5
Figure 1.5
Display mode
The Mode button switches between display modes A, B, C, and D. The DM1 and
DM2 LEDs in combination indicate the current display mode.
To set the display mode, do the following:
Pressing the Mode
button starting at
display mode A
—
Press once
Press twice
Press three times
Depending on the set display mode, the port status and and power supply LEDs show
different information.
Port status LEDs
LEDs marked P1 to P4 indicate the status of the corresponding port. LEDs
representing module ports are grouped and assigned the number of the
corresponding module slot (1 to 6). LEDs not assigned a module slot represent the
four fixed uplink ports (Slot 0).
The meaning of each LED is as follows:
The meaning of each LED is dependent on the current display mode.
Display mode A
In display mode A, the port LEDs indicate if a link has been established.
—
Green
Green
Green
Green
RUGGEDCOM RST2428P
Equipment Manual, 10/2023, C79000-G8976-1528-01
Mode button
Status panel
LED color
Off
On
Flashes once per period
Flashes three times per period
Flashes four times per period
LED color
DM1
Green
Green On
Green Off
Green
LED state
a
a
a
1.2.3 Status panel
LED state Display mode
DM2
Off Display mode A
Off Display mode B
On Display mode C
On Display mode D
Description
No valid link detected.
A link is established. In this state, the
port can receive and send data.
A link is established and the port is in a
"blocking" state. In this state, the port
only receives management data (no
user data).
A link is established, but the port is
turned off by management. In this
state, no data is sent or received via the
port.
A link is established, but the port is in a
"monitoring" state. In this state, ingress
traffic is mirrored to this port.
