- Page 1 TECHNICAL MANUAL Mini art. 6701- art. 6700 Passion.Technology. Design.
-
Page 2: Table Of Contents
Warning Intended use This Comelit product was designed for use in the creation of audio and video communication systems in residential, commercial or industrial settings and in public buildings or buildings used by the public. Installation All activities connected to the installation of Comelit products must be carried out by qualified technical personnel, with careful observation of the indications provided in the Manuals / Instruction sheets supplied with those products. -
Page 3: Monitor Description
Monitor description 1. Brightness control f To increase the value, turn clockwise 2. Colour intensity adjustment for Art. 6701 Contrast adjustment for B/W monitor Art. 6700 f To increase the value, turn clockwise 3. 4.3’’ LCD screen (in colour for Art. 6701, B/W for Art. 6700) 4. -
Page 4: Soft-Touch Keys Description
Soft-touch keys description f Press the desired key once to activate the function associated with it Wait for approximately 1 sec. before pressing the same key again. Pressing the same key several times in quick succession will cancel the command. Lock-release key Key 1 Actuator function (programmable) Key 2 Self-ignition function (programmable) -
Page 5: Installation
Installation 17,5 cm optional fixing CLACK! CLACK! CLACK! -
Page 6: Removing / Fitting The Terminal
Removing / Fitting the terminal Fitting upgrade KIT Art. 6733W (to remove) CLACK! CLACK! CLACK! -
Page 7: Monitor Configuration
Monitor configuration Standard configuration for soft-touch keys Art. (6700W / 6700W/BM / 6701W / 6701W/BM ) + Art. 6733W / DIP S2 Art. 6701B / 6701B/BM DIP 1 DIP 2 DIP 3 DIP 4 INTb INTb INTb INTb INTb INTb INTb NULL NULL... -
Page 8: Advanced Monitor Configuration
Advanced monitor configuration Warning If the default settings (see table on page 7) do not reflect requirements, the keys can be programmed differently by carrying out the steps below. At the end, set S2 DIP switches 1-2-3-4 to the combination 1111 (PROG setting in the configuration tables on pages 8-12). -
Page 9: Programming Buttons For Intercom Call
Programming buttons for intercom call Art. (6700W / 6700W/BM / 6701W / 6701W/BM ) + DIP S2 DIP S1 Art. 6733W Art. 6701B / 6701B/BM DIP 1 DIP 2 DIP 3 DIP 4 INTb INTb INTb INTb ADDRESS INTb INTb INTb PROG Example 1 - all systems (INCLUDING KITS!) - General intercom... -
Page 10: Direct Programming Of Intercom Call
Direct programming of intercom call Allows direct programming of intercom call via the internal units. √ Requires 2 operators Step 1: enter programming mode Operator 1 and Operator 2 carry out the following procedures on 2 internal units: 1. Set S2 DIP switches 1-2 -3-4 to the combination 1111 2. -
Page 11: Programming Keys For Generic Or Coded Actuator
Programming keys for generic or coded actuator Art. (6700W / 6700W/BM / 6701W / 6701W/BM ) + DIP S2 DIP S1 Art. 6733W Art. 6701B / 6701B/BM DIP 1 DIP 2 DIP 3 DIP 4 ADDRESS PROG Example: on a monitor with user code 5, P1 programming = generic actuator, P2 = coded actuator (code 125) Take note of the DIP-switch settings 1. -
Page 12: Programming Buttons For Other Functions
Programming buttons for other functions Art. (6700W / 6700W/BM / 6701W / 6701W/BM ) + Art. 6733W DIP S2 Art. 6701B / 6701B/BM DIP 1 DIP 2 DIP 3 DIP 4 NULL NULL NULL NULL NULL NULL NULL PROG Legend Lock- release Self-ignition Main switchboard call –... -
Page 13: Programming Range
Programming range Take note of the S2, S1 setting and restore it when programming is complete Carry out steps 1 to 4 S2 DIP Range minimum 1 2 3 4 5 6 address 0 0 0 0 1 0 set code, TAB. A on page Range maximum address... -
Page 14: Programming Reset
Programming reset Factory settings: • Button functions for the S2 DIP switch 1-2-3-4 combination; • Intercom address absent; • Range function and min./max. addresses absent; DIP OFF • Ringtone reset. Take note of the S2, S1 setting and restore it when programming is complete S2 DIP DIP ON 1 2 3 4 5 6... -
Page 15: Riser Addresses
Riser addresses TAB. A Dip switch Dip switch Dip switch Dip switch Dip switch Dip switch Dip switch Dip switch Code Code Code Code Code Code Code Code 1,2,3,4,5 1,3,4,5,6 1,2,4,5,7 1,4,5,6,7 1,2,3,5,8 1,3,5,6,8 1,2,5,7,8 2,3,4,5,6 3,4,5,7 2,4,5,6,7 4,5,8 2,3,5,6,8 3,5,7,8 1,2,3,4,5,6 1,3,4,5,7... -
Page 16: Operating Distances With Art. 4888C
6700W 1214/2C 6701W 6701B 4888C A MAX B MAX F MAX H MAX Comelit Art. 4577/4579 1 mm2 (Ø 1,2 mm AWG 17) 200 m 200 m 50 m 100 m (655 feet) (655 feet) (165 feet) (330 feet) UTP5 cat. 5 0,2 mm2 (Ø 0,5 mm AWG 24) -
Page 17: Wiring Diagrams With Art. 4888C
Wiring diagrams with Art. 4888C System with Art. 4888C: 1 Ikall series external unit 1216 6700W 6701W 6701B 1 2 3 4 5 6 6700W/BM 1214/2C 1234 67 6701W/BM 6701B/BM + 6710 2628/2638 1214/2C 1234 67 6700W 6701W 6701B 1 2 3 4 5 6 6700W/BM 1214/2C 1234 67... -
Page 18: System With Art. 4888C: 2 Main Monitors In Cascade Connection
System with Art. 4888C: 2 main monitors in cascade connection 6700W 6700W 6701W 6701W 1216 6701B 6701B 1 2 3 4 5 6 1 2 3 4 5 6 6700W/BM 6700W/BM 1234 67 1234 67 6701W/BM 6701W/BM 6701B/BM 6701B/BM + 6710 + 6710 1214/2C SB2/A19MINIC... -
Page 19: Operating Distances With Kit 8461M-Mb
1214/2C 6701W 1209 4893 4893 A MAX B MAX Comelit Art. 4577/4579 1 mm2 (Ø 1,2 mm AWG 17) 200 m 100 m (655 feet) (330 feet) UTP5 cat. 5 0,2 mm2 (Ø 0,5 mm AWG 24) 100 m 60 m... -
Page 20: Operating Distances With Art. 1210
4681 4681 A MAX B MAX C MAX H MAX Comelit Art. 4577/4579 1 mm2 (Ø 1,2 mm AWG 17) (850 feet) (425 feet) (425 feet) (164 feet) UTP5 cat. 5 0,2 mm2 (Ø 0,5 mm AWG 24) (260 feet) -
Page 21: Wiring Diagrams With Kit 8461M-Mb And Art.1210
Wiring diagrams with KIT 8461M-MB and Art.1210 KIT 8461M-MB: standard single-family system 6700W 6701W 6700W/BM 6701W/BM 1234 67 110-240V 30 Vdc 30 Vdc 1209 4893 MNK/039QC Local door-opener button System with Art. 1210 1216 6700W 6701W 6701B 1 2 3 4 5 6 1214/2C 6700W 6701W... -
Page 22: Kit 8461M-Mb Or System With Art. 1210: Secondary Monitor In Branch Connection
KIT 8461M-MB or system with Art. 1210: secondary monitor in branch connection 1216 6700W 6701W 6701B 1 2 3 4 5 6 6700W/BM 1234 67 1234 67 6701W/BM 6701B/BM 1214/2C + 6710 6700W 6701W 6701B 1 2 3 4 5 6 6700W/BM 1234 67 6701W/BM... - Page 24 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
