Device management
4.1 Connecting to the device
USB console port
Connect a workstation directly to the USB Type-B console port to access the boot-
time control and device interfaces. The console port provides access to the device's
console and Web interfaces.
Electrical Hazard – risk of temporary network packet corruption
Do not expose the USB console port to large static electric fields.
For service only
The USB console port is intended to be used for service of the device only, such as
initial configuration or troubleshooting. Management of the system during normal
operation must be done over Ethernet.
Note
Required driver for Microsoft Windows
For Microsoft Windows users, the RUGGEDCOM USB Serial Console driver must be
installed on the users workstation before connecting via the USB Type-B console
port. For more information, refer to the associated
Manual""SINEC OS Configuration Manuals" [https://support.industry.siemens.com/cs/
ww/en/ps/29634/man]
Use the following settings to connect to the port:
Speed
Data Bits
Stop Bit
Parity
Flow Control
Terminal ID
Ethernet ports
Connect any of the available Ethernet ports on the device to a management switch
and access the SINEC OS console and Web interfaces remotely. Requires an IP
address.
For more information about available ports, refer to "Communication
ports" (Page 49).
For more information about how to assign an IP address to the device, refer to "IP
address assignment" (Page 57).
Note
Single-mode fiber ports only support Ultra Physical Contact (UPC) cable connectors.
56
NOTICE
NOTICE
associated with the installed software release.
115200 baud
8
1
None
Off
VT100
" SINEC OS Configuration
Equipment Manual, 10/2023, C79000-G8976-1528-01
RUGGEDCOM RST2428P
