Page 1: Installation Guide
Installation Guide ® CLRCO2175 Combo — Clear Ice Maker/Refrigerator www.U-LineService.com Phone (414) 354-0300 • FAX (414) 354-7905 Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696 OnlineService@U-Line.com ©2006 U-Line Corporation 08/2006... -
Page 2: Table Of Contents
CLRCO2175 Combo®— Clear Ice Maker/Refrigerator Contents Exterior Cleaning ......Cut-Out Dimensions ...... -
Page 3: Inspect And Plan
CLRCO2175 Combo®— Clear Ice Maker/Refrigerator 2 Inspect and Plan You have received a carton containing your CLRCO2175 Clear Ice Maker/Refrigerator with a package inside containing a Use and Care Guide, a Product Registration Card and water connection parts. Complete and mail the Product Registration Card or register online at www.U-LineService.com. -
Page 4: Exterior Cleaning
3 Prepare Site Your U-Line product has been designed for either free- standing or built-in installation. When built-in, your unit does not require additional air space for top, sides or rear. However, the front grille must NOT be obstructed and clearance is required for water, drain and electrical connections in the rear. -
Page 5: Product Dimensions
Black and White Figure 3 08/2006 CLRCO2175 Combo®— Clear Ice Maker/Refrigerator Reversing the Door (Black and White Units Only) All U-Line units (except Stainless Steel models) may be left- or right-hand opening. The door opening is easily reversed by moving the 34-1/8"... -
Page 6: Other Site Requirements
Drain can NOT be located directly below unit. Unit has a solid base that will not allow unit to drain below itself. Environmental Requirements Many U-Line models are designed to operate in harsh outdoor/marine environments. Special considerations include the following: •... -
Page 7: Side-By-Side Installation Instructions
Side-By-Side Installation Instructions For a complete refreshment center, install your CLRCO2175 Clear Ice Maker/Refrigerator beside a U-Line Drawer or Wine Captain Model (see Figure 11 for typical cut-out). Note that each Side-By-Side Installation will be different. • Cut-out width for a side-by-side installation is the total of the widths listed under Cut-Out Dimensions in each unit’s Installation Guide. -
Page 8: Full Overlay Door Panel
Full Overlay Door Panel Door Panel Preparation A full overlay door panel completely covers the doorframe and handle to give a built-in appearance. See your U-Line dealer for the optional Full Overlay Door Panel Kit. 2175 Models: P/N U-OL2175B -- Black P/N U-OL2175W -- White 2115 &... - Page 9 It is important to ensure that all drilled holes are drilled to the correct depth in order to avoid splits in the wood when hardware is installed. 08/2006 CLRCO2175 Combo®— Clear Ice Maker/Refrigerator Installation Instructions Removing Existing Door 1. Remove the door shelves by first pulling shelves up at a 45°...
- Page 10 CLRCO2175 Combo®— Clear Ice Maker/Refrigerator Tape Back of Wood Panel 1-3/4" Top Top of Wood Panel 3/8" Figure 19 Both Sides Drill ø 5/32" x 3/8" Deep 7 Places Model 2175 6 places Model 2115 and CLR2160 For use with #10 x 5/8"...
- Page 11 4. Replace the door closure assembly onto the bottom pivot post (see Figure 26). Be sure that bosses on closers align with holes in hinge and hinge plate. 08/2006 CLRCO2175 Combo®— Clear Ice Maker/Refrigerator Door Closure Top Top Pivot Plate Screw to attach Handle...
-
Page 12: Checking Door Alignment
CLRCO2175 Combo®— Clear Ice Maker/Refrigerator 5 Adjust Door Checking Door Alignment The unit’s door is aligned at the factory before shipment. However, its alignment could have been disturbed during shipment or during door panel installation. IMPORTANT Properly aligned, the door should be 1/8" below the top of the unit’s cabinet, NOT flush with the top (see Figure 27). -
Page 13: Drain Connection
The CLRCO2175 can be installed using a Gravity Drain, a Factory-Installed Drain Pump (U-Line P60) or a Locally- Installed (U-Line P60) Drain Pump. Drain lines must have a 5/8-inch inside diameter. The floor drain must be large enough to accommodate drainage from all attached drains. - Page 14 Figure 35 IMPORTANT Before installing your U-Line CLRCO2175 with Factory- Installed U-Line P60 Pump, it is extremely important to check and test all hose connections at the drain pump. There is a possibility that hose connections may have loosened during shipment.
-
Page 15: Water Supply Connection
CLRCO2175 Combo®— Clear Ice Maker/Refrigerator In the event of a power outage, restricted drain or pump failure, the failure to use the U-Line P60 drain pump or a pump with the above listed specifications, could result in substantial water leakage and pooling with severe and costly water damage and related consequential damages and harm. -
Page 16: Electrical Specifications
CLRCO2175 Combo®— Clear Ice Maker/Refrigerator 3. Carefully bend the water supply line into position and connect the line to the solenoid valve (see Figure 40). Avoid kinking the water supply line. Figure 40 IMPORTANT Normal operation creates some vibration. A water supply line contacting cabinet wall may cause excessive noise during operation or damage to the line. -
Page 17: Leveling Information
(see Figure 43). Figure 43 08/2006 CLRCO2175 Combo®— Clear Ice Maker/Refrigerator 2. If the ice maker is not level, adjust the feet on the corners of the unit as necessary (see Figure 44). Figure 44 3. -
Page 18: Installation Of The Clrco2175
Relocating the Shelves Both the glass shelves in the refrigerator and the inner door shelves can be moved to accommodate your bottles, cans and containers. Glass Shelves on Right-Hand Hinge Units 1. -
Page 19: Initial Start-Up
Once installation and leveling is complete, the unit is ready for initial start-up and operation. The Display panel is located inside the unit, on the top of the refrigerator side(see Figure 47, 1). The LED display shows the temperature set point and is calibrated in degrees Fahrenheit. -
Page 20: Start-Up Troubleshooting
CLRCO2175 Combo®— Clear Ice Maker/Refrigerator Start-Up Troubleshooting Problem Unit does not appear to turn on when POWER icon is pressed. Solution Remember that the compressor will not operate until the water has been filling for about 3 minutes. Make sure unit is plugged in and outlet has power (circuit breaker has not tripped). -
Page 21: Service Information
For more than four decades, U-Line has distinguished itself as the leader in built-in undercounter ice making, refrigeration and wine storage appliances. U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in ®...
