The "RISO SF9490/9390 Basic Guide", which supports the Read
Out Loud feature in Adobe Acrobat Reader, is stored in the
attached "RISO Printer Driver" DVD-ROM.
It contains excerpts from the User's Guide (this guide) explaining
the basic operations for printing using paper originals.
Directory:
\Manual\SF9x9x_BasicGuide.pdf
Recommended operating environment for Read Out Loud:
– Windows 10
– Adobe Acrobat Reader DC
About This Machine
Basic Operations
Functions for Master Making
Functions for Printing
Useful Functions
Functions for Scanning
Setting the Operation Conditions
RISO Console
Replacing Consumables
Maintenance
Troubleshooting
Appendix
063-36003
1
2
3
4
5
6
7
8
9
10
11
12
