Getting Started

FINAL
4/96
p/n 1.024.493
1996 U.S. Robotics Access Corp.
8100 North McCormick Blvd.
Skokie, IL 60076-2999
All Rights Reserved

Advertisement

Table of Contents
loading

Related Manuals for US Robotics Courier V.Everything 3CP3453

Summary of Contents for US Robotics Courier V.Everything 3CP3453

  • Page 1: Getting Started

    Courier V.Everything Internal Modem: Getting Started FINAL 4/96 p/n 1.024.493 1996 U.S. Robotics Access Corp. 8100 North McCormick Blvd. Skokie, IL 60076-2999 All Rights Reserved...
  • Page 2 U.S. Robotics and the U.S. Robotics logo are registered trademarks of U.S. Robotics Access Corp. V.Fast Class and V.FC are trademarks of Rockwell International. Any trademarks, tradenames, service marks or service names owned or registered by any other company and used in this manual are the property of their respective companies.

  • Page 3: Table Of Contents

    Table of Contents About This Manual We Welcome Your Suggestions...iii Chapter 1 The Courier Courier Controls and Connectors ...1-3 Features ...1-4 Chapter 2 Installing the Courier What You Need...2-1 Package Contents...2-2 Important! ...2-2 Plug and Play Setup ...2-4 Standard Setup...2-5 Setting the DIP Switches...2-8 Installing the Courier ...2-10 Connecting the Cables ...2-12...
  • Page 4 Appendix A Technical Specifications Standards Compatibility...A-1 Appendix B Warranty and Notices Limited Warranty ... B-1 Notices... B-3...

  • Page 5: About This Manual

    This manual explains how to set up and start using your Courier V.Everything Internal Modem. Refer to the Command Reference manual, also included with the Courier, for detailed information about using advanced features. We Welcome Your Suggestions We’ve made every effort to provide you with useful, accurate information.

  • Page 6: Chapter 1 The Courier

    Chapter 1 The Courier The Courier V.Everything Internal Modem makes any IBM-compatible computer with an Industry Standard Architecture (ISA) or Extended Industry Standard Architecture (EISA) expansion bus capable of exchanging data with modems or fax machines over standard, analog telephone lines at speeds of up to 33.6 Kbps.
  • Page 7 Calling Online Services Each online service, such as America Online or CompuServe, provides its own customized communications software package. A couple of these packages are included with the Courier. These packages do the dialing and guide you through the steps of registration.

  • Page 8: Courier Controls And Connectors

    Courier Controls and Connectors This section shows the DIP switches and connectors on the Courier and indicates where to find more information about each. Jumpers SEE PAGES 2-4 & 2-7 Figure 1-1. The Courier V.Everything Modem. To Telephone SEE PAGE 2-12 To Wall Jack SEE PAGE 2-12 DIP Switches...

  • Page 9: Features

    Features 33.6 Kbps Connectivity The Courier contains software that enables 31.2 and 33.6 Kbps connection rates, as well as improves throughput at lower speeds. While line conditions may not always allow for 33.6 Kbps connections, the new software makes it more likely that your Courier will achieve and maintain 28.8 Kbps connections.

  • Page 10: Dial Security

    V.Everything The Courier provides full support of the V.34 standard, V.Fast Class, V.32 terbo, and many other modulation schemes, spanning the range of speeds between 33.6 Kbps and 300 bps. We call this unique combination of abilities V.Everything. See the Compatibility section in Appendix B, Technical Specifications, for details.

  • Page 11: Distinctive Ring Support

    Calls to and from Modems and Fax Machines When used with fax-capable communications software, the Courier auto-detects and responds to calls from modems and Group III fax machines using EIA-standard Class 1 or 2.0 fax software. Testing ITU-T V.54 loopback testing is available. The Courier can perform analog, digital, and remote digital loopback tests.
  • Page 12 Dedicated- and Leased-Line Support The Courier does not need to be connected to the public switched telephone network. You can connect a standard telephone cable between the Courier and another modem and make connections without even dialing. You can also connect the Courier to a line that you lease from the telephone company.

  • Page 13: Chapter 2 Installing The Courier

    What You Need You must have these before you start: An IBM-Compatible Computer Your computer must have an ISA or EISA expansion bus and an available expansion slot. Check your computer’s user’s manual to be sure. An Analog Telephone Line The Courier requires a standard, analog telephone line.

  • Page 14: Package Contents

    Package Contents The Courier Phone cable Quick reference card Customer support services card DOS/Windows communications software package A Command Reference manual and this Getting Started manual. Figure 2-1. Contents of the Courier Package. Important! The Courier emulates a serial interface card with a 16550 UART. Like serial interface cards, it must be assigned a unique communications (COM) port number and a unique interrupt request (IRQ) number.
  • Page 15 computer. If other adapter cards are set to use the same COM port or IRQ, conflicts may occur that could result in data loss or lock ups. First, determine whether your computer has a Plug and Play ISA bus. Check your computer’s documentation to be sure. Keep these points about Plug and Play in mind: Your computer’s Basic Input/Output System (BIOS) must support Plug and Play, and...

  • Page 16: Plug And Play Setup

    Plug and Play Setup The Courier is Plug and Play capable, but is shipped with settings for COM2 and IRQ3. To prepare the Courier for installation in a computer with a Plug and Play operating system, locate the jumpers at the bottom corner of the card. Figure 2-2.

  • Page 17: Standard Setup

    Standard Setup If your computer can run Windows applications, follow the steps below to determine how to set up the Courier. If your computer can’t run Windows applications, see Chapter 3, Communicating with the Courier. Before attempting to insert the Courier card in your computer, power ON your computer and start Windows.
  • Page 18 Write down the COM port and IRQ that ComTest recommends, and then select Next >. _______ _______ If ComTest gives you the choice, select Write to SYSTEM.INI and then select Next >, and then Finish. Eject the QuickLink II diskette, exit Windows, and then power OFF your computer.
  • Page 19 To change the IRQ setting, place the jumper over the pins that correspond to the IRQ for the Courier: 3, 4, 5, 7, or 9. Figure 2-5. Setting the IRQ Jumpers. To change the COM port setting, (1, 2, 3, or 4), position the jumpers in one of the following ways: COM1 COM2...

  • Page 20: Setting The Dip Switches

    Setting the DIP Switches The DIP (Dual In-line Package) switches are located on the bracket of the Courier. The default settings are suitable for most applications, but review this section to be sure they suit yours. Table 2-1. DIP Switch Settings. Factory Setting Switch...
  • Page 21 Factory Setting Switch Setting IMPORTANT: When you power ON or reset the Courier, the DIP switch settings override the settings you may have made previously using AT commands. If you change the DIP switch settings while the Courier is powered ON, you can avoid powering the Courier off to make the new settings take effect.

  • Page 22: Installing The Courier

    Installing the Courier NOTE: The illustrations in this section may not match the appearance of your computer. For more detail, refer to your computer’s user’s manual. Switch off the computer’s power and unplug the computer’s power cord. Remove the screws that hold on the computer’s cover and then slide the cover off.
  • Page 23 Find an empty slot that provides enough room to install the Courier. Remove the screw that holds on the slot cover and then remove the slot cover. Save the screw! Insert the Courier into the slot and press down on the top edge of the Courier until it is seated firmly.

  • Page 24: Connecting The Cables

    Connecting the Cables Connect one end of the phone cable to the wall jack and the other end to the Courier port labeled JACK. If you have a telephone that you’d like to connect to the Courier, plug its cable into the Courier port labeled PHONE. Continue with Chapter 3, Communicating with the Courier.

  • Page 25: Chapter 3 Communicating With The Courier

    Communicating with the Courier The methods of verifying communication with the Courier vary depending on the operating system your computer uses. Windows 95 Windows 3.x Windows NT This chapter provides advice about how to get many popular operating systems to communicate with the Courier. The last section, Testing the Courier, explains how to verify that your Courier and software are working together correctly.
  • Page 26 Start a communications software package (such as HyperTerminal, which is included with Windows 95) and dial the U.S. Robotics BBS at (847) 982-5092. Go to File directories, then 5) U.S. Robotics Courier. Download the MDMUSRCR.INF file. Or, ftp://ftp.usr.com/SYS/PCB/dl05 and get MDMUSRCR.INF. Installing the INF File Go to an MS-DOS Prompt: Microsoft®...
  • Page 27 At the Install New Modem panel, click Next. Windows 95 will auto-detect your Courier and install the appropriate support. Finding Out Which COM Port Windows 95 Assigned (Plug and Play Only) If you set the Courier to Plug and Play when you installed it, you need to know which COM port your system has chosen for the Courier, especially if you plan to use communications software created for Windows 3.x.
  • Page 28 Windows 95 Dial-Up Networking: Internet Access This section explains how to set up the Courier for accessing the Internet using Windows 95 Dial-Up Networking. You can also use Dial-Up Networking for accessing remote LANs. Make sure Dial-Up Networking is installed. Click Start | Settings | Control Panel.
  • Page 29 Customize the TCP/IP Settings. Click Start | Settings | Control Panel. From the Control Panel, double-click on Network. Select TCP/IP -> Dial-Up Adapter | Properties… Click on the DNS Configuration tab. Select Enable DNS. Type in your Host: and Domain: names, which are provided to you by your Internet service provider.
  • Page 30 From the Dial-Up Networking window, put the cursor over your new icon and click the right mouse button. Select Properties from the menu that appears. Click Server Type…, and then deselect Log on to Network, NetBEUI, and IPX/SPX Compatible. Select OK, then OK. Double-click on your new connection icon to connect! Courier V.Everything Internal Modems: Getting Started...

  • Page 31: Windows 3.X

    Windows 3.x First, try testing the Courier by following the steps below. Use any communications software package for this test. For example, Windows includes Terminal, a minimally equipped communications program. Because Terminal supports serial port rates of up to only 19200, Quick Link II Fax is used in this example.
  • Page 32 If you don’t get an OK response, refer to Chapter 16, Troubleshooting, in the Courier Modems Command Reference manual. Dial the U.S. Robotics BBS at (847) 982-5092. For example, ATDT18479825092 <Enter> dials the U.S. Robotics BBS as a long-distance call. NOTE: If you need to dial 9 to get an outside line, dial as in this example: ATDT9,18479825092 <Enter>.

  • Page 33: Windows Nt

    For other Windows software packages, see Chapter 4, Setups for Common Windows Software Packages. For instructions about how to set up your Windows communications software package, call our fax-on-demand service (at 800-762-6163 or 847-676-1598) or our BBS (at 847-982- 5092). Request document 10000 for a list of our technical support documents.
  • Page 34 connected. You should be able to send AT <Enter> and get an OK response. From the Control Panel, double-click Network. The Network Settings window appears. Scroll down the list of Installed Network Software and select Remote Access Service. Click Configure… The Remote Access Setup windows appears. Click Add…...
  • Page 35 Click Cancel to select the Courier from a list. Select US Robotics Courier V.34, and then click OK and exit from Network setup. When you’re prompted to restart NT, click Don’t Restart Now.

  • Page 36: Dos

    Because there is no communication capability built in to DOS, you must install and run a third-party communications software package to operate the Courier. You must choose the COM port, IRQ, and the I/O address within the communications application that you are using. These are the standard I/O address and IRQ settings for each COM port: COM Port...

  • Page 37: Linux

    These are the standard I/O address and IRQ settings for each COM port: COM Port COM1 COM2 COM3 COM4 Nonstandard COM/IRQ settings are done by adding switches (command line parameters) to the COM.SYS (or SIO.SYS) line in CONFIG.SYS. For example, the following line selects COM3 and IRQ5: \OS2\BOOT\COM.SYS /i5/c3 For help with OS/2 Warp installations, download the file...
  • Page 38 These are the standard port names and settings: Outgoing Calls Incoming Calls /dev/cua0 /dev/ttyS0 /dev/cua1 /dev/ttyS1 /dev/cua2 /dev/ttyS2 /dev/cua3 /dev/ttyS3 Use the setserial command to tell Linux about any nonstandard COM/IRQ combinations that you may have set using the Couriers jumpers. Setserial also selects serial port speed and I/O port address.

  • Page 39: Chapter 4 Setups For Common Windows Software Packages

    Setups for Common Windows If you are running one of the following software packages, follow the steps given to configure it for use with the Courier. America Online v2.0 NetManage Chameleon v4.5 pcAnywhere v2.0 for Windows ProComm Plus v2.0 for Windows These instructions are valid as of the printing of this manual and may not apply to future releases of the software packages.
  • Page 40 The following window will appear. Change the Setup Modem String to match the string in the figure below. Select OK, then OK, then OK. NetManage Chameleon 4.5 You should know in advance which Internet service provider (for example, PSINet or NETCOM) you will be using. NetManage provides a number of configuration templates for many popular Internet service providers.
  • Page 41 Click Setup | Communications | Modem. Select U.S. Robotics Courier Dual Standard. Setups for Common Windows Software Packages...

  • Page 42: Pcanywhere 2.0 For Windows

    pcAnywhere 2.0 for Windows From the Smart Setup window, go to the Your Modem area and select USRobotics Courier HST Dual Standard. Select the serial port and the protocol running on the network into which you’ll be dialing, and then select OK. Courier V.Everything Internal Modem: Getting Started...

  • Page 43: Procomm Plus 2.0 For Windows

    ProComm Plus 2.0 for Windows Double-click on the PROCOMM PLUS icon. Select Setup, and then Setup... Select Data Modem/Connection, and then Connection Setup as shown in the following window: Select Install New Modem or Connection. Under AutoDetect, select Start Search. Setups for Common Windows Software Packages...

  • Page 44: Prodigy

    After the search is complete, go to the Modems list and select US Robotics Dual Standard 28800, and then select Prodigy Start Prodigy. From the Prodigy SIGN-ON window, select Comm Options Setup. From the Set Up window, select a Modem Speed of 9600 bps and select the Communications Port that the Courier is using;...

  • Page 45: Trumpet Winsock

    Trumpet Winsock From Windows, double-click the Trumpet Winsock icon. Select Dialler, and then Edit Scripts. Open the LOGIN.CMD file. Change these lines: output AT&F1\13 input 10 OK\n output atdt<phone number to dial> Exit and save the changes you made. From File | Setup, under SLIP Port, enter the COM port number that the Courier is using, its Baud Rate, and check Hardware Handshake.

  • Page 46: Winfax Pro 4.0

    WinFax PRO 4.0 During installation, you are asked the following question: Do you want Setup to test COM ports for a fax device? Select Yes. When the following screen appears, choose as the Model U. S. Robotics, Inc Courier Dual Standard FAX, and then select Continue.

  • Page 47: Standards Compatibility

    Standards Compatibility The Courier uses multiple standard data communications protocols and is also compatible with many nonstandard schemes. NOTE: The International Telecommunication Union (ITU-T) was formerly the International Telegraph and Telephone Consultative Committee (CCITT). Modulation ITU-T V.34 33.6/31.2/28.8/26.4/24/21.6/19.2/16.8/14.4/12 Kbps; 9600/7200/4800 bps asynchronous Trellis Coded Modulation (TCM) V.FC 28.8/26.4/24/21.6/19.2/16.8/14.4 Kbps...
  • Page 48 handshake adjustment to 300 bps Quadrature Amplitude Modulation (QAM). ITU-T V.32bis 14.4/12 Kbps; 9600/7200 Coded Modulation (TCM); 4800 bps asynchronous Quadrature Amplitude Modulation (QAM) ITU-T V.32 9600 (TCM); 4800 bps asynchronous, Quadrature Amplitude Modulation (QAM) ITU-T V.22bis 2400 bps asynchronous, Quadrature Amplitude Modulation (QAM) Bell 212A 1200 bps (also V.22) asynchronous, Differential...

  • Page 49: Additional Specifications

    TIA/EIA-592 Service Class 2.0 Asynchronous Facsimile DCE Control Standard ITU-T V.17 14.4/12 Kbps ITU-T V.29 9600/7200 bps ITU-T V.27ter 4800/2400 bps ITU-T V.21 300 bps Additional Specifications Supported serial port rates Adaptive Speed Leveling (ASL) Communications channel Data format Flow Control Buffers Command Buffer Test Options Failed Call Timeout...
  • Page 50 Answer Tone Timeout Answer Tone Detector Loss of Carrier (Disconnect Timer) Equalization Receive Sensitivity Transmit Level Transmitter Frequency Tolerance Certification Ringer Equivalence Courier V.Everything Internal Modem: Getting Started 60 seconds 2080-2120 Hz 0.7 second default, programmable 0.2-25.5 sec. Adaptive - 43 dBm + 2 dBm - 9 dBm maximum .01% FCC Part 15, Class B Domestic;...

  • Page 51: Appendix B Warranty And Notices

    Appendix B Warranty and Notices Limited Warranty U.S. Robotics Access Corp. warrants to the original consumer or other end user purchaser that this product is free from defects in materials or workmanship for a period of five years from the date of purchase.
  • Page 52 Should you encounter problems in operating this device, first follow the instructions in Chapter 16, Troubleshooting, of the Courier Modems Command Reference manual. The chapter contains solutions to operating problems as well as procedures to follow if there is an apparent Courier malfunction. Service/Support To obtain service under this warranty, contact U.S.

  • Page 53: Notices

    Notices FCC Registration FCC15: CJE-0269 FCC 68: CJEUSA-73130-FA-E Connecting to the Telephone Company’s Lines The telephone company may request the telephone number(s) to which the Courier is connected and the FCC information printed above. If the Courier is malfunctioning, it may affect the telephone lines. In this case, disconnect the Courier until the source of the difficulty is traced.
  • Page 54 IC (Industry Canada) This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the radio interference regulations of Industry Canada (formerly Canadian Department of Communications). Le présent appareil numérique n'émet pas de bruits radio-électriques dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Règlement sur le brouillage radioélectrique édicté...
  • Page 55 For your own protection, make sure that the electrical ground connections of the power utility, telephone lines, and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas. WARNING: Do not attempt to make such connections yourself; contact the appropriate electric inspection authority or electrician.
  • Page 56 33.6 Kbps · 1-4 access Internet · 1-1 remote · 1-2 Adaptive Speed Leveling (ASL) · 1-5, A-3 adminstrator login · 3-9 America Online · 4-1 BIOS · 2-3 Bulletin Board System (BBS) · 1-2 cables, connecting · 2-12 caller ID feature · 1-6 carrier loss redial feature ·...
  • Page 57 high speeds, attaining · 1-4 HyperTerminal · 3-2 IC notices · B-4 Industry Standard Architecture (ISA) · 1-1 INF file for Windows 95 · 3-1 installing the Courier · 2-10 Internet access · 1-1 requirement · 2-2 setting · 2-7 JACK ·...
  • Page 58 TCP/IP · 1-1, 3-4 testing the Courier · 1-6, 3-7 Trumpet Winsock · 4-7 U.S. Robotics BBS · 3-8 contacting the writers · iii UART · 2-2 upgrading the Courier's software · 1-5 V. protocols · A-1 V.34 · 1-4, A-1 V.Everything, defined ·...
