- Page 1 Promaster 310 Owner/Operator Manual Models 990018 25 HP Kohler 990020 23 HP Kawasaki ENGLISH FRANÇAIS ESPAÑOL 08495100A 1/02 Supercedes 08495100 Printed in USA...
-
Page 2: Controls And Features
ENGLISH 1. Parking Brake Lever 2. Throttle Lever 3. Choke Control 4. Oil Pressure Warning Light 5. Deck Lift Lever 6. Cut Height Lever 7. Ignition Switch 8. PTO Switch 9. Handlebar 10. Hydraulic Oil Cooler 11. Muffler 12. Hydraulic Pump 13. -
Page 3: Table Of Contents
• Record Unit Model and Serial numbers here. • Record Engine Model and Serial numbers here. UNAUTHORIZED REPLACEMENT PARTS Use only Gravely replacement parts. The replacement of any part on this vehicle with anything other than an Gravely authorized replacement part may adversely TABLE OF CONTENTS Storage . -
Page 4: Safety
SAFETY ALERTS Look for these symbols to point out important safety precautions. They mean: Attention! Personal Safety Is Involved! Become Alert! Obey The Message! The safety alert symbols above and signal words below are used on decals and in this manual. Read and understand all safety messages. - Page 5 1 & 2. DANGER Read the operator’s manual. OL1801 Keep children and others away from unit while operating. OL4140 Never direct discharge toward other people. Thrown objects can cause injury. OL0910 Look down and behind before and while backing. OL4780 Keep children out of work area and under watchful care of a responsible adult.
- Page 6 NEVER place your hands or any part of your body or clothing inside or near any moving part while unit is running. ALWAYS keep hands and feet away from all rotating parts during operation. Rotating parts can cut off body parts.
- Page 7 Replace fuel cap securely and clean up spilled fuel. Never fill containers inside a vehicle or on a truck or trailer bed with a plastic liner. Always place containers on the ground away from your vehicle before filling. When practical, remove gas-powered equipment from the truck or trailer and refuel it on the ground.
-
Page 8: Assembly
WARNING: AVOID INJURY. Read and understand Assembly, Fuel and Battery Safety Rules before proceeding. Tools required: • socket wrench, 15/16" • tire gauge Unpack Unit Remove unit and all other components from the shipping container. Install Handlebar 1. Remove nut securing handlebar to shaft. 2. - Page 9 Throttle Lever Move lever to FAST (1) position to increase engine speed. Move lever to SLOW (2) position to decrease engine speed. OE0340 Choke Pull choke control out to start a cold engine. Push control in as engine warms up. OE0590 Handlebar Turn handlebar clockwise to steer right.
- Page 10 5. Fill fuel tank to within 1/2" (1.3 cm) below bottom of filler neck. NOTE: Fuel tank capacity is 7.5 gal. (28.4L). 6. Replace fuel cap and tighten. 7. Clean up any spilled fuel. TO STOP IN AN EMERGENCY Turn ignition key to OFF. STARTING THE ENGINE 1.
-
Page 11: Maintenance
Gravely Dealers will provide any service or adjustments which may be required to keep your unit operating at peak efficiency. Should engine service be required, contact an Gravely dealer or an authorized engine manufacturer's service center. WARNING: AVOID INJURY. Read and... - Page 12 2. Disconnect cables from battery (negative, then positive). 3. Clean terminals and battery cable ends with wire brush. 4. Coat terminals with grease or petroleum jelly. 5. Reconnect cables to battery (positive, then negative). 6. Replace battery cover. Electrolyte Level Every 25 hours of operation or each week check electrolyte level of each cell by removing caps one at a time.
-
Page 13: Service And Adjustments
CHECK ENGINE OIL COOLER Check engine oil cooler every 25 hours. Check more often when operating in dirty or dusty conditions. See engine manual for detailed instructions. CLEAN HYDRAULIC OIL COOLER Blow out hydraulic oil cooler with compressed air every 25 hours of operation to remove dust and debris. - Page 14 1. Adjusting Bolt 2. Plate Bolt 3. Notch 4. Neutral Switch 5. Neutral Bracket Figure 7 ADJUSTING DIRECTION CONTROL PEDAL 1. Remove jam nut from stop bolt and remove stop bolt from frame. 1. Control Pedal 4. Jam Nut 2. Stop Bolt 5.
- Page 15 STEERING BELT ADJUSTMENT 1. Loosen idler nut. 2. Tighten adjustment screw. Torque to 23 - 27 in. lbs. (2.6 - 3 Nm). 3. Tighten idler nut. Idler Nut Figure 10 BATTERY WARNING: AVOID INJURY. Read and understand Battery Safety Rules in Safety section before proceeding.
-
Page 16: Storage
1. Ignition ground wire disconnected. run when ignition 2. Ignition switch failure. key in off position Mower won’t 1. Attachment blocked. engage 2. Bad PTO switch. See your authorized Gravely Dealer to add these optional accessories. Part No. 78900300 79200300 79200400 79200500 79200600... -
Page 17: Specifications
SPECIFICATIONS Model Number 990018 Description Name PM 310 25 HP Length 70" (177.8 cm) Height 50.8" (129 cm) Width 50.3" (127.8 cm) Weight lbs. (kg.) 929 (422) Battery Brakes Dynamic Disc - Parking Steering Turning Radius Tire Size - Front 23 x 10.5 - 12 4 ply - Rear 16 - 6.50 - 8... -
Page 18: Warranty
• The purchaser must transport the product to and from the place of warranty repair. Product Registration • The Gravely dealer must fill out and return the warranty registration card to validate the warranty. Service Parts and Accessories • Service parts and accessories not purchased with the product... - Page 19 GRAVELY A Division of Ariens Company 655 West Ryan Street P.O. Box 157 Brillion, WI 54110-0157 920-756-2141 Fax 920-756-2407 www.gravely.com...
