Configuring the Switch

Showing Port Statistics

You can display statistics on network traffic from the ports. These statistics can be
used to identify potential problems with the switch (such as a faulty port or unusually
heavy loading). All values displayed have been accumulated since the last system
reboot, but can be reset to zero by clicking the CLEAR button. The current statistics
are not displayed until you click the REFRESH button.
Parameter
Interface Statistics
Received Octets
Received Unicast Packets
Received Errors
Transmitted Multicast Packets
Transmitted Broadcast Packets The total number of packets that higher-level protocols
Received High Priority Packets
Transmitted High Priority
Packets
Received Multicast Packets
Received Broadcast Packets
Transmitted Octets
Transmitted Unicast Packets
Transmitted Errors
Received Normal Priority
Packets
Transmitted Normal Priority
Packets
3-8

Table 3-3 Port Statistics

Description
The total number of octets received on the interface, including
framing characters.
The number of subnetwork-unicast packets delivered to a
higher-layer protocol.
The number of inbound packets that contained errors preventing
them from being deliverable to a higher-layer protocol.
The total number of packets that higher-level protocols
requested be transmitted, and which were addressed to a
multicast address at this sub-layer, including those that were
discarded or not sent.
requested be transmitted, and which were addressed to a
broadcast address at this sub-layer, including those that were
discarded or not sent.
The total number of received packets that set as High Priority in
the QoS settings.
The total number of transmitted packets that set as High Priority
in the QoS settings.
The number of packets, delivered by this sub-layer to a higher
(sub-)layer, which were addressed to a multicast address at this
sub-layer.
The number of packets, delivered by this sub-layer to a higher
(sub-)layer, which were addressed to a broadcast address at this
sub-layer.
The total number of octets transmitted out of the interface,
including framing characters.
The total number of packets that higher-level protocols
requested be transmitted to a subnetwork-unicast address,
including those that were discarded or not sent.
The number of outbound packets that could not be transmitted
because of errors.
The total number of received packets that set as High Priority in
the QoS settings.
The total number of transmitted packets that set as High Priority
in the QoS settings.
