Service Manual
2010
2115R
2115WC
2115WCOL
2175/2275DWRR
2175R
2175RF
2175WC
2175WCOL
CLR2160
CLRCO2175
CO2175/CO2275DWR
CO2175F
2175BEV
2275DWRWS
2275DWRWOL
2275ZWC
2275ZWCOL
1115R
1115WC
1175BEV
1175R
1175WC
ADA24R
Entertain with U-Line Elegance
www.u-line.com

Advertisement

Table of Contents
loading

Related Manuals for U-Line 2115R

Summary of Contents for U-Line 2115R

  • Page 1 Service Manual 2010 2115R 2115WC 2115WCOL 2175/2275DWRR 2175R 2175RF 2175WC 2175WCOL CLR2160 CLRCO2175 CO2175/CO2275DWR CO2175F 2175BEV 2275DWRWS 2275DWRWOL 2275ZWC 2275ZWCOL 1115R 1115WC 1175BEV 1175R 1175WC ADA24R Entertain with U-Line Elegance www.u-line.com...

  • Page 2: Section 1 - General Information

    POTENTIAL PROBLEMS WITH HFC-134A Three generations of pride and quality manufacturing and design improvements are built into all U-Line products. The result: U-Line This service manual has been written to cover products leads the market with innovative technology and superior manufactured with HFC-134A.

  • Page 3: Table Of Contents

    SECTION 1 - GENERAL INFORMATION Introduction ..................................1-1 Potential Problems With HFC-134A........................1-1 Safety Precautions ...............................1-4 Safety Alert Definitions ............................1-4 General Precautions ............................1-4 U-Line Corporation Limited Warranty........................1-5 Product Liability Policy..............................1-6 Serial Number Format ..............................1-7 Warranty Claims Procedure............................1-7 Proof of Purchase .................................1-7 Parts Listing..................................1-8 SECTION 2 - TROUBLESHOOTING Customer Call Guide ..............................2-1...
  • Page 4 1115WC ..................................4-82 1175BEV ..................................4-86 ADA24R ..................................4-90 SECTION 5 - WIRING DIAGRAMS CLR2160 ..................................5-1 CLRCO2175 ................................5-1 2115R, 2115WC, 2175R, 2175WC ........................5-2 2275DWRWS/2275ZWC ............................5-2 2175DWRR .................................. 5-3 2175RF ................................... 5-3 CO2175F ..................................5-4 CO2175DWR ................................5-4 1175R/1115R/1175WC/1115WC/1175BEV/ADA24R ..................5-5...

  • Page 5: Safety Precautions

    • Use only genuine U-Line replacement parts. Imitation parts can damage the unit, affect its operation or General Precautions performance and may void the warranty.

  • Page 6: U-Line Corporation Limited Warranty

    (consisting of the compressor, the condenser, the evaporator, the hot gas bypass valve, the dryer and the connecting tubing) in each U-Line product to be free from defects in materials and workmanship for a period of five years from the date of purchase.

  • Page 7: Product Liability Policy

    Line’s evaluation, any claim for damage may be declined. If the unit in question is a U-Line CLR or CLRCO with a drain pump, both the unit and the drain pump (regardless of the manufacturer) must be returned to U-Line Corporation.

  • Page 8: Serial Number Format

    Department at 1-800-779-2547. This will allow you to get a proof of purchase, if needed, before you submit the claim. At U-Line, parts and labor claims are paid separately. Included in 0914997-11-XXXX labor are freon and recovery charges, all other parts are handled by the parts department.

  • Page 9: Parts Listing

    If U-Line requires a defective part to be returned, a warranty.

  • Page 10: Section 2 - Troubleshooting

    • Is the ice maker bin arm down? When the arm is up, the ice maker will not make ice. • Is the door or drawers sealing properly? U-Line’s warranty is 90 days for door adjustments. • Has the ice maker been turned off at the display?
  • Page 11 Section 2 - Troubleshooting CLR2160 Model Only: Concern Response The cubes are wet. • The storage bin that holds the ice is not refrigerated. The cubes in the bin are slowly melting down. The bin will maintain a temperature of 32°F to 34°F. The floor is very warm in front of my unit.

  • Page 12: Refrigeration System Diagnosis Guide

    Section 2 - Troubleshooting REFRIGERATION SYSTEM DIAGNOSIS GUIDE System Suction Suction Compressor Condenser Capillary Evaporator Wattage Pressure Line Discharge Tube Condition Normal Normal Slightly below Very hot Very hot Warm Cold Normal room temperature Overcharge Higher than Very cold may Slightly warm Hot to warm Cool...

  • Page 13: Troubleshooting

    Section 2 - Troubleshooting TROUBLESHOOTING DANGER Never attempt to repair or perform maintenance on the unit until the main electrical power has been disconnected from the unit. Cause Remedy Will not eject ice (water frozen). 1. Control setting too cold. 1.
  • Page 14 Section 2 - Troubleshooting Cause Remedy Low ice production. 1. Control set too cold. 1. Adjust control warmer. 2. Fan motor stalled. 2. Replace fan motor. 3. Ice cubes too large. 3. Lower water fill adjustment. 4. Dirty condenser. 4. Clean condenser. 5.
  • Page 15 Section 2 - Troubleshooting Cause Remedy Water leak (under unit). 1. Water supply line leaking at solenoid valve inlet. 1. Tighten or replace fitting. 2. Water line leaking at solenoid valve outlet. 2. Replace water line and fitting. 3. Water line leaking at fill tube. 3.

  • Page 16: Section 3 - Service And Repair

    Section 3 - Service and Repair OPERATION entering the sequence, keep the COLDER key pressed until you completely release the ON/OFF key for the third time. The display will cycle through a series of numbers to tell which relays are CLR2160 energized.
  • Page 17 Section 3 - Service and Repair ICEMAKER EVAPORATOR HIGH PRESSURE 2276 LOWPRESSURE R4: WATER TRANSITIONAL PRESSURE SUPPLY IN CAPILLARY TUBE R5: WATER CIRCULATION PUMP R4: HOT GAS BYPASS VALVE R1: CONDENSER R3: COMPRESSOR CONDENSER RELAY HOT GAS / FUNCTION COMP CIRC PUMP WATER IN Mode 1:...
  • Page 18 Section 3 - Service and Repair TROUBLESHOOTING (CONTINUED) This can be caused by poor incoming water quality. The CLR2160 is designed to produce clear ice in most water; however, abnormal No ice water conditions may result in the need for further filtering. Check the ice bin temperature.

  • Page 19: Clrco2175

    (3) until the requirement is satisfied. The U-Line Model CLRCO2175 combines the best of Échelon Thus, upon start-up, the user will see one slab of ice dropped in refrigeration and clear ice-making capabilities into a single unit.
  • Page 20 Section 3 - Service and Repair ULIN_0328_A Figure 2. CLRCO2175 Mode 1: Ice Making and Refrigeration...
  • Page 21 Section 3 - Service and Repair ULIN_0329_A Figure 3. CLRCO2175 Mode 2: Ice Making and No Refrigeration (or Ref Defrost)
  • Page 22 Section 3 - Service and Repair ULIN_0330_A Figure 4. CLRCO2175 Mode 3: Refrigeration and No Ice Making...
  • Page 23 Section 3 - Service and Repair ULIN_0331_A Figure 5. CLRCO2175 Mode 4: Ice harvest (No Refrigeration Possible)
  • Page 24 Section 3 - Service and Repair ULIN_0332_A Figure 6. CLRCO2175 Mode 5: Off...
  • Page 25 Section 3 - Service and Repair Figure 7. CLRCO2175 Mode 6: Water Fill - No Refrigeration Possible (Normal Start-Up) 3-10...
  • Page 26 Section 3 - Service and Repair Figure 8. CLRCO2175 Mode 7: Cleaning (No Refrigeration Possible) 3-11...
  • Page 27 Section 3 - Service and Repair THERMISTOR OUTAGE E1, E2, E7, E8, E9 Bad thermistor errors. Replace thermistor. Check for thermistor errors by accessing In the event that the condenser thermistor (T4) fails, the unit will “View thermistor # status (2, 19, 20, or 21).” If stop all functions and display “ER”...
  • Page 28 Section 3 - Service and Repair Too much ice Display is showing something other than “SP (38),” “ER” or “CL.” Ensure there is Permagum around the thermistor hole. If there is, proceed to the next step. Push one of the keys to see if the display is reset. The control board is equipped with adjustment to adjust the level Turn unit on and off via the display pad.

  • Page 29: 2175R/2115R/2175Wc/2115Wc/2175Bev/2175Dwrr/2275Dwrws/2275Zwc

    The liquid then flows to the dryer where it is strained and filtered. From the dryer, the refrigerant flows through the capillary tube which meters the liquid refrigerant to the evaporator. The COMPRESSOR CONDENSER DRYER EVAPORATOR CAPILLARY TUBE ULIN_0280_A Figure 9. 2175R/2115R/2175WC/2175BEV/2275DWRR/2175DWRR 3-14...
  • Page 30 Section 3 - Service and Repair COMPRESSOR COMPRESSOR CONDENSER COMPARTMENT CONDENSER COMPARTMENT THERMISTOR THERMISTOR SOLENOID VALVE SOLENOID VALVE DRYER DRYER SOLENOID VALVE SOLENOID VALVE EVAPORATOR EVAPORATOR CAPILLARY TUBE CAPILLARY TUBE BOTTOM BOTTOM COMPARTMENT COMPARTMENT THERMISTOR THERMISTOR DRYER DRYER EVAPORATOR EVAPORATOR CAPILLARY TUBE CAPILLARY TUBE DWR052...

  • Page 31: Refrigerator Too Warm

    Section 3 - Service and Repair suspected of not operating correctly, you can run through this During the forced defrost no heating will occur. This is just a sequence to ensure each component is turning on and off through prolonged off cycle. the board correctly.

  • Page 32: Co2175F/2175Rf/Co2175Dwr

    Section 3 - Service and Repair CO2175F/2175RF/CO2175DWR • Drain heater off (CO2175F/2175RF only) GENERAL Defrost Mode: U-Line Frost Free Refrigeration System • Bypass solenoid valve open • Refrigerant flows through bypass system Cooling Mode: • Vapor flows from condenser to evaporator without a phase •...
  • Page 33 Section 3 - Service and Repair Air flow in at evaporator blade Air passes though fin tube evaporator Air flow out at evaporator outlet Condensate drains down trough under evaporator, into drain pan, and into condensate pan through drain hose. The drain trough is warmed during defrost by contact with evaporator fins and drain heater attached to the drain pan.
  • Page 34 Section 3 - Service and Repair ICE MAKER • Following the water fill relay 7 remains energized for the balance of the 10 minutes that it needs to remain on. WARNING Storage mode • The bin arm is in the UP position, either held in place by the DO NOT cycle ice maker by hand.
  • Page 35 Section 3 - Service and Repair ULIN_0348a_A Figure 13. CO2175F Harvest-1 Cycle (First 30 Seconds Figure 14. CO2175F Harvest-2 Cycle (After 30 Seconds) 3-20...
  • Page 36 Section 3 - Service and Repair Figure 15. CO2175F Harvest-3 Cycle (Post Harvest) Figure 16. CO2175F Water Fill Cycle 3-21...
  • Page 37 Section 3 - Service and Repair ULIN_0350a_A Figure 17. CO2175F Freeze Cycle Figure 18. CO2175/2275DWR Harvest-1 Cycle (First 30 Seconds) 3-22...
  • Page 38 Section 3 - Service and Repair ULIN_0345_A Figure 19. CO2175/2275DWR Harvest-2 Cycle (After 30 Seconds) Figure 20. CO2175/2275DWR Harvest-3 Cycle (Post Harvest) 3-23...
  • Page 39 Section 3 - Service and Repair ULIN_0346_A Figure 21. CO2175/2275DWR Water Fill Cycle ULIN_0347_A Figure 22. CO2175/2275DWR Freeze Fill Cycle 3-24...
  • Page 40 Section 3 - Service and Repair THERMISTOR OUTAGE E1, E2, E7, E8, E9 Bad thermistor errors. Replace thermistor. Check for thermistor errors by accessing If the refrigerator thermistor (T1) fails, the unit will continue to “View thermistor # status (2, 19, 20, or 21).” If operate based on the freezer temperature.
  • Page 41 Section 3 - Service and Repair Too much ice Display is showing a random snaking of characters or a degree symbol is flashing. Ensure the bin arm is correctly moving during an ice production cycle and that it can touch the top of the ice. If not, the arm may The unit is in a special showroom mode.

  • Page 42: 1175R/1115R/1175Wc/1115Wc/1175Bev/Ada24R

    Section 3 - Service and Repair 1175R/1115R The reduction of pressure on the liquid refrigerant causes it to boil or vaporize until it reaches saturation temperature. As the low 1175WC/1115WC temperature refrigerant passes through the evaporator coil, it 1175BEV/ADA24R continues to absorb a lot of heat, causing the boiling action to GENERAL continue until the refrigerant is completely vaporized.
  • Page 43 Section 3 - Service and Repair THERMISTOR OUTAGE Noise If the refrigerator thermistor (T1) fails, the unit will continue to Some noise is normal, such as a hum from the fans/compressor. operate based on a preset time interval of 10 minutes on and 30 Display is showing something other than “SP (38)”...

  • Page 44: Operating Environmental/Climate Control Requirements

    Center, CODWR & Dual Zone(Z) precautions when touching a bare circuit board. Wear an anti- Many U-Line models are designed to operate in harsh outdoor/ static wriststrap and ground it to an electrical ground or marine environments. Special considerations include the following: grounded water pipe.
  • Page 45 Section 3 - Service and Repair ADJUSTING THE SET-POINT 2. Press the WARMER or COOLER icon to scroll to the desired - 2275DWRWS ONLY range (RW, WW, SW, BV). 1. Press and release the WARMER icon. The top of the F in °F of 3.
  • Page 46 Section 3 - Service and Repair VIEWING ACTUAL TEMPERATURE button three times. The display will show “0” and the board will - 2275DWRWS ONLY beep once. When in this mode the WARMER and COLDER keys will act as up and down arrows to select the desired option. The To view the temperature in the top and bottom drawer (T1 and LIGHT key is the ENTER key and will enter a function.

  • Page 47: Échelon Service Menu

    6. Defrost length adjustment—up to 99 minutes The length of the defrost can be adjusted up to 99 minutes long. 3. Install a jumper on J3. The jumper can be obtained from U-Line P/ The other defrost parameters still apply. Lengthening a defrost N 68080.

  • Page 48: Error Codes

    Section 3 - Service and Repair This allows calibration of the sensor to cabinet for abnormal 18. Adjust thermistor 4 offset operations. By adjusting this number colder you can change the This allows calibration of the sensor to cabinet for abnormal average cabinet temperature to a colder value.
  • Page 49 BP_VALVE Model Number Relay 1 Relay 2 Relay 3 Relay 4 Relay 5 Relay 6 Relay 7 Compressor/ 2175R 61/75 Light Compressor/ 2115R 71/73 Light Compressor/ 2115WC 72/74 Light Compressor/ 2175WC 62/76 Light 2175DWRR Compressor/ Light 1 Pan Heat Mull Heat...
  • Page 50 Section 3 - Service and Repair Model Thermistor 1 Thermistor 2 Thermistor 3 Thermistor 4 Door Switch 1 Door Switch 2 2175R EVAP 2115R EVAP 2175WC EVAP 2115WC EVAP 2175DWRR EVAP Ambient Bottom Drawer Top Drawer CO2175F Drain Pan 2175RF...

  • Page 51: Échelon Service Quick Reference Card

    Section 3 - Service and Repair Échelon Service Quick Reference Card 3-36...

  • Page 52: Échelon Electronic Control Quick Reference Guide

    Section 3 - Service and Repair Échelon Electronic Control Quick Reference Guide 3-37...

  • Page 53: Origins Electronic Control

    Section 3 - Service and Repair ORIGINS ELECTRONIC CONTROL VIEWING ACTUAL TEMPERATURE In viewing temperature in these modes any offsets are taken into Origins Keypad Options account. This means that if you place a thermistor in a known temperature, let’s say ice water, it may not read the 32°F that you would assume.

  • Page 54: Origins Service Menu

    Section 3 - Service and Repair turn back on. If desired, you can manually cancel this mode by 3. Error log touching the LIGHT button. Release and the unit will automatically A list of the errors in the order they occurred will scroll once start normal operation.

  • Page 55: Error Codes

    Section 3 - Service and Repair Error Codes E4 Compressor had 100% runtime between two defrost cycles. E5 Thermistor 1 out of range + 10°F for more than 12 hours. E1 Thermistor 1 is open. E6 Thermistor 1 out of range -10°F for more than 12 hours. E2 Thermistor 1 is shorted.

  • Page 56: Refrigeration System Diagnosis Guide

    (cool) (cool) (cool) DEFROST INFORMATION - ALL MODELS Hours Between Defrost Time Model Length/min Stop Point (Runtime) (Adjustable) 2175R 42° 2115R 42° 2175WC 45° 2115WC 45° 2175BEV 42° 2175/2275DWRR 42° CO2175F 18*/45 42° 2175RF 18*/45 42°...

  • Page 57: Specifications

    THERMISTORS To ensure the windings are not shorted check the S and R to The U-Line Model CLR2160 uses two thermistors. The ground. thermistors are used in conjunction with the control panel to monitor the unit’s functions and troubleshooting capabilities. A...

  • Page 58: Clrco2175

    Section 3 - Service and Repair CLRCO2175 COMPRESSOR/COIL SPECIFICATIONS FF7.5HBK Voltage 115.0 DANGER DANGER Frequency 60.0 Electrocution can cause death or serious injury. Burns from 25.5 hot or cold surfaces can cause serious injury. Take precautions when servicing this unit. Start Winding 11.2 •...
  • Page 59 Also check S to R and you should get the sum of the run and start windings. To ensure the windings are not shorted, check the S and R to ground. OVERLOAD PROTECTOR STARTING RELAY RELAY COVER ULIN_0576_AW Figure 28. 2175R/2115R/2175WC/2115WC/2175BEV/ 2175WRR/2175DWRWS EMY70HER Voltage 115-127 3-44...

  • Page 60: Co2175F/2175Rf/Co2175Dwr

    Section 3 - Service and Repair CO2175F/2175RF/CO2175DWR COMPRESSOR/COIL SPECIFICATIONS EMU45HSC EMY70HER DANGER DANGER 5408 70081 Electrocution can cause death or serious injury. Burns from hot Voltage 115.0 115-127 or cold surfaces can cause serious injury. Take precautions when Frequency 60.0 60.0 servicing this unit.

  • Page 61: 1175R/1115R/1175Wc/1115Wc/1175Bev/Ada24R

    12uF IMPORTANT The U-Line ADA24R models employ both a 12VDC evaporator fan assembly and condenser fan assembly. The motors are powered by a 12VDC power supply located in the base of the unit. These fans are designed to operate in conjunction with the compressor and should be running whenever power is applied to the compressor electricals.

  • Page 62: Adjustments And Repair

    Section 3 - Service and Repair ADJUSTMENTS AND REPAIR Leveling IMPORTANT IMPORTANT It is extremely important that the unit is level for maximum production. If it is not: Doors or drawers will not work properly. In ice maker units, uneven sized cubes will be formed. Ice production will reduce and water spilling into the storage area can occur causing the ice in the bin to melt prematurely (Figure 32).
  • Page 63 Section 3 - Service and Repair NOTE: If door is adjusted correctly, but panel is not square with the adjacent cabinets, slight adjustments can be made by drilling the holes in the vinyl-coated steel panel slightly oversized (Figure 37). Drill 5/32" x 3/8" Deep for use with #10 x 5/8"...

  • Page 64: Door Alignment - Origins Models

    Section 3 - Service and Repair ADJUSTING DOOR ALIGNMENT 1. Loosen (do not remove) top and bottom hinge screws (Figure 42 and Figure 43). Door Closer Inserts Boss ULIN_0298a_A Figure 41 8. Mount the door, install top hinge pivot pin. Door Alignment - Origins Models The unit’s door is aligned at the factory before shipment.
  • Page 65 Section 3 - Service and Repair CHECKING DRAWER ALIGNMENT 3. Remove the mounting screws (Figure 45 and Figure 46). The unit’s drawers are aligned at the factory before shipment. i t n However, their alignment could have been disturbed during shipment or during overlay panel installation.
  • Page 66 Section 3 - Service and Repair SIDE-TO-SIDE ADJUSTMENT l l i r See Figure 46. The drawer will need a side-to-side adjustment if, i t n when viewed from the top, the drawer front is not square with the sides of the cabinet. This is caused by one of the slides being mounted too far forward on the unit’s liner.
  • Page 67 Section 3 - Service and Repair TOP-TO-BOTTOM (AND LEFT-TO-RIGHT) ADJUSTMENT i l A i l S i l A - t f ULIN_0320_A Figure 50 t i n 4. Repeat the procedure for the other slide. ULIN_0323_A t i n Severe Adjustment Figure 52 NOTE: The slides have extra mounting holes that may be used.
  • Page 68 Section 3 - Service and Repair l l i r i t n i l S ULIN_0325_A Figure 54 NOTE: Front location holes are shown. Corresponding rear holes will also need to be marked. 4. Drill all the new holes with a #30 drill bit. 5.

  • Page 69: Ice Cube Thickness Adjustment

    Section 3 - Service and Repair Ice Cube Thickness Adjustment Sample INTERVAL - AS REQUIRED area Ice thickness adjustments are made using the control panel as follows: 1. To enter the thickness adjustment mode: a. Touch and hold the UP ARROW button. b.

  • Page 70: Parts Replacement

    Section 3 - Service and Repair Parts Replacement 7. Plug in the fan connection. 8. Reinstall fan bracket to liner, making sure the fan wires are tucked NOTE: Echelon models do not require removal of the ice maker or freezer housing to access the fan motor, drain or evaporator.
  • Page 71 Section 3 - Service and Repair REPLACING EVAPORATOR FAN MOTOR 9. Reinstall fan bracket to liner, making sure the fan wires are tucked - CO2175DWR behind the fan bracket. 10. Reinstall unit and test. 1. Disconnect unit from power source. 2.
  • Page 72 Section 3 - Service and Repair REPLACING ICE MAKER 7. Remove three screws from wall of freezer housing. 8. Remove ice maker assembly. 1. Unplug unit. 9. Install new ice maker assembly. 2. Disconnect ice maker wire harness at plug (Figure 60).
  • Page 73 Section 3 - Service and Repair REPLACING MOLD AND HEATER 4. Remove one screw and detach limit switch from mold. - CO2175F/CO2175DWR 5. Detach heater leads. 1. Remove ice maker assembly. Refer to Replacing Ice Maker 6. Remove two screws and mold from support housing. Assembly.

  • Page 74: Plumbing - Clr2160 And Clrco2175

    The unit can be installed using a gravity drain, a factory-installed drain Waste pump (U-Line P60) or a locally installed drain pump. Drain lines must ULIN_0570_A have a 5/8" inside diameter. The floor drain must be large enough to Figure 63 accommodate drainage from all attached drains.
  • Page 75 Figure 66 IMPORTANT IMPORTANT Before installing your U-Line unit with factory- installed U- Line P60 pump, it is extremely important to check and test all hose connections at the drain pump. There is a possibility that hose connections may have loosened during shipment.

  • Page 76: Tools Required

    9. Unplug unit power cord from electrical outlet. ** Depending on your model, your unit may have been packaged with these items. If you need to order these items, please contact U-Line and 10. Reinstall back panel. order Part # U-CLRDRAINKIT.
  • Page 77 ULIN_S_0168_A Figure 70 Figure 72 3. Your U-Line icemaker requires a drain connection. This unit can be 5. Determine the location of your drain and begin to route the drain purchased with or without a factory-installed drain pump. If a tubing in that direction.
  • Page 78 Section 3 - Service and Repair 10. Once pushed completely into the opening finish routing the drain tubing to the desired location. Common installations use a floor Standpipe P60 Pump Required drain, standpipe, garbage disposal, or Y-branch tailpiece-type drain connection (Figure 73 - 76). After the installation is complete, check the unit to ensure it is level both side to side and front to Air gap must back.

  • Page 79: Water Supply Connection

    Section 3 - Service and Repair WATER SUPPLY CONNECTION 2. Locate the U-Line supplied garden hose fitting. Ensure the end of the copper tubing has been cut straight and free of burrs. Slide the When connecting the water supply, follow these guidelines: compression nut and ferrule onto the copper tubing as shown (Figure 78).

  • Page 80: Section 4 - Parts

    We require that some parts be returned to overflow from ice maker mold, damage the unit, and can void the to U-line, so we may return them to our vendor. It will be noted on warranty.

  • Page 81: Clr2160

    Section 4 - Parts CLR2160 (1 of 2)
  • Page 82 Section 4 - Parts CLR2160 (1 of 2) Item Part No. Part No. Part No. Description Black White Stainless Steel 80-17071-01 80-17071-02 80-17071-03 Door Assembly, RH 80-17071-13 Door Assembly, LH 23025 23025 23025 Nameplate 26071-01-S 26071-02-S Handle Assembly 42173-BLK 42173-NAT Hole plug (included with handle assembly) 12094-04-S 12094-06-S...
  • Page 83 Section 4 - Parts CLR2160 (2 of 2)
  • Page 84 Dryer (included with 2269-S) 2819 2819 2819 Process tube (included with 2269-S) 2269-S 2269-S 2269-S Condenser Assembly 2892-02 2892-02 2892-02 Wire Assembly Pump(to power cord) 41978 41978 41978 U-Line Cleaner (6 applications per order) Shown 14159-01 Commercial handle (SS Accessory only) Shown...
  • Page 85 Section 4 - Parts CLRCO2175 (1 of 4)
  • Page 86 Grommet (included with 70078-S) 71011 71011 71011 Overload (included with 70078-S) 71012 71012 71012 Relay (included with 70078-S) 70078-CAP 70078-CAP 70078-CAP Cover (included with 70078-S) 41978 41978 41978 U-Line Cleaner (6 applications per order) Shown 14159-01 Commercial handle (SS accessory only) Shown...
  • Page 87 Section 4 - Parts CLRCO2175 (2 of 4)
  • Page 88 Section 4 - Parts CLRCO2175 (2 of 4) Item Part No. Part No. Part No. Description Black White Stainless Steel 5300 5300 5300 Fan motor, condenser 5303 5303 5303 Fan blade, condenser 41826 41826 41826 Fitting, water line, 90° 42114 42114 42114 Screw, water valve...
  • Page 89 Section 4 - Parts CLRCO2175 (3 of 4) 4-10...
  • Page 90 Section 4 - Parts CLRCO2175 (3 of 4) Item Part No. Part No. Part No. Description Black White Stainless Steel 68092 68092 68092 Thermistor, white 68072-S 68072-S 68072-S Circuit Board Assembly 68080 68080 68080 Switch jumper (included with 68072-S) 41992 41992 41992 Support, circuit board (included with 68072-S)

  • Page 91: Clrco2175

    Section 4 - Parts CLRCO2175 (4 OF 4) 4-12...
  • Page 92 Section 4 - Parts CLRCO2175 (4 of 4) Item Part No. Part No. Part No. Description Black White Stainless Steel 80-37005-00-S 80-37005-00-S 80-37005-00-S Valve Manifold Assembly (includes dryer and process tube) 73004 73004 73004 Bypass Valve (included with 80-37005-00-S) 2819 2819 2819 Process tube (included with 80-37005-00-S)

  • Page 93: 2175R

    Section 4 - Parts 2175R (1 of 2) 4-14...
  • Page 94 Section 4 - Parts 2175R (1 of 2) Item Part No. Part No. Part No. Description Black White Stainless Steel 80-17060-01 80-17060-02 80-17075-01 Door Assembly, RH 80-17075-02 Door Assembly, LH 23025 23025 23025 Nameplate 26070-01-S 26070-02-S Handle Assembly 42173-BLK 42173-NAT Hole plug (included with handle assembly) 12094-01 12094-03...
  • Page 95 Section 4 - Parts 2175R (2 of 2) 4-16...
  • Page 96 Section 4 - Parts 2175R (2 of 2) Item Part No. Part No. Part No. Description Black White Stainless Steel 2303-S 2303-S 2303-S Condenser Assembly** 2800 2800 2800 Process tube 2694 2694 2694 Dryer 31434-1 31434-1 31434-1 Rivet, thermistor cover 26091 26091 26091...

  • Page 97: 2115R

    Section 4 - Parts 2115R (1 of 2) 4-18...
  • Page 98 Section 4 - Parts 2115R (1 of 2) Item Part No. Part No. Part No. Description Black White Stainless Steel 80-17064-01 80-17064-02 80-17080-01 Door Assembly, RH 80-17080-02 Door Assembly, LH 23025 23025 23025 Nameplate 26071-01-S 26071-02-S Handle Assembly 42173-BLK 42173-NAT...
  • Page 99 Section 4 - Parts 2115R (2 of 2) 4-20...
  • Page 100 Section 4 - Parts 2115R (2 of 2) Item Part No. Part No. Part No. Description Black White Stainless Steel 68092 68092 68092 Thermistor, quick connect white 68072-S 68072-S 68072-S Circuit Board Assembly 68080 68080 68080 Switch jumper (included with 68072-S)

  • Page 101: Wc/2175Wcol

    Section 4 - Parts 2175WC/2175WCOL/2175WCOL2 (1 OF 2) 1, 2 4-22...
  • Page 102 Section 4 - Parts 2175WC/2175WCOL/2175WCOL2 (1 OF 2) Item Part No. Part No. Part No. Description Black White Stainless Steel 80-17057-01 80-17057-03 Door Assembly, RH 80-17057-13 Door Assembly, LH 80-17081-02 Overlay Door (Model U-2175WCOL-00) 80-17104-11 Overlay Door (Model U-2175WCOL2-00) 26088-4-BLK Handle Assembly 42173-BLK Hole plug (included with handle assembly)
  • Page 103 Section 4 - Parts 2175WC/2175WCOL /2175WCOL2(2 OF 2) 4-24...
  • Page 104 Section 4 - Parts 2175WC/2175WCOL /2175WCOL2(2 of 2) Item Part No. Part No. Description Black Stainless Steel 68092 68092 Thermistor, quick connect white 68072-S 68072-S Circuit Board Assembly 68080 68080 Switch jumper (included with 68072-S) 41992 41992 Support, circuit board (included with 68072-S) 41993 41993 Support, circuit board (included with 68072-S)
  • Page 105 Section 4 - Parts 2115WC/2115WCOL/2115WCOL2 (1OF2) 4-26...
  • Page 106 Section 4 - Parts 2115WC/2115WCOL/2115WCOL2 (1 of 2) Item Part No. Part No. Description Black Stainless Steel 80-17065-01 80-17065-03 Door Assembly, RH 80-17065-13 Door Assembly, LH 80-17081-01 Overlay Door (Model U-2115WCOL-00) 80-17104-12 Overlay Door (Model U-2115WCOL2-00) 26088-6-BLK Handle Assembly 42173-BLK Hole plug (included with handle assembly) 31493-8-BLK 31496-8-GRY...
  • Page 107 Section 4 - Parts 2115WC/2115WCOL/2115WCOL2 (2 OF 2) 4-28...
  • Page 108 Section 4 - Parts 2115WC/2115WCOL/2115WCOL2 (2 of 2) Item Part No. Part No. Description Black Stainless Steel 68092 68092 Thermistor, quick connect white 68072-S 68072-S Circuit Board Assembly 68080 68080 Switch jumper (included with 68072-S) 41992 41992 Support, circuit board (included with 68072-S) 41993 41993 Support, circuit board (included with 68072-S)
  • Page 109 Section 4 - Parts 2175BEV/2175BEVOL/2175BEVOL2 (1 OF 2) 4816 4816 Screw (included with 23027-03) 4-30...
  • Page 110 Section 4 - Parts 2175BEV/2175BEVOL/2175BEVOL2 (1 of 2) Item Part No. Part No. Description Overlay Door Stainless Steel 80-17094-03 Door Assembly, RH 80-17094-13 Door Assembly, LH 80-17094-01 Overlay Door (Model U-2175BEVOL-00) 80-17104-11 Overlay Door (Model U-2175BEVOL2-00) 41319 41319 Foot, leveler 2891-01 2891-01 Light Socket Assembly...
  • Page 111 Section 4 - Parts 2175BEV/2175BEVOL/2175BEVOL2 (2 OF 2) 4-32...
  • Page 112 Section 4 - Parts 2175BEV/2175BEVOL/2175BEVOL2 (2 of 2) Item Part No. Part No. Description Black Stainless Steel 68092 68092 Thermistor, quick connect white 68072-S 68072-S Circuit Board Assembly 68080 68080 Switch jumper (included with 68072-S) 41992 41992 Support, circuit board (included with 68072-S) 41993 41993 Support, circuit board (included with 68072-S)

  • Page 113: Dwrr

    Section 4 - Parts 2175DWRR/2275DWRR (1 OF 2) 4-34...
  • Page 114 Section 4 - Parts 2175DWRR/2275DWRR (1 of 2) Item Part No. Part No. Description Black Stainless Steel 2175DWR-TOP-BLK Drawer Front Assembly 41604 Screw, handle 26070-05-S Handle, overlay 12094-07 12094-08 Gasket, door 26094 26094 Housing, display 14138-02 14138-02 Drawer, no front, top 23025 23025 Nameplate...
  • Page 115 Section 4 - Parts 2175DWRR/2275DWRR (2 of 2) 4-36...
  • Page 116 Section 4 - Parts 2175DWRR/2275DWRR (2 of 2) Item Part No. Part No. Description Black Stainless Steel 68092 68092 Thermistor, quick connect white 68072-S 68072-S Circuit Board Assembly 68080 68080 Switch jumper (included with 68072-S) 41992 41992 Support, circuit board (included with 68072-S) 41993 41993 Support, circuit board (included with 68072-S)

  • Page 117: 2275Dwrws/2275Dwrwol

    Section 4 - Parts 2275DWRWS/2275DWRWOL (1 OF 2) 4-38...
  • Page 118 Section 4 - Parts 2275DWRWS/2275DWRWOL (1 of 2) Item Part No. Description Item Part No. Description 18066-Vinyl Wine Rack Assembly 80-29010-03 Grille Assembly, SS 12094-08-GREY Gasket, drawer, grey 20033-ZP Screw (included with grille) 12094-07-BLK Gasket, drawer, black 70077-S Compressor Assembly 14016 Front, top drawer 2800...
  • Page 119 Section 4 - Parts 2275DWRWS/2275DWRWOL (2 OF 2) 4-40...
  • Page 120 Section 4 - Parts 2275DWRWS/2275DWRWOL (2 of 2) Item Part No. Description Item Part No. Description 2953 Main harness to plug 2694 Dryer (included with 2303-S) 2959 Dual Harness 2800 Process tube (included with 2303-S 41992 Support, circuit board 2303-S Condenser Assembly (included with 68064) 11508-02...

  • Page 121: Co2175F

    Section 4 - Parts CO2175F (1 of 4) 4-42...
  • Page 122 Section 4 - Parts CO2175F (1 of 4) Item Part No. Part No. Part No. Description Black White Stainless Steel 80-17060-01 80-17060-02 80-17075-01 Door Assembly, RH 80-17060-01 80-17060-02 80-17075-02 Door Assembly, LH 23025 23025 23025 Nameplate 26070-01-S 26070-02-S Handle Assembly 42173-BLK 42173-NAT Hole plug (included with handle assembly)
  • Page 123 Section 4 - Parts CO2175F (2 0f 4) 1, 2 26 26 27 27 13 13 43 43 25 25 10 10 31 31 29 29 34 34 28 28 30 30 44 44 32 32 33 33 4-44...
  • Page 124 Section 4 - Parts CO2175F (2 of 4) Item Part No. Part No. Part No. Description Black White Stainless Steel 5408-CAP 5408-CAP 5408-CAP Cover 5263-S 5263-S 5263-S Fan motor, condenser 5188 5188 5188 Fan blade, condenser 41787 41787 41787 Nut (included with 5263-S) 31550-1-S 31550-1-S 31550-1-S...
  • Page 125 Section 4 - Parts CO2175F (3 of 4) 4-46...
  • Page 126 Section 4 - Parts CO2175F (3 of 4) Item Part No. Part No. Part No. Description Black White Stainless Steel 68092 68092 68092 Thermistor, quick connect white 68072-S 68072-S 68072-S Circuit Board Assembly 68080 68080 68080 Switch jumper (included with 68072-S) 41992 41992 41992...
  • Page 127 Section 4 - Parts CO2175F (4 of 4) 4-48...
  • Page 128 Section 4 - Parts CO2175F (4 of 4) Item Part No. Description 80-39010-00 Ice Maker Assembly 150-CO2175F Faceplate Assembly 627000 Cover 628210*† Gear 80-39015-00* Motor 627163*† Spring 625836*† Valve switch plate 31403* Switch spacer 627302*† 627680* Insulator 2506* Hold switch 2918 Wire harness 2506*...

  • Page 129: 2175Rf

    Section 4 - Parts 2175RF (1 of 3) 4-50...
  • Page 130 Section 4 - Parts 2175RF (1 of 3) Item Part No. Part No. Part No. Description Black White Stainless Steel 80-17060-01 80-17060-02 80-17075-01 Door Assembly, RH 80-17060-01 80-17060-02 80-17075-02 Door Assembly, LH 23025 23025 23025 Nameplate 26070-01-S 26070-02-S Handle Assembly 42173-BLK 42173-NAT Hole plug (included with handle assembly)
  • Page 131 Section 4 - Parts 2175RF (2 of 3) 4-52...
  • Page 132 Section 4 - Parts 2175RF (2 of 3) Item Part No. Part No. Part No. Description Black White Stainless Steel 5408-CAP 5408-CAP 5408-CAP Cover 5263-S 5263-S 5263-S Fan motor, condenser 5188 5188 5188 Fan blade, condenser 41787 41787 41787 Nut (included with 5263-S) 31550-1-S 31550-1-S 31550-1-S...
  • Page 133 Section 4 - Parts 2175RF (3 of 3) 4-54...
  • Page 134 Section 4 - Parts 2175RF (3 of 3) Item Part No. Part No. Part No. Description Black White Stainless Steel 68092 68092 68092 Thermistor, quick connect white 68072-S 68072-S 68072-S Circuit Board Assembly 68080 68080 68080 Switch jumper (included with 68072-S) 41992 41992 41992...

  • Page 135: Co2175Dwr

    Section 4 - Parts CO2175DWR/CO2275DWR (1 of 4) 4-56...
  • Page 136 Section 4 - Parts CO2175DWR/CO2275DWR (1 of 4) Item Part No. Part No. Description Black Stainless Steel 80-29010-01 80-29010-03 Grille 20033-BLK 20033-ZP Screw (included with grille) 11969 11969 Back panel 41342 41342 Screw, back panel 26014 26014 Ice bucket 80-48001-00 80-48001-00 Drawer Organizer Assembly 26000...
  • Page 137 Section 4 - Parts CO2175DWR/CO2275DWR (2 of 4) 4-58...
  • Page 138 Section 4 - Parts CO2175DWR/CO2275DWR (2 of 4) Item Part No. Part No. Description Black Stainless Steel 2175DWR-TOP-BLK Drawer Front Assembly, top 41604 Screw, handle 26070-05-S Overlay handle 12094-07 12094-08 Gasket, drawer 26094 26094 Display housing 14138-02 14138-02 Drawer, no front, top 23025 23025 Nameplate...
  • Page 139 Section 4 - Parts CO2175DWR/CO2275DWR (3 of 4) 4-60...
  • Page 140 Section 4 - Parts CO2175DWR/CO2275DWR (3 of 4) Item Part No. Part No. Description Black Stainless Steel 68092 68092 Thermistor, quick connect white 68072-S 68072-S Circuit Board Assembly 68080 68080 Switch jumper (included with 68072-S) 41992 41992 Support, circuit board (included with 68072-S) 41993 41993 Support, circuit board (included with 68072-S)
  • Page 141 Section 4 - Parts CO2275DWR (4 of 4) 4-62...
  • Page 142 Section 4 - Parts CO2275DWR (4 of 4) Item Part No. Description 80-39011-00 Ice Maker Assembly 150-DWRCO Faceplate Assembly 2506* Hold switch 2506* Bin switch 2506* Valve switch 2917 Limit switch 2918 Wire harness 11641*† Face plate 18031 Bin arm 20044 Screw 31400...

  • Page 143: 2275Zwc/2275Zwcol

    Section 4 - Parts 2275ZWC/2275ZWCOL (1 of 3) 4-64...
  • Page 144 Section 4 - Parts 2275ZWC/2275ZWCOL (1 of 3) Item Part No. Part No. Description Overlay Stainless Steel 80-17104-01 80-17100-13 Door, LH 80-17104-01 80-17100-03 Door, RH 42173-BLK Hole plug (included with handle assembly) 12094-01 12094-01 Gasket, door 12095-10 12095-10 Gasket, door, center 11994-BLK-S 11994-BLK-S Pivot plate...
  • Page 145 Section 4 - Parts 2275ZWC/2275ZWCOL (2 of 3) 4-66...
  • Page 146 Section 4 - Parts 2275ZWC/2275ZWCOL (2 of 3) Item Part No. Part No. Description Overlay Stainless Steel 41319 41319 Foot, leveler, 1/4-20 2948 2948 Power cord 70077-S 70077-S Compressor 2800 2800 Process tube (included with compressor) 2694 2694 Dryer (included with compressor) 31021 31021 Grommet (included with compressor)
  • Page 147 Section 4 - Parts 2275ZWC/2275ZWCOL (3 of 3) 4-68...
  • Page 148 Section 4 - Parts 2275ZWC/2275ZWCOL (3 of 3) Item Part No. Part No. Description Overlay Stainless Steel 26100 26100 Display housing 41992 41992 Support, circuit board (included with 68084-S) 41993 41993 Support, circuit board (included with 68084-S) 42106 42106 Screw, #6-32 x .38 68084-S 68084-S Main Circuit Board Assembly...

  • Page 149: 1175R

    Section 4 - Parts 1175R (1 of 2) 4-70...
  • Page 150 Section 4 - Parts 1175R (1 of 2) Item Part No. Part No. Part No. Description Black White Stainless Steel 80-17051-01 80-17051-02 80-17067-03-E Door Assembly, right-hand 80-17067-13-B Door Assembly, left-hand 23051-01 23051-01 23051-01 Nameplate 26078-01 26078-02 Handle Assembly 41604 41725 Screw, handle 20031 20031...
  • Page 151 Section 4 - Parts 1175R (2 of 2) 4-72...
  • Page 152 Section 4 - Parts 1175R (2 of 2) Item Part No. Description 1951-S Condenser Assembly ** 2800 Process tube 2694 Dryer 41855 Screw, evaporator 31434-1 Rivet, thermostat cover 26091 Cover, thermistor 68073 Thermistor, quick connect white 26059-02 Control Display Assembly 66010 Reed switch 20026...

  • Page 153: 1115R

    Section 4 - Parts 1115R (1 OF 2) 4-74...
  • Page 154 Section 4 - Parts 1115R (1 OF 2) Item Part No. Part No. Description Black Stainless Steel 80-17062-01 80-17066-03-C Door Assembly, RH 80-17066-13-C Door Assembly, LH 31493-6-BLK 31493-6-BLK Gasket, door 41604 Screw, handle 31447-BLK 31447-BLK Hole plug 23051-01 23051-01 Nameplate 26077-01 Handle Assembly 66016...
  • Page 155 Section 4 - Parts 1115R (2 of 2) 4-76...
  • Page 156 Section 4 - Parts 1115R (2 of 2) Item Part No. Description 26059-02 Control Display Assembly 31434-1 Rivet, thermostat cover 26091 Cover, thermistor 66010 Reed switch 68073 Thermistor, quick connect white 41863 Rivet, reed switch 2878-01-S Evaporator, roll-bond 31154 Insulation, .38 ID x .88 OD, black 31391-2 Drain trough, white 11508...

  • Page 157: 1175Wc

    Section 4 - Parts 1175WC (1 of 2) 4-78...
  • Page 158 Section 4 - Parts 1175WC (1 of 2) Item Part No. Part No. Description Black Stainless Steel 80-17070-01 80-17069-03-G Door Assembly, SS door is field reversable 23051-01 23051-01 Nameplate 26078-01 Handle Assembly 31493-4-BLK 31493-4-BLK Gasket, door 31447-BLK 31447-BLK Hole plug 41604 Screw, handle 20031...
  • Page 159 Section 4 - Parts 1175WC (2 of 2) 4-80...
  • Page 160 Section 4 - Parts 1175WC (2 of 2) Item Part No. Description 1951-S Condenser Assembly ** 2800 Process tube 2694 Dryer 41855 Screw, evaporator SS 41855-02 Screw, evaporator Black 31434-1 Rivet, thermostat cover White 31434-2 Rivet, thermostat cover Black 26091 Cover, thermistor White 26091-03 Cover, thermistor Black...
  • Page 161 Section 4 - Parts 1115WC (1 of 2) 4-82...
  • Page 162 Section 4 - Parts 1115WC (1 of 2) Item Part No. Part No. Description Black Stainless Steel 80-17063-01-D 80-17068-03-G Door Assembly, SS Door is Field Reversable 23051-01 23051-01 Nameplate 26077-01 Handle Assembly 31447-BLK 31447-BLK Hole plug 41604 Screw, handle 31493-6-BLK 31493-6-BLK Gasket, door 66016...
  • Page 163 Section 4 - Parts 1115WC (2 of 2) 4-84...

  • Page 164: 1115Wc

    Section 4 - Parts 1115WC (2 of 2 Item Part No. Part No. Description Black Stainless Steel 2223-S 2223-S Condenser Assembly** 2800 2800 Process tube 2694 2694 Dryer, R-134A 31434-1 31434-1 Rivet, thermistor cover White 31434-2 31434-2 Rivet, thermistor cover Black 26091 26091 Cover, thermistor White...

  • Page 165: 1175Bev

    Section 4 - Parts 1175BEV (1 OF 2) 4-86...
  • Page 166 Section 4 - Parts 1175BEV (1 OF 2) Item Part No. Description 80-17069-03-G Door Assembly, FieldReversable 23051-01 Nameplate (included with #1) 31493-4-BLK Gasket (included with #1) 31447-BLK Hole plug (included with #1) 20031 Screw (included with #1) 66016 Magnet (included with #1) 20042-BLK Screw, hinge (included with hinge assembly) 41747-SSB...
  • Page 167 Section 4 - Parts 1175BEV (2 OF 2) 4-88...
  • Page 168 Section 4 - Parts 1175BEV (2 of 2) Item Part No. Description 1951-S Condenser Assembly ** 2800 Process tube 2694 Dryer 31434-1 Rivet, thermostat cover White 31434-2 Rivet, thermostat cover Black 26091 Cover, thermistor White 26091-03 Cover, thermistor Black 68073 Thermistor, quick connect white 26058 Control Display Assembly White...

  • Page 169: Ada24R

    Section 4 - Parts ADA24R (1 0F 2) 4-90...
  • Page 170 Section 4 - Parts ADA24R (1 0F 2) Item Part No. Description Item Part No. Description 70077-S Compressor** 31578 Foam Washer 68103 Transformer 11508 Drain Cup 2819 Process Tube* 31391-3 Drain Trough 2694 Drier* 21012-WHT Rivet 41319 Leveling Leg 41855-01 Screw 31021 Grommet*...
  • Page 171 Section 4 - Parts ADA24R (2 0F 2) 4-92...
  • Page 172 Section 4 - Parts ADA24R (2 0F 2) Item Part No. Part No. Description Black Stainless Steel 80-17119-01 80-17121-01 Glass Door Right Hand Hinge 80-17121-02 Glass Door Left Hand Hinge 80-17118-01 80-17120-01 Solid Door Right Hand Hinge 80-17120-02 Solid Door Leftt Hand Hinge 23051-01 23051-01 Nameplate...
  • Page 173 Section 4 - Parts This page intentionally left blank. 4-94...

  • Page 174: Section 5 - Wiring Diagrams

    Section 5 - Wiring Diagrams CLR2160 PINK PINK GREEN (GROUND) WHITE OVERLOAD BLACK RELAY NEUTRAL JUMPER PLUG WITHOUT GREEN WASTE WATER PUMP P60 WASTE PUMP (GROUND) BLACK EMBRACO COMPRESSOR WHITE WHITE GREEN TO DISPLAY WHITE (GROUND) WHITE (NEUTRAL) BLACK/YELLOW WATER HOT GAS YELLOW VALVE...

  • Page 175: 2115R, 2115Wc, 2175R, 2175Wc

    Section 5 - Wiring Diagrams 2115R, 2115WC, 2175R, 2175WC, 2175BEV 2275DWRWS, 2275ZWC WIRING DIAGRAM POWER CORD ASSEMBLY BLACK-HOT BLACK (SMOOTH) GREEN WHITE GROUND BLACK-NEUTRAL (RIBBED) WHITE TO MAIN TO BOTTOM DISPLAY DISPLAY WHITE VALVE VALVE WHITE BLACK WITH YELLOW COND...

  • Page 176: 2175Rf

    Section 5 - Wiring Diagrams 2175DWRR, 2275DWRR 2175RF...

  • Page 177: Co2175F

    Section 5 - Wiring Diagrams CO2175F CO2175DWR, CO2275DWR...
  • Page 178 Section 5 - Wiring Diagrams 1175R, 1115R, 1175WC, 1115WC, 1175BEV ADA24R...
  • Page 179 Section 5 - Wiring Diagrams This page intentionally left blank.

  • Page 180: Product Information

    E-mail: onlineparts@u-line.com ABOUT U-LINE Building on 45 years, U-Line has captivated those with an appreciation for the finer things with exceptional design, inspired innovations and attention to even the smallest details. U-Line is synonymous with premium built-in undercounter ice making, refrigeration and wine storage appli- ances, the U-Line Corporation is committed to luxury under the counter.

This manual is also suitable for:

2175r2175wcolClr2160Clrco2175Co2175dwrCo2275dwr ... Show all

Table of Contents
