Rimage DL5200 Specifications

Rimage DLN5200/DL5200 Specifications
Note: For printer specifications, refer to your Everest Printer User Guide or PrismPlus! Printer User Guide.
Item
Rimage DLN5200
Rimage DL5200
Input Bin Capacity
Output Capacities
Rimage DLN5200
(Embedded PC)
Rimage DL5200 PC
requirements
Height
Width
Depth
DLN5200 Weight
DL5200 Weight
Power
Operating Temperature
Humidity
5/17/2007
Description
Two disc recorders, Rimage DLN5200 autoloader, an Everest printer, a network-
ready embedded PC, and Rimage software.
Two disc recorders, Rimage DL5200 autoloader, an Everest printer, and Rimage
software.
One removable 50-disc bin.
Five single-disc output trays and one 75-disc output bin.
Celeron D 340 processor with 533Mhz Front Side Bus
512MB DDR2-400, SDRAM
Windows XP Embedded with Service Pack 2
Two 36 GB, Serial ATA, 10,000 RPM, 8 MB cache, Hard Drives
Pentium 4 2.8 GHz, 512MB L2 Cache , 800MHz FSB
512MB DDR2-200, 400Mhz Bus
Windows 2000 Professional with SP4; Windows XP Professional with SP2 or
higher; Windows Server 2003.
Rimage recommends 4 hard drives – One for the OS, one for the Rimage System
Folder, and two for caching (one for each recorder).
One open PCI slot for the provided FireWire®/USB card.
23.25 inches (59.1 cm)
14.5 inches (36.8 cm)
Allow an additional 2.4 inches (6.1 cm) of space for the door to swing open.
23.5 inches (59.1 cm)
Allow an additional 2.5 inches (6.4 cm) for cabling in the rear of the autoloader.
51 lbs (23.2 kg) without Everest printer, 95 lbs. (43.2 kg) with Everest printer.
44.5 lbs (20.2 kg) without Everest printer, 88.5 lbs. (40.2 kg) with Everest printer.
100 – 240VAC, 60/50 Hz, 4.7 – 3.7 Amps
60° to 80º F (15.5º to– 26.7° C)
40–80% non-condensing
1
