Smart Sensors (Laser Type)
ZX Series (ZX-L-N)
Ordering Information
■ Sensors
Sensor Heads (Reflective)
Optical system
Diffuse reflective
Spot beam
Line beam
Regular reflective
Spot beam
Line beam
*1. For an average count of 4,096.
Sensor Heads (Through-beam)
Optical system
Through-beam
1-mm dia.
1 to 2.5-mm dia.
5 mm
10 mm
30 mm
*1. For an average count of 64.
*2. The cable length for all models is 0.5 m.
Amplifier Units
Appearance
Note: Compatible connection with the Sensor Head.
Beam shape
Sensing distance
40±10 mm
100±40 mm
300±200 mm
40±10 mm
100±40 mm
300±200 mm
30±2 mm
Measuring width
Sensing distance
0 to 500 mm
500 to 2000 mm
0 to 500 mm
Power supply
DC
ZX Series (ZX-L-N)
For the most recent information on models that have been certified for
safety standards, refer to your OMRON website.
Resolution*1
2 μm
16 μm
300 μm
2 μm
16 μm
300 μm
0.25 μm
Resolution*1
4 μm
---
4 μm
12 μm
Output type
NPN
PNP
Smart Sensors (Laser Type)
Model
ZX-LD40
ZX-LD100
ZX-LD300
ZX-LD40L
ZX-LD100L
ZX-LD300L
ZX-LD30V
ZX-LD30VL
Model *2
ZX-LT001
ZX-LT005
ZX-LT010
ZX-LT030 0.5M
Model
ZX-LDA11-N 2M
ZX-LDA41-N 2M
.
1

Advertisement

Table of Contents
loading

Related Manuals for Omron ZX-L-N

Summary of Contents for Omron ZX-L-N

  • Page 1 Smart Sensors (Laser Type) ZX Series (ZX-L-N) For the most recent information on models that have been certified for safety standards, refer to your OMRON website. Ordering Information ■ Sensors Sensor Heads (Reflective) Optical system Beam shape Sensing distance Resolution*1 Model 2 μm...
  • Page 2 Smart Monitor Basic supports the same functions as the Smart Monitor. *3. It is prohibited to copy, to reproduce, and to distribute a part of or whole part of this document without the permission of OMRON Corporation. ZX Series (ZX-L-N) Smart Sensors (Laser Type)

  • Page 3: Specifications

    *4. Temperature characteristic: The temperature characteristic is measured at the measurement point with the Sensor and reference object (OMRON’s standard reference object) secured with an aluminum jig. Note: Highly reflective objects can result in incorrect detection by causing out-of-range measurements.
  • Page 4 *3. For an average count of 64. The value is 5 μm for an average count of 32. *4. For an average count of 64. The value is 15 μm for an average count of 32. ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 5 *2. The output can be switched between a current output and voltage output using a switch on the bottom of the Amplifier Unit. *3. Setting is possible via the monitor focus function. *4. A Calculating Unit (ZX-CAL2) is required. ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 6 1,000 VAC, 50/60 Hz for 1 min, Leakage current: 10 mA max. Materials Case: PBT (polybutylene terephthalate), Cover: Polycarbonate Accessories Instruction sheet, 2 clamps * Contact your OMRON representative for CompoWay/F communications specifications. ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 7 − inclination − inclination −20 −4 −4 −10 −8 −6 −4 −2 −10 −8 −6 −4 −2 −10 −8 −6 −4 −2 Angle of inclination (°) Angle of inclination (°) Angle of inclination (°) ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 8 + inclination − inclination −1 −1 −2 −2 −3 −3 + inclination − inclination −4 −4 −10 −8 −6 −4 −2 −10 −8 −6 −4 −2 Angle of inclination (°) Angle of inclination (°) ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 9 Black paper paper 10° inclination 0° inclination −1 −1 −1 −2 −2 −2 −3 −3 −3 −10° inclination −4 −4 −4 48 50 48 50 48 50 Distance (mm) Distance (mm) Distance (mm) ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 10 28.0 28.4 28.8 29.2 29.6 30.0 30.4 30.8 31.2 31.6 32.0 28.0 28.4 28.8 29.2 29.6 30.0 30.4 30.8 31.2 31.6 32.0 28.0 28.4 28.8 29.2 29.6 30.0 30.4 30.8 31.2 31.6 32.0 Distance (mm) Distance (mm) Distance (mm) ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 11 140 mm 2,000 μm 2,000 μm 2,000 μm 410 μm 100 μm 430 μm ZX-LD300L 100 mm 300 mm 500 mm 2,000 μm 2,000 μm 2,500 μm 750 μm 300 μm 650 μm ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 12 WD = 250 mm WD=450 mm WD = 450 mm Sensing distance: 500 mm Sensing distance: 500 mm −1 −2 Emitter Receiver Emitter side Receiver side side side −3 −4 Light interruption (mm) Light interruption (mm) ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 13 500 600 0 100 500 600 Distance (mm) Distance (mm) −2 −4 −6 ZX-LD30V/LD30VL Voltage Output Current Output Measurement range Measurement range (4 mm) (4 mm) Distance (mm) −2 Distance (mm) −4 −6 ZX Series (ZX-L-N) Smart Sensors (Laser Type)

  • Page 14: I/O Circuit Diagrams

    (linear output ground) together with the linear output (black line) for linear output. Each of these grounds must be used for the designed purpose. When not using the linear output, con- nect the linear ground (shield) to the 0-V ground. ZX Series (ZX-L-N) Smart Sensors (Laser Type)

  • Page 15: Part Names

    ZX-LT010 ZX-LT030 Display area Emitter Laser ON indicator (green) Light emitter Lit when light is emitted. Emitter side sensor head Emitter connector Connector Receiver side Receiver side sensor (Optical filter) head connector Receiver ZX Series (ZX-L-N) Smart Sensors (Laser Type)

  • Page 16: Maintenance

    2. Use a soft cloth (for lenses) with a small amount of alcohol to remove the remaining dust. Do not use a scrubbing action when cleaning because scratches on the filter could result in Sensor inaccuracy. ZX Series (ZX-L-N) Smart Sensors (Laser Type)

  • Page 17: Laser Safety

    3. To avoid exposure to hazardous laser radiation, do not displace nor remove the protective housing during operation, maintenance, and any other servicing. 4. The user should return the product to OMRON for all repair and servicing. 5. As for other countries, observe the regulations and standards specified by each country.
  • Page 18 The maximum accessible emission level permitted within a particular class. For your reference, see ANSI Z136.1-1993, Section 2. Symbol and border: black Background: yellow Figure A Warning label - Hazard symbol Legend and border: black Background: yellow Figure B Explanatory label ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 19 DANGER if greater than 2.5 mW cm 10.Delay required between indication & emission. 11.Variance required for Class IIb or iV demonstration laser products and light shows. 12.DANGER logotype. 13.Required after August 20, 1986. ZX Series (ZX-L-N) Smart Sensors (Laser Type)

  • Page 20: Use Precautions

    Labels (4.3.14 and 4.7) Area Posting (4.3.15) • Administrative & Procedural Controls Standard Operating Procedures (4.4.1) • Output Emission Limitations (4.4.2) LSO Determination Education and Training (4.4.3) • • Authorized Personnel (4.4.4) Alignment Procedures (4.4.5) ZX Series (ZX-L-N) Smart Sensors (Laser Type)

  • Page 21: Laser Product Classifications

    Note: Conditions for safe viewing of diffuse reflections for Class 3B visible lasers are: minimum viewing distance of 13 cm between screen and cornea and a maximum viewing time of 10 s. Other viewing conditions require a comparison of the diffuse reflection exposure with the MPE. ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 22 Class II Caution logo type Certification and Caution identification label logo type Aperture label Certification and Identification Label Note: Use of controls, adjustments, or procedures other than those specified herein may result in hazardous radiation exposure. ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 23 Mounting Holes 32.7 Two, M4 holes 4.75 4.75 35° 47± 12.5 Light axis Two, 4.5-dia. 15 dia. mounting holes Emitter Receiver axis axis Reference plain Measurement center Lens (10 dia.) Lens (16 dia.) ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 24 Light axis center Slit (1 x 10) Mounting Holes Mounting Holes 14± 14± Two, M3 holes Two, M3 holes Sensor Head-Amplifier Unit Connecting Cable (Provided) +200 1,500 15 dia. 2.6 dia × 2 Connector Connector ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 25 Vinyl-insulated round cable, 5.2 dia. (conductor Standard: 100 mm cross-section: 0.09 mm , 10-conductor insulator diameter: 0.7 mm), Standard: 2 m 11.7 11.7 Current/voltage output selector switch (set to voltage output when shipped) Voltage output ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 26 ■ Accessories (Order Separately) Calculating Unit Operation Connectors 24.9 indicators ZX-CAL2 19.5 15.1 54.9 44.05 14.4 36.7 Side-view Attachments ZX-XF12 Light axis center Two, 2.2 dia. 10.6 ZX-XF22 Light axis center Two, 2.2 dia. Seal ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 27 ZX-XC4A (4 m) 15.5 dia. 15 dia. ZX-XC8A (8 m) ZX-XC9A (9 m) Vinyl-insulated round cable, 5.2 dia., 10 conductors 12 pins (male) 12 pins (female) ∗ ZX-XC1A: 1,000 ZX-XC4A: 4,000 ZX-XC8A: 8,000 ZX-XC9A: 9,000 ZX Series (ZX-L-N) Smart Sensors (Laser Type)
  • Page 28 CSM_1_11_1219 In the interest of product improvement, specifications are subject to change without notice. E349-E1-03 OMRON Corporation Industrial Automation Company Sensing Devices Division H.Q. Application Sensors Division Shiokoji Horikawa, Shimogyo-ku,...
