１.Preparation before construction
1.1.Scope of Delivery
Verify that following items are available for use prior to using this feature.
■ Wired Set (S4E_1P)
No Product name
Power Monitor
1
Wall Surface /
2
Desktop Mounting Plate
Wood screws (+) for Wall Surface /
3 Desktop Mounting Plate
(dia. 4 x 20 mm)
4 AC Adapter
5 Power Meter
6 End Crimp Terminals
7 Isolation Cap (Red)
8 DIN Rail
Wooden Screws
9
for the Enclosed DIN Rail
10
Stopper
Enclosed Measuring
11
Unit Connector
※（ ）is amount of spare parts.
Shape Qty
1 unit
POWER MONITOR
This is a plate used to install
1 pc
the Product on a wall or on a
desk.
These are wood screws for
2 pcs
the Wall Surface / Desktop
Mounting Plate.
This is the power supply for
1 unit
the Power Monitor.
1 unit
2 pcs
※ （１）
For power meter.
2 pcs
※ （１）
1 pc For power meter and N1.
2 pcs Wooden Screws
The stopper for power meter
2 pcs
and N1.
The RS-485 connector for
1 pc
power meter.
