Pro-Stance 36
Owner/Operator Manual
Manuel du Propriétaire/Utilisateur
E10
™
The use of any gasoline exceeding 10% ethanol (E10) or
10% MTBE will void the product warranty.
L'utilisation d'une essence contenant plus de 10%
d'éthanol (E10) ou de 10% de MTBE annulent la garantie.
ENGLISH
FRANÇAIS
Models
994119 – Pro-Stance 36
(SN 000101 +)
994120 – Pro-Stance 36 CARB
(SN 000101 +)
•
04596200A
5/14
Printed in USA

Advertisement

Table of Contents
loading

Related Manuals for Gravely Pro-Stance 36 CARB

Summary of Contents for Gravely Pro-Stance 36 CARB

  • Page 1 Manuel du Propriétaire/Utilisateur Models 994119 – Pro-Stance 36 (SN 000101 +) 994120 – Pro-Stance 36 CARB (SN 000101 +) The use of any gasoline exceeding 10% ethanol (E10) or 10% MTBE will void the product warranty. L’utilisation d’une essence contenant plus de 10% d’éthanol (E10) ou de 10% de MTBE annulent la garantie.

  • Page 2: Table Of Contents

    They are also printed on a serial Customer Note: If the Dealer does not number label on your unit (see Figure 1). register your product, please fill out, sign and return the product registration card to Gravely or go to www.gravely.com. EN - 2...
  • Page 3 PARTS Equipment described within this manual may Use only Gravely replacement parts. The be optional. Some illustrations may not be replacement of any part on this unit with applicable to your unit.

  • Page 4: Safety

    SAFETY Read these safety rules and follow them 4. Notice closely. Failure to follow these rules could NOTICE: Indicates information or procedures lead to loss of control of unit, severe personal that are considered important but not hazard injury or death to you or bystanders or result related.
  • Page 5 2. Safety Decal Description 1. Danger! DANGER! Read manual, set parking brake, remove key and remove spark Read Owner/Operator plug before you adjust Manual. Allow operation or repair unit. only by properly trained adult, never children. Never direct discharge toward other people. Thrown objects can cause injury.
  • Page 6 MAX. FILL Keep feet and hands away Fill fuel tank to bottom of from all rotating or moving neck – MAXIMUM. parts. WARNING: Overfilling may cause severe damage to DO NOT step or stand in evaporative system! this area. • Never fill fuel tank when engine is running, hot or unit is indoors.
  • Page 7 Never let children or untrained people Personal Protection operate or service the equipment. Local Always wear appropriate clothing including regulations may restrict the age of the hard hat, protective gloves, safety glasses operator. and hearing protection. Long hair, loose The owner/user can prevent and is clothing or jewelry may get tangled in moving responsible for accidents or injuries parts.
  • Page 8 Stop on level ground, lower implements, Operation disengage drives, engage parking brake (if provided), disengage PTO, shut off engine Never operate machine in a closed or poorly and allow moving parts to stop before leaving ventilated area. Never run an engine in an the operator’s position for any reason enclosed area.
  • Page 9 Dust, smoke, fog, etc. can reduce vision and DO NOT park on slopes unless necessary. When parking on slope always chock or cause an accident. block wheels. Always set parking brake. Only operate in good light, keeping away Choose a low ground speed so you will not from holes and hidden hazards.
  • Page 10 Keep the nozzle in contact with the rim of Reverse connections may result in sparks the fuel tank or container opening at all which can cause serious injury. Always times until the fueling is complete. Do not connect positive (+) lead of charger to use a nozzle lock open device.
  • Page 11 ALWAYS keep body and hands away from Storage pin holes or nozzles which eject hydraulic NEVER store unit with fuel in fuel tank, fluid under pressure. inside a building where any ignition sources NEVER attempt to make any adjustments or are present.

  • Page 12: Setup

    SETUP IMPORTANT: See engine manual for fuel type. WARNING: AVOID INJURY. Read 13. Inspect all hardware and tighten if loose. and understand entire Safety Section before proceeding. 14. Check safety interlock system functions (see Safety Interlock System on NOTICE: Refer to Controls And Features on page 16).

  • Page 13: Controls And Features

    CONTROLS AND FEATURES Figure 4 1. Right Transaxle Bypass Lever 13. Oil Pressure Light 2. Left Transaxle Bypass Lever 14. Hour Meter 3. Operator Platform 15. Mower Deck Lift Pedal 4. Steering Levers 16. Mower Deck Lift Lever 5. Battery 17.

  • Page 14: Operation

    OPERATION Oil Pressure Light (Item 13) WARNING: AVOID INJURY. Indicates when engine oil Read and understand entire pressure is low. Safety section before proceeding. NOTE: It does not indicate engine oil level. See Troubleshooting on CONTROLS AND FEATURES page 39 or refer to engine See Figure 4 for Controls and Features manual for details.
  • Page 15 HOUR METER Item 14 MOWER LIFT AND HEIGHT-OF- CUT (HOC) SYSTEM Measures and displays (1) the amount of time engine has been run, time spent on jobs and (Figure 4 and Figure 6) service intervals. This time cannot be cleared. Deck Lift Pedal (Item 15) and Mower Operation Lift Lever (Item 16)
  • Page 16 If 4. Release pedal or mower lift lever. unit does not function as described, contact HOC Setting your Gravely dealer for repairs. Indicator NOTICE: When parking brake is engaged, steering levers are locked in neutral.
  • Page 17 Steering Levers (Item 4) Power Take Off (PTO) Switch (Item 20) 1. ON (Pull PTO switch) Mower blades engage. 2. OFF (Push PTO switch) Mower blades disengage. NOTICE: The engine will not start unless the steering levers (Item 4) are in the neutral position, the PTO switch is in the Off position and parking brake is set.
  • Page 18 • Do not modify the fuel system to use 3. Engage parking brake. (see Parking different fuels. Brake Lever (Item 19) on page 16). • Never mix oil and gasoline. 4. If engine is cold, pull choke into On position. If engine is warm or hot, do not NOTICE: All gasoline is not the same.
  • Page 19 IMPORTANT: Never engage the PTO if mower is plugged with grass or other material. This may cause damage to the electric clutch. 6. Move throttle to fast position. 7. Move steering levers forward to obtain a slow ground speed. 8. Turn OFF the PTO switch to disengage mower.
  • Page 20 1. Platform Latch 2. Lock Bolt Figure 9 FOR BEST PERFORMANCE • Cut grass when it is dry. • Keep mower blades sharp. • Keep mower deck properly leveled per factory standards. • Do not set height of cut too low. For very tall grass, mow twice.

  • Page 21: Maintenance Schedule

    See Parking Brake Interlock System on page 16. Interlock System Check Hydraulic Fluid Check hydraulic oil level mark on expansion tank. Add 15W-50 synthetic motor oil (Gravely p/n 00057100) or equivalent as needed. Do not overfill. See Check Hydraulic Fluid Level on page 25. Check Tires See Specifications on page 41 for correct tire pressure.
  • Page 22 Period Service Task Check Mower Blades Check mower blades for wear. Sharpen or replace as Every needed. See Mower Blades on page 26. Hours Check Air Filter Check air filter for dirt. Clean as required. Follow engine manual for maintenance schedule. Every Lubricate Unit Oil all pivot points and pin connections.

  • Page 23: Service And Adjustments

    Gravely Dealers will provide any service which may be required to keep your unit operating at peak efficiency. Engine service can be obtained from a Gravely Dealer or the engine manufacturer’s authorized service center. WARNING: AVOID INJURY. Read and understand entire Safety section before proceeding.
  • Page 24 4. Turn engine oil filter counterclockwise to remove. 5. Apply a film of clean engine oil to gasket of new filter. IMPORTANT: Avoid Damage! Do not use wrench to tighten oil filter. 6. Install filter. Turn filter clockwise until gasket makes contact with mounting surface.
  • Page 25 75 hours of operation and then can result in severe burns. Fluid in every 400 hours. Use 15W-50 synthetic hydraulic system can penetrate motor oil (Gravely p/n 00057100) or skin and result in serious injury or death. equivalent.
  • Page 26 CARBON CANISTER FILTER (If Equipped) (Figure 13) 1. Purge Plug 2. Oil Filter 3. Filter Guard 1. Carbon Canister 4. Mounting Hardware 2. Carbon Canister Filter Figure 12 Figure 13 Purging the Hydraulic System 1. Check the carbon canister filter for debris accumulation every time the unit WARNING: This adjustment is filled with fuel.
  • Page 27 DO NOT sharpen to this pattern. Sharpen to this pattern. 1. Blade Bolt 2. Spring Washer DISCARD if more than 1/2” 3. Blade 4. Blade Spacer 1. Cutting Edge 5. Spindle Assembly 2. Square Corner 3. Air Lift Erosion Figure 14 4.
  • Page 28 ELECTRICAL SERVICE BATTERY Fuse/Relay Panel WARNING: AVOID INJURY. The fuse/relay panel is located behind the Read and understand entire rear access panel below the control panel. Safety section before proceeding. WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm.
  • Page 29 4. Hold Down Bracket 5. Replace battery. See on page 29. Figure 19 Jump-Starting Gravely does not recommend jump-starting Replace Battery your unit. Jump-starting can damage engine 1. Replace battery and secure with hold- and electrical system components. See your down bracket.
  • Page 30 5. Move steering levers from forward to 2. Release parking brake. reverse several times to ensure controls 3. Place rear access panel in the service are free. Return steering levers to position (see Service Access on neutral position. page 23). 6.
  • Page 31 Steering Lever Interlock Adjustment PARKING BRAKE ADJUSTMENT (Figure 22) The parking brake must keep the unit from rolling. Adjustment is required if a steering lever moves forward or backward when the parking Check Adjustment brake is applied. NOTICE: Check parking brake on both sides 1.
  • Page 32 BELTS PTO Mower Belt Replacement (Figure 26 and Figure 27) 1. Gain access to belts (see Belt Access on WARNING: Moving parts can cut page 32). or amputate body parts. ALWAYS wait for moving parts to stop 2. Remove transmission belt (see before performing maintenance or Figure 27).
  • Page 33 3. Verify that there are no twists in belts and that they are routed correctly. 1. Tension Bracket 2. Transmission Belt Figure 27 MOWER DECK Removing Mower Deck Measure PTO idler spring length (Figure 28 and Figure 29) at outer ends of spring. Adjust to 11.75 –...
  • Page 34 1. Deck Lift-Assist Spring Figure 28 1. Mower Lift Arm NOTICE: Support mower deck on blocks or 2. Mower Lift Link jack stands before disconnecting links from 3. Drag Link mower lift arms to prevent the deck from 4. Drag Link Mounting Pin falling.
  • Page 35 Check Blade Level and Pitch Blade Side-to-Side Level 1. Raise mower deck to a 3.75" (90)/2.75" (70) cutting height. 2. Shut off engine. Engage parking brake. Remove the ignition key. NOTICE: Place blocks under the bottom edge of the deck, not under the reinforcement bar welded along deck face.
  • Page 36 1. Height Adjuster 2. Deck Lift Bracket Figure 31 Adjust Deck Height (Figure 32) The mower deck has two height options to extend the height-of-cut range. • Low position: 1.5 – 4" (38 – 102 mm) • High position: 2.5 – 5" (64 – 127 mm) To change deck height: 1.
  • Page 37 4. Rotate HOC wheel so the lowest cutting position is indicated (reset dial position if necessary): 2.50 1.50 (64) (38) 5. Tighten belt tensioner. Adjust HOC Belt Tension (Figure 35) 1. Loosen the outer lock nut on the HOC belt tensioner. 2.

  • Page 38: Storage

    1. Loosen the lock nut on the index wheel 4. Repeat steps 1 – 3 at each inspection detent plunger. slot. 2. Rotate the plunger adjustment screw to NOTICE: Adjust air gap as evenly as achieve desired pressure on the HOC possible.

  • Page 39: Troubleshooting

    (see Clean Battery on page 29). 4. Discharged battery. 4. Charge battery (see Charging the Battery on page 29). 5. Faulty starter. 5. See your Gravely Dealer. Engine does not 6. Blown fuse. 6. Check main fuse and replace crank. if necessary.

  • Page 40: Accessories

    4. See your Gravely dealer. 4. Faulty hydraulic drive system. ACCESSORIES SERVICE PARTS See your authorized Gravely dealer to add Always use genuine Gravely parts to keep these optional accessories to your unit. your unit running like new. Part No.

  • Page 41: Specifications

    Refer to engine manual. Tank Capacity – gal. (L) 6 (22.7) Transmission Type Hydrostatic Drive Transmission Oil Use 15W-50 synthetic motor oil (Gravely p/n 00057100) or equivalent Hydraulic Oil Filter Size and Weight Length – in. (cm) With Operator Platform Raised 60.3 (153) With Operator Platform Lowered 72.25 (183.5)

  • Page 42: Warranty

    Commercial Mowing Equipment Limited Warranty Ariens Company (Ariens) warrants to the original purchaser that Ariens, Gravely and Countax brand products purchased on or after 1/1/2013 and designated or labeled commercial products by Ariens Company will be free from defects in material and workmanship for the time period noted in the chart below.
  • Page 43 Exclusions – Items Not Covered by This Warranty • Parts that are not genuine Ariens, Gravely or Countax service parts are not covered by this warranty and may void the warranty. • Damages resulting from the installation or use of any part, accessory, or attachment which is not approved by the Ariens Company for use with product(s) identified herein are not covered by this warranty.
  • Page 44 • Products are designed to the specifications in the area that the product was originally distributed. Different areas may have significantly different legal and design requirements. This warranty is limited to the requirements in the area in which the unit was originally distributed.
  • Page 46 Gravely 655 West Ryan Street Brillion, WI 54110 920-756-4688 Fax 920-756-2407 www.gravely.com www.ariens.com.au WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
