Sylvania SP332-ASST3-PL, 058465807528 - Speaker Quick Start Guide

Introduction

You can use SP332-ASST3-PL with iPads, iPhones and enjoy handsfree calling. In order to get the best results when using the device, please read this manual first before using.

Important Waterproof/Safety Information

DO NOT submerge the SP332-ASST3-PL speaker in water, this unit is not intended to function properly after being under water.

SP332-ASST3-PL is rated IPX6, which means the speaker can be heavily splashed with water or left in the rain(but not submerged in water) for approximately a limited time. If the SP332-ASST3-PL gets wet, it is recommended that you dry the speaker completely before using it again.

Please note: Speaker is not water-resistant when the silicone cover is open. Please make sure that cover is closed and secure before using in a wet environment.

Description

1. ON/OFF button
2. Play/Pause/Phone
3. MIC
4. Previous/Volume –
5. Next/Volume +
6. Blue LED(Bluetooth)
7. Red LED(Charging)
8. Green LED(AUX)
9. Micro USB Charging Port
10. AUX in Port

Included

1. Speaker
2. USB Micro Charging Cable
3. 3.5 mm Audio Cable
4. User Manual

Specifications

Bluetooth Version: 2.1+EDR

Supported Profiles: A2DP, HFP, AVRCP

Bluetooth Range: 33ft (10m)

Dimensions: 180 mm x 65 mm

Battery: rechargeable Lithium-ion battery

Charging: 5V @ 500 mA

Operation

Powering On

Press and Hold "ON/OFF" button 2 seconds to power ON, the Blue LED will start to flash.

If an Aux (3.5 mm) cable is connected to the unit, the Blue LED will turn off, and the Green LED will stay illuminated, notifying you, the unit is in Aux-In mode.

Powering Off

Press and Hold "ON/OFF" button 2 seconds to power OFF

Bluetooth Mode

Pairing

The unit will automatically go into "Pairing Mode" when it is powered ON.

Go into your Bluetooth device settings menu and look for "Sylvania SP332"

After the unit has paired and connected, it will re-connect automatically when the unit is powered on and the device is in range.

Note: Bluetooth Timeout: 10 minutes

Begin Streaming Music

Press "" to start playing music

Press and Hold "" 2 seconds to play the next track

Press and Hold "" 2 seconds to play previous track

Press either "" or "" for volume control

Making and Receiving Phone Calls

When the unit is connected and paired to your device, the unit allows you to make or receive phone calls with its built-in microphone.

Press "" to accept a call

To end a call press ""

To reject a call, press and hold "" for 2 seconds

Aux-In Mode

Plug in the supplied 3.5 mm cable into the unit. The other end is connected to your device. The Green LED will only illuminate when in "Aux" mode.

Please note music and volume can be controlled by your device.

Charging

Attach the USB cable to the unit, and plug into any USB charger. If the unit is completely discharged, it will take approximately 4 hours to fully charge.

The Red LED will illuminate during charging, when it has completed, the Red LED will turn off.

Note: There will be a beep when the battery is low and needs to be recharged.

LED Status

Troubleshooting

For service assistance and product information, please call: 1-800-968-9853.
Curtis International Ltd.
7045 BECKETT DRIVE, UNIT 15, MISSISSAUGA, ON, L5S 2A3
www.curtisint.com
