U-Line Echelon CLRCO2075 Features

Custom 1/4" Door Panel: 28-5/32" H x 23-1/32" W (71.5 cm x 58.5 cm)
3/4" Full Overlay Panel: 29-7/8" H x 23-3/4" W (75.9 cm x 60.3 cm)
See Overlay Door Panel Preparation Instructions
23-15/16
(60.6)
34-1/8
(86.7)
FULL
RETRACT
HEIGHT
* WATER DRAIN
35-1/8
* POWER
(89.2)
CORD
FULL
EXTEND
HEIGHT
9-1/8
(23)
* WATER INLET
* ON BACK OF UNIT
E X C L U S I V E F E A T U R E S O F É C H E L O N ™
1. High daily ice production, ice storage, and
refrigerator capacity
BENEFIT: Produces up to 40 pounds of ice per
day and stores up to 15 pounds. Refrigerator section
is a generous 2.5 cubic feet.
2. Optional full overlay door capability (panel kit)
using a 3/4 inch thick panel
BENEFIT: Provides a fully integrated appearance
with surrounding cabinets. Overlay panel is easily
attached to the door.
3. Automatic electronic control module that controls
daily ice production
BENEFIT: Maximizes the daily ice production by
monitoring and automatically making adjustments for
changes in the ambient room and water temperatures.
Provides for a consistently shaped ice cube.
4. Easy to set, adjustable, LED temperature controller
BENEFIT: Digital readout of temperature setting
and actual refrigerator section temperatures. Easy
ability to see and adjust to desired temperature.
5. Three fully encapsulated, contoured, spill proof
shelves
21-3/4
(55.2)
23-5/16
(59)
24
(61)
3-3/8
(8.6)
WATER VALVE
5-1/2
5-7/8
(13.95)
(14.9)
INCHES (CENTIMETERS)
Model CLRCO2075
Clear Ice Maker/Refrigerator
The industry's only built-in, under the counter
combination clear ice maker/refrigerator
which produces up to forty (40) pounds of
clear ice per day and stores fifteen (15) pounds.
7
(17.8)
2-7/8
(7)
WATER DRAIN
BENEFIT: Upscale appearance that contains spills
to one shelf. Easy to clean. Stylized, etched bottom
shelf.
6. Two adjustable, contoured, self contained inner
door "pick-off" shelves
BENEFIT: These highly stylized shelves are
adjustable for the storage of a variety of different
bottle, can, and container sizes and shapes thereby
providing optimum space utilization and flexibility.
The self contained shelves can be removed and used
to transport their contents to other cooking areas in
the home or outside patio.
7. Indented or recessed shelf channels support the
encapsulated shelves
BENEFIT: Provides a sleek, clean appearance to
the interior of the refrigerator section by eliminating
protruding shelf supports. Also provides a more
secure, rigid fit for the encapsulated shelves.
8. Consumer friendly, self diagnosing controller
BENEFIT: In the rare event of a problem, a
flashing LED indicator light explains if there is a need
to call for service.
