DL5200/DLN5200 Specifications

Note: For printer specifications, refer to your Printer User Guide.
Standard system Rimage DL5200 autoloader, an Everest printer, and Rimage software.
Rimage DLN5200 autoloader, an Everest printer, a network-ready embedded PC, and Rimage
software.
Number of Recorders
Software DL5200: Pentium 4 2.8 GHz, 512MB L2 Cache , 800MHz FSB
requirements
512MB DDR2-200, 400Mhz Bus
Microsoft Windows® 2000 Professional Service Pack 4, Microsoft Windows XP Professional
Service Pack 1or 2, Windows Server 2003
Rimage recommends 4 hard drives – One for the OS, one for the Rimage System Folder, and
two for caching (one for each recorder).
One open PCI slot for the provided FireWire®/USB card.
Ships with the correct software installed on the embedded PC. Operate only with the Rimage
software installed on the embedded PC.
DLN5200: Celeron D 340 processor with 533Mhz Front Side Bus
512MB DDR2-400, SDRAM
Windows XP Embedded with Service Pack 2
Two 36 GB, Serial ATA, 10,000 RPM, 8 MB cache, Hard Drives
Operates only with the Producer Software Suite.
Input bin capacity One removable 50-disc bin.
Output capacity Five single-disc output trays and one 75-disc output bin.
Physical size
Height
Width*
Depth**
Weight
Weight with
Everest
* Allow an additional 2.4 inches (6.1 cm) of space for the door to swing open.
** Leave an additional 3.5 inches (9 cm) for cabling.
Supported DL5200: Microsoft Windows® 2000 Professional Service Pack 4, Microsoft Windows XP
operating systems Professional Service Pack 1or 2, Windows Server 2003.
DLN5200: The DLN5200 has an embedded operating system. The DLN5200 and software will
function only with the embedded operating system.
Power 100 – 240VAC, 60/50 Hz, 4.7 – 3.7 Amps
Temperature and Operating Temperature
humidity 60° to 80º F (15.5º to 26.7°
C)
Networking ability Refer to the Rimage Advanced Setup Guide for instructions on submitting orders from a
networked computer.
Media Refer to your printer user guide for the correct media requirements. Rimage Media Kits™ are
requirements designed for optimum recording and print performance.
110768_F
Rimage DL5200
2
DL5200 DLN5200
23.25 inches (59.1 23.25 inches (59.1
cm) cm)
14.5 inches (36.8 cm) 14.5 inches (36.8 cm)
23.5 inches (59.1 cm) 23.5 inches (59.1 cm)
44.5 lbs (20.2 kg) 51 lbs (23.2 kg))
88.5 lbs. (40.2 kg) 95 lbs. (43.2 kg))
Humidity
40% to 80% non-condensing
Important Information
Rimage DLN5200
2
Storage Temperature
5° to 95° F (-15° to 35° C)
