Stamina FREEFORM R2000 AIR ROWER Owner's Manual page 17

STORAGE
1. To store the R2000 AIR ROWER , simply keep it in a clean dry place.
2. To avoid damage to the electronics, remove the batteries from the COMPUTER(19) before storing the
R2000 AIR ROWER for one year or more.
3. Move the R2000 AIR ROWER with the MOVING WHEELS(66) on the FRONT STABILIZER
(4). Lift the Rear Stand of the RAIL FRAME(2) to move the R2000 AIR ROWER . Refer
to the illustration below. Do not use the SEAT(51) to move the R2000 AIR ROWER . The
SEAT(51) will move and the SEAT CARRIAGE(10)
4. The MAIN FRAME(1) and the RAIL FRAME(2) can be
separated to minimize the unit size for storage. Remove the
PULL PIN(98) from the MAIN FRAME(1). Lift up the MAIN
FRAME(1) and pull out the RAIL FRAME(2) to separate.
Insert the PULL PIN(98) back to the hole in the MAIN
FRAME(1) for storage.
17
