LM5171-Q1 EVM User Guide
The LM5171EVM-BIDIR Evaluation Module (EVM) is designed to showcase the LM5171-Q1 high performance
dual-channel bidirectional controller suitable for, but not limited to, the automotive 48-V to 12-V dual battery
system applications.
The EVM can be configured as a bidirectional power converter in the form of either a current source or voltage
source. The direction of power flow can be controlled either by an external command signal or by the on-board
jumper. Through the onboard interface headers, the EVM can be operated by a DSP, an FPGA, an MCU, or
other digital controllers. Two EVMs can be paralleled to make a 3 or 4 phases interleaved converter for higher
power. More EVMs can be paralleled for greater number of phases. Many convenient jumper headers are also
included for versatile configurations of the EVM.
Refer to the
LM5171-Q1 Multiphase Bidirectional Current Controller Data Sheet
technical information of the LM5171-Q1 device.
1 Features and Electrical Performance...................................................................................................................................
2
Setup........................................................................................................................................................................................5
2.1 EVM Configurations...........................................................................................................................................................
Setup.....................................................................................................................................................................13
2.3 Test Equipment................................................................................................................................................................
2.4 Jumper Settings for Typical Operation Modes.................................................................................................................
3 Test Procedure......................................................................................................................................................................
3.1 Buck Mode Power-Up and Power-Down Sequence........................................................................................................
3.2 Boost Mode Power-Up and Power-Down Sequence.......................................................................................................
3.3 Bidirectional Operation Power-Up and Power-Down Sequence......................................................................................
Files...........................................................................................................................................................................23
4.1
Schematics.......................................................................................................................................................................23
Materials.................................................................................................................................................................26
SNVU843 - APRIL 2023
Submit Document Feedback
ABSTRACT
CAUTION
!
Read the user's guide before use.
CAUTION
Hot surface! Contact can cause burns. Do not touch!
Table of Contents
Circuit.......................................................................................22
Copyright © 2023 Texas Instruments Incorporated
Table of Contents
(SNVSC75) for detailed
LM5171-Q1 EVM User Guide
3
5
13
13
21
21
22
22
1
Advertisement
Table of Contents
Related Manuals for Texas Instruments LM5171-Q1
Summary of Contents for Texas Instruments LM5171-Q1
-
Page 1: Table Of Contents
User’s Guide LM5171-Q1 EVM User Guide ABSTRACT The LM5171EVM-BIDIR Evaluation Module (EVM) is designed to showcase the LM5171-Q1 high performance dual-channel bidirectional controller suitable for, but not limited to, the automotive 48-V to 12-V dual battery system applications. The EVM can be configured as a bidirectional power converter in the form of either a current source or voltage source. - Page 2 ..........................Table 2-4. J18 60-Pin Header Description ..........................12 Table 4-1. Bill of Materials................................26 Trademarks All trademarks are the property of their respective owners. LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 3: Features And Electrical Performance
C Interface for Monitoring and Diagnose. (J31) The electrical performance of the EVM is show in Table 1-1. Figure 2-1 shows the simplified EVM schematic. SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 4: Table 1-1. Electrical Performance
Buck mode operation (DIR > 2 V, onboard analog 12VDC-Port 14.5 output voltage loop closed) SYSTEM CHARACTERISTICS Switching frequency External clock synchronization Full load efficiency Junction temperature, T –40 °C LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 5: Setup
Dynamic MOSFETs dead time adjustment • Individual channel current monitoring or total current monitoring • Synchronization to external clock • External shutdown command through DT/nSD pin (J17-pin45) SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 6: Figure 2-1. Simplified Evm Schematic
AGND 10 nF AGND CSA2 CSB2 ¥ 0.22 µF 4.7 µH 100 µF 470 µF PGND PGND PGND Figure 2-1. Simplified EVM Schematic LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 7: Figure 2-2. Evm Board Top View And Layout
Setup Figure 2-2. EVM Board Top View and Layout Partitions SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 8: Headers
External digital voltage loop – = All jumper pins open. (1,2) = Pins 1 and 2 closed. (2,3) = Pins 2 and 3 closed. LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 9: Table 2-2. Two-Pin Header Settings
Sepic input is energized by 48V-port input connection Sepic input is disconnected and not energized CC Control CC control allowed CC control inactive SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 10 CC control input port USB2ANY pullup for Pullup by USB2ANY board Pullup by external signal source through J17 Jumper pins Closed. Jumper pins Open. LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 11: Table 2-3. J17 60-Pin Header Description (1)
J17 is the interface connector to MCU, or external digital controller, or to J18 of the main EVM if the host EVM serves as a secondary EVM in the multiphase configuration. I = input pin O = output pin SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 12: Table 2-4. J18 60-Pin Header Description (1)
J18 is the interface connector to the secondary EVM in the multiphase configuration if the host EVM serves as the main. All control commands and control signals are sent through J18 to J17 of the secondary EVM. I = input pin O = output pin LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 13: Bench Setup
Boost Mode with Voltage Regulation • Buck Mode with Current Regulation • Boost Mode with Current Regulation • 2-EVM Daisy-Chain for 3 or 4-Phase Operation SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 14: Figure 2-4. Jumper Settings In Buck Mode With Voltage Regulation
Figure 2-4. Jumper Settings in Buck Mode with Voltage Regulation The status of the EVM is as follows: • UVLO: 48 V via J1 • Phase interleaving angle: 180° via J6 LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 15: Regulation
2.4.2 Boost Mode with Voltage Regulation Jumper Settings in Boost Mode with Voltage Regulation shows the jumper settings of boost mode with voltage regulation. SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 16: Figure 2-5. Jumper Settings In Boost Mode With Voltage
2.4.3 Buck Mode with Current Regulation Figure 2-6 shows the jumper settings of buck mode with current regulation. LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 17: Figure 2-6. Jumper Settings In Buck Mode With Current Regulation
. Also note the load needs to be set to CV mode. 2.4.4 Boost Mode with Current Regulation Figure 2-7 shows the jumper settings of boost mode with current regulation. SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 18: Figure 2-7. Jumper Settings In Boost Mode With Current
2.4.5 2-EVM Daisy-Chain for 3 or 4-Phase Operation Figure 2-8 shows the jumper settings for 2-EVM Daisy-Chain. LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 19: Figure 2-8. Jumper Settings In 2-Evm Daisy-Chain For 3 Or 4-Phase Operation
Jumper Settings in 2-EVM Daisy-Chain for 3 or 4-Phase Operation described four-phase operating with 90° interleaving. By connecting secondary EVM J30 pin 2,3 instead of pin 1,2, three-phase operating is obtained. SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 20 J6 is open and J32 is closed in main EVM, thus interleaving angle changes automatically between 3 phase and 4 phase. Note for bidirectional operation, the source and load needs to be set referring to Bench Setup. LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 21: Test Procedure
Test Procedure 3 Test Procedure Please read the LM5171-Q1 data sheet (SNVSC75) and this user guide before using the EVM. A typical EVM test bench setup is shown in Figure 2-2. The power supplies and loads need to be capable of handling the input and output voltage and current rating of the board. -
Page 22: Boost Mode Power-Up And Power-Down Sequence
Signals required from an MCU or other digital control circuit include UVLO, EN1/EN2, DIR, ISETA or ISETD. Contact TI for info on operating the EVM with the MSPM0 Launchpad or C2000 MCU. LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 23: Design Files
To download the Schematics for the EVM board, see the design files at www.ti.com/tool. Figure 4-1. EVM Schematic Part 1: Over view Figure 4-2. EVM Schematic Part 2: Bias Supplies SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 24: Figure 4-3. Evm Schematic Part 3: Controller
Design Files www.ti.com Figure 4-3. EVM Schematic Part 3: Controller Figure 4-4. EVM Schematic Part 4: Outer Voltage Loop LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 25: Figure 4-5. Evm Schematic Part 5: Protection
Design Files Figure 4-5. EVM Schematic Part 5: Protection Figure 4-6. EVM Schematic Part 6: Power stage SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 26: Bill Of Materials
C27, C28, C29, C63, C64, 2220 C66, C67, C68, C69, C70, C71, C104, C105 CAP, CERM, 1 uF, 100 V, +/- 10%, X7R, 1206 GRM31CR72A105KA01L MuRata LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 27 J32, J33, J37, J38, J39, J40, J41, J42, J43, J44 J8, J9, J10, J11 Banana Jack Connector Standard Banana 6095 Keystone Solder Lug Electronics SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 28 RES, 15.0 k, 1%, 0.1 W, AEC-Q200 Grade 0, CRCW060315K0FKEA Vishay-Dale 0603 RES, 316, 1%, 0.1 W, AEC-Q200 Grade 0, CRCW0603316RFKEA Vishay-Dale 0603 LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 29 Texas Instruments Crossover, 20MHz, 0.9pA Ib, RRIO, CMOS Operational Amplifier, DBV0005A (SOT-23-5) Automotive Catalog Single Differential TL331BQDBVRQ1 Texas Instruments Comparator 5-SOT-23 -40 to 125 SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 30: Board Layout
The EVM includes various headers for flexible configurations suitable for different applications. Figure 4-8 through Figure 4-17 show the EVM PCB artwork. Figure 4-8. EVM Top Layer Silkscreen LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 31: Figure 4-9. Evm Top Layer Copper
Design Files Figure 4-9. EVM Top Layer Copper SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 32: Figure 4-10. Evm Middle Layer 1
Design Files www.ti.com Figure 4-10. EVM Middle Layer 1 LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 33: Figure 4-11. Evm Middle Layer 2
Design Files Figure 4-11. EVM Middle Layer 2 SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 34: Figure 4-12. Evm Middle Layer 3
Design Files www.ti.com Figure 4-12. EVM Middle Layer 3 LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 35: Figure 4-13. Evm Middle Layer 4
Design Files Figure 4-13. EVM Middle Layer 4 SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 36: Figure 4-14. Evm Middle Layer 5
Design Files www.ti.com Figure 4-14. EVM Middle Layer 5 LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 37: Figure 4-15. Evm Middle Layer 6
Design Files Figure 4-15. EVM Middle Layer 6 SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 38: Figure 4-16. Evm Bottom Layer Copper
Design Files www.ti.com Figure 4-16. EVM Bottom Layer Copper LM5171-Q1 EVM User Guide SNVU843 – APRIL 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 39: Figure 4-17. Evm Bottom Layer Silkscreen
Design Files Figure 4-17. EVM Bottom Layer Silkscreen SNVU843 – APRIL 2023 LM5171-Q1 EVM User Guide Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 40 STANDARD TERMS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms set forth herein.
