Page 1 User’s Manual The Printronix L5535 Multifunction Printer...
Page 2: Consumables Information
For the best possible performance of your Printronix printer, use Genuine Printronix parts and supplies. For the name of your nearest Printronix full service distributor, call: United States (800) 733-1900 or (714) 368-2300...
Page 3 L5535 Multifunction Printer User’s Manual 171516-001C...
Page 4: Software License Agreement
The term “Software Product” includes the Software resident in the printer and its documentation. The Software Product is licensed (not sold) to you, and Printronix, Inc. either owns or licenses from other vendors who own, all copyright, trade secret, patent and other proprietary rights in the Software Product.
Page 5 Software Product and printer. Limited Software Product Warranty Printronix, Inc. warrants that for ninety (90) days after delivery, the Software will perform in accordance with specifications published by Printronix, Inc. Printronix, Inc. does not warrant that the Software is free from all bugs, errors and omissions.
Page 6 CONSEQUENTIAL OR INCIDENTAL DAMAGES, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. 3. Printronix, Inc. will not be liable for any loss or damage caused by delay in furnishing a Software Product or any other performance under this Agreement.
Page 7: Communication Notices
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Printronix is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by any unauthorized changes or modifications to this equipment.
Page 8 Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. Printronix cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of non-Printronix option cards.
Page 9 Anmerkung: Um die Einhaltung des EMVG sicherzustellen sind die Geräte, wie in den Handbüchern angegeben, zu installieren und zu betreiben. This product has been tested and found to comply with the limits for Class A Information Technology Equipment according to European Standard EN 55022.
Page 10: Trademark Acknowledgements
Dataproducts is a registered trademark of Dataproducts Corporation. DuraFusion, IGP, LaserLine, LinePrinter Plus, PGL, PSA, and Printronix are registered trademarks of Printronix, Inc. EIA is a registered service mark of the Electronic Industries Association. Epson is a registered trademark of Seiko Epson Corporation.
Page 11 PhoenixPage PCL 5 is a registered trademark of Phoenix Technologies LTD. PKUNZIP is a registered trademark of PKWARE, Inc. SELFOC is a registered trademark of Nippon Sheet Glass Co., Ltd. 3M is a registered trademark of the Minnesota Mining and Manufacturing Company.
Page 12 Hiroshige and Marigold are trademarks of AlphaOmega Typography, Inc. Printronix, Inc. makes no representations or warranties of any kind regarding this material, including, but not limited to, implied warranties of merchantability and fitness for a particular purpose. Printronix, Inc. shall not be held responsible for errors contained...
Page 13: Table Of Contents
Table of Contents 1 Introduction ... 19 About This Manual...19 General Safety Precautions...20 Safety Label Locations And Printer Views ...22 About The Printer ...27 Features ...27 Emulations ...27 Fonts And Forms...28 2 Initial Setup ... 29 Installation Overview ...29 Loading Paper ...30 Loading Fanfold Paper...30...
Page 14 Table of Contents Using The Control Panel ...46 Liquid Crystal Display (LCD) ...47 Function Keys ...48 3 Printer Configuration ... 53 Printer Configuration...53 Unlocking And Locking The Configuration Menu ...53 Unlocking The Configuration Menu ...54 Locking The Configuration Menu...54 Moving Within The Configuration Menu ...55 Moving Within The Configuration Menu ...55...
Page 15 Clearing Service Level Messages...161 Maintenance ...162 User Replacement Schedule ...163 General Cleaning...172 General Cleaning ...172 Vacuuming The Printer ...172 Cleaning The Chargers ...180 Cleaning The Fuser Unit Cover Glass ...186 Cleaning The Cut Sheet Option Rollers ...191 Major Cleaning ...197 Major Cleaning ...197...
Page 16 Table of Contents 6 Troubleshooting ... 207 Troubleshooting...207 Maintaining Print Quality ...207 Diagnostics ...208 Fanfold Paper Jams ...209 Paper Jam Near The Tractor ...209 Paper Jam Near The Paper Output Section ...210 Cut Sheet Paper Jams ...216 Paper Jam In The Transport Input Section ...217 Paper Jam In The Transport Output Section ...220 Paper Jam In Face Up Or Down Paper Path ...221 System Status And Error Messages...222...
Page 17 Table of Contents RS-422 Serial Interface...264 Centronics Parallel Interface ...268 Dataproducts Parallel Interface...272 IEEE 1284 Parallel Interface Configuration...275 Termination Resistors ...276 Ethernet Interface Configuration ...276...
Page 18 Table of Contents...
Page 19: Introduction
Introduction About This Manual This manual explains how to use your printer. Safety Notices And Special Information For your safety and to protect valuable equipment, it is very important that you read and comply with all information highlighted under the following special headings:...
Page 20: General Safety Precautions
The operator-accessible power switch does not shut off all power to the printer. You must unplug the power cord to shut off all power to the printer. The power outlet must be installed near the equipment and must be easily accessible.
Page 21 Do not operate the printer in a room that is not properly ventilated. The room should be at least 1,000 cubic feet with complete air exchange every two hours. Keep combustible materials away from the printer. Dispose of used toner properly, as it is flammable.
Page 22: Safety Label Locations And Printer Views
Chapter 1 Safety Label Locations And Printer Views Safety Label Locations And Printer Views...
Page 23 Legend: Face Down Paper Output Tray Top Cover Front Upper Cover Power Paper Stacker(Optional) Rear Cover Top Cover Cut Sheet Paper Input Cassette (Optional) Power Switch CAUTION 10) Host I/O Connections 11) Fanfold Paper 12) Control Panel 13) CAUTION 14) Face Up Paper Output Tray 15) Rear Cover Figure 1: Front and Side Views...
Page 24 Chapter 1 Safety Label Locations And Printer Views Legend: Open/Close Button Front Upper Cover CAUTION CAUTION WARNING Figure 2: Front View with Front Upper Cover Open...
Page 25 Legend: Fuser Unit Cleaning Unit Discharge LED (not visible) Main Charger Toner Cartridge Optional Cut Sheet Paper Input Cassette Control Panel Developing Unit Waste Toner Recovery Unit 10) Transport Unit 11) Smoke Filter Box 12) Flash Lamp Power Supply Figure 3: Front View with Front Covers Removed...
Page 26 Chapter 1 Safety Label Locations And Printer Views Legend: Power Switch Serial Port Diagnostic Port General Purpose I/O Port Optional Coax/Twinax Port Parallel Port/Optional Ethernet Port Figure 4: Rear Cover...
Page 27: About The Printer
Ethernet™ network adaptor (optional) • Coax/Twinax interfaces (optional) • Power stacker (optional) Emulations Your printer comes equipped with the Printronix emulation software (which emulates an impact printer). Printronix LinePrinter Plus includes the following printer protocols: • P-Series • P-Series XQ •...
Page 28: Fonts And Forms
Proprinter ® • Epson FX-1050 Printronix LinePrinter Plus provides portrait and landscape image orientation. Automatic 1-up, 2-up, 4-up, and gray bar overprinting are also provided. The emulation also offers optional proportional (scalable) fonts. The following optional emulations are also available: ®...
Page 29: Initial Setup
The installation and setup of your printer is intended to be done by a service provider who has been trained and authorized by Printronix. Your service provider is also responsible for doing a preinstallation site survey, unpacking the printer, connecting the power and host data cables, and installing the first set of consumable items in the printer.
Page 30: Loading Paper
(without ragged edges or paper chaff). NOTE: If the printer runs out of paper during printing, you do not need to turn off printer power to replace paper. If you leave the power on when you replace the paper then place the printer online, it will resume printing automatically where it left off.
Page 31 3. Pass the leading edge of the paper between the lower paper guides, as shown in the illustration below. Legend: Tractor Unit Lower Paper Guide First paper fold is toward printer Loading Fanfold Paper...
Page 32 Chapter 2 Loading Paper Legend: Tractor Pins Tractor Gate Tractor Lock 4. Unlock only the right tractor by pushing forward on the tractor lock. 5. Open the left and right tractor gates and place the paper about half-way onto the tractor pins. IMPORTANT Do not push the paper past the tractors into the area of the paper jam sensor.
Page 33: Loading Cut Sheet Paper
To change the paper output tray selection, see the Cut Sheet Output option on the Paper Control menu, page 100. NOTE: If the printer runs out of paper during printing, you need not turn off the printer to replace paper. If you leave the power on when you replace the paper and place the printer online, it will resume printing automatically where it left off.
Page 34 Chapter 2 Loading Paper To load cut sheet paper, do the following steps: 1. Pull out the paper cassette and remove its cover. 2. Load the new paper uniformly in the cassette, making sure the leading edge of the paper is at the front of the cassette. Do not load more paper than specified below, otherwise a paper jam may occur.
Page 35: Changing Cassette Paper Size
3. Cover the cassette and insert it into the printer, making sure it is completely seated. If the cassette is not seated, a paper jam may result. 4. If you are reloading paper following a “CUT-SHEET PAPER EMPTY” message with the printer power on, press ONLINE to place the printer online.
Page 36 (as shown in the table that follows). When the plastic inserts in the cassette contact the paper size sensors on the printer, the printer determines that the paper cassette is in position and identifies the paper size.
Page 37: Cut Sheet Tray Linking
Cut Sheet Tray Linking If your printer is equipped with the cut sheet paper feed option, you can use Tray Linking. Tray Linking is disabled by default. With Tray Linking enabled, when the active cut sheet paper tray runs out of paper, the printer automatically switches to the other paper tray and continues printing.
Page 38: Variable Tray Sizes
If you are using the Custom Tray Width feature, use the control panel to adjust the width of the image in the printer to match your nonstandard width paper. To set a custom tray width, see Variable Tray Width on the Paper Control menu, on page 96.
Page 39: Variable Tray Length
Variable Tray Length If your printer is equipped with the cut sheet paper feed option, it is possible to override the standard cut sheet paper tray lengths. This feature is called Custom Tray Length. The standard cut sheet paper tray sizes are listed in the table on page 37. Using Custom Tray...
Page 40: Powering On The Printer
60 Hz power source, as shown on the rear panel label. Using an incorrect power source may damage the printer. 1. Turn on the printer by setting the power switch to | (on). 2. Note that when you power on the printer, the following occurs: a.
Page 41: Power Paper Stacker
NOTE: The printer can be set to power on in the OFFLINE state instead of the ONLINE state. To print, ONLINE must be lit; if it is not, press ONLINE. If other messages and prompts appear on the control panel, answer the prompts and follow the directions as explained in Table 6, “Error Messages,”...
Page 42: Parts Of The Power Stacker
Chapter 2 Power Paper Stacker Parts Of The Power Stacker The front (output side) of the power stacker is shown in the following figure. Legend: AUTO Key STOP Key DOWN Key HEAVY Key Hook Head/Tail Length Measuring Gauge (in inches) Safety Stop Bar (not visible in figure) Elevator Top/Bottom Adjust Knob...
Page 43: Stacker Operation Keys
• STOP: Stops the elevator, and displays the message “STACKER NOT READY” on the printer control panel. The STOP key may be used to stop the elevator from lowering after pressing the DOWN key.
Page 44: Setting The Stacker Page Length
(See the Paper Control menu on page 96.) Removing Paper 1. After a print job, press the PAGE EJECT key on the printer control panel. 2. Tear the paper at the perforation. 3. Press the DOWN key on the stacker to lower the elevator.
Page 45: Stacker Full
(LED is not lit). This key is only active in STOP mode and when there is no paper in the stacker. 7. If the printer reports an error which requires the paper path to be cleared, be sure to reload the paper with the first perforation facing inward (see page 30).
Page 46: Using The Control Panel
(See the Paper Control menu on page 96. Also see “Reprinting Pages after Fault Condition on page 223.) 8. Press the ONLINE key on the printer control panel, to place the printer online. Using The Control Panel...
Page 47: Liquid Crystal Display (Lcd)
JOB IN PROCESS lights continuously. JOB IN PROCESS does not light when the printer is not processing data, no data exists in the buffer, and the printer is not receiving data. STAND BY...
Page 48: Function Keys
Using The Control Panel ONLINE ONLINE is lit continuously when the printer is online (when the printer is ready to print and accept data from the host). It flashes when the printer is offline or when the printer stops because of an error.
Page 49: Clear Key
See Chapter 3 for more information. TEST Key When the printer is offline, you can run a test print, as configured under the Test Print menu (page 96), by pressing the TEST key. To stop the test print, press TEST again.
Page 50: Page Eject Key
When the JOB IN PROCESS status indicator lights steadily, pressing PAGE EJECT causes the printer to print all data in the printer. The page is then cut at the perforation (unless the Burst On Eject option is disabled). When the JOB IN PROCESS status indicator flashes, pressing PAGE EJECT causes the printer to attempt to print any data in the buffer.
Page 51: Cancel Key
CANCEL Key The CANCEL key performs the following functions when the printer is offline: • Cancels the current page in process • Cancels any pages queued to print but not yet printed • Cancels any input data not yet processed •...
Page 52 Chapter 2 Using The Control Panel...
Page 53: Printer Configuration
Unlocking And Locking The Configuration Menu In order to configure the printer with the control panel, you need to unlock the ENTER key, which is locked by default. The locked state secures your configuration, preventing alteration.
Page 54: Unlocking The Configuration Menu
3. From this point, either print or modify your current configuration. Locking The Configuration Menu Step 1. At any place within the menu, you can lock the ENTER key. 2. Place the printer online. The second line of the LCD varies, depending on the emulation. Press LCD Message...
Page 55: Moving Within The Configuration Menu
The example shown configures the printer for a form length of 12 inches. Follow these guidelines to move through all of the...
Page 56 Chapter 3 Moving Within The Configuration Menu Paper Control Image Width Form Length 1.0 inches 2.0 inches 1.5 inches 2.1 inches 2.0 inches 2.2 inches 2.5 inches 2.3 inches 3.0 inches 2.4 inches 14.6 inches* 11.0 inches* 14.7 inches 24.0 inches 30.0 inches * equals factory default value Press:...
Page 57: Printing The Current Configuration
Control menu until you reach Print Config. 5. Select Print Config. 6. Select the current option. 7. The STAND BY light flashes, and the printer prints the specified configuration. 8. Lock the ENTER key. 9. Place the printer online. Printing The Current Configuration...
Page 58: Factory Settings
Factory Settings The configuration defaults set at the factory are listed below. These values are available for loading at any time, and are maintained in the printer until a new configuration is loaded. Table 1. Factory and Configuration Parameters Config. Control...
Page 59 Table 1. Factory and Configuration Parameters Menu Item TOF Action Buffer Size In K Dataproducts Data Bit 8 PI Ignored Data Polarity Resp. Polarity Latch Data On Prime Signal TOF Action Buffer Size In K Serial Interface Type Data Protocol Baud Rate Word Length Stop Bits...
Page 60 Chapter 3 Moving Within The Configuration Menu Table 1. Factory and Configuration Parameters Idle Response One Char Enquiry IEEE 1284 Prime Signal TOF Action Buffer Size in K Ethernet Buffer Size in K Auto Switching Parallel Hotport Port Type Trickle Time Time Out Report Status Serial Hotport...
Page 61 Table 1. Factory and Configuration Parameters Menu Item MAC Address Novell Protocol NetBIOS Protocol Novell Frame PPM Port Number PPM Port Timeout Paper Control Paper Selection Fanfold Options Image Width Form Length Paper Length Fanfold Output Burst on Eject No Back Feed Cut Sheet Options Cut Sheet Output Tray Linking...
Page 62 Chapter 3 Moving Within The Configuration Menu Table 1. Factory and Configuration Parameters Vertical Image Shift Toner Reprint on Fault Paper Type Reset Toner Full Miscellaneous Panel Key Sound Alarm Power-up State Hex Dump Mode PTX Setup Option Set Up Parse Set Up SFCC Display Language File System...
Page 63: Changing Printer Configurations
Bold Chars. Extra Bold Char. Changing Printer Configurations In order to properly configure the printer, it is important that you have a current configuration printout, as described previously. From this printout, determine which parameters you need to change for the printer to operate correctly with the host computer, or your specific applications.
Page 64 Chapter 3 Moving Within The Configuration Menu Step 4. Select the menu to access available parameters or submenus. 5. Scroll through the parameters until you reach the one you want. 6. Select this submenu parameter to access the value options. 7.
Page 65: Saving Configurations
IMPORTANT If you do not save your configuration, all of the new values will be lost when you turn off the printer. You can save up to eight different configuration sets to meet eight unique print job requirements. For example: Config.
Page 66 NOTE: If the “Protect Config.” option is enabled, the new configuration is not saved unless the existing configuration has been deleted. Step 1. Place the printer offline. 2. Unlock the ENTER key. 3. Select the Config. Control menu. 4. Scroll through the Config.
Page 67 Step 8. Lock the ENTER key. 9. Place the printer online (LCD depends on printer emulation). NOTE: If you want to make the new printer configuration active at power-up, select this configuration as the “Power-Up Config.” Saving Configurations Press LCD Message Save Config.
Page 68: Configuration Menus
The following pages describe the configuration menus and their options. For details on a particular menu, see the specified page. Config. Control Active Emulation* (page 69) (page 73) Load Config. Line Printer+ Save Config. IGP/PGL Print Config. IGP/VGL Delete Config. PCL5 Power-up Config.
Page 69: Config. Control Menu
Configs. Names Load Configuration The printer can store numerous configurations. This option allows you to select and load a specific configuration. The factory default for loading is configuration 0. Note that configuration 0 is a factory-preset configuration that cannot be changed and is always available for loading.
Page 70 NOTE: If the “Protect Save CFG” option is enabled, the new configuration is not saved unless the existing configuration has been deleted. Print Configuration Print configuration allows you to output a listing of various stored printer configuration parameters. You can print the following configurations: • Current •...
Page 71 Power-up Configuration Power-up configuration allows you to specify one of nine (0-8) configurations to be used upon printer power-up. The factory default for power-up is configuration 0. Protect Configs The Protect Configs (protect saved configuration) option allows you to specify whether or not a new configuration should “overwrite”...
Page 72 Continue until you have entered the name you want to give to this configuration, then press ENTER to save. The name you entered will now represent this configuration on the printer’s front panel. To exit this menu without saving, press any key other than the ENTER key.
Page 73: Active Emulation (If Installed)
There are two methods for selecting the desired emulation. The first is by selecting the emulation directly from the printer menu. The second is by sending a host command which will switch the emulation automatically (see the appropriate Programmer’s Reference Manual for details).
Page 74: Mode Menu
“Mode” refers to the emulation software that you use. Your printer comes equipped with the Printronix LinePrinter Plus emulation software (which emulates an impact printer). The IGP/PGL, IGP/ VGL, IPDS, CTHI, and PhoenixPage PCL5 software emulations are available as options.
Page 75: Host Interface Menu
When you turn on the printer, it reads the Flash memory as part of its initialization, to determine what emulations are installed. Based on this information, the printer then creates the appropriate selections on the Mode menu. During power-up, the printer also loads the power-up set of configuration values.
Page 76: Centronics Parameters
Enable. Ignores the PI signal and treats the data as characters or control codes • Disable. Causes the printer to interpret the eight data lines as VFU commands when the PI signal is true. = Factory Default = If installed...
Page 77 Data Polarity The Data Polarity parameter must be set to match the data polarity of your host computer. • Standard. Does not expect the host computer to invert the data. • Inverted. Expects the data received on the data lines from the host computer to be inverted.
Page 78 Chapter 3 Host Interface Menu TOF Action • Reset. A form feed is performed before a warm start when the Prime Signal is asserted from the host. This setting is only used if the Prime Signal parameter is enabled. • Do Nothing.
Page 79: Dataproducts Parameters
• Enable. Ignores the PI signal and treats the data as characters or control codes • Disable. Causes the printer to interpret the eight data lines as VFU commands when the PI signal is true. Dataproducts Parameters = Factory Default...
Page 80 Chapter 3 Host Interface Menu Data Polarity The Data Polarity parameter must be set to match the data polarity of your host computer. • Standard. Does not expect the host computer to invert the data. • Inverted. Expects the data received on the data lines from the host computer to be inverted.
Page 81 TOF Action • Reset. A form feed is performed before a warm start when the Prime Signal is asserted from the host. This setting is only used if the Prime Signal parameter is enabled. • Do Nothing. Nothing occurs before a warm start when the Prime Signal parameter is asserted.
Page 82: Serial Parameters - Rs-232 & Rs-422
FF Hex Data Protocol The Data Protocol parameter allows you to select the software flow control protocol used for communications between the printer and the host computer. You can also turn off software flow control. = Factory Default = If installed...
Page 83 ETX/ACK The ETX/ACK protocol enables the flow of communication to the printer by sending a block of data, and ending the block with an End of Text (ETX) signal. When the printer receives the ETX signal, it acknowledges the signal, thereby indicating it has received the entire block of data.
Page 84 Online State Online Offline With the SERIES 1, 1 CH protocol selected, if the printer receives a Series 1 poll character from the host, the printer removes the poll character from its input data stream and discards it. After a delay, called the poll delay, the printer replies to the host by sending the appropriate response character, per the preceding table.
Page 85 If there is enough room in the printer buffer, the printer will send a high signal; if the buffer is full, the printer will send a low signal. DTR tells the host if it is safe to send more data. (If the host sends data during an unsafe condition, data will be lost.) DTR is not...
Page 86 Host Interface Menu Baud Rate Sets the baud rate of the serial interface in the printer. Baud rate is the speed at which serial data is transferred between the host computer and the printer. The choices for the RS-232 and RS-422 interfaces are 600, 1200, 2400, 4800, 9600, 19,200, 38,400, 57,600, 115,200 Baud.
Page 87 This parameter determines when the printer generates the Request to Send (RTS) signal to the host computer. RTS is a status signal that the printer sends to the host to indicate whether or not the printer is ready to receive data.
Page 88 Msec. This parameter selects the Series 1 delay time, in milliseconds, that the printer waits prior to sending the Series 1 response to the host. NOTE: This parameter is used only with the SERIES 1, 1 CH and SERIES 1, 2 CH protocols. See the description of the Data Protocol menu option on page 83 for more information.
Page 89 Serial Parameters - RS-232 & RS-422 One Char Enquiry The One Char Enquiry mode uses the Poll Character to detect a request from the host and sends a response back to the host. This option also allows you to turn this feature on and off. The default is disabled.
Page 90: Ieee 1284 Parallel Parameters
Chapter 3 Host Interface Menu IEEE 1284 Parallel Parameters Host Interface Centronics Dataproducts Serial The IEEE 1284 interface is faster and more versatile than that of the Centronics interface and supports bidirectional communication. Configuration of this interface is controlled from the host. Prime Signal •...
Page 91: Ethernet Submenu
Interface Centronics Dataproducts Serial The Ethernet interface allows you to locate the printer on a LAN rather than attach the host directly into the printer. The detailed configuration of this option is given in the PrintNet User’s Manual . Buffer Size In K This option configures the amount of memory allocated for the Ethernet buffer.
Page 92: Ethernet Parameters (If Installed)
Novell signals. See the Novell chapter in the PrintNet User’s Manual for more details. If the printer is connected to a Printer Manager utility, the PPM Port number and PPM Port Timeout settings must match the settings in the Printer Manager program.
Page 93: Auto Switching Parameters
Auto Switching Parameters Host Interface Centronics Dataproducts Serial Parallel Hotport Port Type Trickle Time Timeout 10 sec.* 1/4 sec.* Centronics* (1-60) 1/2 sec. Dataproducts 1 sec. IEEE 1284 2 sec. Ethernet 4 sec. Disable 8 sec. 16 sec. C/T Hotport Port Type Trickle Time Timeout...
Page 94: Auto Switching
Parallel Hotport menu, RS-422 under the Serial Hotport menu. Trickle Time When the printer is printing data from a host and a second job is received by the printer from a different host, Trickle Time prevents the second host from timing out while it is waiting for its data to be printed.
Page 95: Report Status
Timeout This is the value used by the printer to time out from the current port and check the other selected Port Types for data to print. When the printer has not received data from the host after a certain period of time, it needs to Timeout in order to service the other ports.
Page 96: Paper Control Menu
Chapter 3 Paper Control Menu Paper Control Menu Paper Control Menu Paper Control Paper Fanfold Selection Options Fanfold* Form Length Image Width Upper Tray Lower Tray 2.0 inches Inch Select* 2.1 inches 2.2 inches Length in 14.6 inches* Inches* 14.7 inches 1.0 inches 1.5 inches 2.0 inches...
Page 97 Cutsheet Options Cut Sheet Tray Linking Output Face Down* Disable* Face Up Enable Hor. Image Ver. Image Shift Shift -100/100 inches -100/100 inches -99/100 inches -99/100 inches -98/100 inches -98/100 inches 0/100 inches* 0/100 inches* 100/100 inches 100/100 inches Paper Type Reset Toner Full Standard*...
Page 98 If the form length parameter setting is within the valid range for the paper length parameter, the printer uses the value for both the form length and paper length parameters.
Page 99 If the form length parameter is outside the valid range for the paper length parameter, the printer finds a multiple or divisor of the form length parameter closest to 11 inches. For example, a form length parameter setting of 10 inches...
Page 100 Cut Sheet Output specifies which output tray is used. You may select the face down (default) or face up orientation. The face down tray is located on the top of the printer, the face up tray is located above the optional power stacker.
Page 101 If the cut sheet trays are of different sizes, and Tray Linking is enabled, the printer will not switch to the alternate tray when the first tray runs out of paper. The printer also will not display the usual “CUT-SHEET PAPER EMPTY”...
Page 102 Also, you cannot modify the length for a standard cut sheet tray. The length depends on the cassette paper size and is recognized by the printer using the paper size detector sensors. Horizontal Image Shift Horizontal Image Shift specifies the amount to shift an image to the right for precise positioning on the page.
Page 103 Paper Type Paper Type allows you to set the printer for either standard or synthetic paper. The default is Standard; use this setting for most types of media. Use the Synthetic setting for special types of media such as plastic cards.
Page 104: Miscellaneous Menu
Etc. Miscellaneous Menu Panel Key Sound Panel key sound allows you to configure the printer to beep when you press a key (switch). The default setting is On. Alarm Alarm allows you to configure the printer to beep when a printer fault condition occurs.
Page 105 The default setting is Online. Hex Dump Mode Hex dump mode allows you to place the printer into the “hex dump” mode, in which the printer outputs a hexadecimal data stream. The purpose of hex dump mode is to see exactly what data is received by the printer, in order to debug forms, for example.
Page 106 Chapter 3 Miscellaneous Menu If a fault occurs while printing a hex dump, the printer reverts to the normal fault state. When the fault is cleared, the printer resumes printing the hex dump (either a partial line with a form feed, or nothing at all).
Page 107 Optimize And Reboot Reclaims flash space from deleted flash files. After pressing ENTER, wait for the printer to reboot. Print File List Prints a summary of the files stored in flash memory and several...
Page 108: Font Memory Menu (Not In Pcl5 Emulation)
“Saving Configurations” on page 65. 2. Change the power-up configuration to match the configuration you just saved. See the Config. Control menu option “Power-up Configuration” on page 69. 3. Turn the printer power off and then on again. Standard Bold Chars. Extra Bold Chars.
Page 109 The font cache stores bitmaps that are created on demand from the font outlines stored in Flash memory. The cache allows the printer to print scalable fonts at optimum speed.
Page 110: Test Print Menu
Chapter 3 Font Memory Menu (Not In PCL5 Emulation) Bold Chars. The Bold chars option specifies the thickness or stroke weight of the text fonts. The allowable range is 0 to 512, in increments of 1. Extra Bold Chars. Default is 448. Extra Bold Char.
Page 111: Print Statistics Menu
Printer Life Printer Life displays the total number of hours that the printer has been powered up, the total number of pages that have been printed by the print engine, and the total number of pages that have been printed for each of the service levels.
Page 112: Maintenance Menu
Chapter 3 Print Statistics Menu Maintenance Menu Maintenance User Maint. Clear Level A Clear Level B Clear Level C The Maintenance menu provides access to information about service levels for end-users and service technicians. User Maint The User Maintenance option resets the service level page count after you complete preventive maintenance (levels A, B, and C).
Page 113: Loading Flash Memory
Emulation software and fonts are supplied on one or more 3.5 inch, diskettes. Each emulation file is “executable,” which means you can expand it and copy it into the printer’s flash memory with a single command. The other kinds of files are not executable; however, before they can be downloaded, you might need to convert them into downloadable format.
Page 114: The Cnvt2Fls Utility Program
Chapter 3 Loading Flash Memory The CNVT2FLS Utility Program The CNVT2FLS program is a DOS utility that is supplied with the flash software on diskette. This utility converts logo, form, TIFF, setup, and font files into downloadable format. To convert files into downloadable format, do the following: 1.
Page 115 . The file named file_name2 is a flash downloadable file that can be copied and downloaded to the printer, as detailed later in this section. The utility takes the filename you specify for file_name3 and stores this information within the downloadable output file ( file_name2 ).
Page 116 Chapter 3 Loading Flash Memory 6. Repeat step 5 for any additional font files to be converted. 7. To convert a setup file, enter the following at the DOS prompt, for example: CNVT2FLS setup.ptx setup.dwn setup.ptx A <Return> where setup.ptx is the name of one of the setup files you want to convert.
Page 117: Downloading Into Flash Memory
NVRAM. 4. Set the printer power switch to O (off). 5. If the printer is already connected to the parallel port of an IBM- compatible computer that is using the PC-DOS™ or MS-DOS operating system, skip to step 11. If not, continue with step 6.
Page 118 9. Connect the parallel data cable to the parallel port of the printer. 10. Plug the printer AC power plug into its electrical outlet. 11. Power on the computer. 12. Set the printer power switch to | (on).
Page 119 Downloading Into Flash Memory 19. Get the name of the compressed emulation file on the diskette by typing the following at the DOS prompt: DIR A: <Return> (If the diskette is in drive B, type B: <Return>) The file name of the compressed file on the diskette takes the form part_num .zip, for example 123456.zip.
Page 120 .exe, for example 123456.exe. Write down the complete name of the file with the .exe extension. This is the file you will download into the printer. 31. On the printer control panel, press and hold down the ONLINE+CLEAR keys. Without releasing the keys, power the printer on.
Page 121 DOS command, for example: 123456.exe -pb2 <Return> 34. While the file is being copied into memory, the printer LCD informs you of the load process and status. (Messages are listed in the table on page 228.) 35.
Page 122 .dwn Write down the complete name of each file with the .dwn extension. 44. Download the files to the printer by using the DOS copy command. Enter the following at the DOS prompt, for example: copy /b file_name1.dwn+file_name2.dwn+... LPT1 <Return>...
Page 123: Flash Messages
54. Reconnect the customer’s data input cable(s) to the printer, if required. 55. Plug the printer AC power plug into its electrical outlet. 56. Set the printer power switch to | (on). If the printer is on line, press the ONLINE key to place the printer offline. Press the >...
Page 124 ERROR: FLASH The printer encountered an DID NOT PROGRAM error while trying to program the DC flash memory. ERROR: FLASH The printer could not find any NOT DETECTED DC flash memory. ERROR: NO DRAM The printer could not find any DETECTED DC DRAM.
Page 125 ERROR: PROGRAM The downloaded program is not NOT COMPATIBLE compatible with the printer. ERROR: PROGRAM The printer did not detect an NOT VALID emulation program in DC flash memory, or the emulation program in DC flash memory is present but corrupted.
Page 126 Power off the printer and download the program again. Enable the “Overwrite Files” menu selection.
Page 127 DC flash memory. FILE SYS WRITE One or more errors occurred CHECK FLASH while the printer was writing a file into the flash file system. The printer has marked the corrupt file for deletion. The cause can be data that became...
Page 128 RAM. xx indicates how much of the program has been downloaded. LOADING PROGRAM The printer has deleted the old INTO FLASH program from the flash file system, and is now writing the new program into the flash file system.
Page 129: Consumables Replacement
Note 2: Replace at 300,000 pages or sooner if print quality is no longer acceptable. Drum life is dependent upon media used and proper maintenance and operation of the printer. Print media other than bond paper (e.g. labels, card stock, plastic, or vinyl) may reduce drum life by as much as 50%.
Page 130: Replacing The Toner Cartridge
Vinyl gloves may be worn to prevent toner from contacting the skin. If necessary, use only cold water to remove toner from skin or clothing. Opening The Front Cover 1. Take the printer offline. 2. When paper motion stops, wait 15 seconds, then open the printer front upper cover. Legend:...
Page 131 3. Rotate the old toner cartridge counterclockwise until the notch is aligned with the pin in the toner hopper, and remove the cartridge. Legend: Notch Toner Cartridge Positioning Pin 4. Put the old cartridge into a plastic bag and discard it. 5.
Page 132 Chapter 4 Consumables Replacement 6. Remove the new toner cartridge from its package. 7. With the cover tape facing up, begin inserting the cartridge into the toner hopper, and slowly pull off the cover tape in the direction of the arrow. Remove the last of the tape just as the cartridge is completely inside the hopper.
Page 133 Replacing The Toner Cartridge 9. Rotate the cartridge clockwise until it stops. Legend: Toner Cartridge 10. If any toner has spilled, remove it with wet tissue paper or a toner vacuum. 11. Close the front upper cover.
Page 134: Replacing The Waste Toner Bottle
To replace the waste toner bottle, perform the following steps: 1. When paper motion stops, wait 15 seconds, then open the printer front upper cover. (See page 130.) 2. Lower the opening lever, pull the green handle toward you, and open the waste toner recovery unit.
Page 135 Waste Toner Bottle 4. Remove the waste toner bottle from the unit and discard it. 5. Install a new waste toner bottle. 6. Close the printer front cover. 7. Clear Error 28, “WASTE TONER FULL,” as follows: a. Press CLEAR.
Page 136: Replacing The Photoreceptor Drum
Consumables Replacement Replacing The Photoreceptor Drum Drum life depends on media used and proper maintenance and operation of the printer. Print media other than bond paper (e.g., labels, card stock, plastic, or vinyl) can reduce drum life as much as 50%.
Page 137 Replacing The Photoreceptor Drum 3. Open the waste toner recovery unit by pushing downward on the lever. Pull the green handle and swing the unit outward away from the printer. Legend: Waste Toner Recovery Unit Green Handle Opening Lever...
Page 138 Chapter 4 Consumables Replacement 4. Loosen the three thumbscrews on the upper inner cover. Then remove the cover. Legend: Thumbscrews (3) Upper Inner Cover CAUTION Failure to do the next step will damage the photoreceptor drum. 5. Rotate the developing unit lever fully clockwise so that it is pointing straight up (to separate the developing unit from the photoreceptor drum).
Page 139 Replacing The Photoreceptor Drum 6. Remove the developing unit by holding the lever in one hand and pulling the developing unit partially out of the printer. Legend: Hanger 7. With the other hand, grasp the hanger and remove the developing unit from the printer.
Page 140 Chapter 4 Consumables Replacement CAUTION The transfer charger must be in the down position to avoid scratching the drum. Failure to perform steps 9 and 10 will damage the drum. 9. Rotate the transfer elevator drive shaft counterclockwise. Watch the charger movement: a.
Page 141 Replacing The Photoreceptor Drum 10. Lower the transport unit by turning the green lever on the transport unit to the left. Legend: Green Lever 11. Loosen the three thumbscrews securing the drum plate and remove the drum plate.
Page 142 Chapter 4 Consumables Replacement 12. Remove the two screws on the lower inner cover. Then remove the cover. Legend: Drum Plate Thumbscrews (3) Screws (2) Lower Inner Cover 13. Remove the nut from the end of the drum shaft. Legend:...
Page 143 Drum Auxiliary Rod 15. Carefully pull the old drum outward along the drum auxiliary rod. Hold the front and back sides when the drum is nearly out of the printer, and remove it with both hands. Legend: Drum 16. Pack the old drum for shipment using the original packaging...
Page 144 The drum must rest on the rubber rollers to avoid being scratched. 21. When the drum is fully inserted into the printer, the end of the drum will be slightly recessed relative to the front of the printer. At this point, the rubber guide rollers should be visible. Slightly...
Page 145 Failure to lock the drum in place properly may cause severe damage to the printer. Never force the drum onto the shaft. If it feels as though the drum is not seating properly, remove the drum and inspect the shaft for any foreign material or burrs.
Page 146: Proper Disposal Of A Drum Unit
Chapter 4 Consumables Replacement Proper Disposal Of A Drum Unit Federal regulations prohibit inappropriate disposal of laser print drums. Dispose of used drums by shipping them to one of the following organizations: Within U.S.A. U.S. Fuji Electric Inc. 240 Circle Drive N. Piscataway, NJ 08854 Attn: Rod Storm Phone: (732) 560-9410...
Page 147: Removing The Developing Unit
(If damage occurs, contact your service representative.) 1. Turn the power switch OFF. 2. Open the printer front upper cover. 3. Open the waste toner recovery unit by pushing downward on the opening lever. Pull the green handle and swing the unit outward away from the printer.
Page 148 Chapter 4 Consumables Replacement 4. Remove the three thumbscrews and the upper inner cover. Legend: Upper Inner Cover Thumbscrews (3)
Page 149 CAUTION Failure to do the next step will damage the photoreceptor drum. 5. Rotate the developing unit lever fully clockwise so that it is pointing straight up (to separate the developing unit from the photoreceptor drum). Legend: Lever Removing The Developing Unit...
Page 150 Consumables Replacement 6. Remove the developing unit by holding the lever in one hand and pulling the developing unit partially out of the printer. 7. With your other hand, grasp the hanger and remove the developing unit from the printer.
Page 151: Replacing Or Adding The Developer
Replacing Or Adding The Developer Legend: Toner Cartridge Toner Hopper Auger Toner Sensor Developing Tank Developing Roller Toner Supply Roller Screws (3) Cover 10) Developing Unit Replacing Or Adding The Developer Cross Section of Developing Unit...
Page 152 1. Prepare a plastic bag in which the developing unit can be placed and place the developing unit in the plastic bag. 2. Remove the developing unit from the printer. (See figure below.) 3. If you are replacing the developing unit, dispose of the old unit properly, and go to step 10.
Page 153 5. Remove the three screws on the developing unit cover and remove the cover. CAUTION The toner sensor is sensitive to both electrostatic discharge (ESD) and positional adjustment. Do not touch the sensor with your hand or jar it from its factory-set position. 6.
Page 154 Chapter 4 Consumables Replacement 9. Vacuum the toner from the toner spray-guard brush on the developing unit. 10. Shake the new developer bottle several times, remove the bottle cap, and screw the nozzle tightly onto the bottle. 11. While rotating the developing roller knob counterclockwise, evenly pour the entire bottle of developer powder into the developing unit.
Page 155: Installing The Developing Unit
Installing The Developing Unit CAUTION Failure to perform the next step will damage the photoreceptor drum. 1. On the developing unit, rotate the lever fully clockwise so that it is pointing straight up. 2. Holding the lever in one hand and the hanger in the other hand, insert the developing unit on the guide rail.
Page 156 Chapter 4 Consumables Replacement 3. Rotate the hanger to the right so that it rests against the developing unit, and push the developing unit in. 4. Rotate the developing roller knob counterclockwise until the unit drops into its final resting position. The positioning pin should protrude through the main body of the developing unit.
Page 157 5. Rotate the developing unit lever fully counterclockwise to lock the developing unit in place. Legend: Positioning Pin Lever Developing Roller Knob Installing The Developing Unit...
Page 158 Chapter 4 Consumables Replacement 6. Install the upper inner cover, and secure it with the three thumbscrews. Legend: Upper Inner Cover Thumbscrews (3) 7. Close the waste toner recovery unit and ensure that it latches. 8. Close the printer front cover.
Page 159: Scheduled Maintenance
Scheduled Maintenance Scheduled Maintenance In order to perform user maintenance on the printer, you need the following tools: Brush Cleaner Drum Auxiliary Rod Drum Freshener Pad Fuser Cover Glass Scraper Special Dry Tissue Paper Standard Toner Vacuum Cleaner Toraysee Cloth...
Page 160: Service Level Page Counts
Maintenance log sheets are provided in Appendix A. These may be photocopied and kept in a binder near the printer. Be sure to use them each time either you or your service provider perform printer maintenance.
Page 161: Clearing Service Level Messages
At 900,000 pages, your service provider must do Level F, Level E, and Level D service. Service level messages will not cause the printer to stop printing. When one of the above messages appears, do the appropriate scheduled maintenance or call your factory-trained service representative to do the maintenance.
Page 162: Maintenance
Chapter 5 Maintenance Maintenance User Cleaning Schedule Do the actions in the table below after the specified number of letter size pages (4% coverage) have been printed. Action General cleaning Clean the chargers Clean cover glass Clean cut sheet cassette pickup rollers and reverse rollers Major cleaning...
Page 163: User Replacement Schedule
Note 2: Replace at 300,000 pages or sooner if print quality is no longer acceptable. Drum life is dependent upon media used and proper maintenance and operation of the printer. Print media other than bond paper (e.g. labels, card stock, plastic or vinyl) may reduce drum life by as much as 50%.
Page 164 Chapter 5 Maintenance Level D Maintenance - 300,000 Pages Maintenance Kit, Level D, L5535 • Main charger • Precharger • Transfer charger • Smoke filter Item Part Number 706802-001...
Page 165 Level E Maintenance - 600,000 Pages Item Maintenance Kit, Level E, L5535 • Main charger • Precharger • Transfer charger • Smoke filter • Cleaning unit • Halogen lamp • Transport belt (set of 3) • Cutter motor User Replacement Schedule...
Page 166 Chapter 5 Maintenance Level F Maintenance - 900,000 Pages Maintenance Kit, Level F, L5535 • Main charger • Precharger • Transfer charger • Smoke filter • Xenon (flash) lamp 706809-001...
Page 167 Level G Maintenance - 1,200,000 Pages Item Maintenance Kit, Level G, L5535 • Main charger • Precharger • Transfer charger • Smoke filter • Cleaning unit • Halogen lamp • Transport belt (set of 3) • Cutter motor • Trigger coil unit...
Page 168 Chapter 5 Maintenance Level H Maintenance-2,400,000 pages Maintenance Kit, Level H, L5535 • Main charger • Precharger • Transfer charger • Smoke filter • Cleaning unit • Halogen lamp • Transport belt (set of 3) • Cutter motor • Trigger coil unit •...
Page 169 Table 5. Parts The Service Provider Replaces Item Part # Main charger 705741-001 Precharger 705742-001 Transfer charger 705743-001 Smoke filter 703540-001 Flash power supply filter LED air filter 703543-001 Lamp housing filter 202838-001 Cleaning unit 705740-001 Transporting belt-3 703531-035 Xenon lamp 703541-001 Main charger 705741-001...
Page 170 Chapter 5 Maintenance Table 5. Parts The Service Provider Replaces Item Part # LED for discharge lamp 703531-561 EPS1 Sensor Lever 703531-585 EPS3 Sensor Lever 703531-588 EPS4 Sensor Lever 703531-067 Note 1: When the cleaning unit has been vacuumed every 150,000 pages and has been used under nominal operating conditions, it must be replaced at 600,000 pages.
Page 171 User Replacement Schedule AVVERTENZA Il condensatore dell’unitá fusore deve essere sostituito almeno ogni 2.400.000 pagine in fprmato lettera. La mancata sostituzione puó causare lesione al personale e danni all’apparecchiatura. CAUTION Due to the high temperature of the flash fusing unit, keep the area under the fuser free of paper debris.
Page 172: General Cleaning
General Cleaning General Cleaning General Cleaning For best print quality, clean the printer according to the schedule in Table 3, page 162. Depending upon the density of your print jobs, the printer may require cleaning every 10,000-20,000 sheets. Vacuuming The Printer Following is the general cleaning procedure: 1.
Page 173 Vacuuming The Printer 4. On the waste toner recovery unit, press the Open lever down. Pull the handle toward you and open the unit. 5. Vacuum the developing unit and toner hopper.
Page 174 Chapter 5 General Cleaning 6. Vacuum the cleaning unit. 7. Vacuum the fuser unit.
Page 175 Vacuuming The Printer 8. Vacuum the lamp housing filter on the underside of the fuser unit.
Page 176 Chapter 5 General Cleaning CAUTION The transfer charger must be in the down position to avoid scratching the drum. Failure to perform steps 9 and 10 will damage the drum. 9. Rotate the transfer elevator drive shaft counterclockwise. Watch the charger movement: a.
Page 177 15. After cleaning, return the transport unit to its original position (push it into the printer while holding down the green lever). When the transport unit is in position, raise the green lever to the right to raise the transport surface.
Page 178 Chapter 5 General Cleaning 16. Using a vacuum, clean the toner, paper dust, etc. in the tractor area. Legend: Tractor 17. Open the paper guide by pressing the green lever down. Legend: Paper Guide Green Lever...
Page 179 Vacuuming The Printer 18. Open the lid on the top cover. 19. Open the paper guide by pressing the guide lever down. 20. Using a vacuum, clean the paper dust, etc. inside the paper guide. Legend: Paper Guide...
Page 180: Cleaning The Chargers
Chapter 5 General Cleaning Cleaning The Chargers 1. Turn the power switch OFF. 2. Open the printer front upper cover. 3. Loosen the thumbscrew and remove the main charger by pulling it toward you. Legend: Thumbscrew Main Charger...
Page 181 4. Place the main charger on a flat, clean work surface. CAUTION The charger wires are delicate. Handle the chargers with care. 5. Using the brush cleaner (listed on page 159), clean the exposed side of the charger grid and the body of the main charger to remove paper dust, etc., as shown below.
Page 182 Chapter 5 General Cleaning 6. Position the main charger with the charger grid up and the front end of the charger toward you, as shown in the figure below. Refer to the figure below and the inset drawing in the figure, and remove the charger grid from the main charger as follows: a.
Page 183 7. Using the brush cleaner, clean both sides of the charger grid, as shown below. Legend: Brush Cleaner Charger Grid 8. Using the wire cleaner (listed on page 159), clean the two wires in the main charger, as shown below. Clean both wires thoroughly.
Page 184 Chapter 5 General Cleaning 9. Reinstall the charger grid. 10. Return the main charger to its original position. Fasten the main charger screw to secure it. 11. Open the waste toner recovery unit.
Page 185 12. Loosen the thumbscrews (2), precharger screw and transfer/ separator charger screw, and remove the chargers by pulling them toward you. Legend: Transfer/Separator Charger Thumbscrews Precharger 13. Place the chargers on a flat, clean work surface. 14. Using the brush cleaner and the wire cleaner, clean the chargers by removing the dust and dirt on the wires.
Page 186: Cleaning The Fuser Unit Cover Glass
Attendez qu’elle refroidisse complétement avant de la manipuler. Dopo l’uso, l’unitá fusore é calda. Attendere il completo raffeddamento dell’unitá prima di intervenir sulla medesima. 1. Turn the power switch OFF. 2. Open the printer front upper cover. WARNUNG AVISO ATTENTION AVVERTENZA...
Page 187 CAUTION The transfer charger must be in the down position to avoid scratching the drum. Failure to perform steps 3 and 4 will damage the drum. 3. Rotate the transfer elevator drive shaft counterclockwise. Watch the charger movement: a. If the charger starts to move up, it is already in the down position.
Page 188 6. Grasp the handle and pull out the fuser unit until the second handle is visible. 7. Grasp the second handle with your other hand and remove the fuser from the printer. 8. Place the fuser on a clean, flat surface with the cover glass facing up.
Page 189 CAUTION Do not scratch or place your hands directly on the cover glass. Fingerprints on the cover glass or lamps will cause them to break. 9. Using the fuser cover glass scraper (listed on page 159), remove the dirt and toner buildup on the cover glass surface. 10.
Page 190 Lamp Duct Filter Unit 12. Vacuum the lamp filter, then reinstall it. 13. Vacuum any paper dust from the printer frame. 14. Aligning the guide pins in the screw bracket with the holes in the side frame of the printer, install the fuser.
Page 191: Cleaning The Cut Sheet Option Rollers
NOTE: This procedure only applies to printers with the cut sheet option installed. 1. Turn the power switch OFF. 2. Remove the upper and lower paper cassettes from the printer. 3. There are two pickup roller units (upper and lower) located at the back of the cassette opening.
Page 192 General Cleaning 4. On the upper roller unit, loosen the green thumb screw. Slide the unit to the left, and pull the unit toward you and out of the printer. Legend: Green Thumbscrew 5. On the lower roller unit, loosen the green thumb screw. Slide the unit to the left, and pull the unit toward you and out of the printer.
Page 193 Cleaning The Cut Sheet Option Rollers 7. Install the upper and lower pickup roller units: a. Align the shaft pin with the slot in the coupling, and align the alignment pin on the unit with the hole in the frame. b.
Page 194 Chapter 5 General Cleaning 8. There are two reverse roller units (upper and lower) located at the back of the cassette opening (underneath the upper and lower pickup roller units). Upper Reverse Roller Unit Lower Reverse Roller Unit 9. On the upper reverse roller unit, loosen the green thumb screw. Remove the roller unit by moving it downward while sliding it to the left.
Page 195 Cleaning The Cut Sheet Option Rollers 10. On the lower reverse roller unit, loosen the green thumb screw. Remove the roller unit by moving it downward while sliding it to the left. 11. Wipe off the dirt on the reverse rollers with a Toraysee cloth (listed on page 159).
Page 196 Align the shaft pin with the slot in the coupling, and align the alignment pin on the unit with the hole in the frame. b. Tighten the green thumb screw. Legend: Hole in Frame Shaft Pin Alignment Pin Coupling 13. Install the upper and lower paper cassettes into the printer.
Page 197: Major Cleaning
Major Cleaning Major Cleaning 1. Turn the power switch OFF. 2. Open the printer front upper cover. 3. Open the waste toner recovery unit by pushing downward on the lever. Pull the green handle and swing the unit outward away from the printer.
Page 198 Chapter 5 Major Cleaning 4. Loosen the three thumbscrews on the upper inner cover. Then remove the cover. Legend: Upper Inner Cover Thumbscrews (3)
Page 199 5. Loosen the three thumbscrews securing the drum plate and remove the drum plate. CAUTION Do not turn the cleaning unit upside down, or toner might spill. Do not touch the brush surface with your hand. Legend: Thumbscrews (3) Drum Plate Cleaning Unit Handle 6.
Page 200 Chapter 5 Major Cleaning 7. Vacuum the brush on the cleaning unit. Turn the end of the shaft to rotate the brush. Continue to rotate and vacuum the brush until the entire brush surface is cleaned. Legend: Cleaning Unit Cleaning Unit Handle Brush...
Page 201 8. Remove the discharge LED retaining screw. CAUTION Do not flex the discharge LED as it will break 9. Remove the discharge LED by pulling it toward you. Legend: Discharge LED Screw 10. Using a Toraysee cloth (listed on page 159), wipe off the dirt on the discharge LED.
Page 202: Cleaning The Photoreceptor Drum
• Cleaning the drum may result in stains. A drum left unused in the printer for a long time after cleaning may especially be affected. Therefore, after cleaning and installing the drum in the printer, use maximum size paper to print an image repeatedly until no stains remain.
Page 203 Cleaning The Photoreceptor Drum 4. If the drum contains toner build-up, clean it with the drum freshener pad (listed on page 159). Turn the drum little by little while polishing the drum surface with the freshener pad. Polish with a slight force in the direction of the drum axis, using a circular motion.
Page 204: Cleaning The Developing Unit
Chapter 5 Major Cleaning Cleaning The Developing Unit 1. Loosen the thumb screw and remove the main charger by pulling it toward you. Legend: Thumbscrew Main Charger 2. Clean the developing unit area with a vacuum cleaner and a soft cloth.
Page 205 3. Wipe the SELFOC lens by moving the unused side of a Toraysee cloth from the inner part of the printer toward you. Wipe the lens in this manner several times until there is no more dirt on the cloth.
Page 206 Chapter 5 Major Cleaning...
Page 207: Troubleshooting
2. Clean the main charger, precharger, and transfer charger. For cleaning instructions, see page 180. 3. If the printer is equipped with the cut sheet option, clean the pickup rollers and the reverse rollers inside the cut paper unit, using the Toraysee cloth. For cleaning instructions, see page 191.
Page 208: Diagnostics
Each time the printer is powered on, it performs a power-on self test. There is no printout during this test. However, the printer displays any errors on the control panel, accompanied by an audible alarm.
Page 209: Fanfold Paper Jams
The error message will remain displayed until the error condition is cleared and you press CLEAR. After the error is cleared, the printer will reprint any pages that were not ejected prior to the error, provided the Reprint on Fault option is enabled.
Page 210: Paper Jam Near The Paper Output Section
Chapter 6 Fanfold Paper Jams Paper Jam Near The Paper Output Section 1. When paper motion stops, wait 15 seconds, then open the front cover. 2. Push down on the opening lever of the waste toner recovery unit, and pull the green handle to swing the unit outward. Legend: Green Handle Opening Lever...
Page 211 3. Loosen three thumbscrews on the upper inner cover. Then remove the cover. Legend: Upper Inner Cover Thumbscrews (3) CAUTION The transfer charger must be in the down position to avoid scratching the drum 4. Rotate the transfer elevator drive shaft counterclockwise. Watch the charger movement: a.
Page 212 Legend: Transfer Charger Transfer Elevator Drive Shaft CAUTION To avoid damaging the printer or causing false paper jams, the transport lever must be in the fully down position before opening the transport unit.
Page 213 Paper Jam Near The Paper Output Section 5. Lower the transport unit by turning the green lever on the transport unit to the left. Pull the transport unit toward you until it stops. Legend: Green Lever 6. Check to see if any paper is jammed.
Page 214 Chapter 6 Fanfold Paper Jams 7. To raise the scuff roller holding the paper, turn knob C clockwise 90 as shown below. Legend: Knob C 8. Separate the paper at the perforations on both the paper input and the output sections. Then pull the jammed paper out.
Page 215 Output Section Legend: Tractor Gate CAUTION To avoid damaging the printer or causing false paper jams, the transport lever must be in the fully down position before closing the transport unit. 9. After removing the pieces of jammed paper, restore the transport unit, waste toner recovery unit, and knob C to their original positions, and close the front cover.
Page 216: Cut Sheet Paper Jams
Chapter 6 Fanfold Paper Jams Cut Sheet Paper Jams 1. Pull out the paper cassette. 2. To lower the paper guide, pull the green lever up. Remove any jammed paper, and return the green lever to its original position. Legend: Paper Guide Green Lever...
Page 217: Paper Jam In The Transport Input Section
Paper Jam In The Transport Input Section 3. Open the lid on the top cover, and pull the green lever up. Remove any jammed paper, and return the green lever to its original position. Legend: Top Cover Green Lever Paper Jam In The Transport Input Section 1.
Page 218 2. Open the waste toner recovery unit cover, and swing out the unit. Legend: Green Lever Opening Lever Waste Toner Recovery Unit CAUTION To avoid damaging the printer or causing false paper jams, the transport lever must be in the fully down position before opening or closing the transport unit.
Page 219 Paper Jam In The Transport Input Section 3. To lower the transport route surface, turn the green transport unit lever to the left. Legend: Green Lever 4. Remove knob A from its place as shown below. Attach knob A to the paper feed shaft, and turn knob A counterclockwise. This causes the jammed paper to be moved to the eject side.
Page 220: Paper Jam In The Transport Output Section
Chapter 6 Fanfold Paper Jams Remove any jammed paper, and return knob A to its original position. Legend: Original Position of Knob A Knob A Paper Feed Shaft 5. Restore the transport unit and the waste toner recovery unit to their original positions, and close the front cover.
Page 221: Paper Jam In Face Up Or Down Paper Path
Paper Jam In Face Up Or Down Paper Path 3. Lower the paper guide by restoring the bottom lever to its original position. Close the front cover. Legend: Knob B Bottom Lever Paper Jam In Face Up Or Down Paper Path 1.
Page 222: System Status And Error Messages
Operator-correctable errors include paper jams, missing consumables, and power paper stacker problems. After correcting the error condition, press CLEAR to remove the message from the display and place the printer offline. If any data resides in the print...
Page 223: Reprinting Pages After Fault Condition
Reprint on Fault option in the Paper Control menu. If Reprint on Fault is enabled (the default): Any pages left in the printer at the time of failure will be reprinted. No data is lost. Fanfold paper: the printer reprints all pages that have not completely exited the printer at the time of failure.
Page 224 Chapter 6 System Status And Error Messages Any pages left in the printer at the time of failure will not be reprinted. Data is lost. (you will need to reprint the lost pages according to your application software.) If Reprint on Fault is confirm : The control panel on the printer returns a message asking whether or not to reprint.
Page 225 If Reprint on Fault is disabled and an error occurs, and if either the “Reload Paper in Tractors” or “Not Reprinting Failed Pages” message appears, then any pages removed from the printer will not be reprinted, and the data on them will be lost. Reprinting Pages After Fault Condition...
Page 226 • If the fault is cleared, and if you do not need to reload the paper into the tractors (for example, the printer ran out of toner): a. The printer goes OFFLINE. b. Press ONLINE to resume printing.
Page 227: Error Messages
(in Step 2), the following message appears: Reprinting Failed Pages a. The printer reprints only the pages affected by the fault. b. Press ONLINE to resume printing. Error Messages Table 6, “Error Messages,” on page 228, lists errors by error code and shows which are operator-correctable, which require field service, and which require reprinting.
Page 228 Chapter 6 System Status And Error Messages LINE JOB IN STAND BY SYNC AVAIL PROCESS CANCEL ONLINE FAULT PAGE ONLINE CLEAR TEST SHIFT EJECT Legend: Status Indicators Liquid Crystal Display (LCD) Sensor Positions A - D Function Keys Error Code Error Message FRONT COVER OPEN...
Page 229 Error Code Error Message CUT SHEET PAPER EMPTY PAPER JAM AT FUSER (C) PAPER JAM AT EXIT (D) PAPER JAM AT EXIT (D) PAPER JAM AT EXIT (D) PAPER JAM AT EXIT (D) PAPER JAM AT EXIT (D) PAPER JAM AT DRUM (B) PAPER JAM AT FUSER (C) PAPER JAM AT EXIT (D) PAPER JAM AT ENTRANCE...
Page 230 Chapter 6 System Status And Error Messages Error Code Error Message PAPER JAM AT ENTRANCE PAPER JAM AT ENTRANCE PAPER JAM AT ENTRANCE TRANSPORT MOTOR FAIL TRACTOR MTR FWD SPEED TRACTOR MTR BKWD SPEED ERR CUTTER FAIL CUTTER FAIL DRUM MOTOR FAIL SURFACE VOLTAGE TOO HIGH SURFACE VOLTAGE TOO...
Page 231 Error Code Error Message NO CLEANING UNIT NO DEVELOPER UNIT WASTE TONER FULL NO WASTE TONER BOX TONER LOW TONER DENSITY TOO HIGH TONER DENSITY TOO LOW TONER EMPTY DEVELOPER MOTOR FAIL LED HEAD OVERHEAT LED FAIL LED FAIL ENGINE CPU FAIL ENGINE CPU FAIL ENGINE CPU FAIL ENGINE CPU FAIL...
Page 232 Chapter 6 System Status And Error Messages Error Code Error Message ENGINE CPU FAIL ENGINE CPU FAIL ENGINE CPU FAIL ENGINE CPU FAIL ENGINE CPU FAIL ENGINE CPU FAIL ENGINE CPU FAIL CONTROLLER COMM. FAIL CONTROLLER COMM. FAIL CONTROLLER COMM. FAIL CONTROLLER COMM.
Page 233 Error Code Error Message STACKER FAIL STACKER FAIL STACKER NOT READY STACKER FULL NO TRANSFER UNIT TRANSFER PLATFORM FAIL TRANSFER PLATFORM FAIL SCUFF LEVER OPEN MAIN CHARGER ERROR TRANSFER CHARGER ERROR PRE-CHARGER ERROR CLEANING BIAS ERROR DEVELOPING BIAS ERROR SEPARATOR CHARGER ERROR TRAY MISMATCH STACKER FAIL...
Page 234 BUFFER OVERRUN BUFFER OVERFLOW TABLE NOTES: 1. For any error with Reprint on Fault enabled: If the printer stops while in the middle of printing a page, reloading the paper and reprinting are required. There may be other cases requiring reloading and reprinting;...
Page 235 3. For error numbers 01, 14, and 15: If the error occurs while paper is not moving, it is not necessary to reload or reprint. 4. For error number 02: If the error is caused by a paper-empty at the lower sensor (Paper Near End Sensor), it is not necessary to reprint.
Page 236 Chapter 6 System Status And Error Messages...
Page 237: A Maintenance Log Sheets
Maintenance Logs The log sheets on the following pages are intended for your use. These may be photocopied and kept in a binder near the printer. Be sure to use them each time either you or your service provider perform printer maintenance.
Page 238 Appendix A Maintenance Logs Level A Maintenance - 15,000 Pages (User) Action Item Clean General cleaning Clean Main charger Clean Precharger Clean Transfer charger Clean Cover glass See Note 1 Clean Cut sheet cassette See Note 2 pickup rollers Clean Cut sheet cassette See Note 2 reverse rollers...
Page 239 Drum life is dependent upon media being used and proper maintenance and operation of the printer. Print media other than bond paper (e.g., labels, card stock, plastic, or vinyl) may reduce drum life by as much as 50%.
Page 240 Drum life is dependent upon media being used and proper maintenance and operation of the printer. Print media other than bond paper (e.g., labels, card stock, plastic, or vinyl) may reduce drum life by as much as 50%.
Page 241 Level D Maintenance - 300,000 Pages (Service) Action Item Clean Flash power supply filter Replace Main charger Replace Precharger Replace Transfer charger Replace Smoke filter Part # Performed By 705741-001 705742-001 705743-001 703540-001 Date...
Page 242 Appendix A Maintenance Logs Level E Maintenance - Action Item Clean Lamp housing filter Clean LED air filter Clean Flash power supply filter Replace Main charger Replace Precharger Replace Transfer charger Replace Cleaning unit See Note 1 Replace Smoke filter Replace Transporting belt-3 Note 1: When the cleaning unit has been vacuumed every 150,000 pages and has...
Page 243 Level F Maintenance - Action Item Clean Flash power supply filter Replace Main charger Replace Precharger Replace Transfer charger Replace Smoke filter Replace Xenon lamp 900,000 Pages (Service) Part # Performed By 705741-001 705742-001 705743-001 703540-001 703541-001 Date...
Page 244 Appendix A Maintenance Logs Level G Maintenance - Action Item Clean Lamp housing filter Clean LED air filter Clean Flash power supply filter Replace Main charger Replace Precharger Replace Transfer charger Replace Cleaning unit See Note 1 Replace Smoke filter Replace Transporting belt-3 Note 1: When the cleaning unit has been vacuumed every 150,000 pages and has...
Page 245 Level H Maintenance - Action Item Clean Flash power supply filter Replace Main Charger Replace Precharger Replace Transfer charger Replace Cleaning unit See Note 1 Replace Smoke filter Replace Transporting belt-3 Replace Lamp housing filter Replace LED air filter Replace Tractor belt 3M264 Replace Drum belt 3M264...
Page 246 Appendix A Maintenance Logs WARNING The flash fuser capacitor (P/N 703531-561) must be replaced at least every 2,400,000 letter size pages. Failure to do so may endanger equipment and personnel. Der kondensator der Flash-Einbrennvorrichtung muß nach mindestens 2.400.000 Seiten im Format “Letter” ausgetauscht werden.
Page 247: B Specifications
Specifications Paper Specifications Paper type Paper size Width Length* * Measured from main folding/cutting perforation to main folding/cutting perforation. Tractor pin holes Fanfold 7 to 16 inches 1 to 30 inches, in multiples of 1/6 inch. See the table and figure below.
Page 248 Appendix B Specifications Specification Pin hole center to folding 1/6, 1/4, 1/ perforation Hole center line to edge of form Hole diameter Distance between centers of two consecutive holes Max. deviation of holes from their center line Max. deviation Left Hand hole to companion Right Hand hole (Center Line to Center Line)
Page 249 Legend: Hole centerline to edge of form Center Line Main Folding/Cutting Perforation Centerline to Centerline Distance between centers of two consecutive holes Center Line Deviation Tractor Pin Hole Pin hole to perforation Fanfold Paper...
Page 250: Performance Characteristics
Appendix B Specifications Paper thickness Paper weight Paper feed Maximum paper stack size 3000 sheets (18 lb.) Folder Perforation Cut to Tie Performance Characteristics Printing Density .010 inch maximum 18 to 44 lb. bond (68-165g/m ), 44-125 lb. tag/label (75-204g/m Automatic paper parking mechanism incorporated 0.12 inches or 3mm minimum...
Page 251: Printing Speed
Printing Speed Fanfold paper Paper Size Orientation Landscape Letter Landscape Portrait Letter Portrait Cut sheet paper. See the table below. Paper Size Cassette Orientation Lower Long edge fed Letter Lower Long edge fed Upper Long edge fed Letter Upper Long edge fed Upper Short edge fed Legal...
Page 252: Host Interfaces
Appendix B Specifications Maximum efective print width Duty cycle Mechanical life Warm-up time First page printing time MTBF/MPBF MTTR Host Interfaces Standard NOTE: Dataproducts parallel interface requires an adapter cable. Optional 14.7 inches 300,000 total pages/ month of fanfold paper form (11-inch length) and or cut sheet paper (letter) 5 years or 18,000,000 pages...
Page 253: Emulations
The L5000 series printers have 32 MB (standard) or 64 MB (optional) of RAM (Random Access Memory), and 8 MB (standard) or 16, 32, or 64 (optional) of Flash Memory. This is standard with all new printer shipments, and all upgraded printers. Emulations LinePrinter Plus...
Page 254: Safety Regulations
Appendix B Specifications Safety Regulations EUROPE Electromagnetic Interference Europe Physical Characteristics and Environment Dimensions (H x W x D) Weight Input voltage range Power consumption 1950 EN 60950 Class A EN55022 Class A 49 inch H x 30 inch W x 34 inch D In crate: 36 inches H x 58 inches W x 61 inches D...
Page 255 Environment Temperature Operating: 50° to 80° F (10° to 27° C) Non-operating: 14° to 95° F(-10° to 35° C) Humidity Operating: 30 to 80% RH Non-operating: 10 to 80% (non-condensing) Temperature (5F) Maximum Temperature/ Humidity Limits Sound level Operating 60 db (A-weighted) max. Full options Standby state 50 dB (A-weighted)
Page 256 Appendix B Specifications...
Page 257: C Host I/O Interfaces
Host I/O Interfaces Interfaces The printer provides connections on the right rear side panel for the following host I/O interfaces: • Serial Interface (RS-232 or RS-422) • Centronics Parallel Interface • Dataproducts Parallel Interface • IEEE 1284 Parallel Interface •...
Page 258 Appendix C Host I/O Interfaces Legend: Parallel Port/Optional Ethernet Port General Purpose I/O Port Optional Coax/Twinax Port Diagnostic Port Serial Port Figure 6. Interface Cable Connections...
Page 259: Performance Considerations
Performance Considerations The printer prints letter size and A4 size fanfold paper at 27 pages per minute portrait (one page every 2.2 seconds) and 35 pages per minute landscape. To sustain printing at full speed, data for each page must be received and rendered in less than 2.2 seconds for portrait mode (otherwise the printer will pause).
Page 260 For application efficiency in IGP/PGL or IGP/VGL, it is best to store a form in the printer and then execute it with dynamic data, rather than send the entire form each time. Also if possible, eliminate sending white space (spaces or tabs) at the end of lines if it is not necessary.
Page 261: Rs-232 Serial Interface
• the printing resolution is 400 dpi Refer to the L5535 Maintenance Manual or contact a qualified service representative for details on adjusting the global memory. RS-232 Serial Interface This interface is used with bit serial devices compatible with EIA RS-232C or CCITT V.24 standards.
Page 262 Host I/O Interfaces RS-232 Serial Interface Connector Pin Assignments The printer provides a 25-pin DB-25S connector on the right, rear side panel for connection of a serial interface cable. This connector is also used for the RS-422 serial interface. Selection of the desired interface is determined by the position of the RS-232/422 switch located on the right, rear side panel of the printer.
Page 263 Transmit Data (TxD) - Serial data stream from the printer for transmitting status and control information to the host. Subject to protocol selection. Request To Send (RTS) - Control signal from the printer. Subject to configuration. Clear To Send (CTS) - Status signal to the printer indicating the host is ready to receive data/status signals from the printer.
Page 264: Rs-422 Serial Interface
The asynchronous interface accepts data as it is provided by the host computer. The maximum cable length from the host computer to the printer is 4000 feet. The maximum baud rate supported by the RS-422 serial interface is 115.2 KB.
Page 265 RS-422 Serial Interface Connector Pin Assignments The printer provides a 25-pin DB-25S connector on the right side panel for connection of a serial interface cable. This connector is also used for the RS-232 serial interface. Selection of the desired interface is determined by the position of the RS232/422 switch located on the right, rear side panel of the printer.
Page 266 CTS is enabled, DSR and CTS must both be asserted for the printer to transmit flow control characters to the host. Data Set Ready (DSR) / Clock B - Status signal to the printer indicating the host is in a ready condition. DSR is ignored unless CTS is enabled.
Page 267 RS-422 Serial Interface Configuration The printer is configured for the RS-422 serial interface via the Serial Interface menu, as described on page 82. The following interface configuration parameters may be modified to meet specific application requirements: Host Protocol Baud Rate...
Page 268: Centronics Parallel Interface
This interface enables the printer to operate with controllers designed for buffered Centronics printers. The interface is capable of transferring up to 200,000 characters per second. The maximum cable length from the controller (host computer) to the printer is 15 feet. Centronics Parallel Interface Connector Pin...
Page 269 Input Signals Signal Signal DATA LINE 1 ACKNOWLEDGE DATA LINE 2 SELECT Return DATA LINE 3 PAPER EMPTY Return Return DATA LINE 4 BUSY Return Return DATA LINE 5 PRIME Return DATA LINE 6 NFAULT Return DATA LINE 7 Return DATA LINE 8 Reserved Return...
Page 270: Centronics Parallel Interface Signals
PAPER EMPTY (PE) - A high true level from the printer to indicate the printer is in a fault condition. SELECT - A high true level from the printer to indicate the printer is ready for data transfer and the ONLINE key has been activated.
Page 271: Centronics Parallel Interface Configuration
Centronics Parallel Interface Configuration The printer is configured for the Centronics interface via the Centronics Interface menu, as described on page 76. The following interface configuration parameters may be modified to meet specific application requirements: Data Bit 8 PI Ignored Data Polarity Resp.
Page 272: Dataproducts Parallel Interface
This interface allows the printer to operate with controllers designed for Dataproducts printers. The interface is capable of transferring up to 500,000 characters per second. The maximum cable length from the controller (host computer) to the printer is 40 feet. Dataproducts Parallel Interface Connector Pin Assignments The printer provides a 36-pin D-shell connector on the right side panel for connection of a parallel interface cable.
Page 273 Dataproducts Parallel Interface Input Signals Signal Signal DATA LINE 1 READY Return DATA LINE 2 ON LINE Return Return DATA LINE 3 DATA REQUEST Return Return DATA LINE 4 Return Return DATA LINE 5 Interface Verif. Return DATA LINE 6 PAPER INST Return Return...
Page 274: Dataproducts Parallel Interface Signals
DC voltages are present, paper is loaded properly, and the printer is not in a fault condition. ON LINE - A high true signal from the printer indicating the Ready Line is true and the ONLINE key on the control panel has been activated.
Page 275: Ieee 1284 Parallel Interface Configuration
TOF Action Buffer Size In K IEEE 1284 Parallel Interface Configuration The printer is configured for the IEEE 1284 interface via the IEEE 1284 Interface menu, as described on page 90. The following interface configuration parameters may be modified to meet...
Page 276: Termination Resistors
220 ohm pullup and 330 ohm pulldown resistors. If you are experiencing communication problems between the printer and host (double or missing characters), the cause may be the value of the termination resistors on the motherboard. Contact your authorized service representative for instructions on replacing the termination resistors.
Page 277 ACK/NAK, 83 Adjustments loading Flash memory, 113 loading flash memory, 117 software upgrades, 113, 117 Alarm, 104 AUTO function key, 43 Baud Rate, 86 Buffer, 78 Buffer Size In K, 88 Buffer Size in K, 91 Busy, 77 Busy Polarity, 77 Buttons See Function keys, 46 Cable connections locations, 257...
Page 278 Prime Signal, 80 Resp. Polarity, 80 TOF Action, 81 Dataproducts parallel interface, 272 Delete Configuration, 71 Diagnostics printer, 208 printer offline, 208 printer online, 209 DIAGNOSTICS PASSED, 123 Diagrams paper path, 46 Display Language, 106, 107 Disposal photoreceptor drum, 146...
Page 279 DRAM AT ADDRESS xxxxxxxx, 124 FLASH DID NOT PROGRAM, 124 FLASH NOT DETECTED, 124 FLASH TYPE IS NOT SUPPORTED, NO DRAM DETECTED, 124 NVRAM FAILURE, 124 PROGRAM NEEDS MORE DRAM, PROGRAM NEEDS MORE FLASH, PROGRAM NOT COMPATIBLE, 125 PROGRAM NOT VALID, 125 SECURITY PAL NOT DETECTED, SHORT AT ADDRESS xxxx, 125 WRITING TO FLASH, 125...
Page 280 Index DIAGNOSTICS PASSED, 123 ERROR DRAM AT ADDRESS xxxxxxxx, 124 ERROR DC PROGRAM NOT VALID, ERROR FLASH DID NOT PROGRAM, ERROR FLASH NOT DETECTED, ERROR FLASH TYPE IS NOT SUPPORTED, 124 ERROR NO DRAM DETECTED, 124 ERROR NVRAM FAILURE, 124 ERROR OCCURRED FLUSHING QUEUES *, 124 ERROR PROGRAM NEEDS MORE...
Page 281 Serial See Serial Interface menu., 82 Host interface specifications, 252 Idle Response, 88 IGP / PGL Emulation, 27 IGP / VGL Emulation, 27 Impact Printer Emulation, 27 Important notice, 19 INSUFFICIENT RAM REBOOT/ADD RAM, Interface connections I/O locations, 257 Interfaces...
Page 282 Index Labels safety See Safety., 22 Latch, 77 LCD See Liquid crystal display, 46 LED print head cleaning, 204 Lens SELFOC cleaning, 204 LINE SYNC status lamp, 47 LinePrinter Plus emulation, 27 Liquid crystal display (LCD), 46 Loading cut sheet paper, 33 Loading fanfold paper, 30 LOADING FONTS, 127 Loading paper, 30...
Page 283 ERROR FLASH TYPE / IS NOT SUPPORTED, 124 ERROR FLASH / DID NOT PROGRAM, 124 ERROR FLASH / NOT DETECTED, ERROR NO DRAM / DETECTED, 124 ERROR NVRAM / FAILURE, 124 ERROR OCCURRED / FLUSHING QUEUES *, 124 ERROR PROGRAM / NEEDS MORE DRAM, 125 ERROR PROGRAM / NEEDS MORE FLASH, 125...
Page 284 Output section transport paper jams in, 220 Page counts service level, 160 PAGE EJECT function key, 50 Page length printer setting, 44 stacker setting, 44 Pages reprinting after fault, 223 Panel Key Sound, 104 Paper loading, 30 loading cut sheet, 33...
Page 285 253 environment, 254 host interfaces, 252 memory requirements, 253 performance, 250 physical, 254 safety regulations, 254 Printronix LinePrinter Plus emulation, 27 Protect Config., 71 PTX SETUP Options, 106 Quality print maintaining, 159 print problems with, 159 Recommended vacuum cleaners, 159...
Page 286 112 Setting cassette paper size, 35 SHIFT function key, 49 Software loading into Flash memory, 113 loading into flash memory, 117 Specifications printer electromagnetic interference, 254 emulations, 253 environment, 254 host interfaces, 252 memory requirements, 253 performance, 250...
Page 287 STAND BY status lamp, 47 Start Test, 111 Status lamps, 46 FAULT, 48 JOB IN PROCESS, 47 LINE SYNC, 47 ONLINE, 48 STAND BY, 47 SYS AVAIL, 47 STOP function key, 43 Stop Bits, 86 Switches See Function keys, 46 SYS AVAIL status lamp, 47 System Memory, 111...
Page 288 Index XON/XOFF, 83...
Page 290 NL-6600 AD Wijchen The Netherlands Phone: (31) 24 6489489 Fax: (31) 24 6489499 , Schweiz GmbH RINTRONIX 42 Changi South Street 1 Changi South Industrial Estate Singapore 486763 Phone: (65) 542-0110 Fax (65) 543-0220 Visit our website at: www.printronix.com 171516-001C...

Printronix L5535 User Manual

1 Introduction

2 Initial Setup

3 Printer Configuration

4 Consumables Replacement

5 Scheduled Maintenance

6 Troubleshooting

A Maintenance Log Sheets

B Specifications

C Host I/O Interfaces

Quick Links

Related Manuals for Printronix L5535

Summary of Contents for Printronix L5535

Table of Contents
