U-Line Echelon CLRCO2075 Installation Manual

Echelon series clear ice maker/refrigerator
Hide thumbs Also See for Echelon CLRCO2075:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
™

Installation Guide

CLRCO2075 —
Clear Ice Maker/Refrigerator
www.U-LineService.com
Phone (414) 354-0300 • FAX (414) 354-7905
Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696
OnlineService@U-Line.com
©2005 U-Line Corporation
02/2005

Advertisement

Table of Contents
loading

Related Manuals for U-Line Echelon CLRCO2075

Summary of Contents for U-Line Echelon CLRCO2075

  • Page 1: Installation Guide

    ™ Installation Guide CLRCO2075 — Clear Ice Maker/Refrigerator www.U-LineService.com Phone (414) 354-0300 • FAX (414) 354-7905 Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696 OnlineService@U-Line.com ©2005 U-Line Corporation 02/2005...

  • Page 2: Table Of Contents

    CLRCO2075 — Clear Ice Maker/Refrigerator Contents Exterior Cleaning ......Cut-Out Dimensions ......

  • Page 3: Inspect And Plan

    CLRCO2075 — Clear Ice Maker/Refrigerator 2 Inspect and Plan You have received a carton containing your CLRCO2075 Clear Ice Maker/Refrigerator with a package inside containing a User Manual, a Product Registration Card and water connection parts. Complete and mail the Product Registration Card or register online at www.U-LineService.com.

  • Page 4: Exterior Cleaning

    3 Prepare Site Your U-Line product has been designed for either free- standing or built-in installation. When built-in, your unit does not require additional air space for top, sides or rear. However, the front grille must NOT be obstructed and clearance is required for water, drain and electrical connections in the rear.

  • Page 5: Product Dimensions

    Figure 3 02/2005 CLRCO2075 — Clear Ice Maker/Refrigerator Reversing the Door (Black and White Units Only) All U-Line units (except Stainless Steel models) may be left- or right-hand opening. The door opening is easily reversed by moving the hinge hardware to the opposite side.

  • Page 6: Other Site Requirements

    CLRCO2075 — Clear Ice Maker/Refrigerator 4. Remove the two door closer inserts from the existing bottom hinge and install as shown on the new bottom hinge (see Figure 8). Hinge Screw Door Closer Inserts Figure 7 Figure 8 5. Remove existing bottom hinge (3 screws) and remount on opposite side TOP.

  • Page 7: Side-By-Side Installation Instructions

    ™ Side-By-Side Installation Instructions For a complete refreshment center, install your CLRCO2075 Clear Ice Maker/Refrigerator beside a U-Line Drawer or Wine Captain Model (see Figure 11 for typical cut-out). Note that each Side-By-Side Installation will be different. • Cut-out width for a side-by-side installation is the total of the widths listed under Cut-Out Dimensions in each unit’s Installation Guide.

  • Page 8: Full Overlay Door Panel

    A full overlay door panel completely covers the doorframe and handle to give a built-in appearance. See your U-Line dealer for the optional Full Overlay Door Panel Kit (P/N U-OL2075B — Black or P/N U-OL2075W — White). Appropriate hardware, Modified Handle, Replacement Hinges and a copy of these instructions will be included in the kit.
  • Page 9 CAUTION Be careful not to drill too deep! Drilling holes too deep may destroy your door panel. 02/2005 CLRCO2075 — Clear Ice Maker/Refrigerator 4. Drill hole for upper door hinge (top of panel) (see Figure 16, Top View). 13/32" 0.177" diameter 3/8"...
  • Page 10 CLRCO2075 — Clear Ice Maker/Refrigerator 5. Remove the top handle and discard. (This handle will be replaced with the Modified Handle included in the Full Overlay Door Panel Kit.) 6. Remove the two screws located on both sides of the lower handle.
  • Page 11 1. Remove the existing hinges from the unit, saving the door closure assembly. 2. Install the new Replacement Top Hinge onto the unit (see Figure 24). 02/2005 CLRCO2075 — Clear Ice Maker/Refrigerator Door Panel Wood Panel Top Hinge Plate (5/8" Longer than Existing Top Hinge Plate) #10 x 5/8"...

  • Page 12: Checking Door Alignment

    CLRCO2075 — Clear Ice Maker/Refrigerator 5 Adjust Door Checking Door Alignment The unit’s door is aligned at the factory before shipment. However, its alignment could have been disturbed during shipment or during door panel installation. IMPORTANT Properly aligned, the door should be 1/8" below the top of the unit’s cabinet, NOT flush with the top (see Figure 26).

  • Page 13: Drain Connection

    Gravity Drain, you may have ordered the CLRCO2075 with a U-Line P60 Drain Pump. See Figures 32, 33 and 34 for typical installations requiring a Drain Pump. If you need to install a P60 Drain Pump into your unit, see Locally-Installed Drain Pump on Page 15.
  • Page 14 Figure 34 IMPORTANT Before installing your U-Line CLRCO2075 with Factory- Installed U-Line P60 Pump, it is extremely important to check and test all hose connections at the drain pump. There is a possibility that hose connections may have loosened during shipment.

  • Page 15: Water Supply Connection

    CLRCO2075 — Clear Ice Maker/Refrigerator In the event of a power outage, restricted drain or pump failure, the failure to use the U-Line P60 drain pump or a pump with the above listed specifications, could result in substantial water leakage and pooling with severe and costly water damage and related consequential damages and harm.

  • Page 16: Electrical Specifications

    CLRCO2075 — Clear Ice Maker/Refrigerator 3. Carefully bend the water supply line into position and connect the line to the solenoid valve (see Figure 39). Avoid kinking the water supply line. Power Cord Figure 39 IMPORTANT Normal operation creates some vibration. A water supply line contacting cabinet wall may cause excessive noise during operation or damage to the line.

  • Page 17: Leveling Information

    (see Figure 42). Figure 42 02/2005 CLRCO2075 — Clear Ice Maker/Refrigerator 2. If the ice maker is not level, adjust the feet on the corners of the unit as necessary (see Figure 43). Figure 43 3.

  • Page 18: Installation Of The Clrco2075

    Relocating the Shelves Both the glass shelves in the refrigerator and the inner door shelves can be moved to accommodate your bottles, cans and containers. Glass Shelves on Right-Hand Hinge Units 1.

  • Page 19: Initial Start-Up

    • Solid • Flashing Note: LED lights only apply to the Ice Maker, and the Refrigerator will continue to work and cool as normal even if LEDs are flashing. Other Settings Other settings for the Clear Ice Maker side of the CLRCO2075 are factory preset.

  • Page 20: Start-Up Troubleshooting

    CLRCO2075 — Clear Ice Maker/Refrigerator Start-Up Troubleshooting Problem Unit does not appear to turn on when switch is set to ON. Solution Remember that the compressor will not operate until the water has been filling for about 3 minutes. Make sure unit is plugged in and outlet has power (circuit breaker has not tripped).

  • Page 21: Service Information

    For more than four decades, U-Line has distinguished itself as the leader in built-in undercounter ice making, refrigeration and wine storage appliances. U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in undercounter icemakers, Combo ®...
