Maintenance - Stamina FREEFORM R2000 AIR ROWER Owner's Manual

OPERATIONAL INSTRUCTIONS
USING THE CELL PHONE BRACKET
The CELL PHONE BRACKET(20) can move up and down. Move up the CELL PHONE BRACKET(20),
then slide the Cell Phone into the gap between the CELL PHONE BRACKET(20) and the
COMPUTER(19). Move down the CELL PHONE BRACKET(20) to clip the Cell Phone in position.
Cell Phone

MAINTENANCE

The safety and integrity designed into the R2000 AIR ROWER can only be maintained when
the R2000 AIR ROWER is regularly examined for damage and wear. Special attention should
be given to the following:
1. Pull on the HANDLEBAR(3) and verify that the Magnetic System provides tension and the seat travel
is smooth and stable.
2. Clean the roller tracks in the RAIL(14) with an absorbent cloth.
3. Verify that all nuts and bolts are present and properly tightened. Replace missing nuts and bolts.
Tighten loose nuts and bolts.
4. Check the condition of the CHAIN(36). Replace the CHAIN(36) if it is cracked or broken.
16
