For more information about hot swapping/hot plugging requirements, refer to the
associated
cs/ww/en/ps/29634/man].
Required tools/hardware
Torx T10 screwdriver
Removing a media module
To remove a media module, do the following:
1.
2.
3.
Installing a media module
To install a media module, do the following:
1.
2.
RUGGEDCOM RST2428P
Equipment Manual, 10/2023, C79000-G8976-1528-01
The new media module is of a different type
The module was installed in an empty slot while the device is in operation
"SINEC OS Configuration Manuals" [https://support.industry.siemens.com/
Hardware
Using a Torx T10 screwdriver, loosen the screw that secures the media module
to the chassis.
Pull the media module from the chassis to disconnect it.
Figure 3.2
Removing a media module
Install a new media module or a blank module (to prevent the ingress of dust
and dirt).
Remove the current media module from the slot.
Insert the new media module into the slot.
Quantity
1
For removing/installing modules.
Communication ports
3.1 Media modules
Detail
51
