8000i IR Introduction | en 2.4.3 Monitoring area The monitoring area defines the effective space that can be observed by the video-based fire detection. It is depending on the setting of the camera lens. 2.4.4 Different angle types There are different types of angles influencing the set-up of the camera. The following overview helps to get a better understanding of angles which are important for the video- based fire detection.
  • Page 12 | Introduction AVIOTEC 8000i IR Opening angle of the lens The opening angle of the lens can be set from wide-angle to telephoto setting. This influences the field of view of the camera. 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH...
  • Page 13 AVIOTEC 8000i IR Introduction | en Angle for vertical alignment of the camera The vertical alignment of the camera is also important for the video-based fire detection. A flat angle is recommended. Angle for horizontal alignment of the camera Align the camera according to your application by adjusting the angle of the horizontal alignment of the camera.
  • Page 14 | Introduction AVIOTEC 8000i IR 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH User manual...

  • Page 15: System Overview

    Subject to the installation and operating conditions explained in this manual, it can, for example, supplement traditional fire detection systems or provide means of fire detection where traditional fire detection systems are technically limited. AVIOTEC 8000i IR operates as stand-alone unit and doesn’t need a separate evaluation unit.
  • Page 16 | System overview AVIOTEC 8000i IR 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH User manual...

  • Page 17: Uninterruptible Power Supply

    AVIOTEC 8000i IR System overview | en Power-over-Ethernet (PoE) allows to use the Ethernet cabling for data transmission and for supplying power to the network device in the same cable. It is possible to realize long cable lengths in a PoE network system. The standard power supply for the video-based fire detection is Power-over-Ethernet.
  • Page 18 | System overview AVIOTEC 8000i IR 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH User manual...

  • Page 19: Algorithm

    AVIOTEC 8000i IR can be used as primary fire detection system when the application is not covered by any code of practice or other kind of standards or if the necessary approvals/ releases have been obtained for the intended applications in accordance with the applicable laws and other regulations.

  • Page 20: Smoke Detection Characteristics

    | System overview AVIOTEC 8000i IR 3.2.2 Smoke detection characteristics Notice! All smoke detection properties are influenced by wind. The video stream is analyzed for potential fire events by searching for typical smoke movement and optical appearance of smoke.
  • Page 21 AVIOTEC 8000i IR System overview | en applies to the maximum detection speed and maximum width. It is not sufficient to measure one value at the bottom and the other value at the top of the smoke plume (see chapter Technical data).
  • Page 22 | System overview AVIOTEC 8000i IR 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH User manual...

  • Page 23: Tamper Detection

    AVIOTEC 8000i IR System overview | en The smoke detection covers a large area of application. Nevertheless, there might be some disruptive factors in the operational environment of the customer. Objects with a similar movement pattern of smoke might cause false alarms, e.g. escalators or conveyor belts.

  • Page 24: Video Management System

    A Video Management System is a unique enterprise IP video security solution that provides seamless management of digital video, audio, and data across any IP network. It nevertheless offers interfaces and standards to integrate the camera. AVIOTEC 8000i IR is compatible with the Bosch video management system BVMS. A connection to other video management systems is possible, but must be checked in a single case.

  • Page 25: Installation

    AVIOTEC 8000i IR Installation | en Installation Notice! Qualified personnel only. Assembly and installation must only be performed by qualified personnel. Notice! Avoid backlight. Backlight can disturb the video-based fire detection algorithm. Notice! Avoid image regions with continuous upward motion.

  • Page 26: Configuring The Camera Before Installation

    | Installation AVIOTEC 8000i IR – Download the latest firmware and tools (e.g. Configuration Manager) – IP address range change on Computer – A multimeter for testing the relay output – Analog monitor and cable for camera alignment Configuring the camera before installation...

  • Page 27: Network And Poe Power - Rj45

    AVIOTEC 8000i IR Installation | en Use STP Category 5e cable with RJ45 connectors (the camera network socket is Auto MDIX compliant). The LEDs beside the Ethernet connection indicate network connection (green lit) and ð IP traffic (orange flashing). The camera can be supplied with a power supply in case of missing PoE feature of the network or for redundancy reasons.

  • Page 28: 10-Pin I/O Connector

    | Installation AVIOTEC 8000i IR – Use STP Category 5e (or higher) cable with punch down connector. Note: If needed, test the cable by putting the network cable tester in the RJ45 port. – Power can be supplied to the camera via the Ethernet cable compliant with the Power- over-Ethernet standard and/or via the 24V AC / 12-26V DC auxiliary power.

  • Page 29: Alarm Input

    AVIOTEC 8000i IR Installation | en - IN + 12VDC / 24VAC ALARM Alarm outputs There are two outputs for alarm and trouble. Alarm output switching capability: – Max. voltage 30 VAC or +40 VDC. Max. 0.5 A continuous, 10 VA. 4.6.2 Alarm input...
  • Page 30 | Installation AVIOTEC 8000i IR - IN + 12VDC / 24VAC ALARM IN1 ALARM IN2 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH User manual...
  • Page 31 AVIOTEC 8000i IR Installation | en 7 mm (0.28”) 2 mm (0.08in) Alarm in: There are 2 alarm inputs. Use the alarm input to connect external alarm devices such as door contacts or sensors: +5 V nominal, +40 VDC max, Dry contact;...

  • Page 32: Camera Integration

    | Camera integration AVIOTEC 8000i IR Camera integration The video-based fire detection can be easily integrated into the network environment of the customer. There are several possibilities to connect the camera. Various combinations are possible. The individual customer network properties determine the performance and scalability of the system.

  • Page 33: Local Area Network

    AVIOTEC 8000i IR Camera integration | en Internet Monitoring Center Fire alarm control panel Mobile devices Local Area Network Due to the IP-based camera, the integration of the video-based fire detection into the network of the customer is easy. There are a lot of opportunities regarding to scalability and enlargement of the network.
  • Page 34 | Camera integration AVIOTEC 8000i IR 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH User manual...

  • Page 35: Local Area Network With Recording Solution

    AVIOTEC 8000i IR Camera integration | en Local Area Network with recording solution Recording and archiving functionality in the network can be realized by a video recording manager (VRM). Fire cause analysis and traceability due to legal matters are only two examples of a recording solution.
  • Page 36 | Camera integration AVIOTEC 8000i IR 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH User manual...

  • Page 37: Monitoring Center

    AVIOTEC 8000i IR Camera integration | en Monitoring Center Notice! No direct connection to fire services in EN54 compliant installations. Authorities can allow a connection to fire services after verifying alarms in a monitoring center. Exceptions are possible due to local regulations.
  • Page 38 | Camera integration AVIOTEC 8000i IR 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH User manual...

  • Page 39: Fire Alarm Control Panel

    Camera integration | en Fire Alarm Control Panel AVIOTEC 8000i IR can be connected to the a fire alarm control panel. Alarms and troubles will be triggered by relay outputs of the camera. There are two separate relays for alarm and trouble.

  • Page 40: Mobile Devices

    | Camera integration AVIOTEC 8000i IR - IN + 12VDC / 24VAC ALARM See the documentation of the individual manufacturer for further information about the connection to a fire alarm control panel. Mobile Devices Another advantage of the network integration of the video-based fire detection is the expandability to mobile devices, such as tablets or smartphones.
  • Page 41 AVIOTEC 8000i IR Camera integration | en Bosch Sicherheitssysteme GmbH 2023.10 | 02 | F.01U.414.168 User manual...

  • Page 42: Access To The Device

    | Access to the device AVIOTEC 8000i IR Access to the device Configuration Manager Notice! Camera settings should preferably be made in the Configuration Manager, as advanced functionalities are available there. You can get access to the camera via Configuration Manager available at https:// downloadstore.boschsecurity.com/...

  • Page 43: Adjustment Of Detection Settings

    AVIOTEC 8000i IR Adjustment of detection settings | en Adjustment of detection settings Notice! Camera settings should preferably be made in the Configuration Manager, as advanced functionalities are available there. Notice! For further parameters and ambient conditions to be considered, see the planning manual.

  • Page 44: Adjustments Of Image Regions

    | Adjustment of detection settings AVIOTEC 8000i IR Sensitivity high Smoke If a higher robustnes Default setting If no moving objects against false alarms are expected. is needed. Flames If a higher robustnes Default setting If no moving objects...

  • Page 45: Adaptation To The Lighting Situation

    AVIOTEC 8000i IR Adjustment of detection settings | en for each mask: 4 ... 120 . A clock icon with a small smoke plume is displayed at the bottom right-hand corner. Verification time flames The following settings (in seconds) are possible to assign an individual verification time for each mask: 4 ...

  • Page 46: Flickering

    Expert Mode Warning! Bosch Security Systems assumes no liability for the reliability of fire detection in case of configuration changes in Expert Mode. This means it is your responsibility to ensure the reliability of the fire detection and, if necessary, perform fire tests.

  • Page 47: Alc

    AVIOTEC 8000i IR Adjustment of detection settings | en Apply white balance – Sodium lamp auto mode allows the camera to continually adjust for optimal color reproduction in an environment with sodium vapor light sources (street lighting). White balance –...

  • Page 48: Enhance

    | Adjustment of detection settings AVIOTEC 8000i IR Day/Night Auto - the camera switches the IR cut-off filter on and off depending on the scene illumination level. Monochrome - the IR cut-off filter is removed, giving full IR sensitivity.

  • Page 49: Relay Settings

    AVIOTEC 8000i IR Adjustment of detection settings | en Intelligent Defog Select this to activate the automatic intelligent defog feature. This feature continuously adjusts image parameters to provide the best picture possible under foggy or misty conditions. Relay settings The camera includes two built-in relays. Relay 1 (Output 1) that switches in case of a flame or a smoke alarm.
  • Page 50 | Adjustment of detection settings AVIOTEC 8000i IR Trouble type Prerequisite (setting activated) Reference image check IR illumination (hardware defect or IR Scene quality: camera setting) Scene too dark Occluded Reference image check Defocussed or blurry image Tilted Too bright...

  • Page 51: Use Cases

    AVIOTEC 8000i IR Use cases | en Use cases Video content analysis (VCA) is the process of automatically analyzing video images to alarm on predefined events like the detection of moving objects. Fire profiles base on VCA. There are four use cases with the aid of different profiles. These four use cases are described below.

  • Page 52: Troubleshooting

    | Troubleshooting AVIOTEC 8000i IR Troubleshooting The following issues can be solved in the detection settings in the Configuration Manager or in the web browser menu (Configuration > Alarm > Fire detection). False Alarms 9.1.1 False alarms under 4 seconds concerning the whole detection area In this case the general settings of the fire detection have to be adjusted.

  • Page 53: No Fire Detection

    AVIOTEC 8000i IR Troubleshooting | en – Check the video client settings No fire detection – Problem: No detection of fire. – Solution: – Check fire detection settings (Configuration > Alarm > Fire detection) – Check mask settings – Check privacy mask settings –...
  • Page 54 | Troubleshooting AVIOTEC 8000i IR Type ping followed by the IP address of the device. If the device is found, the response appears as "Reply from ... ", followed by the number of bytes sent and the transmission time in milliseconds. Otherwise, the device cannot be accessed via the network.

  • Page 55: Maintenance

    AVIOTEC 8000i IR Maintenance | en Maintenance 10.1 Cleaning It is generally sufficient to use a dry cloth for cleaning, but a moist lint-free cloth or leather shammy may also be used. Do not use liquid cleaners or aerosol cleaners.
  • Page 56 | Maintenance AVIOTEC 8000i IR Testing Inspection frequency Item to inspect annually quarterly regularly Check of the video image 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH User manual...

  • Page 57: Technical Data

    AVIOTEC 8000i IR Technical data | en Technical data Algorithm Overview Min. detection size for Smoke, standard setting (% of picture width) Smoke speed 0.5 - 16 (% of picture height/s) Smoke speed 0%-30% (% of picture width/s) Min. Smoke density (%)
  • Page 58 | Technical data AVIOTEC 8000i IR 2023.10 | 02 | F.01U.414.168 Bosch Sicherheitssysteme GmbH User manual...
  • Page 60 Bosch Sicherheitssysteme GmbH Robert-Bosch-Ring 5 85630 Grasbrunn Germany © Bosch Sicherheitssysteme GmbH, 2023 Building solutions for a better life. 202310121721...
