Page 25: Replacement Procedures
Replacement Procedures Chapter Contents Overview ............10–3 Covers .
Page 26 Sensors/Switches ..........10–77 Gates .
Page 27: Overview
Overview This chapter describes the mechanical structure of the printer and how to detach the various parts. The printer should be reassembled in the reverse order of the procedures specified in this chapter. Return the screws to their original positions, as they may vary in type with the position.
Page 28: Covers
Covers The printer has the following external covers. Rear Cover (left) Top Cover Rear Cover (right) Front Cover Stand Cover 10–4 Replacement Procedures...
Page 29: Front Cover
Front Cover The front cover is designed to open easily by pressing the open/close buttons on either side and pulling the cover toward you. The user may handle the parts behind the front cover daily. Open/close button Front cover Perform the following steps to detach this cover from the printer. 1.
Page 30: Rear Cover
Rear Cover 1. Remove the rear side screws (5). Raise the left rear cover about 1 cm and remove it from the printer. (The back of the printer is shown below.) Screws (5) 10–6 Replacement Procedures...
Page 31 2. Remove the screws (3) on the paper exit side. Screws (3) Replacement Procedures 10–7...
Page 32 3. If the optional power stacker is connected, do the following: a. Remove the plate under the cover. b. Remove the ground line and connector on the stacker. c. Remove the screw which secures the connector cover. Screw for FG wire Screw Connector cover 10–8...
Page 33 4. Remove the rear side screws (5). Raise the right rear cover about 1 cm and remove it from the printer. On the inside of the rear cover there are tabs for adjusting the position of the cover on the printer. When attaching the cover, insert these tabs into the centering slot on the printer.
Page 34: Top Cover
Top Cover It is necessary to remove the rear cover before removing the top cover. Then, remove the top cover as described below. 1. Pull out the tray by removing the screws (2) fastening the paper face–up output tray. 2. Remove the screws (4) on the paper exit side. Screws (4) Screws (2) Paper face–up...
Page 35 4. Open the front cover. Remove the screws (4) and detach the front control panel. 5. Disconnect the front cover interlock (CIL) switch connector. Front cover interlock switch connector Screw Control Panel Replacement Procedures 10–11...
Page 36 6. Lift and remove the top cover from the printer. This may require two people (one for the paper feed side, the other for the paper output side). Top Cover Screw 10–12 Replacement Procedures...
Page 37: Stand Cover
Stand Cover 1. Remove the right and left screws (4) securing the stand cover. 2. Remove the cover by pulling it toward you. Screws (4) Stand cover Replacement Procedures 10–13...
Page 38: Inside The Front Cover
Inside the Front Cover The items shown below are behind the front cover. The green levers and handles are used by the operator on a regular basis. Lamp for discharger Main charger (not visible) Toner cartridge Cleaning unit Optional cut– Fuser unit sheet paper output unit...
Page 39: Waste Toner Recovery Unit
Waste Toner Recovery Unit This unit contains a bottle that collects waste toner carried from the drum cleaner via screw conveyer belt. Attached to the right and left sides of the bottle’s neck are the light emitters and receptors of the waste toner bottle full sensor (WTBF), which detects the full condition.
Page 40 Waste toner bottle When the waste toner bottle becomes full, replace it with a new bottle by following the steps below, and discard the full bottle. Do not reuse the bottle. 1. Lower the lever, pull the green handle toward you, and open the toner recovery unit.
Page 41: Printer Control Menu
3. Remove the waste toner bottle from the unit, and install a new waste toner bottle. 4. To clear the Waste Toner Full error, enter the Printer Control menu in the configuration menu. Select the Reset Toner Full option and press ENTER. (Refer to page 7–12 in Chapter 7, “Troubleshooting,”...
Page 42 Waste toner bottle full sensor Remove the waste toner bottle full sensor (WTBF) by following these instructions, (after removing the waste toner bottle from the waste toner recovery unit). Sensor–B PC Board Sensor–A PC Board Connectors (3) Screws (4) 1. Disconnect the three connectors. 2.
Page 43 Waste toner bottle set sensor The waste toner bottle set sensor (WTBS) is a limit switch that detects whether the waste toner bottle is set. 1. Remove the connectors. 2. Remove the screws (2) securing the sensor bracket. 3. Remove the sensor. Screw Bracket Sensor...
Page 44 Waste toner bottle unit 1. Remove the bottle and sensors. 2. Detach one end of the spring as shown below. 3. Remove the waste toner bottle unit by lifting it. Spring 10–20 Replacement Procedures...
Page 45: Developing Unit
Developing Unit See Chapter 3, “Consumables,” for installation and replacement procedures. Toner cartridge See Chapter 3, “Consumables,” for installation and replacement procedures. Photoreceptor Drum and Peripheral Equipment Photoreceptor drum See Chapter 3, “Consumables,” for installation and replacement procedures. Drum peripheral equipment The equipment listed below is located around the photoreceptor drum.
Page 46 Main charger (MCH), pre–charger (PCH), Transfer / separator charger (TCH / SCH) Any of these chargers can be removed by loosening thumb screws and pulling toward you along the guide rail. Main charger thumb screw Pre–charger thumb screw Transfer/separator charger thumb screw 10–22 Replacement Procedures...
Page 47 Discharge lamp (PEL) 1. Remove the inner cover. 2. Remove the discharge lamp screw and pull the lamp toward you along the guide rail. Discharge lamp screw Inner cover Screw Replacement Procedures 10–23...
Page 48 Drum cleaning unit If the drum plate is removed, the drum cleaning unit can be removed by grasping the handle and pulling it toward you. CAUTION Do not turn the drum cleaner unit upside down, as it spills toner. Drum cleaning unit handle Drum plate...
Page 49 Separator claw unit In order to remove the separator claw unit, it is necessary to remove the rear cover and top cover, and then either push the transfer unit lever over to lower the transport surface, or pull the transport unit out toward you, to make space underneath the separator claw unit.
Page 50 4. Loosen the screw fastening the pre–charger to the printer unit, and then remove the separator claw block from the front. 5. When removing the separator claw solenoid, the screws (2) securing the solenoid, and the E–ring on the tip of the solenoid arm must be removed. a.
Page 51 Drum support roller There are three small rollers with gum rings near where the drum is to be removed, to prevent the drum surface from contacting metal parts in the vicinity. To remove the rollers on the lower right and left, remove the screws (1 each) securing each bracket.
Page 52: Fuser Unit
Fuser Unit DANGER Take care in handling the fuser unit, as the unit reaches high temperatures (over 139 C when temperature fuse melts) immediately after operation. Be sure to wait to handle it until it is completely cooled down. Also, never scratch or touch the cover glass with your hands. Fingerprints on lamps will cause them to break.
Page 53 3. Grasp the handle and pull out the fuser unit until the second handle is visible. 4. With the other hand, grasp the second handle and remove the fuser from the printer. 5. Place the fuser on a clean, flat surface with the cover glass facing up. This unit contains the following replaceable parts: Pre–heat lamp (Halogen lamp/PHL) Fuser flash lamp (Xenon lamp)
Page 54 4. Remove the screws (pre–heat lamp 2 / flash lamp 3) securing the lamp terminals, and extract the lamps from the bracket. Flash (xenon) lamp Pre–heat (halogen) lamp 5. Of the screws (2) fastening the rear side’s bracket, remove the screw holding the pre–heat lamp.
Page 55 Temperature fuse 1. Remove the screw securing the fuse holder to the fuse box. Fuse box Fuse holder 2. Remove the screw securing the fuse holder cover. Screw 3. Open the cover and remove the screws (3) securing the temperature fuse. Mechanical System 10–31...
Page 56: Transfer/Transport Unit
Lamp duct filter To replace the lamp duct filter, remove the screws (2) that secure the unit to the fuser box. Then remove the screws (2) holding the lamp duct filter cover to the unit. Filter plate Air filter Lamp duct filter unit Screw...
Page 57 2. Remove the screws (6) that are securing the right and left slide rails to the unit. Screws Slide rail 3. Lift the unit from the rails, and remove it. The following replaceable parts are on the transfer/transport unit: Transport belt Vacuum fan (VAF) Elevator paper start sensor Elevator paper intermediate sensor...
Page 58 Transport belt When replacing the transport belt, the transfer/transport unit must be turned upside–down. When turning the unit upside–down, be sure to put a rest underneath it to protect the protruding tips of the sensor levers. Also, be careful when handling the lever.
Page 59 4. Remove the screw (1) securing the drive shaft, then remove the stainless plate. 5. Remove the E–rings (2) securing the drive shaft to the unit frame, and remove the bearing. Bearing E–ring Unit frame Mechanical System 10–35...
Page 60 6. Remove the base conveyer from the unit frame. Remove the screw (1) fastening the high–voltage wire, and remove the wire. 7. Remove the E–rings (2) holding the drive shaft to the base conveyer, then slide the bearing off the shaft to remove it. E–ring Bearing Drive shaft...
Page 61 Front side Back side 10. To adjust the belt tension, loosen the screws (2 right, 2 left) fastening the base conveyer, and adjust the tension of the belt by turning the set screw with a hex wrench. Set screw Mechanical System 10–37...
Page 62 11. Adjust the distance between the belt and the conveyer base to approximately 1 cm when the belt center is pulled up with a force of 200 grams. Firmly tighten the screws (2 right, 2 left) to fasten the conveyer base. Belt Conveyer base Vacuum fan / EPS3 / EPS4...
Page 63 TC Connector block of the transfer / separator charger The TC connector block of the transfer/separator charger is attached to the unit frame on the rear side of the transport unit. When replacing this connector block, replace the terminal block that is connected by cable at the same time. 1.
Page 64 Varistor 1. Remove the screws (front s ide and rear side, 1 each) securing the transport paper guide. 2. Remove the transport paper guide. Screws Transport paper guide Varister Spacer 3. Remove the screws (2) securing the varistor terminal, and remove the varistor. 10–40 Mechanical System...
Page 65: Inside The Rear Cover
Inside the Rear Cover tm1–6 The area inside the rear cover is shown below. Head cooling fan Head blower fan Sleeve motor Magroll motor I/O board Fuser reflector plate cooling fan Main body section feed motor board Transfer blower elevator DC power supply Smoke filter...
Page 66 MPU board When removing the MPU b oard, disconnect the connectors, and remove the screws (4) securing the board. I/O board When removing the I/O board, disconnect the connectors, and remove the screws (6) securing the board. Screw Screw Screw Screw 10–42 Mechanical System...
Page 67: Dc Power Supply Board
DC Power Supply Board 1. Before removing the DC Power Supply board, turn the power switch OFF and unplug the power cord. 2. Remove the screws (3) on the right rear cover. Screws (3) Mechanical System 10–43...
Page 68 3. Loosen the screw (1) on the connector cover in the lower part of the rear cover, and slide the connector cover to the left. Then remove the screw (1) inside the connector cover. Screw 4. Lift the right rear cover 1 cm, then remove it. Rear cover (right) 10–44 Mechanical System...
Page 69 5. Move the breaker switch to the OFF position. 6. Remove the screws (8) holding the power supply unit cover, then remove the cover. The DC Power Supply board will be visible inside the power supply unit. DC power supply board 7.
Page 70: Motors
Motors Cutter motor The cutter unit must be removed before replacing the cutter motor (see page 10–74 for cutter unit detail). 1. Disconnect the cutter motor’s connector, and remove it through the hole in the frame. Also remove the pulley drive belt. Pulley Screw Set screw...
Page 71 Drum motor 1. Remove belt A by pulling the tension roller downward. Then, remove belts B and C by turning pulleys F and G, respectively. Belt A (703531–032) Tension roller Pulley F Pulley G Belt B (703531–031) Belt C (703531–031) Mechanical System 10–47...
Page 72 Motor cover Screw 2. Remove the screws (3) fastening the motor cover, then remove the motor cover by moving it downward. 3. Remove the E–ring and the tab washer from the motor shaft. 4. Loosen the set screw using the hex wrench, and remove the flywheel. 5.
Page 73 Sleeve motor (SLM) / Magroll motor (MRM) 1. Remove the connectors, one for the sleeve motor, the other for the magroll motor. 2. Remove the screws (8) fastening the assembly bracket with motors. Bracket Sleeve motor Connector Magroll motor 3. Remove screws securing motors from rear of bracket. 4.
Page 74 Feed motor (FMT) / Encoders (FME19/20) In the feed motor block, encoders 19 and 20, along with the motor itself (with bracket), are replacement parts, and are removed as follows: 1. Remove two (2) sensor conn ectors. Before removing, mark both connectors for identification so that they are connected properly when installing the motors.
Page 75 5. Remove the belt and remove the screws (3) which attach the feed motor bracket to the printer base, then pull out the bracket with the feed motor attached. Belt (703531–031) Motor Set screw Encoder 19 Disc Bracket Screws (3) Encoder 20 Disc Screws Light Emit-...
Page 76 Bracket Screws Tractor motor/tractor drive belts For the steps below, assume that the I/O boards are already removed. Belt A is removed first, belt B second. Belt A (703531–031) Belt B (703531–031) 10–52 Mechanical System...
Page 77 1. To maintain the correct perforation of the fan–fold paper, inscribe alignment marks on pulleys C and S as shown below. Then, remove belt A by rotating pulley C, and remove belt B by rotating pulley S. Pulley C Belt A Align- ment marks...
Page 78 2. After removing the motor cover, disconnect the tractor motor connectors (2). Screws Connectors 3. Remove the screws (4) fastening the tractor motor to the printer base. 4. Remove the tractor motor by pulling it through an opening in the paper feed guide.
Page 79 Transfer elevator motor The following steps assume that the transport unit is already removed from the printer. 1. Detach the cable clamp, and disconnect the motor connector. 2. Remove the screws (4) which attach the transfer elevator motor to the bracket, then remove the transfer elevator motor from the bracket.
Page 80: Fans
Fans Head cooling fan (HCF) 1. Disconnect the head cooling fan’s connector, remove the screws (2) securing the bracket to the main unit, and remove the fan with the bracket attached. Connector Bracket Screws 2. Remove the screws (2) securing the head cooling fan to the bracket. Bracket Screw Head cooling fan...
Page 81 Head blower fan (HBF) LED air filter The head blower fan has the role of sending air through the duct inserted between the main charger and LED head, to prevent particles such as toner from adhering to the head. A filter is attached to the intake, to prevent dust from clogging the duct’s draft hole.
Page 82 Fuser reflector cooling fan (FCF) To remove the fuser reflector cooling fan, disconnect the connector, and remove the screws (4) securing the fan and fan plate to the duct. Duct Fuser re- flector cooling fan Fan plate Connector Screw 10–58 Mechanical System...
Page 83: Solenoids
Solenoids Paper output gate solenoid (EGSL) / Face gate solenoid (FGSL) The paper output gate solenoi d and face gate solenoid are both removed by disconnecting the connector, and remov ing the screws (2) that are securing the bracket to the main unit. Face gate solenoid Connectors Screws...
Page 84: Miscellaneous
Miscellaneous Tension arm The tension arm above the eject gate solenoid is removed by removing the E–ring on the rotation axis. Tension arm E–ring 10–60 Mechanical System...
Page 85 Main charger (MCH) Varistor One terminal of the main charger varistor is connected to the main charger connecter via high voltage cable, so removal of this is done by removing the screw securing this connecter, and removing the screw securing the other terminal to the rear panel. Varistor Screws Mechanical System...
Page 86 Drum motor drive belt The following steps describe how to replace the drum motor drive belts. Three (3) belts are installed with the drum motor drive unit and should be removed in the following order: Belt A, Belt B, and Belt C. Belt A (703531–032) Belt B (703531–031) Belt C (703531–031)
Page 87 Output roller drive belts Five (5) belts, A through E, are incorporated into the roller drive mechanism. These belts must be removed in the following order: A, B, D, E, and C. Belt E (703531–030) Belt D (703531–029) Belt A (703531–028) Belt B (703531–031) Belt C (703531–031) 1.
Page 88 3. Remove the screw (1) fastened to the scuff roller shaft, and remove the flange. Belt E Flange H Screw Belt D 4. Remove belts D and E. 5. Remove belt C by turning pulley H. 6. Remove the screws (3) fixing the feed motor to the bracket, and then remove the motor with the bracket attached.
Page 89 Face–down paper out drive belt To remove the belt, slacken the belt by pulling the tension roller toward the right. Belt (703531–034) Tension roller Pickup roller unit 1. Pull out the upper and the lower cassettes. There are two pickup roller units at the back: upper pickup roller and lower pickup roller.
Page 90 2. Loosen the green set screw, slide the unit to the left, and then pull it toward you. Follow the same procedure for pulling out the lower pickup roller unit. Set screw 3. When installing the unit, align the unit shaft’s pin with the slot in the coupling as shown, and also align the alignment pin on the shaft with the unit frame’s hole.
Page 91 Reverse roller unit 1. There are two (2) reverse roller units, one underneath the upper pickup roller unit and one underneath the lower pickup roller unit. Reverse roller unit (lower side) Reverse roller unit (upper side) Thumbscrew 2. Loosen the green thumbscrew, remove the unit by moving it downward while sliding it to the left.
Page 92 3. When installing the unit, align the pin on the unit shaft with the slot in the coupling, and also align the unit’s alignment pin with the hole on the frame. Coupling Shaft’s pin Alignment pin Hole on the unit frame 4.
Page 93: Under The Top Cover
Under The Top Cover The following units and parts are arranged under the top cover (top view). LED array unit Nip switch Drum surface potential sensor Drum cleaner set sensor (Rear side) (Front side) High voltage Paper output (corona) power Paper output sensor 1 supply unit...
Page 94: Led Array Unit
LED Array Unit It is necessary to remove the developing unit ahead of time in order to remove this unit (see “Developing Unit” on page 10–21). 1. Disconnect the connectors from the LED print head unit, and remove the screw (1) on the head thermistor terminal.
Page 95 3. Remove the screws (4) securing the LED print head, then lift the print head to remove it. CAUTION Do not touch the surface of the print head, as you will leave fingerprints. Screws LED print head 4. When installing the LED print head, insert the alignment pins (2 pins – 1 right, 1 left) into the center holes as shown.
Page 96 5. After positioning the print head, insert the screws (2) into the proper screw holes as shown above, tighten them firmly, and then remove the alignment pins (2). 6. Rub thermal compound over the heat pipe and print head. Install the heat pipe. 7.
Page 97: High-Voltage Power Supply Unit
High–voltage (Corona) Power Supply Unit This unit is removed by disconnecting the connector and disconnecting the high voltage wire terminal connected to the output terminal, then removing the screws (4) securing the unit to the main body and the screw holding down the frame ground. CAUTION When installing the high–voltage power supply unit, be sure to connect the connectors properly.
Page 98: Cutter Unit
Cutter Unit The cutter unit is removed by the following procedure. CAUTION Bearings can fall out of the pulley when removing it. Also, the pulley must be put on the same way it was removed. This pulley is three pulleys molded into one piece.
Page 99 2. Remove the screws (2 each, front and rear) fastening the cutter unit. 3. Disconnect the connectors to the cutter motor and cutter sensor in the rear. Screws Connectors Mechanical System 10–75...
Page 100 4. Remove the cutter unit by pulling it downward from the rear side, as the front is obstructed by the front panel. Screws Cutter unit 10–76 Mechanical System...
Page 101: Sensors/Switches
Sensors / Switches Drum surface potential sensor 1. Disconnect the connector of the drum surface potential sensor on the rear side, and remove the screw (1) securing the sensor’s bracket. Screw Bracket 2. Remove the screws (2) on the front side. Screws Mechanical System 10–77...
Page 102 3. Remove the screws (2) securing the sensor to the bracket, and remove the sensor. Drum Surface Drum Support Roller Potential Sensor NOTE: When installing a new sensor, you must perform the adjustment procedure using the dummy drum. Refer to page 9–11 in Chapter 9, “Board Adjustments.”...
Page 103 Drum cleaner set sensor The drum cleaner set sensor is a limit switch to detect whether the drum cleaner is set. It is assembled to the inside of the rear panel so that the points close when the drum cleaner is set. Drum Cleaner Set Sensor To remove this sensor, disconnect the connector on the rear side, remove the screws (2) securing the bracket, put your hand in from the top of the rear panel and extract...
Page 104 Paper output sensor 0 (EPS0) / Nip switch (NPSW) Attached to the scuff guide located at the exit to the paper output section are paper output sensor 0 that detects the timing of the paper arriving and the transport speed of the paper, and a nip switch to detect whether the scuff roller that sends paper from the fuser to the paper output section is nipping.
Page 105 Nip switch The nip switch is located closer to the rear panel than the paper output sensor 0. In order to remove this switch, remove the screws (not visible in the illustration below) securing the bracket to the scuff guide from the paper output side. Put your hand in from the top of the rear panel, and remove the switch and bracket.
Page 106: Gates
Gates The paper output section has two stages of gates, the paper output gate and the face gate. Both of these gates are linked with solenoid coils (EGSL, FGSL) on the rear side. In order to remove the gates, remove the screws (1 each) of this link, securing the shaft to the front panel and rear panel.
Page 107: Behind The Stand Cover
Behind the Stand Cover Smoke Filter 1. Loosen the thumb nut on the front and open the cover of the filter box. Smoke filter Thumb nut 2. Pull the metal fitting out about 20 mm and unlock. Lever Mechanical System 10–83...
Page 108 3. Rub petroleum jelly on the rubber seal on the bottom of the smoke filter. Then replace the smoke filter. Smoke filter 10–84 Mechanical System...
Page 109: Flash Power Supply Unit
Flash Power Supply Unit The following steps describe replacement of the flash power supply unit. (For additional information, refer to page 6–19 in Chapter 6, “Electrical and Wire Data.”) DANGER When replacing the flash power supply, take care of the following: When main power is switched off, wait at least 5 minutes for the high–voltage DC charge in some components to be completely discharged before proceeding to the next step.
Page 110 1. Turn off the printer and turn off the standby switch. 2. Turn off the No–Fuse Breaker (NFB), and pull the power connector out of the electrical outlet. 3. Remove the screws (4) at the left and right of the stand cover, and remove the cover.
Page 111 4. Disconnect connector J11 and TRG from the flash power supply. 5. Open the cover of the AC line casing, and disconnect AC lines “L” (black) and “N” (white). 6. Remove the screw fastening the FG wire to the base frame. Connector J11 (to MPU) High voltage...
Page 112 8. Remove the screws (2) fastening the flash power supply. 9. Grasp the flash power supply and pull it out. If you cannot pull it, loosen the screws (4) fastening the metal fittings on the rear of the flash power supply and try again.
Page 113: Capacitors
Capacitors In printers where there are six (6) cylindrical capacitors (instead of one (1) rectangular capacitor) inside the flash power supply unit, follow the steps below to replace the capacitors. DANGER When main power is switched off, wait about 5 minutes for the high–voltage DC charge in some components to be completely discharged before touching the printer base or other metal parts having no coating.
Page 114 3. Remove the screws (5) fastening the rear cover and remove the cover. Screws Rear cover Screws 4. Remove the screws (2) securing three capacitors to each plate, then remove the plates. capacitors Screw Plate 10–90 Mechanical System...
Page 115 5. Remove the screw and the stopper on each set, and then remove the capacitor located at the back first. Next, replace the capacitors one by one to avoid incorrect wiring. Screw Stopper 6. After completing replacement, attach the screws and stoppers, followed by the screws on the plates which each hold three capacitors.
Page 116: Other
Other Tractor Removal The tractor is secured by the tractor splined shaft and tractor shaft, and is removed as follows. However, in order to remove the tractor, the I/O board must be removed from the rear ahead of time. (See I/O board removal on page 10–41.) I/O Board Tractor Tractor shaft...
Page 117 1. Remove the E–ring securing the tractor splined shaft and remove the screw (1) securing the tractor shaft on the front side. Screw E–ring 2. Remove the tractor drive belt (see page 10–52). 3. Slide the tractor splined shaft to the rear side. Screw Tractor spline shaft 4.
Page 118: Tractor Adjustment Procedure
Tractor Adjustment Procedure After removing and replacing tractors, perform the following procedure to adjust the tractor shaft alignment, in order to alleviate the problem of paper pulling away from the tractor guides. This adjustment spaces the spline shaft and the support shaft evenly apart, and places the support shaft perpendicular to the frame.
Page 119 6. Unlock the tractors and slide both tractors to the center of the shaft. Also slide the left tractor spacer to the center of the shaft. Spacer 7. Place the tractor alignment tools between the spline shaft and the support shaft, one at each end, over the bearings on the spline shaft.
Page 120 Alignment tool Support shaft Alignment tool Spline shaft 8. Lift up the support shaft and apply a small amount of force toward the spline shaft. Once the support shaft is against the alignment tool, tighten the screw holding the support shaft on the left side frame. Repeat this procedure on the right side frame.
Page 121 9. Ensure that the tractor alignment tools can be easily removed. If they are too tight or too loose, make the adjustment again. 10. Remove the tractor alignment tools. 11. Return the left tractor spacer, left and right tractors, and clamp (or “C” clip) to their original positions.
Page 122: Paper Back-Feed Sensor
Paper Back–feed Sensor The paper back–feed sensor is removed by removing the screw (1) securing the bracket from the tractor side, removing the sensor with the bracket attached, and disconnecting the connector. Paper back–feed sensor Paper Near–end Sensor To remove the paper near–end sensor, remove the screws (4) securing the sensor bracket to the printer base.
Page 123: Control Panel
Control Panel 1. Remove the screws (4) securing the control panel to the printer base. 2. Disconnect the connector to the port on the control panel, and remove the panel. Port connector Screws (4) Mechanical System 10–99...
Page 124: Controller Module
Controller Module The controller module consists of the following subassemblies: Motherboard Power Supply Cooling Fan Floppy Disk Drives Removal and replacement procedures for each of these subassemblies are described in the following pages. 10–100 Mechanical System...
Page 125: Printer Rear Cover
Printer Rear Cover 1. Disconnect the AC power cable from the power source. 2. To gain access to the controller module, remove the screws (5) securing the printer rear cover and lift up to remove. Mechanical System 10–101...
Page 126 Rear Cover Screw Controller Module 10–102 Mechanical System...
Page 127: Motherboard
Motherboard 1. Remove the printer rear cover (page 10–102). 2. Remove the screws and washers (4 each) from the host interface panel and remove the panel (page 10–104). 3. Grasp the edge of the motherboard and pull it slightly out of the card cage to gain access to the 6 interface cables connected to the edge–mounted connectors on the motherboard.
Page 128 Motherboard Host Interface Panel 10–104 Mechanical System...
Page 129: Power Supply
Power Supply 1. Remove the printer rear cover (page 10–102). 2. Remove the controller module side cover (page 10–106). 3. Remove the screw and washer (1 each) which secure the AC line cover to the module side panel. 4. Remove the AC connector from the controller module top panel by pushing its retaining ears toward the connector body and pushing the connector through its mounting hole.
Page 130: Power Supply
AC Connector Power supply Side Cover Rotated for clarity 10–106 Mechanical System...
Page 131: Cooling Fan
Cooling Fan 1. Remove the printer rear cover (page 10–102). 2. Remove the controller module side panel (page 10–106). 3. Disconnect the fan power cable connector and remove the cable tie wrap (not shown). 4. Remove the screws and washers (2 each) securing the fan. 5.
Page 132 Side Cover 10–108 Mechanical System...
Page 133: Floppy Disk Drives
Floppy Disk Drives 1. Remove the printer rear cover (page 10–102). 2. Remove the controller module side panel (page 10–106). 3. Disconnect the interface cable and power cables from the floppy disk drives. 4. Remove the screws (4) which hold the two disk drive brackets to the controller module.
Page 134: Floppy Disk Drives
Floppy Disk Drives (2) Bracket 10–110 Mechanical System...
Page 135: Specifications
Specifications Replacement Schedule ..........A–2 Replacement Intervals .
Page 136: Replacement Schedule
Replacement Schedule NOTE: To ensure optimum print quality, use genuine Printronix supplies. Part numbers are provided on the pages that follow. To order supplies, call the number below for your region: For the Americas Phone: (800) 733-1900 Fax: (714) 368–2354 For Europe, the Middle East, and Africa Phone: (33) 1–46–25–1900...
Page 137: Replacement Intervals
Replacement Intervals DANGER The flash fuser capacitors (P/N 703542–001 or 703531–561) must be replaced at least every 2,400,000 letter size pages. Failure to do so may endanger equipment and personnel. GEFAHR Die Blitzfixierkondensatoren (P/N 703542–001) müssen mindestens alle 2,400,000 Papierseiten (Briefkopfgröße) ersetzt werden. Bei Nichtbeachtung können Personal und das Gerät geschädigt werden.
Page 138: Basic Specifications
Basic Specifications Printing method LED array electrophotographic system Charging system Corona discharge Exposure system LED array Photoreceptor drum Se/Te alloy Developing method Dry two–component developing system Developer Two–component developer (magnetic toner + carrier) Toner particle diameter: approx. 8 µm Carrier particle diameter: approx. 40 µm Fusing method Flash fusing system, based on an Xe lamp (light–emitting energy: approx.
Page 139: Paper Specifications
Paper SpecifIcations Paper types Fan–fold (standard) Cut–sheet (optional) Paper sizes Fan–fold paper: Length 1 to 24 inches (2.5 to 61.0 cm) Width 7 to 16 inches (17.8 to 40.6 cm) When the optional power stacker is used, paper length range is 7 to 12 inches (17.8 to 30.5 cm.) Cut–sheet paper letter (landscape), legal (portrait), ledger (portrait), A3 (portrait), B4 (portrait), A4 (landscape)
Page 140: Performance Characteristics
Performance Characteristics Printing density 300 x 300 dpi 400 x 400 dpi or 240 x 240 dpi (options) Printing speed 4.44 inches per second for continuous forms printing 24 ppm (lower cassette, cut–sheet, letter size landscape) 21 ppm (upper cassette) Maximum effective print width 14.6 inches Duty cycle...
Page 141: Memory Requirements
Memory Requirements Depending upon the dot resolution of the printer and the type of paper used, the following controller memory requirements must be met to allow the printer to run at optimum speed. For paper up to 16 inches in length: Paper Resolution Memory...
Page 142: Physical Characteristics And Environment
Physical Characteristics and Environment Dimensions (H x W x D) 47.5” H x 50.6” W x 36.5” D (120.7 cm H x 128.5 cm W x 92.7 cm D) or 30.8” D (78.2 cm D) with the front cover and control panel removed In crate: 57.25”...
Page 143: Metric Conversion Tables
Metric Conversion Tables Length Multiply To Obtain foot 0.3048* meter (m) foot 30.48* centimeter (cm) foot 304.8* millimeter (mm) inch 0.0254* meter (m) inch 2.54* centimeter (cm) inch 25.4* millimeter (mm) meter 3.280840 foot centimeter 0.03280840 foot millimeter 0.003280840 foot meter 39.37008 inch...
Page 144 Mass and Density Multiply To Obtain pound* 0.4535924 kilogram (kg) ounce* 28.34952 gram (g) kilogram 2.204622 pound* gram 0.03527397 ounce* * avoirdupois Temperature To Convert From Use Formula temperature Celsius (t temperature Fahrenheit (t = 1.8t + 32 temperature Fahrenheit (t temperature Celsius (t = (t –...
Page 145 Illustrated Parts List Overview ............C–3 Maintenance Tools .
Page 146 Miscellaneous Details ..........C–82 P/S EU Assembly (Main Power Supply Assembly) .
Page 147: Overview
Overview This appendix contains a list of required maintenance tools, a parts list sorted by description, and the illustrated parts for the L5031 printer. The illustrations begin on page C–13. When locating parts, note the following: Illustrations are followed by corresponding part number descriptions. In illustrations, a small locator letter refers to a magnified area shown by a large locator letter.
Page 148: Maintenance Tools
Maintenance Tools In order to perform maintenance on the printer, the following tools are required. Item Part # Cleaner, Brush 703531–169 Cleaner, Wire (felt tip) 703531–168 Drum, Auxiliary Rod 703531–170 Drum, Dummy 703531–173 Drum, Freshener 703531–171 Engine Checker 703531–197 Engine Height Adjuster 703531–174 LED Positioning Pin (2 ea/set) 703531–172...
Page 149: Parts List By Description
Parts List by Description Item Part Number Page Bearing, Conveyer 703531–554 C–27 Belt, 106MXL 703531–057 C–53 Belt, 158MXL 703531–058 C–53 Belt, 265MXL4.8 703531–034 C–45 Belt, 3M–132–6 703531–028 C–93 Belt, 60S3M174 (6 ea./set) 703531–029 C–93 Belt, 60S3M177 703531–033 C–71 Belt, 60S3M210 703531–030 C–93 Belt, 60S3M501...
Page 150 Item Part Number Page Cable Assembly, Serial 232/422 703678–001 C–67 Cable Assembly, for Disk Drive Power 703676–001 Cable (from CN25 to Developer Drive Assembly) 703531–537 C–59 Cable, Varistor/High Voltage 703531–163 C–41 Capacitor (1 per set) 703531–561 C–81 Capacitor (6 per set) 703542–001 C–81 Cassette (L250–A3)
Page 151 Item Part Number Page Developer 703548–001 C–19 Developing Drive Unit 703531–143 C–41 Developing Unit 703533–001 C–17 Disk Drive Assembly, Floppy 140790–001 Drum Guide Unit, Front 703531–128 C–57 Drum Support Unit 703531–130 C–57 Drum, Photoreceptor 703535–001 C–17 EPS3 703531–125 C–27 EPS4 703531–126 C–27 Fan for Fuser, Cooling...
Page 152 Item Part Number Page Harness Assembly, Halogen 703531–112 C–99 Harness Assembly, I/O 26 703531–107 C–41 Harness Assembly, Power Supply 703531–164 C–41 Harness Feed P003, Wire 703531–076 C–53 Harness Feed P004, Wire 703531–077 C–53 Harness Feed P031, Cable 703531–078 C–53 Harness, for Stacker J011 703531–094 Harness, for Stacker J012 703531–095...
Page 153 Item Part Number Page Motor Unit, Elevator 703531–141 C–41 Motor Unit, Feed 703531–040 C–93 Motor Unit, Magroll 703531–039 C–71 Motor Unit, Sleeve 703531–038 C–71 Motor Unit, Tractor 703531–041 C–57 Motor Unit, Transfer Elevator 703531–159 C–75 Motor, Swinger (2ea./set) 703531–080 O–Ring, CO–0013–A (3ea./set) 703531–111 C–57 Operation Sw.
Page 154 Item Part Number Page Roller, Pickup/Reverse Unit 703531–213 Screw Kit, L5000 703531–210 Sensor, Exit 703531–120 C–93 Sensor A, PCB 703531–153 C–35 Sensor Assembly, Resist. (2ea./set) 703531–072 C–53 Sensor B, PCB 703531–154 C–35 Sensor, Drum Surface Potential Assembly 703531–110 Sensor Unit, Paper End 703531–167 Sensor Unit, Timing 703531–073...
Page 155 Item Part Number Page Toner Cartridge 703532–001 C–19 Tractor Unit Assembly 703531–114 C–57 Transfer Unit 703531–137 C–17 Transport Shaft “B” Assembly 703531–224 C–27 Tray Unit, Face Up 703531–166 C–15 Trigger Coil 703531–165 Varistor Assembly/Transfer Charger 703531–103 C–27 Illustrated Parts List C–11...
Page 156 BLANK PAGE C–12 Illustrated Parts List...
Page 157 FRONT VIEW BACK VIEW Overview Illustrated Parts List C–13...
Page 158: Front View Of Printer
Figure 1. Front View of Printer C–14 Illustrated Parts List...
Page 159 Quantity Item Part Description – Figure 1. Front View of Printer Assembly 703531–003 Cassette (S500–A4) 703531–004 Cassette (S500–Letter) 703531–005 Cassette (S250–A4) 703531–006 Cassette (S250–Letter) 703531–007 Cassette (S250–B4) 703531–008 Cassette (S250–A3) 703531–009 Cassette (S250–Legal) 703531–010 Cassette (S250–Ledger) 703531–011 Swing Plate 703531–166 Face Up Tray Assembly 703531–524 Cover, Front Stand, Painted...
Page 160: Printer Front Cover Assembly Open
Figure 2. Printer Front Cover Assembly Open C–16 Illustrated Parts List...
Page 161 Quantity Item Part Description – Figure 2. Printer Front Cover Assembly Open Assembly 703533–001 Developer Assembly (See Figure 3, Item 5, For Details) 703536–001 Main Charger (See Figure 4, Item 5, For Details) 703531–118 El Assembly (D/L) (See Figure 4, Item 10, For Details) 703534–001 Cleaning Assembly (See Figure 5, Item 5, For Details)
Page 162: Developer Assembly
15 Ref. Figure 3. Developer Assembly C–18 Illustrated Parts List...
Page 163 Quantity Item Part Description – Figure 3. Developer Assembly Assembly 703533–001 Developer Assembly 703532–001 Toner Cartridge 703548–001 Developer Illustrated Parts List C–19...
Page 164: Miscellaneous Details
Figure 4. Miscellaneous Details C–20 Illustrated Parts List...
Page 165 Quantity Item Part Description – Figure 4. Miscellaneous Details Assembly 703536–001 Main Charger 703531–118 LED For Discharge Assembly 703538–001 Pre–Charger Illustrated Parts List C–21...
Page 166: Cleaning Assembly & Photoreceptor Drum
Figure 5. Cleaning Assembly & Photoreceptor Drum C–22 Illustrated Parts List...
Page 167 Quantity Item Part Description – Figure 5. Cleaning Assembly & Photoreceptor Drum Assembly 703534–001 Cleaning Assembly 703535–001 Photoreceptor Drum Illustrated Parts List C–23...
Page 168: Transfer Assembly
NOTE: ITEM 5 IS NOT PART OF THIS ASSEMBLY Figure 6. Transfer Assembly (Sheet 1 of 3) C–24 Illustrated Parts List...
Page 169 Figure 6. Transfer Assembly (Sheet 2 of 3) Illustrated Parts List C–25...
Page 170 Figure 6. Transfer Assembly (Sheet 3 of 3) C–26 Illustrated Parts List...
Page 171 Quantity Item Part Description – Figure 6. Transfer Assembly Assembly 703531–208 Guide, Paper Transport (upper) 703531–103 Varistor Assembly/Transfer Charger 703531–127 High–Voltage Connect Assembly 703537–001 Transfer Charger 703531–139 Conveyor Assembly 703531–212 Transport Shaft “A” Assembly 703531–554 Bearing, Conveyer 703531–553 Holder, Bearing 703531–224 Transport Shaft “B”...
Page 172: Fuser Assembly
Figure 7. Fuser Assembly (Sheet 1 of 4) C–28 Illustrated Parts List...
Page 173 Figure 7. Fuser Assembly (Sheet 2 of 4) Illustrated Parts List C–29...
Page 174 Figure 7. Fuser Assembly (Sheet 3 of 4) C–30 Illustrated Parts List...
Page 175 THIS VIEW ROTATED 180 Figure 7. Fuser Assembly (Sheet 4 of 4) Illustrated Parts List C–31...
Page 176 BLANK PAGE C–32 Illustrated Parts List...
Page 177 Quantity Item Part Description – Figure 7. Fuser Assembly Assembly 703544–001 Lamp Housing Filter 703531–138 Glass Frame Assembly (Six Items In This Assembly) 703531–066 Fuser Cover Glass 703531–113 Connector/Fuser FU–Male 703531–102 Fuser Fuse Assembly 703541–001 Xenon Lamp Assembly 703531–065 Halogen Lamp Illustrated Parts List C–33...
Page 178 ITEM 20 IS NOT PART NOTE: OF THIS ASSEMBLY Figure 8. Base, WT Assembly C–34 Illustrated Parts List...
Page 179 Quantity Item Part Description – Figure 8. Base, WT (Waste Toner) Assembly Assembly Base, WT Assembly 703531–153 Sensor–A PC Board 703531–106 Microswitch V–014–1C23 703531–154 Sensor–B PC Board 703539–001 Waste Toner Box Illustrated Parts List C–35...
Page 180: Back View Of Printer
Figure 9. Back View of Printer C–36 Illustrated Parts List...
Page 181 Quantity Item Part Description – Figure 9. Back View of Printer Assembly 703531–203 Top Cover Assembly 703531–202 Rear Cover Assembly, Right 703531–201 Rear Cover Assembly, Left 703531–206 Top Cover Holder, C CK 703531–205 Top Cover Holder, A CK ––––––––– See Figure 10 For Close–up Of Printer 703531–062 Power Supply for Corona’s HV Power Supply 703531–063...
Page 182 Figure 10. Back View of Printer, Closeup (Sheet 1 of 2) C–38 Illustrated Parts List...
Page 183 Figure 10. Back View of Printer, Closeup (Sheet 2 of 2) Illustrated Parts List C–39...
Page 184 BLANK PAGE C–40 Illustrated Parts List...
Page 185 Quantity Item Part Description – Figure 10. Back View of Printer, Closeup Assembly 703531–190 Cut Sheet Output Assembly (See Figure 11 For Details) 703531–068 Heat Pipe Assembly (See Figure 12 For Details) 703531–189 Cut Sheet Feeder Assembly (See Figure 13 For Details) –––––––––...
Page 186 BLANK PAGE C–42 Illustrated Parts List...
Page 187 Quantity Item Part Description – Figure 10. Back View of Printer, Closeup (continued) Assembly 703531–117 AC Blower Assembly (See Figure 22 For Details) 703531–062 Power Supply For Corona (See Figure 23 For Details) 703531–148 DC Power Supply Assembly (See Figure 25 For Details) 703531–147 Connector Assembly For Transfer Ozone (See Figure 24, Item 5, For Details)
Page 188: Cut Sheet Output Assembly
Figure 11. Cut Sheet Output Assembly C–44 Illustrated Parts List...
Page 189 Quantity Item Part Description – Figure 11. Cut Sheet Output Assembly Assembly 703531–221 Output Assembly Roller–8 703531–222 Output Assembly Roller–9 703531–226 Output Assembly Roller–12 703531–O75 PHINT ON1517LA–(A) (Optical Sensor) 703531–034 Belt, 265MXL4.8 Illustrated Parts List C–45...
Page 190: Led Array
Figure 12. LED Array C–46 Illustrated Parts List...
Page 191 Quantity Item Part Description – Figure 12. LED Array Assembly 703551–001 LED Array (240 DPI) 703551–002 LED Array (300 DPI) 703551–003 LED Array (400 DPI) 703531–068 Heat Pipe Assembly Illustrated Parts List C–47...
Page 192: Cut Sheet Feeder Assembly
5(3) Figure 13. Cut Sheet Feeder Assembly (Sheet 1 of 4) C–48 Illustrated Parts List...
Page 193 Figure 13. Cut Sheet Feeder Assembly (Sheet 2 of 4) Illustrated Parts List C–49...
Page 194 Figure 13. Cut Sheet Feeder Assembly (Sheet 3 of 4) C–50 Illustrated Parts List...
Page 195 Figure 13. Cut Sheet Feeder Assembly (Sheet 4 of 4) Illustrated Parts List C–51...
Page 196 BLANK PAGE C–52 Illustrated Parts List...
Page 197 Quantity Item Part Description – Figure 13. Cut Sheet Feeder Assembly Assembly 703531–189 Cut Sheet Feeder Assembly 703531–072 Resist Sensor Assembly 703531–050 Pick Up Roller Assembly 703531–577 Thumbscrew, In/Out 703531–051 Reverse Assembly 703531–071 Cassette Sensor BD–1 703531–070 Feeder Board With ROM–OP–1 703531–069 Feeder ROM–OP1 703531–077...
Page 198: Front View, Left Side
Figure 14. Front View, Left Side (Sheet 1 of 3) C–54 Illustrated Parts List...
Page 199 Figure 14. Front View, Left Side (Sheet 2 of 3) Illustrated Parts List C–55...
Page 200 Figure 14. Front View, Left Side (Sheet 3 of 3) C–56 Illustrated Parts List...
Page 201 Quantity Item Part Description – Figure 14. Front View, Left Side Assembly 703531–130 Drum Support Assembly 703531–111 O–Ring CO–0013–A 703531–128 Guide Assembly, Front Drum 703531–114 Tractor Assembly 703531–037 Motor Assembly, Drum 703531–075 PHINT ON1517LA–(A) (Optical Sensor) 703531–041 Motor Assembly, Tractor 703531–031 Belt 60S3M264 703531–232...
Page 202: I/O Board
Figure 15. I/O Board C–58 Illustrated Parts List...
Page 203 Quantity Item Part Description – Figure 15. I/O Board Assembly 703531–152 I/O PC Board 703531–537 Cable (from CN25 to Developer Drive Assembly—see Figure 19, items 20 and 25 ) Illustrated Parts List C–59...
Page 204 Figure 16. PE Sensor Assembly C–60 Illustrated Parts List...
Page 205 Quantity Item Part Description – Figure 16. PNE (Paper Near–End) Sensor Assembly Assembly 703531–154 Sensor–B PC Board 703531–153 Sensor–A PC Board Illustrated Parts List C–61...
Page 206: Controller Module Assembly
Figure 17. Controller Module Assembly (Sheet 1 of 4) C–62 Illustrated Parts List...
Page 207 Figure 17. Controller Module Assembly (Sheet 2 of 4) Illustrated Parts List C–63...
Page 208 Figure 17. Controller Module Assembly (Sheet 3 of 4) C–64 Illustrated Parts List...
Page 209 Figure 17. Controller Module Assembly (Sheet 4 of 4) Illustrated Parts List C–65...
Page 210 BLANK PAGE C–66 Illustrated Parts List...
Page 211 Quantity Item Part Description – Figure 17. Controller Module Assembly Assembly 704056–001 Controller Module Assembly 703813–001 PCBA 030 Motherboard, 33MHz, V3 704360–001 PCBA 040 Motherboard, 33Mhz, V2 703678–001 Serial Cable 703679–001 Diagnostic Cable Assembly 703680–001 Parallel Cable Assembly 703595–001 Print Engine Cable 703682–001 Front Panel Cable 202377–001...
Page 212: Head Blower Fan Assembly
Figure 18. Head Blower Fan Assembly C–68 Illustrated Parts List...
Page 213 Quantity Item Part Description – Figure 18. Head Blower Fan Assembly Assembly 703531–104 Head Cleaning Fan 703531–001 LED Air Filter Illustrated Parts List C–69...
Page 214: Developer Drive Assembly
Figure 19. Developer Drive Assembly C–70 Illustrated Parts List...
Page 215 Quantity Item Part Description – Figure 19. Developer Drive Assembly Assembly 703531–143 Developer Drive Assembly 703531–219 Plate, Developer Assembly Gear #9 703531–134 Gear Assembly For Developer Assembly 703531–215 Plate, Developer Assembly Gear #10 703531–039 MAGROLL Motor Assembly 703531–038 Sleeve Motor Assembly 703531–216 Plate, Developer Assembly Gear #6 703531–217...
Page 216: General Details
Figure 20. General Details (Sheet 1 of 2) C–72 Illustrated Parts List...
Page 217 Figure 20. General Details (Sheet 2 of 2) Illustrated Parts List C–73...
Page 218 BLANK PAGE C–74 Illustrated Parts List...
Page 219 Quantity Item Part Description – Figure 20. General Details Assembly 703531–107 I/O 26 Harness Assembly 703531–108 Drawer Harness Assembly 703531–075 PHINT ON1517LA–(A) (Optical Sensor) 703531–159 Transfer Elevator Motor Assembly Illustrated Parts List C–75...
Page 220: Filter Assembly Box
Figure 21. Filter Assembly Box C–76 Illustrated Parts List...
Page 221 Quantity Item Part Description – Figure 21. Filter Assembly Box Assembly 703540–001 VEFE Assembly (Ozone Filter Box) 703531–116 Blower Assembly (Main Blower Fan) Illustrated Parts List C–77...
Page 222: Ac Blower Assembly
Figure 22. AC Blower Assembly C–78 Illustrated Parts List...
Page 223 Quantity Item Part Description – Figure 22. AC Blower Assembly Assembly 703531–117 AC Blower Assembly Illustrated Parts List C–79...
Page 224: Power Supply For Flash Lamp
Figure 23. Power Supply For Flash Lamp C–80 Illustrated Parts List...
Page 225 Quantity Item Part Description – Figure 23. Power Supply For Flash Lamp Assembly 703531–064 Power Supply For Flash Lamp 703531–550 Power Supply For Flash Lamp 703542–001 Capacitor (used on 703531–064) 703531–561 Capacitor (used on 703531–550) Illustrated Parts List C–81...
Page 226: Miscellaneous Details
Figure 24. Miscellaneous Details C–82 Illustrated Parts List...
Page 227 Quantity Item Part Description – Figure 24. Miscellaneous Details Assembly 703531–147 Connect Assembly For Transfer Ozone 703531–163 Varistor/High–Voltage Cable Illustrated Parts List C–83...
Page 228: P/S Eu Assembly (Main Power Supply Assembly)
Figure 25. P/S EU Assembly (Main Power Supply Assembly) C–84 Illustrated Parts List...
Page 229 Quantity Item Part Description – Figure 25. P/S EU (External Unit) Assembly (Main Power Supply Assembly) Assembly 703531–148 DC Power Supply Assembly 703531–150 Power Supply Sub–PC Board 703531–149 Power Supply PC Board Illustrated Parts List C–85...
Page 230: Mpu Pc Board
Figure 26. MPU PC Board C–86 Illustrated Parts List...
Page 231 Quantity Item Part Description – Figure 26. MPU PC Board Assembly 703531–151 MPU PC Board Illustrated Parts List C–87...
Page 232: Back View, Left Side
Figure 27. Back View, Left Side (Sheet 1 of 5) C–88 Illustrated Parts List...
Page 233 Figure 27. Back View, Left Side (Sheet 2 of 5) Illustrated Parts List C–89...
Page 234 Figure 27. Back View, Left Side (Sheet 3 of 5) C–90 Illustrated Parts List...
Page 235 Figure 27. Back View, Left Side (Sheet 4 of 5) Illustrated Parts List C–91...
Page 236 Figure 27. Back View, Left Side (Sheet 5 of 5) C–92 Illustrated Parts List...
Page 237 Quantity Item Part Description – Figure 27. Back View, Left Side Assembly 703531–156 Cutter Solenoid Assembly 703531–029 Belt 60&3M174 –––––––– Exit Assembly 703531–031 Belt 60S3M264 703531–040 Feed Motor Assembly 703531–075 PHINT ON1517LA–(A) (Optical Sensor) 703531–028 Belt 3M–132–6 703531–031 Belt 60S3M264 703531–030 Belt 60S3M210 703531–123...
Page 238: Drum Shaft Assembly & Belts
Figure 28. Drum Shaft Assembly & Belts C–94 Illustrated Parts List...
Page 239 Quantity Item Part Description – Figure 28. Drum Shaft Assembly & Belts Assembly 703531–531 Cleaner Driver Coupler (plastic). Replace with 705579–001 (metal). 705579–001 Cleaner Driver Coupler (metal) 703531–032 Belt 60S3M501 703531–532 Gear, Cleaner Drive 703531–031 Belt 60S3M264 703531–075 PHINT ON1517LA–(A) (Optical Sensor) 703531–133 Tension Pulley Drum Assembly 703531–144...
Page 240: Duct Flash Assembly
Figure 29. Duct Flash Assembly C–96 Illustrated Parts List...
Page 241 Quantity Item Part Description – Figure 29. Duct Flash Assembly Assembly 703531–105 Cooling Fan For Fuser Illustrated Parts List C–97...
Page 242 Figure 30. Bracket FU Connect Assembly (Fuser Assembly) C–98 Illustrated Parts List...
Page 243 Quantity Item Part Description – Figure 30. Bracket FU (Fuser Unit) Connect Assembly Assembly 703531–142 Assembly For Fuser 703531–112 HAL Harness Assembly Illustrated Parts List C–99...
Page 244 BLANK PAGE C–100 Illustrated Parts List...
Page 245: Back Of Printer, Left Side
Figure 31. Back of Printer, Left Side (Sheet 1 of 6) Illustrated Parts List C–101...
Page 246 Figure 31. Back of Printer, Left Side (Sheet 2 of 6) C–102 Illustrated Parts List...
Page 247 Figure 31. Back of Printer, Left Side (Sheet 3 of 6) Illustrated Parts List C–103...
Page 248 Figure 31. Back of Printer, Left Side (Sheet 4 of 6) C–104 Illustrated Parts List...
Page 249 Figure 31. Back of Printer, Left Side (Sheet 5 of 6) Illustrated Parts List C–105...
Page 250 ROTATED 180 DEGREES Figure 31. Back of Printer, Left Side (Sheet 6 of 6) C–106 Illustrated Parts List...
Page 251 Quantity Item Part Description – Figure 31. Back of Printer, Left Side Assembly 703531–131 EPSO Assembly (Paper Motion Sensor) 703531–075 PHINT ON1517LA–(A) (Optical Sensor) 703531–106 Microswitch SW V–014–1C23 703531–129 Solenoid Assembly 703531–052 Separating Finger Assembly 703531–111 O–Ring CO–0013–A 703531–110 Sensor, Drum Surface Potential Assembly 703531–135 Charger Connect Assembly 703531–106...
Page 252: Installation/Maintenance Tools
Figure 32. Installation/Maintenance Tools C–108 Illustrated Parts List...
Page 253 Quantity Item Part Description – Figure 32. Installation/Maintenance Tools Assembly 703531–168 Wire Cleaner 703531–169 Brush Cleaner 703531–187 Scraper For Fuser Cover Glass 703531–207 Tractor Alignment Tool 703531–173 Dummy Drum 703531–181 Level 703531–188 Special Paper Tissue 703531–197 Engine Checker L5024 703531–184 Power Supply For Surface Potential 703531–183 Special Cloth...
Page 254 BLANK PAGE C–110 Illustrated Parts List...
Page 255 Optional Cut Sheet Feeder Physical Description ........... D–2 Paper Feed Cassette .
Page 256: Physical Description
Physical Description The front, back, and rear views of the cut–sheet feeder unit are shown in the following illustrations. Front side D–2 Optional Cut Sheet Feeder...
Page 257 Back side Optional Cut Sheet Feeder D–3...
Page 258 Rear side (board side) D–4 Optional Cut Sheet Feeder...
Page 259: Paper Feed Cassette
Paper Feed Cassette Optional Cut Sheet Feeder D–5...
Page 260: Setup And Connection
Setup and Connection Setup The cut–sheet feeder unit is attached to the main unit frame by attaching the hooks of the front and rear frames onto the main unit frame, and securing the burrs of the front and rear frames to the main unit frame with 2 bolts each. D–6 Optional Cut Sheet Feeder...
Page 261 When attaching the cut–sheet feeder unit, remove the wire cover. Pass the lines going to the front cover interlock switch and the operation panel underneath this cover. Optional Cut Sheet Feeder D–7...
Page 262 Connections The cut–sheet feeder unit is connected to the MPU board, I/O board, and DC power supply board, as shown below. J003 D–8 Optional Cut Sheet Feeder...
Page 263: Basic Principles
Basic Principles Upon receiving instructions from the printer, the cut–sheet feeder unit picks up paper from the selected paper cassette and supplies the paper to the transfer point. The unit is equipped with the following sensors and actuators: ICIL2 ICIL1 IPS10–12 /IPS 20–22: Upper/Lower level paper size detector sensors PES1 / PES2 Upper level / Lower level paper empty sensor...
Page 264: Drive Principle
Drive principle There are 4 types of rollers in the transport path of the cut–sheet feeder unit: Carry–out roller – driven by the cut–sheet pick up motor, via the cut–sheet pick up clutch. Input feed roller – driven by the cut–sheet pick up motor, via the cut–sheet pick up clutch.
Page 265: Control Principles
Control principles The following controlling detector terminals (sensors, switches) are assembled into the cut–sheet feeder unit. Upper level / Lower level paper size detector sensor These sensors are each comprised of 3 switches set on the board. There are 7 paper sizes (including no cassette).
Page 266: Paper Feed Cassettes
Paper feed cassettes IPS 12 / 22 IPS 11 / 21 IPS 10 / 20 IPS 10, 11, and 12 = Upper level paper size detector sensors IPS 20, 21, and 22 = Lower level paper size detector sensors There are three holes in the forward end of the cut–sheet paper feed cassettes. Plastic inserts are to be set in these holes according to the size of the cut–sheet paper loaded in the cassette (as shown in the table below).
Page 267: Upper Level / Lower Level Paper Empty Sensor (Pes1 / Pes2
Upper level / lower level paper empty sensor (PES1 / PES2) These sensors are photo–interrupters. When the paper in the paper supply cassette runs out, the lever lowers and blocks the light between the light emitters and receptors, causing detection of no paper. Cut sheet feed sensor (PFS), paper register sensor These sensors are photo–interrupters located partway in the paper transport path.
Page 268: Paper Timing Sensor (Pts
Paper timing sensor (PTS) This sensor is also a photo–interrupter. However, because the output signal is used as the cut–sheet leading–edge detection signal and affects printing quality, the mechanical aspects (lever) have been eliminated. The paper timing sensor consists of an LED light emitter and receptor on either side of the transport path.
Page 269: Cut Sheet Pick Up Motor Encoder (Pme
Cut sheet pickup motor encoder (PME) This is a rotary encoder, comprised of a slotted plate attached to the cut–sheet pick up motor rotating axis, with a light emitter and receptor on either side of the plate. The motor rotation is detected by the pulse string that is created by light passing through the rotating slotted plate.
Page 270: Cut Sheet Feed Motor Encoder (Fme
Cut sheet feed motor encoder (FME) This is also a rotary encoder, comprised of a slotted plate attached to the cut–sheet pick up motor rotating axis, with a light emitter and receptor on either side of the plate. The motor rotation is detected by the pulse string that is created by light passing through the rotating slotted plate.
Page 271: Paper Guide Interlock Switch (Icil
Paper guide interlock switch (ICIL) This is a micro–switch that detects whether the paper guide is open or not. It is also interlocked with this unit’s 24V system (actuator drive system), so that when this switch is off, the actuator power is also off. Optional Cut Sheet Feeder D–17...
Page 272: Detection Errors
Detection errors The errors detected by the previously discussed sensors and switches are as follows: Upper level cassette section error Error Code Contents Pick up miss Paper did not move to the paper register sensor within a certain time after the carry–out roller operated (upper level pick–up misjudgment, timer started with PPC1 coming on, and timed out before...
Page 273: Transfer Unit Error
Transfer unit error Error Code Contents Delayed jam Too much time passed for the paper to move from the paper register clutch to the paper timing sensor (delayed jam, judgment timer started with PRC coming on, and timed out before PTS on). Judgement timer setting = 680msec.
Page 274: Unit Sequencer Section Errors
Unit sequencer section errors Error Code Contents Motor revolution abnormality 1 Revolution abnormality occurred in the cut–sheet pick up motor (PPM revolution abnormality, monitor timer counted up during paper supply preparation operations). Monitor timer setting = 200msec. Motor revolution abnormality 2 Revolution abnormality occurred in the cut–sheet feed motor (PFM revolution abnormality, monitor timer counted up...
Page 275: Basic Operation
Basic Operation The cut–sheet feeder unit executes reset start processing (initializing of CPU, etc.) when power is turned on. It then executes the following main routine while waiting for the cassette specification command and the paper supply preparation start command to be transmitted from the printer. Mechanism initialization Analog input processing Chattering absorption processing...
Page 276 Mechanism initialization This processing is executed only once, to confirm that there are no errors when stopped or when the motor is on. However, when an initializing request is received from the printer, this process is executed again. The ready condition is deactivated and bit waiting for basic status (bit 4) is cleared to “0”, the same as when initializing after reset starting.
Page 277: Cut Sheet Output Unit
Cut Sheet Output Unit Physical Description The front and rear views of the cut–sheet output unit are shown in the following illustrations. Front side Optional Cut Sheet Feeder D–23...
Page 278 Rear side D–24 Optional Cut Sheet Feeder...
Page 279: Setup And Connection
Setup and Connection Setup 1. In order to assemble the cut–sheet output unit, secure the burrs of the front and rear frames to the main unit frame with bolts (2 each). Optional Cut Sheet Feeder D–25...
Page 280 2. After the unit has been attached to the frame and secured, attach the entrance roller joint shaft, and secure the shaft with the E ring. D–26 Optional Cut Sheet Feeder...
Page 281 Connections Connect the cut–sheet output unit connector to the main unit frame connector that is attached to the MPU board’s CN7. Optional Cut Sheet Feeder D–27...
Page 282: Basic Principles
Basic Principles The cut–sheet output unit leads cut–sheet paper ejected from the main unit to the top cover’s face–down output paper tray. This unit has 3 types of transporting rollers, the entrance, intermediate, and output rollers, that are driven by the main unit feed motor. (Refer to “Main Unit Feed Roller Drive,”...
Page 283 Optional Power Paper Stacker Physical Description ........... E–2 Setup and Connection .
Page 284: Physical Description
Physical Description The front, rear, and internal views of the power paper stacker are shown in the following illustrations. Front (Output side) DOWN key HEAVY key STOP key AUTO key Hook Head/tail length measuring gauge Top/bottom (in inches) adjust knob Safety stop bar Safety stop bar Minimum limit...
Page 285 Rear (Input side) Swinger Swinger motor (SM) Feed roller Assisting arm Jam Sensor (PPS) Elevator maximum limit switch (LIMT1) Elevator Elevator Motor Drive Gear Optional Power Paper Stacker E–3...
Page 286 Front (Interior) Safety sensor (SS1) – behind panel Paper surface sensor 2 (PSS2) Transfer belt Paper surface Elevator sensor 1 (PSS1) E–4 Optional Power Paper Stacker...
Page 287 Rear (Interior) Hooks Paper surface sensor 2 (PSS2) Paper surface sensor 1 (PSS1) Safety sensor 2 (SS2) Controller board Optional Power Paper Stacker E–5...
Page 288: Setup And Connection
Setup and Connection CAUTION Before installing or removing the power stacker, the printer must be adjusted to the proper height and be leveled. Failure to do this will damage both the printer and the stacker and will prevent installation or removal. 1.
Page 289 2. Connect the paper stacker connector to the connector located across the noise filter box of the printer main power supply. Connector Noise filter box Optional Power Paper Stacker E–7...
Page 290 3. Attach the ground wire to the proper terminal with the screws, as shown. The paper stacker is connected to the printer as follows: Power Paper Stacker E–8 Optional Power Paper Stacker...
Page 291 4. To remove the stacker, press the release lever (located on the front side) to remove the hooks from the studs. Release lever The power paper stacker contains the following keys for operating the elevator: AUTO: Sets the elevator in automatic mode. Pressing this key causes the elevator table to rise until it reaches its maximum upper position and enables the stacker.
Page 292 Page Length (inches) Max. Stack Height (inches) 8.66 8.66 8.50 8.07 7.64 7.20 10.0 6.77 10.5 6.34 11.0 5.91 11.5 5.47 12.0 5.12 The power stacker folds output paper at the perforation and accumulates it. Fan fold paper output from the printer is transferred by feed roller. After moving between the feed rollers of the unit, they are output on the elevator table through the swinger swinging back and forth.
Page 293 Fan fold paper output from the swingers is folded at the perforation by the assisting arms responding to the actions of the swingers (not activated when the head and tail length of the sheet is 7 x 8.5 inches). Paper is accumulated on the elevator table while being pressed by the transfer belts.
Page 294 The following sensors and actuators are arranged onto this unit: SMT: Stacker motor SS2: Safety sensor 2 SME: Stacker motor encoder SFS: Stacker full sensor Assisting arm drive motor EDS: Elevator down sensor APS1: Assisting arm position sensor LIMT1: Elevator maximum limit switch PMS: Paper moving sensors LIMT2: Elevator minimum limit switch...
Page 295: Drive Principles
Drive Principles Feed roller and transfer belt Both feed roller and transfer belt are driven by the stacker motor. Optional Power Paper Stacker E–13...
Page 296 Also, the space between the transfer belts can be adjusted by the top and bottom adjusting knob. E–14 Optional Power Paper Stacker...
Page 297: Swinger
Swinger The swinger is driven by the swinger motor. Optional Power Paper Stacker E–15...
Page 298: Assisting Arm
Assisting Arm The assisting arm is driven by the assisting arm driving motor. The assisting arm is not activated when the head and tail length of the sheet is 7 x 8.5. E–16 Optional Power Paper Stacker...
Page 299: Elevator Table
Elevator Table The elevator table is driven by the elevator motor. Optional Power Paper Stacker E–17...
Page 300: Control Principles
Control Principles The following control detectors (sensors and switches) are built into the power stacker. Transfer Unit Paper Sensor (PMS) This is a photo–interrupter comprised of a light emitter and receptor and a lever. It is located partway in the paper guide at the entrance of the power stacker. When paper output from the printer passes through the guide and kicks the lever, the light passing between the light emitter and receptor is blocked, causing paper to be detected in that location.
Page 301: Jam Sensor (Pps
Jam sensor (PPS) This also is a photo–interrupter comprised of a light emitter and receptor and a lever. It is located partway on the toothed belt. When the paper fold falls on this belt and kicks the lever, the light passing between the light emitter and receptor is blocked, and the sensor turns on.
Page 302: Paper Surface Sensor 1/2 (Pss1/2
Paper surface sensor 1/2 (PSS1/2) These sensors are each comprised only of light emitters and receptors located on the front side and rear side. When paper stacking up on the elevator table reaches this height, the light is blocked, and turns the sensor on. This sensor controls the height of the elevator table.
Page 303: Stacker Full Sensor (Sfs), Elevator Down Sensor (Eds
Stacker full sensor (SFS), Elevator down sensor (EDS) These are also photo–interrupter sensors, both used for detecting the position of the elevator table. The stacker full sensor indicates that the amount of folded paper has reached the limit. The elevator down sensor indicates that the elevator which has begun its way down has reached the down position (the position where the operator removes the paper).
Page 304 Page Length (inches) Max. Stack Height (inches) 9.37 8.94 8.50 8.07 7.64 7.20 10.0 6.77 10.5 6.34 11.0 5.91 11.5 5.47 12.0 5.12 E–22 Optional Power Paper Stacker...
Page 305: Stacker Motor Encoder (Sme), Elevator Motor Encoder (Eme
Stacker motor encoder (SME), Elevator motor encoder (EME) These sensors detect abnormal DC motor revolution. They consist of a mask attached to the motor axis, light emitters, and light receptors. The motor revolution is monitored by the length of time that blockages of light occur between the light emitter and receptor.
Page 306: Swinger Position Sensor (Sps), Assisting Arm Position Sensor (Aps1
Swinger position sensor (SPS), Assisting arm position sensor (APS1) These sensors detect the home position of the stepping motor. They consist of a slotted plate, light emitters, and light receptors. The location of the slot detected by the light emitters and receptors is set as home position. Motor revolution abnormality is also monitored by whether home position is detected within the set time.
Page 307: Elevator Upper Limit / Lower Limit Switches (Limt1 / Limt2
Elevator Upper limit / Lower limit switches (LIMT1 / LIMT2) These are limit switches to prevent the elevator table from rising too high or dropping too low. If for some reason the elevator table rises abnormally high or drops abnormally low, one of these switches comes on, and the elevator table stops. Elevator upper limit switch Elevator lower...
Page 308: Safety Sensors 1/2 (Ss1/2
Safety sensors 1/2 (SS1/2) These are safety switches in case the operator accidentally gets his hand caught between the frame and elevator table of the power stacker. When this happens, the bar inside the cover tilts, and the contact point opens. This switch is interlocked with the power stacker 24V system (actuator drive system).
Page 309: Detection Errors
Detection Errors The errors detected by these sensors and switches are as follows: Operator call status error Error Code Contents Interlock action Safety sensor 1 or 2 turned off, and interlock operated. Folding defective Defective folding of paper occurred (PPS on or off time counted up).
Page 310: Basic Operation
Basic Operation After initializing (due to turning on the power or receiving an initialization request from the printer), the power stacker enters into the following main loop and repeatedly executes the various subroutines. However, the actuator driving subroutines are selectively executed only upon the power stacker receiving execution commands from the printer.
Page 311 Status confirmation processing Checks the detection data of the sensors and switches within the paper feeding unit. If there is any abnormality, executes abnormality processing. Communication processing Loads data transmitted from the printer, executes command analyzing processing, and returns status. Driving the stacker Initializes, drives, and stops the stacker.
Page 312: Belt Removal Procedures
Belt Removal Procedures This section describes the mechanical structure of the power paper stacker and how to detach the various belts. The power stacker should be reassembled in the reverse order of the procedures described in this section. Return the screws to their original positions, as they may vary in type.
Page 313 3. Remove the screws (3) securing the stacker cover, then pull off the cover. Optional Power Paper Stacker E–31...
Page 314: Inside The Left Frame
Inside the Left Frame Paper Stacker Printer Tension Pulley Belt A Belt C Belt B Belt S Belt D E–32 Optional Power Paper Stacker...
Page 315 1. To remove Belt S, push the tension pulley to the right. Belt S (S3M–250–6) Sensors PPS and PSS3 are provided only for the power stacker 2. 2. Remove Belt A while rotating the gear assembly counterclockwise by hand. 3. Remove Belt B while rotating the gear assembly counterclockwise by hand. Gears Belt A (S3M–84–6) Belt B...
Page 316 4. To remove Belt C, remove the C–clip and remove the gear (G1) by pulling the gear forward. Belt C (S3M–275–6) Gear (G1) Sensors PPS and PSS3 are provided only for the power stacker 2. C–clip 5. To remove Belt D, rotate the gear (G2) by hand and remove it. Belt D (S3M–300–6) Gear (G2) E–34...
Page 317 6. When replacing the belts discussed in steps 1 through 5, reassemble them in reverse order. After replacing Belt D (S3M–300–6), adjust its belt tension: a. Loosen screws A and B. b. Using a fish scale, set the tension to approximately 6 oz. to deflect the belt 10 mm by adjusting screw A.
Page 318: Inside The Right Frame
Inside the Right Frame Paper Stacker Printer Belt E (S3M–275–6) E–36 Optional Power Paper Stacker...
Page 319 1. Before removing Belt E, mark the position of the arrow on the scale, as shown. Belt E (S3M–275–6) 2. Remove the C–clip on the arm. Then detach the arm from the pin, and tilt the arm in the direction of the arrow. C–clip Optional Power Paper Stacker E–37...
Page 320 3. Remove the screw securing the plate. Then remove the plate. 4. Remove the C–clip (shown below), then remove the belt and the pulley. 5. Remove the pointer from Belt E. Then remove Belt E from the gear assembly G3 by pulling the gear assembly forward while rotating the gear forward and backward.
Page 321 6. Place the knob on the shaft and rotate the knob completely clockwise. Then place the pointer back on Belt E where it points to the “12” on the scale. Belt E (S3M–275–6) Pointer Optional Power Paper Stacker E–39...
Page 322: Swinger Belts
Swinger Belts The swinger belts are located on the swinger and assist arm drive units (two on each unit). 1. On the swinger drive unit, disconnect the connectors (2), and detach the cable from the cable clamp. E–40 Optional Power Paper Stacker...
Page 323 2. Remove the C–clip. Then remove the link arm from the slotted disc. C–clip Slotted disc 3. Remove the screws (3) securing the swinger drive unit, and remove the unit. Screws (3) Optional Power Paper Stacker E–41...
Page 324 4. On the assist arm drive unit, disconnect the connectors (2), and detach the cable from the cable clamp. Connectors (2) 5. Remove the C–clip on the arm, then remove the arm. C–clip E–42 Optional Power Paper Stacker...
Page 325 6. Remove the screws (3) securing the assist arm drive unit to the frame, and remove the unit. Screws (3) 7. On both the swinger and the assist arm drive units: remove the screws (4), C–clip, and bush on the plate (motor side). Then remove the plate. Screws (4) C–clip Optional Power Paper Stacker...
Page 326 8. Replace the two belts on each drive unit. E–44 Optional Power Paper Stacker...
Page 327: Perforation Beater Belts
Perforation Beater Belts 1. Using a slotted screw driver, turn the elevator motor drive gear clockwise to lower the elevator table. Elevator Elevator Motor Drive Gear Optional Power Paper Stacker E–45...
Page 328 2. Remove the screws (8) securing each perforation beater. Then remove the eight belts. 3. Remove the screws (18) securing each stacker belt cover. Then remove the eight covers (see illustration on following page). 4. Remove the screws (8) securing each N tension assembly. Then remove the eight assemblies (see illustration on following page).
Page 329 5. Remove the C–clip of the bearings located at the front side of the D–shaft assembly. Beater belt cover C–clip Optional Power Paper Stacker E–47...
Page 330 6. Remove the eight stacker belts by slightly moving the two D–shaft assemblies to the rear side. IMPORTANT Before moving the D–shaft assembly, be sure to slacken the belt at the rear side. See step 5 on page E–34. BELT D (S3M–300–6) 7.
Page 331 Stacker belt Beater belt unit frame Optional Power Paper Stacker E–49...
Page 332: Elevator Belt
Elevator Belt 1. Remove the screws (4) securing the stacker table assembly to the elevator carriage assembly. Then remove the stacker table assembly. 2. Remove the screws (6) securing the stacker elevator bracket to the elevator carriage assembly. Then remove the two brackets. Screws (6) 3.
Page 333 4. Remove the screws (4) on the belt clamp plate, then remove the two belt clamp plates. 5. Remove the tension adjustment nut. Then remove the two elevator upper pulley assemblies from the stacker elevator bracket. Stacker elevator Stacker bracket, bracket Screws (4), in Step 7.
Page 334 CAUTION When installing the elevator upper pulley assembly, adjust the tension nut where it takes 14 oz. to deflect the belt 10 mm. Use caution, as the spring in the tension is very strong. After making the adjustment, lock the second nut to secure the adjustment.
Page 335: Stacker Motor
Stacker Motor 1. Disconnect the stacker motor connector, and detach the cable from the cable clamp. 2. Remove the two belts by rotating the gear assemblies. Refer to page E–33, steps 2 and 3. Belts A & B S3M–84–6 Optional Power Paper Stacker E–53...
Page 336 3. Remove the C–ring on the axis of the stacker motor. Then remove the count part. 4. Remove the screws (2) securing the stacker motor, and remove the motor. E–54 Optional Power Paper Stacker...
Page 337 5. With a hexagon wrench, loosen the set screw securing the stacker motor gear, and remove the gear. 6. Replace the motor. 7. Reassemble the parts in reverse order. Optional Power Paper Stacker E–55...
Page 338 E–56 Optional Power Paper Stacker...
Page 339: Chapter Contents
Host I/O Interfaces Chapter Contents Overview ............F–2 Performance Considerations .
Page 340: Overview
Overview The printer provides connections on the right rear side panel for the following host I/O interfaces: Centronics Parallel Interface Dataproducts Parallel Interface Serial Interface (RS–232 or RS–422) All three interfaces are active simultaneously. The parameters for each interface are selected through the control panel via the “Host Interface”...
Page 341 Diskette Drives Parallel 232/422 Switch Diagnostic Port Serial 1. The RS–232/422 select switch located on the cover plate must be set properly for your application. The factory default setting is RS–232. Figure F–1. Cable Connections Host I/O Interfaces F–3...
Page 342: Performance Considerations
Performance Considerations The printer prints 8.5” x 11” fan–fold paper at 24 pages per minute portrait (one page every 2.5 seconds) and 31 pages per minute landscape. To sustain printing at full speed, data for each page must be received and rendered in less than 2.5 seconds for portrait mode (otherwise the printer will pause).
Page 343 assign a higher priority to the print spooler increase the size of the host’s output buffer dedicate a communication controller to the printer Solving system performance problems with IBM–compatible PC’s varies depending upon the operating system (OS/2 or DOS) and the speed and manufacturer of the PC. Performance problems with networked printers are best left to the expertise of the network administrator, since each element between the printer and the host computer can affect performance.
Page 344: Centronics Parallel Interface
Centronics Parallel Interface This interface enables the printer to operate with controllers designed for buffered Centronics printers. The interface is capable of transferring up to 200,000 characters per second. The maximum cable length from the controller (host computer) to the printer is 15 feet.
Page 345: Centronics Parallel Interface Signals
Centronics Parallel Interface Signals The Centronics interface signals are defined below. PAPER EMPTY – A high true level from the printer to indicate the printer is in a fault condition. SELECT – A high true level from the printer to indicate the printer is ready for data transfer and the ON LINE key has been activated.
Page 346: Centronics Parallel Interface Configuration
Centronics Parallel Interface Configuration The printer is configured for the Centronics interface via the “Host Interface” menu. The following interface configuration parameters may be modified to meet specific application requirements: Data Bit 8 Enable* or Disable Paper Instruction Line Enable or Disable* Data Polarity Standard* or Inverted Strobe Polarity...
Page 347: Dataproducts Parallel Interface
Dataproducts Parallel Interface This interface allows the printer to operate with controllers designed for Dataproducts printers. The interface is capable of transferring up to 500,000 characters per second. The maximum cable length from the controller (host computer) to the printer is 15 feet. Dataproducts Interface Connector Pin Assignments The printer provides a 36–pin D–shell connector on the right side panel for connection of a parallel interface cable.
Page 348: Dataproducts Parallel Interface Signals
Dataproducts Parallel Interface Signals The Dataproducts interface signals are defined below. READY – A high true signal from the printer indicating AC power and DC voltages are present, paper is loaded properly, and the printer is not in a fault condition. ON LINE –...
Page 349: Dataproducts Parallel Interface Configuration
Dataproducts Parallel Interface Configuration The printer is configured for the Dataproducts interface via the “Host Interface” menu. The following interface configuration parameters may be modified to meet specific application requirements: Data Bit 8 Enable* or Disable Paper Instruction Line Enable or Disable* Data Polarity Standard* or Inverted Strobe Polarity...
Page 350: Termination Resistors
Termination Resistors For parallel interface configurations, the printer is equipped with 470–ohm pullup and 1K pulldown terminating resistors located on the printer motherboard, p/n 703220–xxx. Generally, these terminating resistors are suitable for most applications. If, however, the standard terminating resistor pack is not compatible with the particular interface driver requirements of your host computer, other values or combinations of pullup/pulldown resistors may be necessary.
Page 351: Rs-232 Serial Interface
RS–232 Serial Interface This interface is used with bit serial devices compatible with EIA RS–232C or CCITT V.24 standards. The interface circuit characteristics are compatible with the Electronic Industry Association Specification. The printer is configured as Data Terminal Equipment (DTE). The serial data transfer baud rate is selectable from the control panel.
Page 352: Rs-232 Serial Interface Signals
Table F–3. RS–232 Serial Interface Pin Assignments Signal Direction Chassis Ground Not applicable Transmit Data (TxD) From printer Receive Data (RxD) To printer Request To Send (RTS) From printer Clear To Send (CTS) To printer Data Set Ready (DSR) To printer Signal Ground Not applicable Carrier Detect (CD)
Page 353: Rs-232 Serial Interface Configuration
RS–232 Serial Interface Configuration The printer is configured for the RS–422 serial interface via the “Host Interface” menu. The following interface configuration parameters may be modified to meet specific application requirements: Host Protocol None Baud Rate 9600 Data Word Length 8 Data Bits Stop Bits 1 Bits...
Page 354: Rs-422 Serial Interface
RS–422 Serial Interface This interface is used with bit serial devices compatible with EIA–RS–422A or CCITT V.27 and V.11 standards. The interface circuit characteristics are compatible with the Electronic Industry Association Specification. The printer is configured as Data Terminal Equipment (DTE). The serial data transfer baud rate is selectable from the control panel.
Page 355 Table F–4. RS–422 Serial Interface Pin Assignments Signal Direction Chassis Ground Not applicable Transmit Data A (TxDA) From printer Transmit Data B (TxDB) From printer Receive Data A (RxDA) To printer Receive Data B (RxDB) To printer Request To Send A (RTSA) From printer Request To Send B (RTSB) From printer...
Page 356: Rs-422 Serial Interface Signals
RS–422 Serial Interface Signals The RS–422 serial interface signals are defined below. Received Data (RxD) – Serial data stream from the host to the printer. Transmitted Data (TxD) – Serial data stream from the printer to the host. Subject to protocol selection.
Page 357: S-422 Serial Interface Configuration
S–422 Serial Interface Configuration The printer is configured for the RS–422 serial interface via the “Host Interface” menu. The following interface configuration parameters may be modified to meet specific application requirements: Host Protocol None Baud Rate 9600 Data Word Length 8 Data Bits Stop Bits 1 Bit...
Page 358 F–20 Host I/O Interfaces...
Page 359 Index Cable connections: Vol. 1 2–8 About this manual: Vol. 1 1–20 power cord: Vol. 1 2–8 Auto–load fanfold paper command, theory: signal cables: Vol. 1 2–12 Vol. 1 5–74 Cassette, paper size: Vol. 1 3–23, 5–20; Vol. 2 D–12 Auxiliary rod: Vol.
Page 360: Replacing Consumables
Connector block, transfer/separator charger: Cut sheet feeder unit Vol. 2 10–39 basic operation: Vol. 2 D–21 basic principles: Vol. 2 D–9 Consumables cut sheet feed sensor (PFS): Vol. 2 D–13 See also Installing consumables; Replacing detection errors: Vol. 2 D–18 consumables feed motor encoder (FME): Vol.
Page 361 Documents, related: Vol. 1 1–21 Drive system descriptions: Vol. 1 5–28 Dangers and cautions: Vol. 1 1–20 Drum Dataproducts Parallel Interface: Vol. 2 F–9 cleaner set sensor: Vol. 2 10–79 DC power supply, voltage setting: Vol. 1 cleaning unit: Vol. 2 10–24 3–25 counter, I/O board: Vol.
Page 362: Front Cover Open
system: Vol. 1 6–1 05 – Paper Jam at Fuser: Vol. 1 7–37 adjustments: Vol. 1 6–52 07 – Scuff Lever Open: Vol. 1 7–39 08 – Cut–Sheet Path Open: Vol. 1 7–40 configuration: Vol. 1 6–2 09 – Transport Motor Fail: Vol. 1 7–41 Electromagnetic interference: Vol.
Page 363 power paper stacker: Vol. 2 E–27 Flash power supply: Vol. 1 6–19 condensers: Vol. 2 10–89 filter: Vol. 1 4–42 unit: Vol. 2 10–85 Floppy disk drives: Vol. 2 10–109 Face down paper out drive belt: Vol. 2 10–65 Front cover: Vol. 2 10–5 inside: Vol.
Page 364: Surface Potential
unit: Vol. 2 10–73 Interfaces Centronics: Vol. 2 F–2, F–6 connector locations: Vol. 2 F–2 Dataproducts: Vol. 2 F–2, F–9 performance considerations: Vol. 2 F–4 I/O board: Vol. 2 10–42 RS–232 serial: Vol. 2 F–13 adjusting drum motor: Vol. 1 9–9 RS–422 serial: Vol.
Page 365: Feed Motor
varistor: Vol. 2 10–61 cut–sheet paper pickup motor, theory: Vol. 1 5–43 Main unit drum motor, theory: Vol. 1 5–43 feed motor, control circuit: Vol. 1 6–46 main unit feed motor, theory: Vol. 1 5–43 feed roller drive, theory: Vol. 1 5–31 perforation cutter motor, theory: Vol.
Page 366 Page counts, service levels: Vol. 1 4–5 Paper guide interlock switch: Vol. 2 D–17 Paper Jam at Drum (Error 03): Vol. 1 7–34 Paper backward–feed sensor: Vol. 2 10–98 Paper Jam at Drum (Error 11): Vol. 1 7–49 detection, theory: Vol. 1 5–20 Paper Jam at Entrance (Error 16): Vol.
Page 367: Print Quality Problems
Power, requirements: Vol. 1 2–2 transfer unit paper sensor (PMS): Vol. 2 E–18 Power cord, connecting: Vol. 1 2–8 Power supply Power paper stacker: Vol. 1 3–18; Vol. 2 controller: Vol. 2 10–105 E–1 DC board: Vol. 2 10–43 assisting arm: Vol. 2 E–16 flash assisting arm position sensor (APS1): Vol.
Page 368: Safety Label Locations
Printing operations, theory: Vol. 1 5–64 German: Vol. 1 1–14 notices: Vol. 1 1–20 Printing system descriptions: Vol. 1 5–3 precautions Printronix Standard Architecture (PSA): English: Vol. 1 1–2 Vol. 1 1–23 German: Vol. 1 1–11 regulations: Vol. 2 A–7 sensors, power paper stacker: Vol.
Page 369: Service Level Page Counts
elevator internal start sensor, theory: Vol. 1 stacker elevator down sensor (EDS): Vol. 2 5–40 E–21 stacker elevator motor encoder (EME): paper backward–feed sensor, theory: Vol. 1 Vol. 2 E–23 5–40 stacker elevator switches Paper near–end, theory: Vol. 1 5–40 (ESWA/ESWS/ESWD): Vol.
Page 370: Switches And Display Messages
Vol. 2 E–18 Toner density Stand cover: Vol. 2 10–13 engine checker: Vol. 1 8–19 Supplies, genuine Printronix: Vol. 2 A–2 sensor, I/O board: Vol. 1 9–16 Supply toner command, theory: Vol. 1 5–77 Toner Density Too High (Error 2B): Vol. 1 Support roller, drum: Vol.
Page 371: Transfer/Separation Section
Toner Empty (Error 2A): Vol. 1 7–76 Transport Motor Fail (Error 09): Vol. 1 7–41 Toner level, monitoring, (theory): Vol. 1 Transport unit, cleaning: Vol. 1 4–16 5–52 Troubleshooting: Vol. 1 7–1 Toner supply clutch, I/O board: Vol. 1 9–21 Toner/developer, density: Vol.
Page 372 Index–14...
Page 374 NL-6600 A IJCHEN ETHERLANDS (31) 24 6489489 HONE: (31) 24 6489499 RINTRONIX CHWEIZ HANGI OUTH TREET 1 HANGI OUTH NDUSTRIAL STATE 486763 INGAPORE (65) 542-0110 HONE: (65) 543-0220 ISIT OUR WEBSITE AT: 704766–001C http://www printronix com VOLUME 2 OF 2...

Printronix L5000 Series Maintenance Manual

Table of Contents

10 Replacement Procedures

Specifications

Optional Cut Sheet Feeder

Optional Power Paper Stacker

Host I\/O Interfaces

Quick Links

Chapters

Related Manuals for Printronix L5000 Series

Summary of Contents for Printronix L5000 Series
